Single-shaft multi-blade saw

Trademak srl Piranha 310

Condition: used, Technical data: Max planing width: 230 mm Max planing height: 120 mm Spindle diameter: 40 mm Number of spindles: 5 Spindle sequence: down 5.5 kW right + left 11 kW up 7.5 kW universal 5.5 kW Each spindle on a separate motor Number of upper steel pulling rollers: 5 Number of upper rubber pulling rollers: 3 1 rubber roller in the table top Extraction port diameter: 150 mm Smooth feed adjustment: 4-24 m/min Cardan feed Table lubrication pump Pressure: 6 atm. Electric lifting of the body Power: 400V Overall dimensions: Length: 4240mm Width: 1550mm Pgedpjmiik Tefx Ag Rju Height: 1560mm

Condition: used, Year of construction: 1989, Technical details: bore capacity in steel (diameter): 28 mm throat: 285 mm bore stroke: 165 mm drill capacity in cast iron: Ø 35 mm spindle taper MT: MK 3 spindle speed:: 65 - 1.750 / 4x steples U/min feed: 0,1; 0,2; 0,3 manuell/automatisch mm/U Distance spindle/table max.: 80 - 680 mm table clamping surface:: 500 x 370 mm table rotating: 360 ° Pgodpeu Idkzsfx Ag Rsu drill table adjustment: 600 vertical mm column diameter: Ø 130 mm total power requirement: 7,5 kW weight of the machine ca.: 273 kg dimension machine xH: 0,9 x 0,6 x 1,9 m The machine can cut threads, change of direction left/right selectable via foot switch and/or depth stop Table can be swiveled and adjusted in height. *

Condition: new, Year of construction: 2025, Roller diameter: 640 mm Outrigger overhang: 620 mm Cutting depth: 400 mm Table can be swivelled: yes, -0 to +15° Table size: 870 x 620 mm Belt speed: 1660 m/min Motor power: 2.2 kW / 400V Motor brake: yes / automatic Dust extraction port: 2 x 120 mm Machine length: 1190 mm Machine width: 780 mm Pgedpfsgtdpmox Ag Rju Machine height: 2063 mm Weight: 320 kg

Condition: new, TECHNICAL DATA Gas-fired preheating furnace, make VEI type: VEI_KO_V_GB_400-350 temperature: 350°C burners power: 2 x 200 kW fans: 2 x 4 kW useable dimensions x 2 (h x d x w): 1.000 x 1.400 x 2.800 mm Pedpfxsfbgz Ie Ag Rjgu

Year of construction: 2005, condition: excellent (used), The subject of the auction is the sawmill line BRODPOL The line consists of a log prefeeder plus a cascade, an input feeder, a BRODPOL TT5/500/320/G circular sawmill with a centering device and a receiver, and a distribution table. Pjdpfx Aol H Hy Hog Regu - diameter of the processed log 100 - 320 mm - length of processed log 1250 mm - 6000 mm - diameter of circular saws (only) 500 mm - maximum number of saws on the spindle 5 pcs. - feed speed 10 - 28 m/min. - power of main motors 55 kW + 75 kW Hcwgak9s - required connection of pneumatic supply 6 atm. - capacity up to 20 m³ per hour of operation

Condition: new, Year of construction: 2025, the SQUALO 615 multi-blade or multi-blade circular saw with single shaft is a technological machine, indispensable in a modern sawmill to optimize the production of sawn timber. moreover it is 2-in-1 as it can be configured as a trimming machine with 1 or more movable blades. ideal for the production of strips, squares, sawn timber, profiles, edged planks, prisms, boards, elements for pallets. Psdpfehpbxiex Ag Rjgu Rollers / conveyor belt width 620 mm Width of infeed / outfeed conveyor rollers 620/720 mm Max saw unit width 590 mm Max cutting height (without pad) mm 150 (mm 125 Trimming machine) Min. Length working mm 800 Max width passage 800 mm Blades hole diameter mm 80 (mm 104 Trimming machine) Circular blades diameter 250/470 mm (480 mm Trimming machine) Blade shaft speed rpm 3.800 Variable feed speed with ROLLS 3 - 36 m / min Variable feed speed with CARPET m / min 4 - 25 optional: softstarter start

Condition: used, Year of manufacture: 1986 Colour: Green Price: On request Feed through press Wemhoner VOF2-400-2 Serial number 13350686 Maximum press dimensions 1500x4400mm Maximum stroke 150mm Press pressure 400T 7.5kW, 380V 10 cylinders diameter 120mm Solid plates aluminum 90mm Top and heated, oil boiler included. With infeed and outfeed conveyor. Transport dimensions: Full normal trailer 13000x2400x2400mm, total weight 25,000kg. - Year: 1986 - Serial number: 13350686 - Main motor power [kW]: 7.5 - Press drive: Hydraulic - Max. workpiece length [mm]: 4400 - Max. workpiece width [mm]: 1500 - Max. workpiece height [mm]: 120 - Total stroke [mm]: 150 - Number of stages [pcs]: 1 - Material of press plates: Steel - Number of cylinders [pcs]: 10 - Cylinder diameter [mm]: 130 - Total working pressure [ton]: 400 - Heating boiler present: Yes - Heating type: Oil heated Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Pedpswng S Ajfx Ag Rsgu Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Year of construction: 2005, condition: excellent (used), machine/vehicle number: 72164xxx, The Moba maxipacks Worldwide, the Moba maxipack M16 and M22 are the only machines that are able to package entire chickens in a bag, both frozen and fresh. The maxipack is an extremely reliable machine. Therefore, these machines are well-known in the chicken slaughtering industry for decades. The maxipack is made of stainless steel and high-quality, wear-resistant plastics. These ensure that the maxipack is able to continue to run for years in the production process after extensive mechanical, electrical and electronic revision. Pgjdpfoh Ri A Ajx Ag Rju Moba M16 The Moba M16 taper machine is, suitable packing smaller chickens with a range of 900 to 1200 grams per chicken. - The machine consists of four protective covers with an interlock system that immediately deposits the machine when opened. In combination with the emergency stop, this ensures that the machine is safe to use. - Plastic bags can be easily changed by using the change function. This function ensures that the turntable rotates a quarter turn to ensure enough space to change the bags. - The compressed air system on this Maxipack is adjustable by means of a pressure reducing valve. The pressure reducing valve ensures that the moisture is filtered out of the compressed air. - The maxipack is also equipped with a pressure regulator, that ensures the maxipack to switch off if the pressure drops below 5 bar. Revision Moba M16 Maxipacks that arrive at Bos Technical Support are thoroughly cleaned before starting the revision. For the revision, original Moba high qualitiy components are used. Each maxipack is equipped with a new PLC (Program Logic Controller) that includes the latest software. The 8 pneumatic cylinders that this machine includes are all checked and replaced when necessary. The electrical cabinet is being rebuilt and provided with new wiring. All machines come with an instruction manual and will be extensively tested to determine whether the machine is ready for a prolonged period of time in the production proces. More information? We have multiple Moba M16 and M22 machines in stock for sale and rental. For more information see also our website Specifications Moba Maxipack M22 taper: - Capacity: 800 chickens/hour (per machine) - Tape: 9-12 mm wide (optional 19 mm tape) - Machine weight: 540 kg - Machine size (L-W-H): 2395-850-1700 cm - Weight range: 900-1200 grams - Electrical 3 phase, neutral and ground - Voltage: 400 V - Power consumption: 1.4 KVA/hour - Frequency: 50/60 Hz - Airpressure: 6 bar - Maximum dewpoint: 3 Celsius - Air consumption: 7500 L/hour Bos Technical Support import-export packaging machines. Sorteermachine eier verpakkingsmachine eiersorteermachine egg gradingmachine sortiermachine sortieranlage eierverpackungsmachine Maxipack, Moba, Sanovo, Staalkat, Prinzen, Rational, Kletec

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, WORKING DIMENSIONS 450x260 mm SURFACE PLANER kW 11 THICKNESS PLANER kW 15 SPINDLE MOULDER RIGHT kW 9.2 SPINDLE MOULDER LEFT kW 11 FEED kW 5.5 Pgsdpow E Ev Ijfx Ag Rsu TERSA CUTTERBLOCKS SOUNDPROOF CABIN CE

Year of construction: 2001, condition: good (used), Heavy-duty roller conveyor, 2 units, driven Overall height: 600 mm Width: 1400 mm Length: 7000 mm All dimensions are approximate Podpfeh Icrnjx Ag Regu System is immediately available and has already been dismantled.
