Cutting Lines

SCHELLING VS 12 - FH6 - FH4

Condition: excellent (used), Year of construction: 1996, spindle bore: 160 mm, Swing over bed Ø 1040 mm Swing over cross slide Ø 710 mm Swing in the gap Ø 1580 mm DBC Turning Length 3000/4500 mm Djdpfx Acsxtbf Ee Hjck Gap length 1500 mm Spindle bore 160 mm Spindle power 40 kW Bed width 800 mm Spindle taper 6 Mk Workpiece weight 3500 Speeds / ranges 800 Rpm Feed rate X-Axis 10000 mm/min. Feed rate Z-Axis 10000 mm/min. Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Year of construction: 2008, condition: ready for operation (used), functionality: fully functional, * Wemhöner Basic 1000 Plus - Year of manufacture: 2008 - Very good condition, little used * Type: KT-MB-28/15-240 Dodpfxjxbcuds Ac Hjck * With automatic pin system and inline turn-over device * 2 tables with automatic variable pin system * With Teflon coating for pre-glued foil * Foil laying system for the pin table (pre-glued foil) * Heating plate size: 2800 x 1500 mm * Maximum workpiece size: 2,540 x 1,250 mm * Membrane: Yes * Cutting station * Foil paternoster storage, 3.2 m height with 14 suspension rods * Siemens S7 PLC control * Operator panel for PLC control: SIEMENS TP 270 (touchscreen) * Automatic membrane tensioning * Installed power supply: 38.5 kW * Maximum chamber pressure: 6 bar * Maximum press opening: 150 mm * 6 cylinders with Ø 125 mm * Operating voltage: 400V 50/60Hz * Press chamber height: 40 / 60 mm * Max pressing force: 2400 kN * Hydraulic system operating pressure: 320 bar

Year of construction: 2024, condition: new, Motorized sheet metal shear Technical data Dedpehk Nf Refx Ac Hjck Cutting capacity: 2.5 mm Cutting length: 2550 mm Cutting angle: 1°40′ Stroke rate/min: 35 1/sec Motor power: 3 kW Back gauge range: 550 mm Table width: 400 mm Table height: 850 mm Height: 1260 mm Width: 1350 mm Length: 3100 mm Weight approx.: 1540 kg

Condition: refurbished (used), ECCENTRIC PRESS SGP TYPE : PEZZ 500/1700/1000 PRESSURE : 500t DOWN TABLE DIMENSIONS: 1700x1000mm LENGTH OF STROKE: 20-153mm DISTANCE BETWEEN RAM -TABLE: Min 700mm , Max 800mm Dedpfxshqqnzo Ac Hock WEIGHT: 40.000 kgr MADE IN AUSTRIA

Condition: excellent (used), Year of construction: 2003, machine/vehicle number: 0-241-06-5232, functionality: fully functional, operating hours: 12,608 h, cutting height (max.): 125 mm, cutting width (max.): 2,200 mm, cutting length (max.): 4,300 mm, Panel Saw Holzma HKL11/43/22 Max. cutting width: 4300 mm Max. cutting length: 2200 mm Max. cutting height: 125 mm The saw is in continuous operation, so viewing during operation is possible. The machine will be available from 02/03/2026. Djdpfx Aexfvp Asc Hock

Condition: good (used), Year of construction: 2011, machine/vehicle number: 2212.287, Automatic panelsaw Schelling Typ:FH 6 430 Maskin nr:221.287 År:2011 Panel beam saw Schelling with automatic, rear-feed,lifting table. For sawing board material, chipboard, MDF, Plywood, Board, Laminate etc. Techn info: Dcjdpfx Aetk It Soc Hsk Software MCS Evolution 2.0, SPS, Soft-SPS-Siemens WinAC Operating system WINDOWS XP PC with keyboard and mouse TFT monitor 17" Cutting length 4300mm, automatic detection of the start of the plate Cutting width 4300mm Machine accuracy of the cut length 3m +-0.1mm Positioning accuracy measured at input +-0.1mm Max diameter saw blade 460mm, spindle 30mm Pre-scoring blade 200mm, spindle 20mm motor operation is set from the control console Max panel thickness 120mm Panel stack aligner Main saw blade motor 27kw Saw blade over table 135mm Safety curtain Air cushion table with 3pcs air ball nozzles, radial ventilator fan Table sizes 2650x850mm 620x850mm 2650x2550mm Pressure beam with automatic adjustment of pressure to cut length and package height Package straightener before and after the pressure beam Max package height 120mm (incl. sum of curvature and board thickness tolerance) Pusher with 12 grippers Max clamp opening (gripper) 133mm Min-max force package straightener 400/2000N Speed saw carriage forward 6-150m/min Speed saw carriage back 150m/min Forward feed speed (pusher) up to 25m/min (according to EC Europa EN1870-13) other countries 80m/min Speed feeding back up to 80m/min Push-off device 3 pcs Lift table length x width 4350x2550mm Hydraulic unit Standard version 1600mm lifting height 1.25/2.5m/min raising speed, 1.25/5m/min lowering speed Maximum load 1200 kg/m2 total 9 tons Roller track driven rollers, frequency controlled for stack on lifting table 4100x2600mm Max stack weight 6500 kg Max stack length 1060mm Slots for forklift 4 pcs, distance in the middle 1200mm, slot width 300mm Light curtain for personal protection Roller conveyor driven for package frequency controlled input to lifting table left 5600x2600mm max load 6500kg Roller conveyor driven for packages frequency controlled input to lifting table right 5600x2600mm max load 6500kg Slots for forklift 2 pcs, center distance 900mm, slot width 400mm 2 positioning stops with roller for stack alignment Light curtain (double beam) for personal protection Roller table after saw depth 4300mm, free-running ployamide rollers Angle stop at the rolling table Infeed guide two-lane (beam length 7200mm) 2-sided hardened precision guides rack and pinion drive, two-sided Input carriage (pusher) gear rack servo drive, non-contact measuring system Gripper, (scissor clamps) in pusher 12 pcs Automatic adaptation of the clamping force to the package height (progressive clamping force) can be set to 0 Pusher for panels thickness greater than 6mm,material thinner than 6mm is fed manually Central cleaning system feed trough (pusher) Compressed air 6-8 bar, approx. 1600l/min Power 38 kw, 70 A. 3x400 volts, 50 Hz, operating voltage 24 VDC Dust extraction 4000m/h, air speed 30m/s Diameter connection 80mm (angle connection), 120mm /pressure beam), 150mm (sawdust channel) Total setup area without driven roller conveyors including protective grid approx: 11650x7300mm Driven roller tracks left-right 5500+5500mm Stock no: 2002125BXACEO Subject to incorrect technical data presented

Condition: new, Year of construction: 2025, Delivery ex works Turkey Bending length (A): 3050 mm Press force: 170 tons Sheet thickness 42kgf / mm: 8 mm Sheet thickness 72kgf / mm: 4 mm Upper tool: 1260 Top Tool 85 ° Lower tool: 50, 35, 22, 16 Distance between columns (B): 2550 mm Forward speed: 130 mm / s Working speed: 8 mm / s Retraction speed: 120 mm / s Crowning: manual (CNC-motorized available for an extra charge) X-axis travel: 750 mm X-axis speed: 250 mm / s Backgauge fingers: 2 pieces Front support arms: 2 pieces Dcodegu N Alopfx Ac Hsk Oil tank capacity: 180 liters Main motor power: 11 kW Stroke length (C): 265 mm Installation height (D): 450 mm Projection stand (E): 410 mm Table height (F): 870 mm Table width (G): 170 mm Length (L): 4200 mm Height (H): 2800 mm Width (W): 2200 mm Weight: approx. 7500 kg Cybelec Cybtouch 12 2D Graphic CNC control 3 axes (Y1, Y2, X) expandable with optional R+Z-Axis Eurostamp 2067 lower tool (V: 50, 35, 22, 16) Eurostamp 1260 upper tool 85 ° Narrow table All-steel welded construction Promecam quick clamping system CNC-controlled motorized backgauge (X: 750 mm) Adjustable backgauge fingers Inch and metric system can be selected Ground and chrome-plated cylinders Swiveling control panel Foot control with anti-panic stop & emergency shutdown Lateral protective grille (secured with limit switch) Light curtain on the back of the machine (900 mm) DSP laser finger protection system at the front (CE) BOSCH / REXROTH or HOERBIGER / HAWE hydraulic system BOSCH / REXROTH or ECKERLE hydraulic pump Slidable front support arms (2 pieces) Electronics unit from: SIEMENS, SCHNEIDER, DELTA, ABB, OMRON 380 V 50 Hz Painting: RAL 7035, RAL 5015 Optional special accessories available at an additional cost: -CNC-controlled R-axis (250 mm) -CNC motorized crowning -Servo driven motors backgauge system for X + R axis (Mitsubishi) -Painting in special colors on customer request Documentation in German or English CE conformity

Condition: used, pressure 55 t throat 250 mm stroke 10-90 mm table-size 640 x 495 mm no. of strokes 120 Hub/min ram adjustment 55 mm ram surface 290 x 210 mm Dcjdecp Apyepfx Ac Hsk ram hole 40 H7 mm hole in the table 220 x 190 mm T-slots 22 clamping plate 620 x 485 x 65 mm total power requirement 4,5 kW weight of the machine ca. 3,4 t dimensions of the machine ca. 1,5 x 1,2 x 2,2 m

Condition: used, machine/vehicle number: 005108, Position 1: Front-Loading Panel Saws HOLZMA-HPP 380/43/43 + TLF Dcedowuck Ispfx Ac Hsk Position 2: Horizontal Storage Systems HOLZMA-HPP 380/43/43 + TLF

Condition: good (used), Year of construction: 1980, turning diameter over bed slide: 1,040 mm, turning diameter over top slide: 710 mm, turning length: 2,000 mm, bed width: 600 mm, Optional chuck 1200 mm 2 Axis RSF Digital read out Conical turning attachment Spindle bore 130 mm Central lubrication DBC Turning Length: 2000mm Swing over bed Ø: 1040mm Dcjdpfxjx Tgr Tj Ac Hsk Swing over cross slide Ø:710mm Swing in the gap Ø: 1780mm Gap length: 1000mm Spindle bore: 130mm Bed width: 600mm Tailstock spindle Ø: 130Ø Stroke pinole: 300mm Spindle taper: 6Mk Power: 22kW Speeds / ranges: 600Rpm Feed rate X-Axis: 4000mm/min. Feed rate Z-Axis: 4000mm/min. Length: 6000mm Width: 2100mm Height: 2100mm Weight: 8300kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
