Used Convancional Lathe for sale (5,377)

Condition: good (used), Heavy-duty lathe, lathe, lead screw lathe, lead screw lathe Ncjdpfx Ajyaypksd Nel -Manufacturer: Strunguri Arad, lead screw and feed screw lathe type SNA560x2000 -Turning length: 2140 mm -Turning diameter over bed: 600 mm -Turning diameter over support: 330 mm -Spindle bore: Ø 65 mm -Spindle speeds: 16 - 1600 rpm -Three-jaw chuck: Ø 310 mm -Tailstock mount: MK5 -Drive motor: 11 kW -Accessories included, see photos -Dimensions: 3700/1050/H1400 mm -Weight: 3600 kg

Condition: good (used), Year of construction: 2004, functionality: fully functional, Fanuc control, Spindle bore 66 mm, Turret - driven, Njdpfxjyaynte Ad Nocl Sub spindle, Chip conveyor, Short bar loader.

Condition: good (used), Year of construction: 2008, functionality: fully functional, CNC Lathe Weiler DZ 42 Year of manufacture: 2008 Control: Siemens 840D / Shopturn Nodpoyayc Dofx Ad Nscl Manual loading up to D 220 mm Material passage: 42 mm Max. turning length: 450 mm Spindle speed: 6300 rpm Machining Turret with 16 driven tools X/Z/Y / C-axis Collet chuck

Condition: good (used), Year of construction: 2009, functionality: fully functional, Manufacturer: Gildemeister Model: CTX 410 V4 Year of manufacture: 2009 Control: Heidenhain plus IT Travel: X 170 mm, Z 635 mm, Y +/-40 mm Program run time: 11,400 h Spindle Spindle speed: 5,000 rpm Nsdpfoyax Swex Ad Nocl Spindle bore: 65 mm Turning diameter over cross slide: 375 mm Turning length: 635 mm Turret Tool holder: VDI30 Number of stations: 12 with AGW Dimensions and weight Dimensions: 5,000 mm x 2,500 mm x 2,800 mm Weight: approx. 5,800 kg

Condition: good (used), Year of construction: 2014, operating hours: 8,500 h, functionality: fully functional, turning diameter over cross slide: 800 mm, turning length: 900 mm, turning diameter: 500 mm, spindle bore: 77 mm, spindle speed (max.): 3,200 rpm, Spinner TC 800-77 MCY Year of manufacture: 2014 Maximum turning diameter: 500 mm Maximum turning length: 900 mm Control: Fanuc 31i Maximum swing diameter: 800 mm Main spindle: Maximum speed: 3,200 rpm Drive power (main spindle): 24 / 33 kW Maximum torque: 630 Nm Chuck diameter: 250 mm Spindle nose: A8 Bar capacity: 77 mm Travel distances: X-axis: 360 mm Y-axis: 120 mm (-55/+65) Z-axis: 900 mm C-axis: 360° Tool turret: Tool stations: 12 positions Driven stations: 12 positions Tool holder: VDI 50 Speed range (driven tool stations): max. 4,000 rpm Drive power (driven tool stations): 5 / 9.6 kW Torque: 18 / 35 Nm Feeds: Rapid traverse X: 15 m/min / Z: 24 m/min Total power requirement: - kW Machine weight approx.: 7.5 t Space requirement approx.: 4.3 x 3.0 x 2.2 m Control ON hours: 44,700 Ncedpeyax Hbofx Ad Nol Operating hours: 8,518 Machining hours: 6,631

Condition: used, Year of construction: 2022, controller manufacturer: Siemens, controller model: SINUMERIK 828D, _____ Description: Year of manuf. : 2022 Control : Siemens SINUMERIK 828D Turning diam. : 288 mm Turning length : 243 mm Njdpfsyavz Asx Ad Necl Work area max. turning diameter:288mm max. machining length:243mm X-axis:175mm Z-axis:350mm Main spindle Chuck diameter:210mm Max. bar diameter:67mm Spindle bore diameter:76mm Drive power:10.5/20 kW max. torque:213 NM max. speed:4,500 rpm Tailstock Quill diameter:65mm Quill stroke:80mm Axial force:4,312 N Center point adapter:MT4 Tool turret Number of tool stations:12 Tool holder:BMT45 Powered tools:Yes Max. speed:5,000 rpm

Condition: excellent (used), Year of construction: 2024, operating hours: 20 h, turning diameter over cross slide: 300 mm, turning length: 1,350 mm, turning diameter: 510 mm, spindle bore: 50 mm, spindle speed (max.): 2,500 rpm, spindle motor power: 7,500 W, rapid traverse Y-axis: 8 m/min, rapid traverse Z-axis: 8 m/min, rotational speed (min.): 2,500 rpm, quill travel distance: 160 mm, quill diameter: 75 mm, quill stroke: 160 mm, swing diameter over cross slide: 300 mm, feed rate X-axis: 2 m/min, feed rate Y-axis: 2 m/min, workpiece weight (max.): 600 kg, turning diameter over top slide: 300 mm, overall weight: 2,700 kg, mount diameter: 40 mm, Equipment: documentation/manual, Style CNC is a company specializing in the manufacture of CNC lathes and milling machines for single-piece or small-batch production. If you operate a tool shop, prototyping center, or provide services with very fast turnaround times, Style is an excellent solution. The intuitive graphical software allows you to create a program directly on the touch screen of the machine in just a few minutes. Nedpfx Ajw Eum Ajd Njcl We currently have a demo machine for sale with a limited number of dry run hours. The machine is sold with a full 12-month warranty, including commissioning and training. In Poland, Style CNC has its own dedicated service branch.

Condition: new, Year of construction: 2025, functionality: fully functional, turning diameter over cross slide: 102 mm, turning length: 760 mm, turning diameter: 450 mm, spindle bore: 95 mm, spindle speed (max.): 3,000 rpm, spindle speed (min.): 10 rpm, travel distance X-axis: 250 mm, travel distance Z-axis: 790 mm, spindle motor power: 22,000 W, rapid traverse X-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, total height: 2,250 mm, total length: 2,804 mm, total width: 4,860 mm, quill diameter: 90 mm, quill stroke: 119 mm, feed rate X-axis: 10 m/min, feed rate Z-axis: 10 m/min, turning diameter over bed slide: 582 mm, overall weight: 4,900 kg, swing diameter over bed slide: 582 mm, spindle nose: A2-8, Equipment: documentation/manual, · CNC control Milltronics 9000-DGI · 15" LCD color touchscreen · Ethernet interface · Productivity software: DSA, MSV, Bidirectional Turning Cycle, 9000-DGI Desktop · Spindle load monitoring · Indicator lights for operating status · Constant cutting speed · Rigid tapping · Electronic handwheel on the control panel · Hydraulic 3-jaw chuck 250 mm with soft jaws and foot pedal · Spindle design with quill · Linear roller guides · 12-station tool turret · Toolholder kit with 12 clamps, 2 axial toolholders, · 6 boring bar holders with 7 reducing sleeves · Automatic lubrication system · Full enclosure with sliding doors · Coolant system with pump · Operating and maintenance manual in digital format · Transformer for standard industrial power supply, 400V, 3-phase Available as options: Delivery and commissioning Nsdox Akr Tspfx Ad Necl Automatic tool measurement Hydraulic tailstock Chip conveyor Collet chuck

Condition: new, Year of construction: 2025, functionality: fully functional, machine/vehicle number: 2311151630, turning diameter over cross slide: 650 mm, spindle bore: 153 mm, turning length: 3,150 mm, turning diameter: 650 mm, turning diameter over bed slide: 650 mm, turning diameter over top slide: 410 mm, quill stroke: 150 mm, quill diameter: 100 mm, rapid traverse X-axis: 13 m/min, rapid traverse Z-axis: 13 m/min, spindle speed (min.): 30 rpm, spindle speed (max.): 1,600 rpm, center height over cross slide: 410 mm, feed length X-axis: 330 mm, feed length Z-axis: 3,150 mm, feed rate X-axis: 2 m/min, feed rate Z-axis: 13 m/min, total length: 6,261 mm, total width: 3,588 mm, total height: 2,375 mm, type of input current: three-phase, spindle motor power: 18,000 W, overall weight: 5,200 kg, rotational speed (min.): 30 rpm, rotational speed (max.): 1,600 rpm, torque: 1,050 Nm, controller manufacturer: Milltronics, controller model: 9000 DGI, input voltage: 230 V, drill spindle diameter: 153 mm, nominal power (apparent): 21 kVA, number of spindles: 1, spindle nose: A2-11, tailstock quill diameter: 100 mm, tailstock quill mount: MK 5, tailstock quill stroke: 150 mm, number of slots in tool magazine: 8, Equipment: rotational speed infinitely variable, LIST PRICE of the machine: EUR 149,500.00!!!!! The machine is new and immediately available. Subject to prior sale. Including hinged belt chip conveyor. Delivery of the machine in export packaging ex our warehouse. (Shipping costs to be borne by the buyer) Operating fluids to be supplied by the buyer. Commissioning and training by Milltronics possible. Leasing available (subject to credit approval) Machine details: • CNC control Milltronics 9000-DGI • 15" LCD color touchscreen • Ethernet interface • USB interface • Productivity software, DSA, MSV, bidirectional turning cycle, 9000-DGI Desktop • Connection for external keyboard • Electronic handwheels for manual operation, teaching, or automated processes • Custom macros available • Override potentiometer for axes and spindle • Spindle load monitoring • Key switch to lock the EDIT function • Indicator lights for operating status • Additional "M" function with CNC dwell channel • Constant cutting speed • Rigid tapping • Spindle speed 30 - 1600 rpm • Spindle motor 18 / 11 kW, 2-speed electronic gearbox • Spindle nose type A1-11 • Tool turret with 8 stations, 25 mm • One axial tool holder for standard tools 25 mm x 25 mm • One boring bar holder 38 mm Ncjdpfxjx Akm Rs Ad Nol • Automatic lubrication system • Full enclosure with sliding doors • Coolant system with pump • CE certification • Instruction manual, spare parts list, and wiring diagrams in digital format • Operation and maintenance manuals in digital format • Transformer for standard industrial power, 400 volts, 3-phase • Lifting brackets for craning the machine Optional accessories: Manual 3-jaw chuck 300 mm Hydraulic tailstock quill (only in conjunction with hydraulic chuck) Hydraulic 3-jaw chuck with hydraulic power unit (diameter 300 mm – bore 70 mm) Fixed steady rest with rollers, range 20 – 200 mm Fixed steady rest with rollers, range 180 – 410 mm Follow steady rest with brass supports, range 20 mm – 200 mm 38 mm boring bar holder for turret 25 mm axial tool holder Hinged belt chip conveyor instead of drawers Programming manual in paper format Machine manual in paper format Floor mat with Milltronics logo

Condition: used, Year of construction: 2008, Mazak QTN-100MSY Year: 2008 X/Y/Z/B: 185/100/455/460 mm Max. turning diameter: 280 mm Bar capacity up to 51 mm diameter Main spindle Speed range: 6000 rpm Main drive power: 11 kW Max. torque: 184 Nm Spindle bore diameter: 61 mm C-axis spindle positioning: 0.001° Ncedpfjxn Svdjx Ad Nel Second spindle Speed range: 6000 rpm Drive power: 11 kW Max. torque: 89 Nm Indexing: 0.001° Tool turret Number of tool stations: 12 Driven tools Speed range: 4500 rpm Drive power: 5.5 kW Max. torque: 35 Nm Travel paths X-axis: 185 mm Y-axis: 100 (+/- 50) mm Z-axis: 455 mm W-axis: 460 mm Toolsetter Parts catcher Chip conveyor, right side Coolant pump Barfeeder interface

Condition: excellent (used), CNC lathe DMG CLX 450 V3, year 2018, Siemens, in very good condition. Nsdpfjx Hqh Sjx Ad Nscl

Condition: used, Year of construction: 1985, greates pass round over bed 810 mm swing diameter over face slide 560 mm centre distance 00 mm bed width 480 mm slide valve travel 400 mm upper head travel 180 mm turning tool - shaft cross cut 32 x 25 mm power capacity 22 kW max. torque on the spindle 30 Nm spindle head Gr. 11, DIN 55027 spindle diameter in front bearing 152,4 mm spindle bore 106 mm turning speed range 9 - 1800 U/min turning speeds 24 longitudinal feeds: 0,092 - mm/U face feeds 0,046 - mm/U metric threading 0,5-112 mm inch threading 1/4 - 56 G/1" thread - module mm thread - DP 1 - 224 Pitch tailstock quill diameter 115 mm quill stroke 225 mm taper of tail spindle MK 6 max. workpiece weight between centres 00 kg Nsdexn Ty Rjpfx Ad Necl max. workpiece weight -without tailstock 750 kg 3-jaw chuck Röhm, Ø Overall size ca. 4600x1900x1600 mm weight ca. 4300 kg Number of feed stages and threads: 99 Accessories: 3-axis digital display Mobile chip guard over the entire length (plexiglass) Coolant device Rapid traverse in Z and X axes Multifix steel holder size C with 6 interchangeable cassettes Bed stop with micrometer scale Fixed steady rest - 300 mm Taper sleeve for main spindle MK 6 Travelling center point (center point) MK 6 Bed guides in very good condition!

Condition: excellent (used), CATALOG NUMBER 7650 Technical Data: - Max working length: 1500mm - Max working diameter: 250mm - Milling (disc milling cutter): 7.5kW - Spindle – 2800rpm 3kW - Spindle speed: 700/1200/1500/2000rpm - Grinding unit: 0.75kW - Hydraulic motor: 3kW - Total power: 17.75kW - Air requirement: 6-8bar - Feeder for blanks up to 150x150mm - Extraction port diameter: 100mm, 160mm - Transport dimensions (L/W/H): 4350x2300x1980mm - Weight: approx. 3000kg ADVANTAGES – German-made – Automatic hydraulic copy system – Original DTR documentation – Unpainted Ncedpfx Aswk Hbpsd Nsl – Used lathe, in very good condition Net price: 69,900 PLN Net price: 16,640 EUR based on an exchange rate of 4.2 EUR (Prices may vary with significant exchange rate fluctuations)

Condition: like new (used), Year of construction: 2018, operating hours: 50 h, functionality: fully functional, Heavy Duty Elevating Crossrail Ram Type CNC Vertical Boring and Turning Machine with Hardened & Ground Box Guideways CAPACITY Maximum Turning Diameter - Ø 1,600mm Maximum Turning Height - 1,400mm Maximum Torque - 17,885 Nm Maximum Cutting Force - 3,000 kgf Maximum Workpiece Weight - 8,000 kg TABLE Table Diameter - Ø 1,250 mm Table Speed - 0.9 ~ 360 RPM Table Speed Range - Automatic 2 Step RAM HEAD Tool Size - 32 mm² Spindle Taper - ISO 7/24 #50 Ram Cross Section - 220mm² TRAVEL AND FEEDRATE X-Axis Travel (Saddle Horizontal) - 1,060mm Z-Axis Travel (Ram Vertical) - 900mm Vertical Travel of Cross Rail - 700mm Maximum X / Z-Axis Cutting Feedrate - 7,500mm / Min X / Z-Axis Rapid Feedrate - 7,500mm / Min Cross Rail Rapid Traverse - 300mm / Min ATC Type of Tool Holder - MAS BT 50 12 Tool Magazine Capacity Maximum Tool weight - 50kg MOTOR Table Motor (Cont. / 30 min) - AC 37.0 / 45.0 kW X / Z-Axis Servo Motor AC - 7.0 kW POWER SOURCE Input Power Supply - 415V / 50Hz / 3PH Power Capacity - 80 kVA DIMENSIONS AND WEIGHT Height - 5,290 mm External Width (With Chip Conveyor) - 6,760mm External Depth - 4,565m Weight - 25,800 kg STANDARD SUPPLIED MACHINE FEATURES Nsdsuu Rybjpfx Ad Nocl Fanuc 32i-A Control System Table, Servo Drives And Motors 4 Jaw Independent Chuck Automatic Tool Change System Lubrication Oil Cooler Hydraulic Power Unit Automatic Lubrication System For Guides Coolant System And Wash Gun Foundation Bolts And Nuts Tool Box Through Tool Coolant Operator And Programmer Manuals Splash Guard And Safety Guard Rail X-Axis Slideway Protect Steel Cover Work Light Patrol Lamp (Red, Yellow And Green) NC Power Off Chip Pan Levelling Blocks Electrical And Mechanical Manuals FANUC 32I CNC

Condition: like new (used), Year of construction: 2018, operating hours: 50 h, Heavy Duty Elevating Crossrail Ram Type CNC Vertical Boring and Turning Machine with Hardened & Ground Box Guideways CAPACITY Maximum Turning Diameter - Ø 1,600mm Maximum Turning Height - 1,400mm Maximum Torque - 17,885 Nm Maximum Cutting Force - 3,000 kgf Maximum Workpiece Weight - 8,000 kg TABLE Table Diameter - Ø 1,250 mm Table Speed - 0.9 ~ 360 RPM Table Speed Range - Automatic 2 Step RAM HEAD Tool Size - 32 mm² Spindle Taper - ISO 7/24 #50 Ram Cross Section - 220mm² TRAVEL AND FEEDRATE X-Axis Travel (Saddle Horizontal) - 1,060mm Z-Axis Travel (Ram Vertical) - 900mm Vertical Travel of Cross Rail - 700mm Maximum X / Z-Axis Cutting Feedrate - 7,500mm / Min X / Z-Axis Rapid Feedrate - 7,500mm / Min Cross Rail Rapid Traverse - 300mm / Min ATC Type of Tool Holder - MAS BT 50 12 Tool Magazine Capacity Maximum Tool weight - 50kg MOTOR Table Motor (Cont. / 30 min) - AC 37.0 / 45.0 kW X / Z-Axis Servo Motor AC - 7.0 kW POWER SOURCE Input Power Supply - 415V / 50Hz / 3PH Power Capacity - 80 kVA DIMENSIONS AND WEIGHT Height - 5,290 mm External Width (With Chip Conveyor) - 6,760mm External Depth - 4,565m Weight - 25,800 kg STANDARD SUPPLIED MACHINE FEATURES Fanuc 32i-A Control System Table, Servo Drives And Motors 4 Jaw Independent Chuck Automatic Tool Change System Lubrication Oil Cooler Hydraulic Power Unit Automatic Lubrication System For Guides Coolant System And Wash Gun Foundation Bolts And Nuts Tool Box Through Tool Coolant Operator And Programmer Manuals Splash Guard And Safety Guard Rail X-Axis Slideway Protect Steel Cover Work Light Patrol Lamp (Red, Yellow And Green) NC Power Off Chip Pan Levelling Blocks Nedpoguq Txjfx Ad Necl Electrical And Mechanical Manuals FANUC 32I CNC

Condition: good (used), Year of construction: 1988, 1 used lead and feed screw lathe Make: Weiler Model: 160 B Year of manufacture: 1988 Technical specifications Nedpsw Sdr Hsfx Ad Nocl Centre distance: 650 mm Swing over bed: 320 mm Swing over cross slide: 192 mm Centre height: 160 mm Spindle bore: 40 mm Rated power: 2.4 / 3 kW Spindle speeds: 48 – 2500 rpm Dimensions: approx. L 2.20 x W 1.10 x H 1.40 m Weight: approx. 1 t Equipment Heidenhain digital readout Multifix toolholder with various inserts 3-jaw chuck Emergency stop

Condition: good (used), Year of construction: 2007, Turning Length 3.500 mm Ncsdpfox Hvvusx Ad Nol Turning diameter 720 mm Some technical details are shown on photos.

Condition: excellent (used), Year of construction: 1999, functionality: fully functional, Weiler Praktikant VC Precision Centre Lathe Year of Construction 1999, 3-Axis Siemens Digital Display with AC Drive, Infinitely Variable Spindle Speed, CE Compliant!!!! Technical Data: Nodpfx Adeyapwds Necl - Year of manufacture: 1999, Machine No. 82 - Centre height: 160 mm - Distance between centres: 650 mm - Spindle speeds: up to 4000 rpm, infinitely variable - Spindle bore: 40 mm - Short taper spindle nose DIN 55027 size 5 with bayonet lock - Tailstock Morse Taper MK 3 - Feed rates: 0.02 to 0.63 mm/rev - Cutting threads: Metric, Inch, Module and Diametral Pitch - Metric thread pitches: 0.25 to 8 mm - Weight: approx. 920 kg - Spindle brake, switchable - Machine dimensions approx.: 1.4 m x 1.55 m x 0.95 m, length 1.6 m Accessories and Features: - 3-axis Siemens digital readout - Quick collet chucking device for collets from 2 to 29 mm, in 1 mm increments - 160 mm 3-jaw chuck with 2 sets of jaws - Multifix size A with 3 tool holders - Electronic chip guard - Change gears - Machine feet - Splash guard About the Machine: Offered for sale is a Weiler Praktikant VC lead and feedscrew lathe from year of manufacture 1999, in very good condition. The control system, in combination with the precision centre lathe from Weiler, provides the following functions: graphical display of travel distance and direction, graphical representation of the scale system on the lathe, compensation for tool offset, zero point shifting for workpiece position compensation, radius/diameter switching, graphical display of the main spindle rotation, graphical display of the machine’s speed potentiometer position. A very fine lathe featuring an AC drive with infinitely variable spindle speed. All slides move very smoothly and evenly. Even at high speeds, the Weiler runs quietly. This newer generation of Weiler lathes is very user-friendly and is capable of producing surface finishes comparable to grinding. The digital readout makes operation even easier and more precise. Take the opportunity to inspect the machine under power on site and convince yourself of its condition.

Condition: used, Year of construction: 2012, Technical details: turning diameter: 1800 mm turning length: 6000 mm control: 840 circulation diameter via slide valve: 1140 mm Shift of the planing slide: 680 mm bed width: 1350 mm spindle head: DIN 55027 Gr. 15 spindle diameter in front bearing: 240 mm spindle bore: 110 mm speeds:: 3,55-710 1/min diameter of quill: 220 mm quill stroke: 350 mm Nedpfxsyapp Hj Ad Njcl Maximum torque at the spindle: ca. 21000 Nm feed power Z: 35000 N Feed force X: 25000 N Rapid traverse X: 4 m/min Rapid traverse Z: 4 m/min total power requirement: 55/70 kW dimensions of the machine ca.: ohne Verkleidung 13000x4200x2400 mm weight of the machine ca.: 34000 t

Condition: excellent (used), Year of construction: 2024, DEMONSTRATION MACHINE For sale is a lightly used Drechselmeister Stratos FU 230 woodturning lathe with a center distance of 680 mm and a 2 HP motor. Njdpfx Adeyaphvo Njcl The demonstration machine is in very good condition. Technical Specifications - Center height: 230 mm - Swing diameter: 455 mm (up to 800 mm with optional outboard turning attachment!) - Center distance: approx. 680 mm (extendable!) - Spindle mount: M33 x 3.5 (hardened) with ASR (Euro) anti-release groove* - Spindle and tailstock taper: MT2 - Speed range (2 belt stages): 60 – 1,350 rpm and 180 – 3,750 rpm - Quill travel: 100 mm (with scale and trapezoidal thread) - Motor: 2 HP (connection 230 V) - Weight: 178 kg The machine is located in A-5431 Kuchl and can be viewed at any time during our business hours. Subject to prior sale! Related search terms: woodturning lathe, lathe, turning machine, turning bench, turning tools, woodturning, turning, machine Reference: R-A0117

Condition: excellent (used), Year of construction: 2024, DEMONSTRATION MACHINE For sale: a used Drechselmeister STRATOS XL woodturning lathe with a 3 HP motor! The demonstration machine is in very good condition. Technical data: Ncedpjyapc Hsfx Ad Njl - Center height: 280 mm - Swing over bed: 550 mm (up to 1,000 mm with optional bed extension / outboard turning device!) - Distance between centers: approx. 780 mm (expandable!) - Spindle thread: M33 x 3.5 with ASR (Euro) anti-rotation groove* - Headstock and tailstock with Morse taper MK2 - Frequency inverter (3 belt speeds): - Speed 1: 60 – 1,200 rpm - Speed 2: 100 – 2,200 rpm - Speed 3: 150 – 3,700 rpm - Quill travel: 150 mm (with scale) - Tailstock quill with trapezoidal thread and quick-change system (for ER25 drill quill) - Motor: 3 HP - Weight: approx. 320 kg The machine is located in A-5431 Kuchl and can be inspected at any time during our business hours. Subject to prior sale! Related terms: woodturning lathe, lathe, turning machine, wood lathe, woodturning, turning tools, spindle turning, turning, machine Reference: R-A0117

Condition: excellent (used), Year of construction: 2009, Hwacheon Cutex 160, Year 2009 CNC Control Fanuc OT i 12-station turret LNS bar feeder (max. bar diameter 42 mm) Tool package (including driven tool holders) Chip conveyor Tailstock Technical data: Swing diameter over bed: 550 mm Max. turning diameter: 300 mm Max. turning length: 300 mm X-axis travel: 170 mm Z-axis travel: 335 mm C-axis Max. bar capacity: 45 mm Spindle speed: 6000 rpm Turret: 12 stations Rapid traverse X: 36 m/min Rapid traverse Z: 36 m/min Drive power: 20 kW Nodpeyc Nrysfx Ad Nocl Machine weight approx.: 3200 kg

Condition: used, Year of construction: 2007, controller manufacturer: Siemens, controller model: 840 D, _____ Description: Year of manuf. : 2007 Control : Siemens 840 D Turning diam. : 250 mm Turning length : 650 mm Nsdpeyamflofx Ad Nscl In General: Year of construction:2007 Control:Siemens 840 D Bar capacity:65 mm Turning diameter:350 mm Turning length:650 mm Main spindle: Technology:Motor spindle Speed:5,000 rpm Power max.:35 kW Torque max.:370 Nm C-axis:0.001 Bar capacity:65 mm Chuck:Hainbuch Spanntop size 65 Clamping cylinder:Hollow clamping cylinder Sub spindle: Technology:Motor spindle Speed:5,000 rpm Power:26 kW Torque:290 Nm C-axis:0.001 Chuck:Hainbuch Spanntop size 65 Clamping cylinder:Partial hollow clamping cylinder Z-axis:670 mm X-axis:175 mm Tool carrier i (X/Y/Z): Technology:Tool turret, 12 stations Tool holder:VDI 30 Tool drive:4,000 rpm, 11 kW, 28 Nm X-axis:300 Y-axis:80 mm ( +/- 40 mm) Z-axis:650 mm Tool carrier II (X/Z): Technology:Tool turret, 12 stations Tool holder:VDI 30 Tool drive:4,000 rpm, 11 kW, 28 Nm X-axis:180 Z-axis:650 mm Equipment: Chip disposal:Chip conveyor Coolant supply:IKZ system Measuring systems:Direct in all X-axes (glass scales) Bar loader:IRCO Breuning Part removal:Finished part gripper + indexing belt Emulsion mist separator:Mechanical Set-up mode:Electronic handwheel

Year of construction: 1977, condition: used, turning diameter 700-1500 mm clamping length 3000 mm guage width 1676 mm Control weight of the machine ca. 60 t Nsdpfxjuddglo Ad Nocl Rafamet UBC 150 wheelset lathe for railway wheelsets Serial No.: 152 110 Year of manufacture: 1977 Machining range: Diameter from 700 mm to 1500 mm Gauge of the wheelsets to be machined in standard version: 1435mm track widths: 1435mm , 1524mm , 1676mm Length of wheelsets to be machined: 1640-3000mm Running diameter of the wheelset: 700-1500mm Driving diameter: 350-1350mm Width of the wheelset tyre: up to 140mm Fork dimensions of the wheelset lathe_ 8700x360x3250mm Total installed power: 172kW Weight of the machine: 59200kg Speed of the setting movement Lifting and centring device: 2500 mm/min. Headstocks: 1320 mm/min. Quills: 550mm/min. Supports in the longitudinal direction: 1300 mm/min.

Condition: used, Seriennummer: 0419 Nedpewm Rrdofx Ad Njcl
