Used Revolving Center for sale (12,336)

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, operating hours: 503 h, input voltage: 400 V, controller manufacturer: Masterwood, Equipment: CE marking, Masterwood 12.25 nesting machine Codpfx Akeyxmvpocsrb Working area 2500 x 1250 x 140 16.5 HP router HSK 63-F Toolchanger 10 positions HSK 63-F Drillinghead vertical 5 positions 250m3 vacuümpomp IN NEW CONDITION ONLY 503 HOURS SWITCH ON

Condition: good (used), Year of construction: 2013, functionality: fully functional, input voltage: 400 V, type of input current: three-phase, workpiece length (max.): 3,000 mm, workpiece width (max.): 920 mm, workpiece height (max.): 50 mm, number of axes: 3, actuation type: electric, overall weight: 720 kg, Equipment: CE marking, Drilling machine, compact CNC machining center Vitap Point 2, year 2013, machine is operational and ready for inspection. It has been with our company since new, operated on a single shift as an auxiliary machine, and has not been in use for the past 5 years. Comes with a new toothed drive belt installed, plus one spare. TECHNICAL SPECIFICATIONS Drilling and milling unit - Number of independent vertical spindles: 8 - Number of horizontal spindles on X axis: 4 - Number of horizontal spindles on Y axis: 2 - Saw unit – diameter: 100 mm - Milling head: 3.6 kW ISO 30 – 12,000/24,000 rpm - Spindle rotation speed: 3,600 rpm - Saw rotation speed: 7,000 rpm - Maximum horizontal drilling depth (X and Y axes): 30 mm - Maximum vertical drilling depth: 45 mm - Maximum horizontal tool diameter: 12 mm - Maximum vertical tool diameter: 35 mm - Number of controlled axes: 3 - Motor power: 1.5 kW Codpjy Nyqhjfx Akcjrb Workpiece specifications - Maximum panel thickness: 50 mm - Maximum panel weight: 25 kg - Maximum panel size: X 1,100 mm, Y 50 mm - Minimum panel size: X 270 mm, Y 150 mm, Z 12 mm - Panel feed speed: 25 m/min MACHINE PARAMETERS Electrical data - Rated voltage: 400 V - Frequency: 50 Hz - Rated current: 21.1 A - Total power: 6.4 kW Air pressure: 7 bar Weight: approx. 715 kg

Condition: good (used), Year of construction: 1999, functionality: fully functional, Vertical Machining Center Manufacturer: Johnford / Matra Model: FMC 850 Year of manufacture: 1999 - 24-position double-arm tool changer - Table size: 1000x500 mm Cedpfx Aey Nx I Sskcsrb - Spindle speed: 8,000 rpm - Travel: 800x450 mm - Control: Fanuc Oi - The machine is operational and can be inspected under power with cutting demonstration

Condition: new, Bernardo Universal Lathe Master 400 x 1000 incl. 3-axis Digital Readout Special Accessories: Multifix quick-change tool post, 3 straight holders, 1 prism holder (factory installation – price: €672.00 net, not included in price) Centre distance: 1000 mm Centre height: 200 mm Swing over bed: 400 mm Swing over gap: 560 mm Swing over cross slide: 240 mm Bed width: 210 mm Spindle bore: 52 mm Spindle mount: DIN 55029, D1-5 Spindle speed range: (12) 45 – 2000 rpm Longitudinal feeds: (27) 0.06 – 2.78 mm/rev Cross feeds: (22) 0.01 – 0.72 mm/rev Metric threads: (36) 0.8 – 14 mm Inch threads: (30) 2 – 28 TPI Quill diameter: 45 mm Quill travel: 100 mm Quill taper: MT 4 Motor power: 2.0 / 2.4 kW Machine dimensions (W x D x H): 1860 x 800 x 1600 mm Csdpfsgd Iagox Akcsrb Approx. weight: 810 kg Scope of delivery: • 3-axis digital readout ES-12 V with LCD display • 3-jaw chuck DK11-200 mm / D5 • Faceplate 200 mm / D5, DIN 55029 compliant • Fixed steady rest – max. through diameter 90 mm • Travelling steady rest – max. through diameter 70 mm • Coolant system • Initial fill with Shell Tellus 46 • Removable chip tray • 320 mm face plate • Four-way tool post • Guard for four-way tool post • Safety slip clutch • Micrometer longitudinal stop • Thread chasing dial • LED machine lamp • Reducer bush • Change gears • 2 live centres • Foot pedal with brake function, CE compliant • Motor with magnetic brake as per CE regulations / operating tool set Special Accessories: Multifix quick-change tool post, 3 straight holders, 1 prism holder, factory installation (price: €672.00 net, not included in basic price)

Condition: excellent (used), Year of construction: 2001, Control: Heidenhain TNC 410 Worktable Table size: 2030 x 500 mm Travel distances: X-axis: 1700 mm Y-axis: 600 mm Z-axis: 600 mm Spindle speed range (stepless): 60 – 6000 rpm Rapid traverse: 25 / 25 / 20 m/min Number of tool stations: 22 tools Dimensions: 4.2 x 2.3 x 2.7 m Machine weight: approx. 10,000 kg Crsdpfx Akjy Imqxjcob

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, Working area X: 6,400 mm Working area Y: 1,500 mm Number of milling spindles: 1 Main motor: 13 kW Maximum rotation speed: 24,000 rpm Cjdpfx Aowlcqvokcsrb Tool clamping system: HSK-F63 Tool change positions: 8 Vertical drilling heads: 20 Horizontal drilling units X: 4 Horizontal drilling units Y: 4 2 vacuum pumps, each 360 m³/h Nesting Remote control Software: BIESSE WORKS Overall dimensions: 11,004 × 5,334 mm Weight: 4,900 kg

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: KMM 334-2052, Used CNC Vertical Machining Centres – 3-axis CNC (X/Y/Z) X travel: approx. 800 mm Y travel: approx. 400 mm Z travel: approx. 350 mm Control: Siemens 840D Tool magazine: approx. 42 positions (depending on equipment) Spindle taper: HSK 63 Max. spindle speed: ~10,500 rpm Spindle drive power: approx. 18.5 kW Cjdpfsyklx Sex Akcsrb Weight: approx. 7,500 – 8,800 kg Dimensions: ~3.5 × 3.5 × 3 m (L×W×H)

Condition: like new (used), Year of construction: 2024, machine/vehicle number: 14-1332-015/23270, functionality: fully functional, operating hours: 900 h, input voltage: 400 V, type of input current: AC, travel distance X-axis: 3,200 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 300 mm, number of slots in tool magazine: 14, controller manufacturer: OSAI, total height: 3,000 mm, total length: 5,400 mm, total width: 3,200 mm, overall weight: 4,100 kg, controller model: OPEN, spindle motor power: 12,000 W, nominal power (apparent): 28 kVA, number of spindles: 1, rapid traverse Z-axis: 20 m/min, rapid traverse X-axis: 100 m/min, rapid traverse Y-axis: 100 m/min, spindle speed (max.): 24,000 rpm, Equipment: documentation/manual, CNC AES Vega Ultra 1332, purchased new in March 2024. Machine has seen minimal use and is in like-new condition. Fully functional, tested, and ready for immediate production. Original purchase price: €85,000+ Key Specifications 3-axis Gantry CNC (Pod & Rail) with 2 independent working zones Working area: 3200 × 1300 × 300 mm Maximum speeds (X / Y / Z): 100 / 100 / 20 m/min Automatic Tool Changer: 14 positions, HSK-63F Spindle: HSD 12 kW, air-cooled Boring head: HSD BHZ17 Controller: OSAI Open Smart Premium Components Yaskawa servo motors Güdel linear guides Festo pneumatics Schmalz vacuum system HSD spindle & aggregates High-end European components throughout, suitable for demanding industrial use. Installation & Support Remote or on-site installation support available if required. Cjdpfxewlaxqo Akcjrb Commercial Details VAT not applicable (private company not VAT registered). Reason for sale: downsizing for family reasons Machine can be inspected under power. Additional photos, videos, or technical details available on request.

Condition: good (used), Year of construction: 2009, functionality: fully functional, The supporting structure is made from a thick, monolithic steel block with a reinforced core. The construction is triangular with a wide base and is designed to ensure the machine's stability under all processing conditions. Guideway lubrication is centralized, meaning all guideways on the machine are lubricated from a single point. The CNC features a full aluminum worktable with grooves for vacuum limitation or fixture mounting. This type of worktable is especially useful for “NESTING” operations. The electrical cabinet is built according to international standards, ensuring total reliability of the integrated components. Technical specifications: Working dimensions: With vertical milling: 3260 x 1250 mm With drilling head: 3330 x 1540 mm Cjdoy Nv Ucepfx Akcsrb Maximum workpiece height: 180 mm X, Y, Z axis travel: 3420, 1690, 280 mm Tool storage positions: 12 Vacuum pump: 100 m3/h Power: 10.5 kW Rated voltage: 400 V Frequency: 50/60 Hz Machine weight: 3400 kg Software: Xilog3 (supports .dxf file import) Year of manufacture: 2009

Condition: used, Year of construction: 2016, Used machine Year of manufacture: 2016 Cjdpfx Asy Ih Rgjkcsrb Equipment and technical data: - Electrical connection: 3x400V 50 / 60Hz - Cardanic 5-axis electrospindle 12 kW (S6) HSK F63 - 24,000 rpm - Ceramic bearings including liquid cooling with infinitely variable, height-adjustable dust extraction hood – controlled by electric motor - Full rated power at approximately 12,000 rpm - Speed range: 1,000 – 24,000 rpm - Drive: 3-phase high-frequency motor controlled via inverter - Rotational direction: right/left - 2 controlled compressed air connections - Interface for aggregates - Tool weight (rotating): 6 kg - Maximum saw blade diameter: 350 mm - Spindle cooling: liquid cooling - Continuously adjustable extraction hood - Profit H350 16.30: CNC machining center in gantry design (without tools) with digital drives (driven on both sides). The machine frame of the Profit H350 16.30 is made from thick-walled, electro-welded box sections. The internal steel ribbing in the frame ensures high stability. - Machining area H350 16.30: Axis travel: X = 4,000 mm Y = 1,970 mm Z = 455 mm Working area: X = 3,000 mm Y = 1,500 mm Z = 150 mm clearance height Axis positioning speeds: Depend on the selected safety system (can be taken from the layout). - Gantry drive on both sides - X-axis guidance system: The carriage of the X-axis is driven by a rack and pinion with helical, crowned teeth—this ensures maximum precision. The reduction gear guarantees the highest machining quality and repeat accuracy. The slideways use recirculating ball carriages running on encapsulated, hardened and ground linear guides. - Y-axis guidance system: Slideways use recirculating ball carriages running on encapsulated, hardened and ground linear guides. The Y-axis is positioned by a ground ball screw. - Z-axis guidance system: Slideways use recirculating ball carriages running on encapsulated, hardened and ground linear guides. The Z-axis is positioned by a ground ball screw. - Automatic central lubrication: Grease is supplied under control to the guide carriages of the X, Y, and Z axes as well as to the recirculating ball screws on Y and Z. Lubrication is performed automatically after a preset interval. - 12-position linear tool changer mounted on the left side of the machine frame, including one pickup station for aggregates: The 12-position linear changer ensures minimal changeover times and offers ample space for milling tools. One station for aggregates (see layout for configuration options). Maximum tool diameter: 250 mm Maximum tool length: 240 mm - Drill head DH 18 6H 1S: Vertical: 12 spindles—7 in X-direction and 5 in Y-direction. Horizontal: 6 spindles—4 in X-direction and 2 in Y-direction. Stroke = 70 mm; max. drill length = 70 mm; shank diameter = 10 mm. All spindles individually driven and selectable. 1 grooving saw in X-direction; maximum saw blade diameter 120 mm.

Condition: used, Year of construction: 2005, Used machine Year of manufacture: 2005 Equipment and technical data: Console machine (6 units) Travel dimensions: X = 3490 mm Y = 1690 mm Z = 205 mm Machining dimensions: X = 3050 mm Y = (Max. milling dimension - tool radius) 1345 mm Z = 150 mm Crsdpfx Ajy Ih Rmokceb Drilling head TF 20 Power: 2.2 kW 8 vertical spindles, spindle spacing 32 mm in X 6 vertical spindles, spindle spacing 32 mm in Y 2+2 horizontal spindles in X 1+1 horizontal spindles in Y with integrated grooving saw blade 120 mm with electro-milling spindle 9.2 kW with ISO-30 interface with C-axis with angle aggregate with 12-position tool changer with tool change station for angle aggregates with vacuum pump 80-100 m³/h Total connected load: 16 kW Compressed air: 6 bar Compressed air consumption: 210 NL/min Extraction nozzle: 250 mm Extraction volume: 5300 m³/h Extraction speed: 30 m/sec Dimensions: 5940 x 3800 x 2510 mm Weight: 3700 kg Availability: by arrangement Location: 63934 Röllbach

Condition: used, Year of construction: 2019, Used machine Year of manufacture: 2019 Equipment and Technical Data: - For classic nesting processing with wear plate - Machine frame of welded construction with ground and hardened prism guides for the gantry, unit head, and consoles - Gantry-type traveling column - Helical rack and pinion drive in X and Y axes, ball screw in Z axis for precise positioning - Working dimensions: - Max. support area on nesting table: X = 3100 mm, Y = 1560 mm - Max. traverse paths: X = 4695 mm, Y = 2100 mm, Z = 293 mm - Max. clearance height over DYNESTIC table: Z = 100 mm from table top (without wear plate) - Maximum programmable speed Vector speed: 128 m/min X = 80 m/min, Y = 100 m/min, Z = 25 m/min - DYNESTIC table: - Fixed, continuous processing table with grid layout - Continuous grooves in X and Y directions - Groove spacing: 50 mm - Includes 25 meters of sealing cord for clamping the wear plate Crsdswka Upopfx Akceb - Vacuum fields: Single-circuit vacuum system - Drilling unit 7877: - 19 spindles - Drive power: 1.7 kW - 13 vertical spindles: - Individually selectable - Arranged in U-shape - 5+4 in X direction, 4 in Y direction - 32 mm spacing - Max. drill diameter: 35 mm - Total drill length: 70 mm from screw-on end (depending on panel thickness) - Spindle stroke: 70 mm - Rotational direction: alternating clockwise/counterclockwise - Speed (max): 1000 - 4400 rpm, infinitely variable - Tool holder: M10 thread, 11 mm fit - Without tool, without holder - 6 horizontal spindles: - 2 double drill spindles in X direction - 1 double drill spindle in Y direction - Tool holder: M10 thread, 11 mm fit - Max. total drill length: 63 mm from screw-on end - Without tool, without holder - Milling unit 7842: - Power: 12.0 kW (S6) - Max. speed = 1000 - 24,000 rpm, infinitely variable - Max. power at 12,000 to 24,000 rpm - Air-cooled - With HSK-F 63 tool holder - With right-hand threaded nut (for right-hand rotating tools) - With collet chuck for HSK shank - Ceramic ball bearings (hybrid bearings) - Tool weight max. 6 kg (incl. holder) - Tools: milling and grinding tools max. Ø 160 mm - Safety enclosure according to CE standard - Side and rear safety fence - Vacuum pump: 500 m³/h, dry-running - Personnel safety ensured by light barriers in the front machine area - Hand-held control device for remote operation of the machine with the following functions: - Start/stop of the processing program - Control of processing cycle speed - Reset button - Manual feed/rapid traverse for all axes - EMERGENCY STOP - CAMPUS V7 CAD/CAM software 1x machine license consisting of: - CAMPUS NC-HOPS: - Graphic variant system with WOP and CAD/CAM features for creating part variants using macro technology - CAMPUS MT-Manager - CAMPUS Workcenter - CAMPUS DXF interface - Automatic central lubrication - Automatic lubrication at defined intervals - Additional sealing against dust via pressurization in each guide carriage

Condition: used, DECKEL MAHO DMU 60T HEIDENHAIN 426 Credpfxowg Df Dj Akcob – worktable dimensions (length x width): 900 x 500 mm – table load: 350 kg – maximum feeds in the X/Y/Z axes: 600/525/ 500 mm

Condition: excellent (used), workpiece diameter 30 - 325 mm grinding depth 60 mm clamping length 1000 mm center hole 1 - 30 mm Crodpfey Ihb Sox Akcob weight of the machine ca. 0,2 t dimensions of the machine ca. 0,5 x 0,5 x 1,7 m dressing unit, counter steady, grinding stones

Condition: excellent (used), Year of construction: 2012, travel distance X-axis: 450 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, LOW operating hours! Spindle hours: 1,300 h Power-on hours: 10,700 h Control: SIEMENS 840D SL OPERATE Travel: X = 450, Y = 400, Z = 400 mm Table size: 770 x 410 mm Max. workpiece weight: 200 kg Tool changer magazine with 24 stations Tool holder: SK 40 Max. spindle speed: 15,000 rpm Codpfsy Ifmxex Akcjrb

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, HAAS control (LCD screen, intuitive programming) Table size 914 x 356 mm Table load capacity 680 kgs X-axis travel 762 mm Y-axis travel 406 mm Crodpfx Akoy Ifbceceb Z-axis travel 508 mm Spindle speed 12000 rpm Rapid traverse X/Y/Z = 35,6 m/min Tool magazine 24+1 positions (arm type) Spindle power 22.4 kW Spindle taper SK40 Machine weight approx. 3 630 kg Dimensions (L x W x H): 2 500 x 2 400 x 2 600 mm Accessories, equipment - Electric MPG - Coolant system - Internal coolant supply - Chip auger - RENISHAW infrared tool measuring system with probe - 4th axis preparation - Power failure detection - Machine manuals - Machine mounts The machine is in very good condition and still powered on. It was purchased as a new machine in Hungary. It was used in clean and professional environment.

Condition: used, Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Codey Ifdqjpfx Akcjrb Control: FANUC 31:iA Main Spindle Power: 15/11 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Counter Spindle Power: 11/7,5 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Turning and milling spindle Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler

Condition: used, Year of construction: 1971, functionality: fully functional, turning diameter over bed: 900mm turning diameter over slide rest: 800 mm Center distance: 2.000 mm turning diameter: 1.200 mm turning diameter in the gap (with guide spindle pulled out to the right): approx. 1.460 max. width of the adjustable bed: 900 mm spindle bore: 85 mm turning rate: 14 - 710 min-1 dimensions (LxWxH), approx.: 4.705 x 2.060 x 2.000 mm equipment: 4 fold tool clamping system, HEIDENHAIN three-axis digital readout, Three jawchuck FORKARDT F400, Vibration damping elements Crsdpey Ifdkjfx Akceb The main spindle box was completely overhauled approx. 10 years ago. The vibration-damping elements are included in the scope of delivery. The machine is from the original owner.

Condition: refurbished (used), Year of construction: 2022, functionality: fully functional, turning diameter over bed: 540 mm Crodpey Ifcasfx Akcjb turning length: 1.500 mm turning diameter in the recess: 580 Working travel of the lower slide max. approx.: 415 mm adjustment of upper support, max. approx.: 140 mm turning speed range: 0 - 1.800 U/min diam. of main spinde: 135 mm spindle bore: 68 mm internal taper diameter: 73 mm bed width: 403 mm Equipped with: Three jaw chucks FORKARDT 250 Digital read out 3 axis fixed steady rest feed safety chip tray tool holders, 6 chisel holders, 1 holder for clamping sleeve

Condition: excellent (used), Year of construction: 2010, operating hours: 1,000 h, functionality: fully functional, Controller FANUC Oi-MD Table size 1120 x 560 mm Max. table load 750 kgs X-axis travel 1020 mm Y-axis travel 560 mm Z-axis travel 600 mm Distance spindle nose to table surface 135 – 735 mm Speed ​​60 – 8000 rpm Spindle taper BT40 Tool magazine 20 positions (umbrella magazine) Main drive power 7,5/11 kW Rapid traverse X/Y/Z 24/24/18 m/min Machine dimensions (L x W x H) 2820 x 2530 x 2500 mm Machine weight approx. 6000 kg Accessories - Chip conveyor - Workplace lighting - Signal light Credpfx Aey Id Tkekcob - Handwheel - Feet The machine was modified to a special-purpose machine, but this only refers to side covers. The machine can be used for bar material automatical machining (sawing and milling). However these can be converted back to normal function (just machining center). The machine was hardly used and has 1000 operating hours. Still powered up in Hungary.

Condition: reconditioned (used), Year of construction: 2001, functionality: fully functional, Universal Milling & Drilling Machine DECKEL MAHO DMU 50 M Equipped with Heidenhain TNC 310 control Year of manufacture: 2001 Travel paths: X 500, Y 400, Z 400 mm Speed range: 20 – 4,500 rpm, infinitely variable Includes the following accessories: Manual swivel rotary table with digital display for C + B axes Clamping surface: 700 mm x 500 mm Electronic handwheel for X, Y, Z axes Crodpfxey Id Stj Akcsb Splash guard enclosure Machine lamp 4 adjustable-height machine feet Coolant system Operating manual

Condition: used, Year of construction: 2002, operating hours: 14,700 h, machine/vehicle number: 15115220514, travel distance X-axis: 2,200 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 720 mm, controller manufacturer: Siemens, controller model: Sinumerik 840D/810D, total height: 2,650 mm, total length: 4,472 mm, total width: 2,780 mm, overall weight: 12,500 kg, spindle speed (max.): 12,000 rpm, operating hours of spindle: 14,700 h, number of spindles: 1, number of slots in tool magazine: 30, input voltage: 400 V, Equipment: documentation/manual, Particularly interesting for export customers: Proper disassembly allows the machine to be loaded onto a standard semi-trailer with approximately 2.45 m loading width. Our disassembly team can prepare and load the machine accordingly. As a result, transport costs can be significantly reduced compared to a special transport. Technical Data Manufacturer: DECKEL MAHO Model: DMF 220 linear Year of manufacture: 2002 Machine No.: 15115220514 Control: Siemens SINUMERIK 840D/810D Operator interface: ShopMill ShopMill version: 06.02.04 PLC version: 06.03.06 Tool holder: SK 40 Working spindle: up to 12,000 rpm Tool magazine: 30 stations Table size: 2,600 × 600 mm Max. table load: 2,200 kg Travel paths: X 2,200 mm / Y 560 mm / Z 720 mm Feed rate: up to 20,000 mm/min Rapid traverse X: 18,000 mm/min Rapid traverse Y/Z: 15,000 mm/min Machine weight: approx. 12,500 kg Transport weight: approx. 14,000 kg Max. installation weight: approx. 16,000 kg Electrical Data Connected load: 50 kVA Max. current consumption: 60 A Main fuse: 80 A Power supply: 400 V / 50 Hz Control voltage: 24 V Supply voltage: 230 V Electrical diagram available Equipment / Special Features Siemens SINUMERIK 840D/810D ShopMill operator interface SK40 tool holder 30-station tool magazine Large X-axis with 2,200 mm travel Rigid table design Documentation / technical documents available Electrical diagram available Machine under power Year of manufacture: 2002 Made in Germany Transport optimization possible through disassembly Cedpfx Akjy Nn Eyscsrb Loading onto standard semi-trailer possible Considerably lower transport costs compared to wide-load/special transport

Condition: used, Year of construction: 2013, x-travel 500 mm y-travel 400 mm z-travel 330 mm Crsdpfx Asy Nn Dvskcob weight of the machine ca. 2100 kg

Condition: used, Year of construction: 2011, Base Machine M800 X5 TV 1 WORKING RANGE X: 5,020 mm Y: 1,830 mm Z: 675 mm Clearance Height: 300 mm (from 50 mm suction cup height) MACHINE STRUCTURE The base structure is a monolithic construction made from thick-walled steel. It is reinforced across the entire machine bed with welded components, providing exceptional stability. The table design, with its large base, is the key to ensuring lasting precision and stability. The machine’s layout enables the operator to achieve optimal workflow with minimal space requirements. The mobile gantry is built as a solid monoblock. It is positioned in the X direction on prismatic, ground guides with recirculating ball carriages. The machining unit is mounted on this mobile support carriage, also on prismatic, ground guides and recirculating ball carriages. AXIS MOVEMENT All axes travel on prismatic linear guides with large cross-section and recirculating ball shoes with a wide contact surface, which ensures optimal sliding, even at high speeds and accelerations. The precise and fast positioning of the movable gantry (X-axis) is achieved via helical rack and pinion. Large cross-section recirculating ball screws ensure accurate positioning of the machining unit along the movable gantry (Y and Z axes). The perfect mechanical dynamics and maximum positioning accuracy are controlled by high-quality drives and brushless motors. Max. axis speeds: · X-axis = 90 m/min · Y-axis = 90 m/min · Z-axis = 30 m/min Safety device with bumper and light barrier 1 Bumpers with sensors are fitted to the movable upright, and a light barrier system is installed at the front of the machine. If the operator enters the active zone, the X-axis travel speed is reduced to a lower value of 25 m/min without stopping the machine. This system allows parts to be loaded during pendulum operation without the limitation of access areas, as seen with pressure mat systems. This prevents unwanted interruptions in the machining cycle and offers greater freedom of movement around the worktable. CE certification for the safety system 1 Safety protection fence 1 Side and rear protection fence Automatic central lubrication controlled via CNC 1 The lubrication of the X, Y, and Z axes is controlled by the CNC; intervals are regulated automatically, without manual intervention. Central extraction connector 1 All individual extraction connections of the machining units are collected into a central extraction port. Inside the port, there are various slider valves controlled by the NC. This reduces the required extraction air volume. Chip conveyor 1 Maxi – 5-axis electrospindle 11 kW HSK-63 “Prisma K 1 5-axis electrospindle, 11 kW at 20,000 rpm S1 (100% duty cycle) Speed: max. 20,000 rpm Rotation direction: left/right Liquid cooling Tool interface HSK 63F Inverter 18 kW, stepless, smooth power delivery Max. rotation B-axis = 200° (+-100°) C-axis = 650° Thanks to the non-orthogonal axes, it is possible to perform complex horizontal positioning in a small workspace. This enables the machining of complex geometries without the risk of collision. Credpfx Ajxy Tmnekcsb

Condition: used, Year of construction: 2016, Working area: X=3300 mm Y=1280 mm Z=150 mm Clearance height Operator terminal: 24" LED colour display Handheld terminal for axis speed control Software: "Woodflash Vacuum pump 90 m³/h/50 Hz or 108 m³/h/60 Hz Milling spindle 12 kW HSK F63 (12,000 rpm) 12-position linear tool changer on the left of the machine frame + pickup station Drilling head DH 16 4H 2S: Vertical 12 spindles Horizontal 4 spindles 2 grooving saws Storage location: Nattheim Credpfx Aoxy Tlwokcjb
