Band Saw

PETZING & HARTMANN PEHAKAMAT 360 ZP

Condition: like new (used), Year of construction: 2005, functionality: fully functional, turning length: 450 mm, spindle speed (min.): 25 rpm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 213 mm, travel distance Z-axis: 450 mm, rapid traverse X-axis: 24 m/min, rapid traverse Z-axis: 30 m/min, bar passage: 65 mm, Siemens 840 D CNC Working area Max. swing diameter on bed 505 mm Swing diameter on X-slide 375 mm Chuck diameter 210 mm Bar capacity 65 mm Transverse travel (X) 213 mm Longitudinal travel (Z) 450 mm Feed rates X/Z-axis rapid traverse 24/30 m/min Main spindle Spindle nose (flat flange) 140 h 5 mm Internal diameter of front bearing 100 mm Spindle motor power (40/100% DC) 16/12 kW Torque (40/100% DC) 153/115 Nm Spindle speed 25 - 6.000 rpm Tool turret Number of tool stations 12 Of which motorized 12 Shank diameter (according to DIN 69880) 30 mm Motor power (40% DC) 9 kW Maximum torque (40% DC) 20 Nm Maximum speed 4.500 min-1 Iaedpfx Aew Adhwobuer Tailstock Tailstock stroke, automatic 450 mm Center point attachment 4 CM Tailstock thrust, max 400 daN Machine equipment: • Chip conveyor • Provision for fume extractor • 2 axial motorized modules • 4 radial motorized modules • Fixed tool holders

Condition: used, Year of construction: 1977, roll diameter 320 mm throat 310 mm workpiece height 230 mm table-size 505 x 505 mm cutting speed 12 - 375 m/min turning speeds U/min saw band length 2 mm voltage 400 V total power requirement 1,3 kW weight of the machine ca. 420 kg dimensions of the machine ca. 0,80 x 0,80 x 1,65 m - serial-no.: 22600-77/14 - with stepless feed - welding equipment IDEAL - grinding wheel - machine lamp Iedpfx Aevnv S Tebusar

Condition: reconditioned (used), Year of construction: 2006, CNC Lathe GILDEMEISTER CTX 420 linear Equipped with Siemens 840 D powerline control Year of manufacture: 2006 Max. turning diameter: 324 mm Max. turning length: 600 mm Max. swing diameter: 680 mm Spindle bore: 79 mm Max. spindle speed: 4,500 rpm Including the following accessories: Sliding guard with interior lighting 12-position turret with 12 driven stations Y-axis, C-axis Tool measuring device Parts catcher Ijdpsxzt Dcefx Abusar 3-jaw hydraulic chuck 210 mm with foot switch Hainbuch hydraulic collet chuck IRCO Breuning RBK 10012 bar feeder Signal lamp Tailstock with quill Chip conveyor Oil mist extraction Coolant system with high-pressure coolant (IKZ) and belt filter unit Operating manuals

Condition: good (used), Inert gas welding machine, inert gas welding machine, arc welding system, MIG/MAG welding system -Max. welding power: 400 A -Wire feed: 4-roller drive -Version: Water-cooled -Accessories: incl. ground cable, removable wire feeder, gas fitting, hose package 4 m -Quantity: 1 piece available Ijdpfxowl Dptj Abusar -Dimensions: 500/1010/H1600 mm -Weight: 162 kg

Year of construction: 2004, condition: ready for operation (used), A fully automatic Kasto band saw system is available. Cutting range at 90°: round material: 530mm, square material: 530mm/530mm, flat material: 530mm/640mm, saw blade length: 7675mm, saw blade width: 54mm, saw blade thickness: 1.6mm, cutting speed: 120m/min. Overall system dimensions X/Y/Z: approx. 5200mm/2700mm/2700mm, weight: approx. 6000kg. Including roller conveyors. Documentation available. On-site inspection is possible. Iaodpov S E Edjfx Abuer

Condition: good (used), Year of construction: 2003, Good condition,live tools, measuring arm. Parts shown by hand not come. Technical details shown on pictures. Iajdowybg Sjpfx Abujr

Condition: good (used), Year of construction: 1998, Parts shown by hand not come. Technical data are shown on picture. Iajdpfjwb Aqnex Abuer

Condition: used, Year of construction: 2003, turning diameter max. 420 mm turning length 1090 mm Iedpjucgylsfx Abuoar control FANUC Serie 18i-TB turning spindle Durchlass 108 mm 250 / 315 turning speed range 0-3750 U/min Feed speed 18/24 m/min. workpiece 12 quill stroke 100 mm diameter of quill 110 mm taper MK 4 number of driven tools 12 mm turning speeds 3000 U/min 22 nm coolant tank 140 l total power requirement 22/18,5 kW weight of the machine ca. 6500 KG

Year of construction: 2008, condition: good (used), machine/vehicle number: 431808, Lg.No. 18177 Hydr .flat profile and bar shear with notching device and hole punching machine Technical data: - Flat steel shear cuts up to 375 x 10 mm - 220 x 20 mm - section steel shears - cuts L-steel at 90° up to 130 x 13 mm - steel bar shears - cuts round steel up to 45 mm - square steel up to 45 mm - notching device - with square notcher 100 x 42 x 10 mm - punching machine - punching force 600 KN Iasdpfx Ajmidyisbuor - with stop table - throat 300 mm - punching in steel up to 28 mm Ø in 15 mm - or 34 mm Ø in 12 mm - manual length stop - drive 400 V / 4 kW - space requirement approx. W 600 x H 1550 x D 1500 mm - weight approx. 1300 kg

Condition: repair required (used), Maho MH 900 C without housing Control: CNC 432 (V9) - working range X/Y/Z: 1000mm/500mm/650mm - Rigid angle table: 1150mm x 650mm - Maximum table load: 900 Kg - Spindle mounting: SK50 - Speed: 40 - 1600 rpm - Feed rate: 5 - 2.000mm/min - Rapid traverse: 6 m/min - Space requirement: L-3500mm, W-4185mm, H-2146mm Iedpfx Abjfgg Aaousar Y-axis is not displayed but moves
