Micro-Cut-Kolloidmill-Micro-cutter

PVS PVS 125 V

Condition: as good as new (ex-display), Year of construction: 2023, functionality: fully functional, A used horizontal form, fill, and seal machine (HFFS) from the DEAPHS series is for sale. It is designed for the automatic production, filling, and sealing of pouches made from flat film. ### Current Machine Condition The machine is currently set up for the production of 4-side seal pouches. The machine forms the pouch directly from flat film, takes over the filling process – in conjunction with a suitable dosing system – and then automatically seals the pouch. The DEAPHS series is fundamentally modular in design and can be adapted for other pouch types and applications, depending on the existing or additional equipment, for example: - 3-side seal pouches / sachets - 4-side seal pouches - Doypack / stand-up pouches Adaptation to other pouch types depends on the format, product, and required machine components and is not part of the current setup. ### Possible Applications Depending on the dosing system used, the machine is suitable for packaging, for example: - Powdered products - Granules and granular products - Food products - Animal feed - Cosmetic products - Technical and other non-food products - Single-serve packs, sample sizes, and samples Different dosing and feeding systems can be used for different products. ### Machine Equipment - Independent film unwinding shaft - Pouch bottom sealing - Pouch bottom former - 3 horizontal sealing units - 2 vertical sealing units - Servo-controlled film/pouch feed - Mechanical pouch cut - Vacuum pouch opening - Photoelectric sensor control for printed film - LCD touchscreen display - Panasonic PLC - Servo film drive The separate film unwinding system enables controlled film tension and adjustment to different film widths and pouch formats. ### Possible Dosing Systems Depending on the application, the machine can be combined with the following dosing systems, among others: - Auger dosing - Volumetric cup filler - Multi-head combination weigher - Piston filler - Pump filler / liquid dosing, e.g., Hibar Availability and scope of delivery of the respective dosing systems can be requested separately. ### Technical Data Machine dimensions: approx. 5,500 × 1,100 × 1,400 mm (L × W × H) Net weight: approx. 2,000 kg Power supply: 380 V / 3 phases / 50 Hz Connected load: approx. 6.5 kW Air consumption: approx. 0.23 m³/min ### Installed Components / Manufacturers Fjdpfeum R Ezex Albogg Components from, among others: Mitsubishi, Panasonic, Autonics, ABB, Airtac, and SMC Suitable packaging films, as well as other dosing, feeding, and peripheral equipment, can also be offered depending on the application. Inspection of the machine is possible by appointment. Further information on pouch formats, working widths, possible dosing systems, and scope of delivery can be provided upon request.

Year of construction: 2026, condition: new, The equipment is generally considered project stock or, depending on availability, can be offered as a demonstration machine. Application: Accurate dosing of free-flowing products in precise quantities. Scale Features - Easy operation - Fast and uncomplicated cleaning - Low maintenance requirements - Tool-free assembly and disassembly of all product-contacting format parts - Low maintenance requirements - Corrosion-resistant stainless steel construction (1.4301) - Entire control system integrated within the machine housing - Continuously adjustable vibration system for optimal product flow - High accuracy through combination weighing Technical Data Fedpfeq T R Sbex Albegg - Number of weighing heads: 10 - Weighing hopper volume: 2.5l - Weighing range: 10 - 1000g / 2,500g - Accuracy: ±0.2-1.5g - Speed: 60 bags/min (depending on product) - Control panel: 7" touchscreen display - Power: 1kW / 230V / 50Hz - Dimensions (LxWxH): 1620mm x 1100mm x 1110mm - Machine weight: 380kg

Condition: ready for operation (used), Year of construction: 2023, WP Miniroll compact roll line with high capacity and maximum flexibility. The Werner & Pfleiderer MiniRoll Roll Line is a highly compact and efficient solution for the production of premium-quality small bakery products. Thanks to the integrated Multimatic dividing technology and built-in drum round moulder, this line delivers consistent product quality, excellent hygiene and impressive output – all within a minimal footprint. year of build 2023 only 51 working hours! suited for the production of: • Long-rolled rolls • Round rolls  5-row configuration with 600 mm working width Integrated Multimatic Pro G 2 dividing head, up to 150 gram Dividing range from 55 g to 150 g, measuring piston 55 mm Hourly capacity pieces/hour 3000 Built-in dividing and rolling head Motorized weight adjustment for consistent product results Manual pressure adjustment for precise shaping control Adjustable moulding belt and length-forming unit with pressure plate Resting time of 6 minutes Suitable for trays 600×400, 600×800 and 580×980 mm Integrated storage for up to 3 rolling drums Automatic cleaning positioning Fgodpjx Thvmjfx Albog Router for remote access

Condition: good (used), JBT FMC Foodtech autoclave / retort in nice condition with upgraded controls. Has come direct from a European pate producer. Single door, 1.4m diameter 6 trolley capacity. We also have 2 x 4 trolley A144 versions from the same factory. Fodpfx Alorzbfcsbogg

Condition: excellent (used), Year of construction: 2009, Type: A510 Serial number: 10597961 Year of construction: 2009 Fjdpfx Alsyhm T Eebegg Belt width: 300 mm Speed: max 250 slices/min Slice thickness: 0.5 - 30 mm Infeed length: max 600 mm Product diameter: max 210 x 180 mm Stacking height: max 60 mm Blade diameter: 420 mm Power: 3 x 400V, 50Hz, 2.3kW DImensions: 2350 x 800 x 1850 mm Weight: 420 kg

Condition: good (used), functionality: fully functional, Diameter range: 99 mm - 180 mm Height range: 90 mm - 250 mm Heads: 3 Production capacity: up to 90 cans per minute Fgjdjt Dhv Sjpfx Albsg Tooling for approx.: 153 mm

Condition: ready for operation (used), Year of construction: 2019, Complete cup filling and sealing machine (year of manufacture 2019) with inkjet encoding, conveyor belt extension and dosing bar (incl. perlator inserts, year of manufacture 2020) used in the cheese industry. Filling temperature: Cold filling, round plastic bucket/plastic bucket/plastic bucket 2: Diameter 175mm x height 131mm/diameter 104mm x height 55mm or 65mm/diameter 227mm x height 194mm. Dimensions X/Y/Z and weight, without outfeed conveyor belt and shifting shank: 2200mm/2200mm/3200mm and approx. 3500kg. Fodpfx Alor Dd H Sobogg

Condition: used, Glass bottle filling system for hot filling smoothies. Consisting of the following components: - Unpacking table - bottle rinser - Vacuum filler (with 24 filling valves, Nagema, 1984, type ‘VW 24/1’) - Flash pasteuriser (KZE) - Pressure tank - Capper (Marchesini, type "ML667") - Lid sorter - Tunnel cooler - Blower - Lid inspection (BBull CIS) - Labeller (Anker, 1999, type ‘Roland 10/4’) - Packing table - Conveyors - Control panel - Cooling tower - Steam boiler - Water softening (Lohbeck GmbH, Softtrol CD double system) Additional title: hot filling, with pasteurisation Fsdpfxowgc R Ej Albjgg Capacity: 5000 bo/h Formats: 0.25 liter bottles, twist off caps Features: Unpacking table, rinser, vacuum filler, flash pasteuriser, pressure tank, capper, lid sorter, tunnel cooler, lid blow-off, lid inspection, labeller, packing table, conveyors, control panel, cooling tower, steam boiler

Condition: used, Used Urschel model 1700 stainless steel Comitrol Processor. Recommended for size reduction applications of free-flowing dry and semi-dry products. Processor is designed to install three different reduction heads - slicing head, cutting head or microcut head (ONLY microcut head is inlcuded). Microcut rotor head is driven by 22 kW, 2938 rpm, 50 Hz electric motor. Cutting chamber is sealed and deters escape of dust, vapor and liquid. Includes switchboard and control panel. Dimensions are approximately 1300 mm lenght x 900 mm wide x 1800 mm high, weight approx 500 kg. Fjdoltlulspfx Albogg

Condition: new, power 2,2 (3,0) kW (PS) Fgsdob I Sx Eopfx Albjg electric outlet 400V 50Hz (3 phases) fuse 16 A dimensions: length 1 735 mm width 1 466 mm height 1 290 mm insertion resp. discharge height 850 mm weight 350 kg material 1.4301 / AISI 304 lifting force up to 550 kg / bin rotation time 15 sec fruit discharge height 900 mm fruit discharge width 500 mm suitable for standard bulk bins 1 000 x 1 200 x 970 mm scope of delivery hydraulic power unit
