Turning and Milling CenterOKUMA
MULTUS U 4000-2SW 2000
Machine data
- Machine type:
- Turning and Milling Center
- Manufacturer:
- OKUMA
- Model:
- MULTUS U 4000-2SW 2000
- Year of construction:
- 2015
- Condition:
- good (used)
Price & Location
- Seller location:
- Reckholder 1, 9527 Niederhelfenschwil, Switzerland
Technical details
- Turning length:
- 2,100 mm
- Turning diameter:
- 650 mm
- Spindle speed (min.):
- 30 rpm
- Spindle speed (max.):
- 3,000 rpm
- Travel distance X-axis:
- 695 mm
- Travel distance Y-axis:
- 300 mm
- Travel distance Z-axis:
- 2,100 mm
- Bar passage:
- 112 mm
- Total height:
- 3,030 mm
- Bar diameter (max.):
- 112 mm
- Overall weight:
- 19,000 kg
- Controller manufacturer:
- OKUMA
- Controller model:
- OSP P300S
- Number of spindles:
- 2
- Space requirement length:
- 6,000 mm
- Space requirement width:
- 3,050 mm
Details about the offer
- Listing ID:
- A20279785
- Reference number:
- 50716
- Update:
- 13.10.2025
Description
.. CNC controls OKUMA OSP P300S
BASIC FUNCTIONS
.. number of spindles: 2
.. number of turrets: 1
.. live positions: yes
.. number of c-axes: 2
.. number of y-axes: 1
.. number of b-axes: 1
WORKING RANGE TURNING
.. swing diameter (max): 650 mm
.. turning diameter (max): 650 mm
.. bar diameter (max): 112 mm
.. worpiece length max.: 2100 mm
Gbodpfx Aoxm Rtljfiou
MAIN SPINDLE
.. spindle revolutions (min): 30 /min
.. spindle revolutions (max): 3000 /min
.. spindle torque: 700 Nm
.. spindle diameter: 112 mm
.. spindle positioning: 0.001 °
.. c-axis: yes
COUNTER SPINDLE
.. spindle revolutions (max): 3800 /min
.. spindle positioning: 0.001 °
.. c-axis: yes
X/Z SLIDE
.. Z-axis travel: 2100 mm
.. X-axis travel: 695 mm
.. Y-axis travel: 300 mm
.. rotating range B-axis up to: 240 °
.. traverse velocity Z (max): 1000 mm/min
.. traverse velocity X (max): 1000 mm/min
.. traverse velocity Y (max): 1000 mm/min
.. tool fixture: Milling Spindle
.. - rotation speeds (max): 12000 /min
.. - drive power: 22 kW
TOOL MAGAZINE
.. number of positions: 40
.. tool length max.: 400 mm
.. tool weight max.: 10 kg
X/Z SLIDE
.. Z-axis travel: 1584 mm
.. X-axis travel: 235 mm
.. - counter spindle: yes
ELECTRICAL SPECIFICATIONS
.. mains voltage: 400 V
.. mains frequency: 50 Hz
DIMENSIONS / WEIGHTS
.. space requirements -left/right-: 6000 mm
.. space requirements -front/back-: 3050 mm
.. total height: 3030 mm
.. total weight approx.: 19000 kg
-Big Bore left spindle:
Spindle holder A11 (Din 55026)
Chuck is a SMW KNCS-N 325-104
- Tool holder (top) Milling spindle (Capto C6)
