Panel saw SCM Class Si 400EB (2019)

SCM Class Si 400EB

Format circular saw
Hedpfx Aaezuy Rpotjnr
Manufacturer: SCM
Type: Class Si 400EB
Year of manufacture: 2019
Technical data
Maximum cutting height at 90 degrees: 140 mm (with 400 mm main saw blade)
Maximum cutting height at 45 degrees: 97 mm (with 400 mm main saw blade)
Main saw blade: 400 mm
Scoring saw blade: 120 mm
Swivel range of main saw blade: 0 - 45 degrees
Speed of main saw blade: 3,000 / 4,000 / 5,000 rpm
Speed of scoring saw blade: 8,500 rpm
Power of main motor: 7 kW (9.5 hp)
Power of scoring motor: 1.3 kW (1.7 hp)
Sliding table: 3,200 x 320 mm
Alternative table length: 3,800 x 320 mm
Cutting width with parallel fence: 1,270 mm
Dust extraction connection, safety guard: 120 mm
Dust extraction connection, machine body: 100 mm
Design: EASY 3 UP PLUS CE
Control panel: Swiveling control panel in suspended design
Control system: EASY2 control system with 7" widescreen monitor
Programming of cutting height: Electronic setting and display
Programming of blade tilt: Electronic setting and display
Parallel fence: Electronically programmable
Operator assistance: Supporting functions for complex cutting tasks
Tool data management: Storage of saw blade data
Program memory: Up to 300 programs
Note:
The technical data and descriptions are copies of the original order confirmation. The information is provided for informational purposes only and is not binding.

The listing was translated automatically. Translation errors are possible.
