Vertical turning lathe

Webster & Bennett EVOLUTION R48R

Condition: excellent (used), functionality: fully functional, turning length: 530 mm, turning diameter over cross slide: 620 mm, turning diameter: 260 mm, spindle motor power: 15,000 W, spindle speed (min.): 35 rpm, spindle speed (max.): 3,500 rpm, spindle bore: 80 mm, travel distance X-axis: 195 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 590 mm, rapid traverse X-axis: 12 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 15 m/min, Mori Seiki SL-25Y/500 CNC LATHE With 1.5m LNS bar feeder Control: Mori Seiki MF-T6 Tool holders: (2) Radial live tolls (2) Axial live tools Lasdpfsw Ett Isx Agroi (4) inside tool holders (4) outside tool holders Swing over bed: 815 mm (32.1″) Swing over cross slide: 620 mm (24.4″) Distance between centers: 620 mm (24.4″) Max. turning diameter: 260 mm (10.2″) Max. turning length: 530 mm (20.9″) X-axis travel: 195 mm +130 +65 (7.7″ + 5.1″ + 2.6″) Z-axis travel: 590 mm (23.2″) Y-axis travel: 100 mm ±50 (3.9″ ± 2.0″) Spindle speed range: 35 – 3,500 RPM Spindle nose: JIS A-8 Through spindle hole diameter: 80 mm (3.1″) Spindle bearing inner diameter: 130 mm (5.1″) Number of tool stations: 12 Shank height for square tool: 25 mm (1.0″) Shank diameter for boring bar: 50 mm (2.0″) Turret indexing time: 0.25 sec Rotary tool spindle speed: 100 – 2,000 RPM Rotary tool cutting capability: End mill max Ø20 mm, Face mill max Ø50 mm, Tap max M12 Rapid traverse rate:   X-axis: 12,000 mm/min (472.4 IPM)   Z-axis: 15,000 mm/min (590.6 IPM)   Y-axis: 10,000 mm/min (393.7 IPM) Feed per revolution:   X-axis: 0.001 – 342 mm/rev   Z-axis: 0.001 – 342 mm/rev   Y-axis: 0.001 – 500 mm/rev Jog feedrate: 6,000 mm/min (236.2 IPM) Tailstock travel: 403 mm (15.9″) Tailstock spindle diameter: 110 mm (4.3″) Tailstock spindle travel: 100 mm (3.9″) Tailstock taper: MT-5 (Live center) Spindle motor power (30 min/cont): 15/11 kW (20/15 HP) Rotary tool spindle motor: 3.7/2.2 kW (5/3 HP) Electrical power supply: 44 kVA Coolant tank capacity: 100 liters (26.4 gal) Machine height: 2,060 mm (81.1″) Floor space: 3,183 × 1,799 mm (125.3″ × 70.8″) Machine weight: 5,400 kg (11,900 lbs)

Condition: used, Year of construction: 1980, max. wheel diameter 2500 mm gear width 1200 mm max. module 32 min. module 3 total power requirement 25 kW weight of the machine ca. 60 t dimensions of the machine ca. m Gear , min. / max. 180 / 2,500 mm Module 3 - 32 Helix angle, max. 10 - 35 ° Gear width for straight gears 1,200 mm Stroke length, approx. 100 - 1,200 mm No. of strokes 80 - 350 /min Stroke position adjustable 300 mm Stroke speed 4 - 40 mm Max. weight of workpiece, approx. 18,000 kg Min. / max. no. of teeth 16 / 576 Table size x bore 1,400 x 500 mm Laedpfxet Hwqqj Agrei Grinding wheel Ø, approx. 500 mm Grinding wheel peripheral speed 34 m/s Total electrical load, approx. 45 kW - 380 V - 50 Hz Weight of machine, approx. 60,000 kg Accessories / Special Features: * Hydrostatic guides in grinding slide, table and in all other guideways. * Completely covered working area with sliding doors. * Automatic grinding process for various cycles, with settings for roughing, finishing, fine finishing and automatic dressing cycle after preset number of teeth. * Profile correction is possible via appropriate dressing, as well as additional movement of grinding slide (depth and width crowning). * Approx. 50 change gears. * Grinding slideTilt display device. * Large coolant device with band filter and oil mist exhaust. * Separate switch cabinet. * Separate hydraulic unit. * Separate oil cooling unit. Condition : Very good. Machine can soon be inspected in our showrooms. It is not under power at present. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract. The machine comes directly from a first class gear factory, where it was grinding Quality 5 - 6. Grinding diagrams are available. This type and quality of machine is rarely available. Thank you for your interest. We always have a good selection of gear machines available. Please let us know what you need.

Year of construction: 1986, condition: ready for operation (used), BSTA 60 HL, with BBV 202/120 Ledpjizkmtjfx Agreai CE possible Contact us!

Year of construction: 2000, condition: ready for operation (used), Cutting Erosion Machine MAKINO EU 64 X=600 mm Ledpsgwp Eqefx Agreai Y=400 mm Z=260 mm workpiece dimensions WxDxH max 940x650x260 mm Workpiece weight max 1500 kg Service due before commissioning !!! Current service report from Makino can be sent on request

Condition: like new (used), Year of construction: 2004, functionality: fully functional, grinding length: 500 mm, grinding width: 200 mm, grinding wheel diameter: 250 mm, spindle speed (max.): 4,000 rpm, overall weight: 1,350 kg, Equipment: CE marking, documentation/manual, JONES SHIPMAN 524 EASY SURFACE/PLANE GRINDER Ljdpfew Tyzmjx Agreai MAXIMUM GRINDING DIMENSIONS: 500x200 mm ELECTROMAGNETIC TABLE SIZE: 500x200 mm STANDARD WHEEL SIZE: 250x20x76 mm MAXIMUM WHEEL SIZE: 250x25x76 mm CONTROL SYSTEM: FANUC GE MOTORS & DRIVES: FANUC OPTICAL SCALE MEASUREMENT SYSTEM: HEIDENHAIN MAX WHEEL SPEED: 4000 RPM MACHINE WEIGHT: 1350 KG

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, Vertical Turret Lathe - Double Column with 5 controlled axes - Brand: CKD Blansko / SKD / YOM: 2008 Overhaul and renewals were carried out on the machine in 2019 (completion January 2020), further work was carried out/followed ... The machine can be inspected by appointment under power. TECHNICAL SPECIFICATIONS: Workspace: - Faceplate diameter: 4.000 mm - Swing diameter max.: 5.000 mm - Workpiece height max.: 2.500 mm - Faceplate load max.: 50 tons C-axis: - Speed of the C-axis: 0,01 - 2 rpm - Torque on the faceplate max.: 35.000 Nm Machine: - Total power requirement: 160 kVA - Machine weight: approx. 74 tons EQUIPMENT: - Control: SIEMENS SINUMERIK 840D - Automatic tool changer - Pick-up magazine: 1 Angular head Laedpfx Aeww H Ivogrei - Angular milling head - Oil coolant equipment - Coolant system with paper filter - AC drive for rotary tools - AC drives for X/Z/C/U/W-axis - Full enclosure - Chip conveyor - Slat-band chain conveyor - Documentation - CE marking There is no guarantee for correctness and completeness of the technical details and accessories. - Subject to prior sale - Detailed technical data sheet and information on equipment available on request.

Condition: good (used), Year of construction: 1980, turning diameter over cross slide: 1,020 mm, turning diameter: 1,380 mm, turning length: 3,000 mm, Manufacturer: Leopoldo Pontiggia Type: SFE 700 Year of construction: 1980 3-jaw chuck 1200 mm Heidenhain digital readout system X / Z Axis Feeds in 2 directions Multi-fix tool system with inserts Specifications Metric US Standard Turning length 3000 mm Swing over bed Ø 1390 mm Ledpfxjwp H Rue Agroai Swing over cross slide 1020 mm Spindle bore 150 mm Bed width 700 mm Quill travel 300 mm Spindle mount Metric 80 Mk Power 18 kW Speed 0 - 350 rpm Workpiece weight 8000 Dimensions (estimated) Length 6600 mm Width 1800 mm Height 2000 mm Weight 18000 kg Please note: The information on this page has been provided to the best of our knowledge and, where possible, taken from the manufacturer. The information is given in good faith, but accuracy cannot be guaranteed. Accordingly, they will not constitute representations or terms of contract. We recommend verifying all important details.

Condition: excellent (used), Year of construction: 2007, TECHNICAL DETAILS: - CNC Control: MSX 803III - X Axis travel: 260 mm - Z Axis travel: 590 mm - Y Axis travel: +/- 50 mm - Maximum Turning Diameter: 356 mm - C Axis Indexing Increment: 0.001° - Maximum Turning Length: - Cutting Feed Rate X, Z, Y: - Swing Over Bed: - Swing Over Carriage: - Bar Capacity: Ø 65 mm (main spindle) - Max. Rapid Traverse X, Z: - Main Spindle 12” - Spindle Speed: 5,000 rpm - Spindle Power: 18.5 kW - Torque: - Main Spindle Bore: mm Laodpfxswdrfge Agrei - Main Spindle Nose: A2-6 - Sub-Spindle - Spindle Speed: 6,000 rpm - Spindle Power: 11 kW - Torque: - Sub-Spindle Bore: mm - Sub-Spindle Nose: A2-5 - Turret Positions: 12 - Number of Driven Tool Stations: 12 - Driven Tool Speed: 6,000 rpm - Driven Tool Power: 5.5 kW EQUIPMENT: - Chip conveyor - 3-color status light - Fixed tool holders - Parts catcher MACHINE DIMENSIONS: - Length: 2,705 mm - Width: 2,000 mm - Height: 2,120 mm - Weight: 5,800 kg

Condition: used, Year of construction: 2007, functionality: fully functional, travel distance X-axis: 3,100 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 3,000 rpm, table length: 1,800 mm, table width: 2,000 mm, feed length W-axis: 700 mm, workpiece weight (max.): 12,000 kg, milling spindle length: 700 mm, FPT CASTEL RED HEIDENHEIN TNC 430. Built in 2007. X=3100mm Y=2000mm Z=1000mm Table 2000 x 1800 mm, 12 Ton Cooling through spindle. Laedjwdiu Ejpfx Agrji X Column travel 3,100 mm Y Headstock vertical travel 2,000 mm Z spindle stroke 700 mm W Column in spindle direction 1,000 mm Spindle diameter 130 mm Spindle diameter ISO 50 Spindle speed 3000 rpm Spindle motor 37 kW Rotary table size 1,800 x 2,000 mm Table load 12 tons C-axes 360,000°

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, table width: 700 mm, table length: 2,000 mm, Control: HEIDENHAIN TNC-426 Travel of the X-axis: 2000 mm Y-axis travel: 800 mm Z-axis travel: 800 mm Taper tip: ISO 50 Lsdpfxjvfr Hbs Agrjai Speed range: 20 - 3000 rpm Spindle power: 17 kW
