Used Punch Tool for sale (37,242)

Condition: used, Single-Column Eccentric Press RASTER ZEULENRODA Type PDA 100 Year of manufacture: 1995 Pressing force: 100 tons Throat depth: approx. 360 mm Table size: 1200 x 710 mm Itsdpfx Ahjx U Eiao Nsb Ram area: 900 x 500 mm Table opening: 400 x 120 mm Stroke adjustment: 6 to 82 mm Ram adjustment: 100 mm Installation height, max. stroke, ram Top Dead Center (TDC): max. 469 mm Installation height, max. stroke, ram Bottom Dead Center (BDC): max. 387 mm Strokes per minute: 50-200 s.p.m. Main drive motor power: 18.5 kW Power supply: 400 Volt, 50 Hz - Hydraulically actuated multiple-disc wet clutch and spring-loaded safety brake - Infinitely variable drive via PIV gearbox with inching mode for automatic stroke adjustment and setup operations - Hydraulic overload protection in the ram - Press force and process monitoring via UNIDOR APS - Pneumatic, steplessly adjustable ram weight compensation - Roller feeder MABU WE16, 160 x 3 mm, programmable feed length - Central grease lubrication - Operating manual and documentation for the press Included: Roller feed unit MABU Type WE16 Strip width: 160 mm Strip thickness: max. 3 mm Strip cross-section: max. 300 mm² Roller diameter: 63 mm Strip speed: 40 m/min - Adjacent feeder control MABU Space requirements for eccentric press L x W x H: 270 x 240 x 350 cm Weight of the press: 13.5 tons

Condition: excellent (used), functionality: fully functional, Height 475 mm Width 200 mm Ijdpfox U Efnex Ah Njtb Operating pressure 6/7 bar Operating temperature 0/40° C Weight 20 kg

Condition: used, Year of construction: 1980, control panel Boschert Stanze Year 1990 Iedpfx Aex U A H Njh Netb +++++ Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. +++++

Condition: used, Year of construction: 1990, serial number 28043 weight 3 t pressure 30 t volt 380 V frequency 50 Hz Isdpfx Ahspxri Hs Notb

Condition: good (used), Year of construction: 1988, Ja Stanzkraft 800 kN frequency 50 Hz current 17/11 A voltage 220/380 V round bar steel 32-17 mm square edge steel 30-18 mm 100 x 10 mm flat steel 350 x 16 mm throat 200 mm Ijdpfjryaqysx Ah Notb work height max. 1107 mm total power requirement 4 kW weight of the machine ca. 1,5 t dimensions of the machine ca. 1200 x 700 x 1850 mm

Condition: used, Year of construction: 1975, 1640 weight 280 kg ja +++++ Please note: Iedpfxoh H Eqno Ah Njtb The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. +++++

Condition: used, Year of construction: 1997, Control Heidenhain 355 x-travel 850 mm y-travel 550 mm z-travel 450 mm tool taper SK50 weight of the machine ca. 5,5 t +++++ Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. Iedpfxsd N Smhj Ah Netb +++++

Year of construction: 2005, condition: used, tool adaptor 50 mm driven tools 5 Stück 4 Stück Ijdpfxsgtyhro Ah Netb +++++ Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. +++++

Condition: used, Year of construction: 1988, 220 V frequency 50 Hz combination machine ja extensive accessories ca. 50 Sätze Iodpfxondz Npj Ah Nstb pressure 50 t

Condition: good (used), Year of construction: 2007, functionality: fully functional, Technical details measuring range X-axis 400 mm measuring range Y-axis 400 mm diameter max. 350 mm weight of the machine ca. 420 kg dimensions of the machine ca. 1,23 x 0,75 x 1,91 m Additional information Used Tool Presetter in very good condition. Checked by a service engineer from SPERONI. Test report available. Automatic measuring Pneumatically Activated Axis Movement Spindle Disk Brake Camera CCD Itjdpfx Ahox Uyl Ns Njb LCD Monitor 22" Label Printer DYMO 1 off toolholder for HSK 32 Other tool holders in other sizes are available from the manufacturer. Axis Resolution 1µ Software: Speroni Pro Vision PC DELL Optiplex GX 745 – Pentium Dual-Core CPU E 5200 / 2,50 GHz, 1,00 GB RAM (PC was changed approx. 5 years ago) Optionally, the following adapter can be obtained from the manufacturer: ISO 40 holder HSK 63 A/C holder

Condition: good (used), Year of construction: 2004, functionality: fully functional, Technical details x-travel 620 mm y-travel 420 mm z-travel 400 mm Control Heidenhain TNC 410M table surface area 800 x 400 mm Iodpfjx Ux Euex Ah Njtb tool taper ISO 40 spindle turning speed - stepless 50 - 4000 U/min main drive motor 5,5 kW weight of the machine ca. 2,1 t Additional information * CNC control HEIDENHAIN TNC 410M * Coolant equipment * Machine lamp

Condition: reconditioned (used), Year of construction: 1987, Universal toolroom milling machine DECKEL FP 1 With 3 axes active digital display Heidenhain TNC 113 Year of manufacture: 1987 Travel: X 300 Y 160 Z 340 Speed range: 40 - 2000 rpm With the following accessories: Universal table 600 mm x 250 mm clamping surface Movable vertical milling head Extendable drilling spindle sleeve Stepless feed via potentiometer 1 pcs. Machine vice 1 pc. Counterholder with counterbearing 1 pc. Milling arbor long 0 22 mm Various tool holders S 22 x 2 Bellows Z axis Machine light Automatic central lubrication pump Itjdpfx Aspxm Ansh Nsb Chip collecting plate Coolant device Operating instructions THE MACHINE IS IN A VERY GOOD CONDITION !!!

Condition: reconditioned (used), Year of construction: 1994, Universal Tool Milling Machine DECKEL FP 1 With 3-axis active digital readout Heidenhain TNC 123 Year of manufacture: 1994 Travel: X 300 mm, Y 160 mm, Z 340 mm Spindle speed range: 40 – 2000 rpm Comes with the following accessories: Fixed angle table, 600 mm x 250 mm clamping surface Movable vertical milling head Extendable quill Infinitely variable feed via potentiometer 1 machine vice 1 tailstock with counter bearing 1 long milling arbor Ø 22 mm, Ø 16 mm, Ø 27 mm Various tool holders S 22 x 2 Z axis bellows 1 chip guard Machine lamp Automatic central lubrication pump Itodpfx Aew Agxrsh Nob Coolant system Operating manual THE MACHINE IS IN EXCELLENT CONDITION! THE MACHINE COMES FROM A TRAINING WORKSHOP!

Condition: used, x-travel 300 mm Iedox Uru Aopfx Ah Notb y-travel 275 mm z-travel 200 mm spindle tunring speed 40 - 2.000 U/min tool taper ISO 40 In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice and errors. Prior sale is reserved.

Condition: used, Stud welding machine with shielding gas and lift ignition HBS Type ARC 804 Serial No. 610652 Welding current up to 800 A at 5% duty cycle Welding voltage 30 V Open circuit voltage U0: 95 V Maximum stud diameter 10 mm Rated power 15 kVA Power supply 400 Volt, 50 Hz, 32 A plug Rated current 27 A - Welding current adjustable in 4 steps Isdpex Urcaefx Ah Njtb - Continuously variable welding time setting - Shielding gas connection with continuously adjustable time - Welding gun with lift ignition PMH70 - Hose package length 4.5 m - Ground cable with two leads and two ground clamps - Digital display for current welding time in ms - Indicator lights for external conductor failure (phase failure) - At maximum stud diameter, approx. 3 studs per minute - 1 piece stud holder Ø 8 mm (fitted), 1 piece stud holder Ø 10 mm, 1 support tube - Mobile on transport trolley - Approx. 20 kg welding studs M8 and M10 in steel and stainless steel, including 12 kg M8 x 25 in stainless steel Required space (L x W x H) 500 x 325 x 305 mm Weight of welding machine 60 kg Total weight with transport trolley 145 kg Good condition

Condition: used, Year of construction: 2010, functionality: fully functional, Spindle taper: ISO 40 RPM.: 60-4200 (variable in 2 gears). Travel: X655 Y315 Z430 mm. Table size: 1245 x 230 mm Automatic feed: X & Y Rapid speed: X & Y. Motor: 3 HP. Itsdpoya Hb Tjfx Ah Nob Digital readout: Resson RD-12 (X & Y). Year: 2010 Country of origin: Taiwan. Size (L x W x H): 1750 x 1600 x 2300 mm. Weight: 1000 kg. With pneumatic tool clamping, drilling function in head with automatic feed (travel 130 mm.), vice, indexing table and lots of equipment. All our machines are tested and serviced before delivery.

Condition: used, Bäuerle universal tool grinding machine for woodworking and metalworking tools. Iodpfx Ahoxytmue Nstb

Condition: good (used), Year of construction: 2012, Amada LC 2012 C1 NT / Punch - Laser Machine, Itodpfxeyay Tpe Ah Njb Year of manufacture: 2012, Control: AMNG - Fanuc Series, Punching force: 200 kN, Punching area: 2,500 x 1,270 mm, Laser power: 2,500 W, Laser cutting area: 2,000 x 1,270 mm, Z-axis travel: 100 mm, Max. table load: 150 kg, Turret stations: 46 positions,

Condition: ready for operation (used), Year of construction: 2004, Immediately available from Swiss operation: CNC Punch – Nibbling Machine Boschert Type TWIN 750 CNC/Z Year of manufacture: 2004 Working area: 810 x 1500 mm Sheet length with repositioning up to 9999 mm Table: 750 x 3500 mm Revotol 6 Hydraulic punching force: 28 tons Max. workpiece weight: 200 kg Strokes/min: 250 Strokes/min with fast cycling: 800 X-axis speed: 60 m/min Y-axis speed: 30 m/min Simultaneous X & Y-axis speed: 67 m/min Trumpf tooling Accuracy: plus/minus 0.05 mm Connection: 4.8 / 11 kW Complete tooling included Weight: 11.5 tons Itedpfsyayidjx Ah Nob Price: EUR 9,000.– plus VAT ex location

Year of construction: 1995, condition: ready for operation (used), Immediately available at location: Boschert punching nibbling machine Type KST 40 / 750 PowerLine digital Year of manufacture 1995 Press force 40 tons Stroke height 40 mm Punch diameter max 105 mm Itjdpfxoyaya Nj Ah Neb Sheet thickness max 10 mm Extension tables left and right Quick-change system Digital backgauge system x-axis 0 – 1500 mm left y-axis 0 – 750 mm Tools Weight 3 tons At the price of Euro 2,000.-- plus VAT ex location.

Condition: used, Year of construction: 1985, 1 unit universal milling machine, manufacturer Deckel, model FP 4 MA, serial no. 2204.1463, year of manufacture approx. 1985, Deckel Contour II control, milling table approx. 800x500 mm, 7 T-slots, approx. 25 tool holders. Iodpfx Ahoyaxl De Njtb

Condition: used, 1 piece universal tool milling machine, make Deckel type FP 4 A, serial no. 2204-1177, control by Grundig Elektronik, milling table approx. 800x500 mm, 7 T-slots. Ijdpeyaxk Tsfx Ah Netb

Condition: used, overall weight: 221 kg, total length: 400 mm, total width: 400 mm, total height: 540 mm, Cross tooling column with Gressel Mounting holes 4 Pitch fixing holes 320 mm Length 400 mm Width 400 mm Isdpfxox Ttzzj Ah Njtb Height 540 mm Weight 221 kg If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: used, overall weight: 208 kg, total length: 400 mm, total width: 400 mm, total height: 470 mm, Erowa ER-051145 FL-AA0324 Double side tooling column with Erowa Mounting holes System Erowa Length 400 mm Width 400 mm Height 470 mm Weight 208 kg Itsdpfxjx Ttzbs Ah Njb If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: excellent (used), Year of construction: 1998, overall weight: 35 kg, Metal cutting Tooling REISHAUER - HF 330 Diameter: 330mm 3 Chuck: 3 chuck Itodpfox Ttilox Ah Njb Spindle bore:80mm Connector: 8 Length: 330mm Width: 100mm Height: 0mm Weight: 35kg
