Used Cnc Working Center for sale (56,918)

Condition: used, Year of construction: 1994, functionality: fully functional, machine/vehicle number: 35001032, turning length: 40,000 mm, turning diameter: 890 mm, spindle motor power: 69,000 W, spindle speed (min.): 1 rpm, spindle speed (max.): 1,800 rpm, spindle bore: 122 mm, travel distance X-axis: 500 mm, travel distance Y-axis: 260 mm, type of input current: three-phase, quill stroke: 140 mm, quill diameter: 120 mm, quill travel distance: 3,958 mm, spindle nose: A15, overall weight: 25,500 kg, spindle diameter: 200 mm, feed force X-axis: 10,000 N, feed force Z-axis: 22,000 N, distance between centers: 4,000 mm, Equipment: documentation/manual, For sale is a Heyligenstaedt Heynuflex turning and milling center, which is currently still in production. The machine is in operational condition and can be inspected under power and in operation until September 14, 2026. Machine type: Hn35U/4000 Flex Commission number: 35001032 Year of manufacture: 1994 Working area: - Turning length: 4000 mm - Swing diameter over bed: 890 mm Main drive: - Power at 100% duty cycle: 50 kW - Power at 50% duty cycle: 69 kW Main spindle: - Spindle diameter at the front bearing: 200 mm - Spindle bore: 120 mm - Spindle head shape: Shape A DIN55026 Gr15 - Speed range: - Gear stage 1: 1 – 540 rpm - Gear stage 2: 7 – 1800 rpm Feed: - Rapid traverse speed max.: 15 m/min - Planar feed: 0.5 - 5000 mm/min - Longitudinal feed: 0.5 - 5000 mm/min Tool carrier system: - Tool interface: Capto C8 - Linear travel range Y-axis: +/- 130 mm - Linear travel range X-axis: 980 mm - Tool magazine: 36 tools Tailstock: - Quill diameter/stroke: 125 mm / 140 mm - Axial force min/max: 16000/2500 N - Internal taper quill: MK 5 Control system: - Type: Siemens 880T Chodpszwb Dpefx Albeb If you are interested or would like to arrange a viewing appointment, please do not hesitate to contact us.

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, Technical details turning diameter 820 mm turning length 6000 mm control Siemens Si 840 D sl Csdpfx Ajzuygdslbshb max. workpiece weight between centres 4000 kg total power requirement 155 kW weight of the machine ca. 65 t dimensions of the machine ca. 16350 x 3700 x 3850 m Additional information Original purchase price in 2019: EUR 1.550.000,- Time recording from Feb. 2025 Operating hours = 38601 h Main spindle = 1958 h Milling spindle = 1760 h CNC control Si 840D sl Working area 6000 mm Working height 1390 mm Swing diameter over bed slide/bed 820 mm X-axis travel +850 -25 mm Z-axis travel 6820 mm C-axis, smallest increment +/-0.001° Workpiece spindle Spindle head according to DIN 55026 A15 Bathing through 160 mm Front diameter Bearing 240mm 2-stage gearbox, infinitely variable programmable Drive power at 100/60% duty cycle: 78/87kW Speed ranges: 2 Speed range I: 10-501 rpm Speed range II: 10-1750 rpm Torque I, 60% duty cycle: 8000 Nm Torque II, 60% duty cycle: 2308 Nm C-axis Holding torque with backlash-free spindle brake: 3000 Nm Speed: 0-50 rpm Maximum torque (100/60% duty cycle): 3700/4430 Nm Steady rest clamping range: 70-425 mm Turning, drilling, milling head Tool taper Capto C8 Tool magazine Storage locations: 2 magazines, Baluff chip system Max. tool diameter (each position/every 2nd position) 125/200mm Max. tool length 600mm Tool weight 25kg Tailstock Quick diameter 180mm Stroke 170mm Internal taper MK6 Axially force, manually adjustable 5-30 kN Quick tip height adjustment +/-0.15mm Other: Collision monitoring sensor ACS 3-ARTIS Chip conveyor system Coolant system 980l tank and more

Condition: used, Year of construction: 2005, turning diameter 170 mm Max. Turning length 120 mm bar capacity 52 mm control FANUC MSX-501 travel -x1 axis 140 mm travel -x2 axis 140 mm travel -z1 axis 450 mm travel -z2 axis 410 mm travel -y axis +/- 40 mm travel - b axis (spindle 2) 525 mm speeds station 1 60 - 6000 U/min spindle bore 1 62 mm speeds station 2 60 - 6000 U/min spindle bore 2 62 mm driven tools turning speeds 6.000 U/min Csdpszyvb Iefx Albshb CNC Turning- and Milling Center | ZT 1500 Y - 2005 equipped with 2 turrets for driven tools, Y-axis and bar loader. The machine is in a well-maintained condition. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: ZT1500Y | ZT-1500 Y | ZT 1500Y | ZT-1500-Y

Condition: used, functionality: fully functional, machine/vehicle number: 24423, turning length: 200 mm, turning diameter: 210 mm, spindle motor power: 11,185 W, spindle speed (min.): 40 rpm, spindle speed (max.): 4,000 rpm, spindle bore: 58 mm, travel distance X-axis: 178 mm, travel distance Z-axis: 203 mm, rapid traverse X-axis: 15 m/min, rapid traverse Z-axis: 15 m/min, type of input current: three-phase, feed length X-axis: 178 mm, feed length Z-axis: 203 mm, bar passage: 58 mm, total height: 1,800 mm, total length: 2,300 mm, chuck outer diameter: 203 mm, total width: 2,700 mm, bar diameter (max.): 58 mm, spindle nose: A2-6, overall weight: 8,000 kg, spindle diameter: 203 mm, working range: 200 mm, Equipment: rotational speed infinitely variable, Okuma & Howa ACT-2SP-2 CNC lathe with two parallel spindles, equipped with an Okuma OSP5020L numerical control system. The machine features two hydraulic self-centering chucks and two independent tool turrets, enabling the simultaneous machining of two workpieces. Chedpfozpd Alex Albsb Key features: Turning diameter: approximately 210 mm Turning length: approximately 200 mm Chuck diameter: approximately 203 mm Chuck bore: approximately 58 mm X-axis travel: approximately 178 mm Z-axis travel: approximately 203 mm Spindle speed: approximately 40–4,000 rpm Spindle power: approximately 11 kW per spindle CNC control: Okuma OSP5020L Serial number: 24423 Chip conveyor/extractor included The machine is complete with all its main components, currently not in operation and requiring functional testing. Sold as is. Loading onto the transport vehicle will be handled by the seller. Transportation costs remain the responsibility of the buyer. The machine can be inspected at our facility.

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, turning length: 1,000 mm, turning diameter over cross slide: 680 mm, turning diameter: 465 mm, spindle speed (max.): 3,500 rpm, spindle bore: 76 mm, travel distance X-axis: 300 mm, travel distance Z-axis: 1,050 mm, rotational speed (max.): 3,500 rpm, type of input current: three-phase, total height: 2,120 mm, total length: 4,865 mm, total width: 1,770 mm, spindle nose: FL 220 h5, overall weight: 7,500 kg, Equipment: documentation/manual, rotational speed infinitely variable, The Gildemeister CTX 510 is a rather heavy, industrial CNC turning machine. It is a machine that is particularly interesting if you want to machine a lot of material and are not just doing light turning operations. We acquired this machine in working condition from the first owner and it can also be inspected in working condition! Additional options & accessories: - Full pallet with static VDI-40 tool holders. - Chip conveyor - Marposs measuring arm - Collet chuck 173E (Quadro NC - Marquar) - Adapter sleeve for 185E collet chuck - Coolant gun - High-pressure coolant pump - Chip conveyor - Double foot pedal Chsdpfx Alozyai Nebob - Original Gildemeister documentation. Weight & dimensions: 7,500 kg 4865 x 1770 x 2120 mm (L x W x H incl. chip conveyor)

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, turning diameter: 145 mm, CNC turning machine Gildemeister Twin 42 Year of manufacture: 2004 Control system: Siemens 840D Powerline Turning diameter: 145 mm Max. bar diameter: 45 mm Spindle head: Flat flange 120 h5 Chuck: 130 / 140 mm Main spindle speed: 20–7,000 min⁻¹ Main spindle power: 28 / 22 kW (40/100 % duty cycle) Main spindle torque: 180 / 140 Nm Counter spindle: Yes, same power X-axis: 220 mm Z-axis: 320 mm Y-axis: ±30 mm Rapid traverse X/Y/Z: 30 / 15 / 30 m/min Turret: 2 × 12 stations Tool holder: VDI 25 Machine weight: approx. 5,300 kg Connected power: approx. 40 kVA Design: 60° inclined bed, linear guides Chip conveyor, Bürener type SPE 63/30-250 Z60 Codpozl Dvksfx Albjhb Tool monitoring system, Artis type CTM Tailstock mounted on counter spindle slide, tailstock stroke = 230 mm Tailstock force = 300 daN Center bore MK3 Overload clutch for the X and Z axes of slides 1 and 2 Package for bar machining consisting of: Workpiece extraction device Workpieces can be automatically unloaded from both the main and counter spindles Workpiece dimensions: Ø6 – Ø65 mm, length approx. 300 mm, max. weight 3.5 kg Collet chuck for quick-change tool holders, size 42 Hainbuch Spanntop Connection for bar feed Bar loader magazine, IRCO type SiMag 42

Condition: used, Year of construction: 1995, turning diameter 510 mm turning length 1000 mm control MAZATROL T PLUS total power requirement 22-26 kW weight of the machine ca. 6,5 t Csdpfxozyvcre Albehb

Condition: ready for operation (used), Year of construction: 2008, operating hours: 56,089 h, Swing diameter over bed/cross slide: 820mm/550mm, distance between centers: 2666mm, max. turning diameter: 610mm, max. workpiece length: 2500mm, travel X/Z: 410mm/2560mm, travel Y: -80mm/100mm, max. workpiece weight without/with tailstock: 500kg/1500kg, tool positions: 12, rapid traverse X/Z/Y: 24m/30m/12m/min, feed force X/Z/Y: 17kN/20kN/17kN. Machine dimensions X/Y/Z: approx. 5500mm/2250mm/2550mm, weight: approx. 15000kg, operating hours: approx. 56089. Documentation available. An on-site inspection is possible. Expected to be available from mid-2026. Csdpfx Ajw Dfhuelbjhb

Condition: good (used), Year of construction: 2017, Standard turning diameter 150mm, Cedpfx Aozwm Hpjlbehb maximum cutting diameter 255mm, maximum cutting length 685mm , Bar capacity main spindle 51mm, spindle speed 5,000rpm, sub-spindle 5,000 rpm, C axis 0.001 degrees, 3 x turrets 24 stations, Y axis +/-45mm, milling speeds 6,000 rpm, main spindle 15kw, Fanuc 31i, swarf conveyor, barfeed unit, parts catcher

Condition: excellent (used), Year of construction: 2007, CNC Lathe GILDEMEISTER CTX 420 Linear 2007 Siemens 840 D Technical specifications: Chsdew Slfbepfx Albjb * Turning length: 600 mm * Turning diameter: 680 mm * Spindle bore: 79 mm * Spindle speed: 5000 rpm * Spindle power: 25 kW * Chip conveyor: Yes * Variable spindle speed: 5000 rpm Main spindle with bar capacity: Ø 65 mm Self-centering Autoblock chuck: Ø 250 mm

Condition: excellent (used), Year of construction: 2014, CNC turning and milling center Okuma Multus U4000 1SC 1500 BigBore Control: OSP-P 300S Year of manufacture: 2014 Internal machine number: 35 X-axis: 695 mm Y-axis with travel: +150/ -150 = 300 mm Z-axis: 1,600 mm Chedpfoyk Ddgjx Albob B-axis: 240°, positioning in 0.001° C-axis: 360°, positioning in 0.001° Turning diameter: 650 mm Turning length: 1,500 mm Tool holder: Capto C6 Total number of tool positions: 80 Accessories: NC tailstock Adjustable hydraulic steady rest AX 5 on NC axis Coolant system with strip filter Hydraulic 3-jaw chuck Kitagawa BB 212-11 Automatic touch probe High-pressure coolant IKZ Software option High Cut Pro (High-precision package with Super Nurbs) CAS collision protection system Spindle orientation, main spindle, electric Multitool including turning function for Y-axis Helix function Automatic main power cut-off DNC-DT interface Machining Navi M-i (milling), speed control for minimizing vibrations. One-Touch IGF Chip conveyor

Condition: excellent (used), Year of construction: 1995, Maximum center height: 330 mm Maximum distance between centers: 2000 mm Working area: Max. turning diameter over bed cover: 650 mm Max. turning diameter over cross slide: 360 mm Main spindle: Spindle diameter at front bearing: 140 mm Spindle bore: 107 mm Main drive: 58.5 kW 2-stage speed range: 4 – 750 rpm / 750 – 3060 rpm Feed drive: Rapid traverse rate X/Z axis: 10/10 m/min Turret: Number of tool positions: 12 Chsdpfx Alex Sx Htjbsb Of which, driven tool positions: 6 Cylindrical shank tool holder: VDI 50 mm Dimensions / Weight: Footprint L x W x H: approx. 6400 x 2150 x 2000 mm Weight: 9400 kg Accessories / Special features: • CNC control system HEIDENHAIN TurnPlus EP 90 with color screen • Spindle orientation C-axis • 12-position turret, VDI 50, of which 6 positions with driven tools, manufacturer SAUTER DIN 5482 B 20x17, max. speed 3000 rpm. • Hydraulic 3-jaw chuck Ø 315 mm with various clamping jaws • Hydraulic steady rest with follower device • Hydraulic quill actuation • Air extraction system, manufacturer LTA • Various tool holders VDI 50 • CE compliant In 08/2025, GILDEMEISTER Service replaced the following parts: 1 servo motor, 1 AC servocontroller inverter power module for 2 axes, 1 power module Simodrive, 1 rectifier/inverter module, 1 control unit for 1 axis, 1 control module for 2 axes inverter servo drive, 1 Simodrive power module (1-axis motor) Total repair costs: 17,000.00 EUR net Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: good (used), Year of construction: 1998, functionality: unexamined, Angelini DG 13 Control system: Fanuc OT/C Year of manufacture: 1998 Spindle speed: 3,000 rpm Chip conveyor Tool turret: 12 positions, with driven tools VDI40 Documentation and export are available for an additional charge. Chedpfxszhikrj Albjb Inspection possible while the machine is running. We will gladly send you further details or arrange an on-site inspection.

Condition: used, operating hours: 11,655 h, functionality: fully functional, spindle bore: 65 mm, overall weight: 8,500 kg, spindle diameter: 65 mm, Well-maintained WT150 lathe, including an LNS Quick Load bar loader, fixed chucks, powered chucks, and Hainbuch collets. Chsdpozylw Ejfx Albob

Condition: used, Year of construction: 2018, turning diameter max. 356 mm turning length 705 mm control M730 UM Mapps CELOS greates pass round over bed 920 mm Swing dia. over traverse guideway 742 mm Codpfsvy Ig Hjx Albshb turning speed range - main spindle 4.000 min/-1 power capacity - main spindel 18,5 / 15 kW spindle nose JIS A2-8 spindle bore 80 (91) mm C-Axis 0,001 ° Spindle speed range subspindle 6.000 min/-1 power capacity - Sub spindle 11 / 7,5 kW spindle bore 43 mm C-Axis 0,001 ° x-travel 260 mm z-travel 795 mm Y - Axis +/-50 mm rapid traverse ( X / Y / Z ) 30 / 10 / 30 m/min number of toolpositions 12 pos. Schank height for square tool 25 mm Drill shank diameter 50 mm turret change time 0,27 sec. Spindle speed - driven tools max. 10.000 min -1 power capacity - driven tools 5,5 / 4,2 kW total power requirement 41 kVA weight of the machine ca. 6,4 t dimensions of the machine ca. 5,0 x 3,0 x 2,3 m CNC - Turning- and MillingCenter DMG MORI - NLX 2500 SY / 700 - Subspindle - Tool-Drive - C, Y-Axis - approx. 12,000 operating hours

Condition: used, Year of construction: 2007, Technical details: standard turning dia.: 42 / 140 turning length: 170 mm control: Mitsubishi max. turning diameter: 140 mm bar material dia.: 42 mm turning speed range - spindle: 80-8000 1/min spindle bearing diameter: 120 mm C-Axis: 0,001 ° turning speed range - spindle: 60-6000 1/min spindle nose: JIS A2-6 bar material dia. max: 42 mm collet chuck: 173E C-Axis: 0,001 ° Number of Turrets: 2 . Number of tool stations: 12 x 2=24 pos power capacity - driven tools: 7,5 / 5,5 kW total power requirement: 92,7 kVA weight of the machine ca.: 3,3 t dimensions of the machine ca.: 2,4 x 1,6 x 2,2 m Accerories Chip conveyor Coolantsystem The Boley BE 42 2 has 2 spindles und 2 turrets with 12 toolstations VDI 20 each. It can work simultaneus with 7 Achsen. The machine has ca. 22.000 run hrs. The coolant system has a cooling unit 15 collets 173E come with the machine. Chsdpfx Aszxh R Eelbsb A bar feeder interface is installed. *

Year of construction: 2014, condition: used, Empty weight: 4 kg Length: 78 cm Serial number: 22220 V251403 5-axis machining center comprising: - a NAKAMURA lathe, TYPE: NTMX, year: 2014, 5-axis dual-spindle + milling head. - a SAMSYS+ bar feeder, Model: M3000, year: 2014 - an LNS YOSHIDA chip conveyor Technical specifications: - capacity: - max turning diameter: 200 mm - Max turning length: 780 mm - Distance between centers: max 980 mm / min 210 mm - Bar capacity: 51 mm on both left and right - Chuck size: 165 or 210 mm - Axis travel: - X1/X2 slide travel: 570 mm / 130.5 mm - Z1/Z2/B2 slide travel: 1,297/658/770 mm - Y-axis travel: ±100 - Left/right spindle: - Speed: 5,000 rpm - Tool spindle: - Speed: 12,000 rpm - Tool type: CAPTO C4 - Number of tools in magazine: 24 - Max. tool diameter: 60 mm Chjdpfx Ajzvccdolbjb - Max. tool length: 180 mm - Max. tool weight: 4 kg - Indexing range: 190° - Turret: - Type: 12-sided drum turret - Number of indexing positions: 24 - Square tool size: 20 mm - Round tool size: 20 mm diameter - Spindle speed: 6,000 min⁻¹ - Floor dimensions: L 4,225 mm x W 3,015 mm x H 2,650 mm - Approximate machine weight: 14,500 kg Hours on the counter: approximately 3,622 h Sold with 1 cabinet and 2 workbenches, including contents Online auction held following the closure of the "Supadis" production facility in Le Plessis-Pâté (91), a company specializing in precision machining. This sale includes more than 100 lots, notably several 3-, 4-, and 5-axis CNC machining centers from “Matsuura,” “OKK,” “Biglia,” and “Nakamura Tome,” as well as a “Kasto Functional A” automatic saw. The lot also includes grinding machines, a “Cincinnati” column drill press, “Trimos” and “Mitutoyo” measuring columns, as well as numerous tools, workbenches, and inspection equipment. The sale also includes stocks of raw materials (steel, aluminum, titanium, “Inconel,” “PEEK,” copper, etc.), workshop equipment, compressors, shelving, and various material-handling equipment. Sale organized by Dome Auctions France, OVV No. 331-2026, auctioneer Blandine Camper. The online auction opens Tuesday 18 August and closes Thursday 24 September. Register your account via our website and place your bid. For viewings and inspections check the auction information on the website. Viewing day is on: - Tuesday 22 September Dome Auctions is an innovative auction platform dedicated exclusively to the industrial sector. By focusing on machinery sales from business closures, restructurings, and bankruptcies, we provide a trusted marketplace where buyers and sellers connect with confidence. Unlike general auction houses, Dome Auctions specializes in selling complete industrial assets directly from factories, ensuring quality and reliability. With a commitment to transparency, industry expertise, and tailored service, we streamline the sales process and maximize value for all parties. As online...

Condition: good (used), Year of construction: 1999, - Control system: Heidenhain CNC Pilot 3190/4290 - Turn-Plus software update Chsdpfx Aezggahelbsb - Turning diameter: 500 mm - Turning length: max. 635 mm - Spindle speed: 25-5000 rpm - 12-station turret, no driven tools - Tool holder VDI 30 - Tailstock - Chip conveyor

Condition: good (used), CMZ brand CNC lathe, TX66 Y2 Quattro model, year 2012, with powered tooling on both turrets, Y-axis... Cjdpfxjzcu Hij Albjhb

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, Technical details turning diameter 400 mm turning length - mm control DMG Mori SLIMline z-axis ca. 750–755 mm x-axis 276 mm y-axis +/-60 mm greates pass round over bed 700 mm Additional information The machine is in very good condition and has recently been inspected and measured by a service technician. The lathe was primarily used to manufacture turned plastic parts. CNC lathe with driven tools, C-axis, Y-axis, and counter-spindle CNC control: DMG Mori SLIMline multi-touch control (19"/Operate 4.7 on Siemens) Screen language: German/English Main spindle: A2-8 with AC motor Drive power 25.5/17 kW (100/40% duty cycle) Spindle speed 4000 rpm Hollow clamping system, max. bar capacity 80 mm Counter-spindle: A2-6 designed as a built-in motor spindle ISM 52 with hydraulic clamping device Drive power 14/13 kW (100/40% duty cycle) Spindle speed 5000 rpm 12-station servo tool turret: VDI 40 mount with 12 driven tool stations Equipment: Y-axis +/- 60 mm Direct position measuring system (X and Y axes) Bar package & interface IEMCA KID80/16 short bar loader, bar capacity 80 mm Differential pressure clamping for main spindle Chuck flushing for main spindle Reduction tube for main spindle Hainbuch SPANNTOP nova Combi G80 Axzug collet chuck Cjdpfezu Nxpsx Albshb Differential pressure clamping for counter-spindle Chuck flushing for counter-spindle Automatic workpiece ejector Counter-spindle with internal coolant supply for workholding flushing SMW BB-D210 hydraulic 3-jaw chuck for counter-spindle SMW BB-D250 hydraulic 3-jaw chuck High-pressure pump 12 bar Coolant spray gun bar Dual cartridge filter for coolant, filtration fineness 60 µm Manual tool measuring device in the workspace, Marposs make Tool monitoring system, Easy Tool Monitor 1.0 technology cycle Alternating Speed ??technology cycle 3D data model in STEP format DMG MORI Messenger V2 DMG MORI Netservice – client Finished part discharge conveyor Chip conveyor with right-hand discharge External electronic handwheel Tool holder package

Condition: excellent (used), Year of construction: 2013, MAIN INFORMATION Capacity and Working Area • Model: Mazak Quick Turn Smart 200 • Control: Mazatrol Smart • Year: 2013 • Serial No.: 249187 • Accumulated operating time: 11,755 hours • Cutting time: 1,561 hours • Network: LAN connection • Condition: The machine is in very good technical condition, clean, precise, and very well maintained. • Max. swing diameter: 530 mm • Max. swing over cross slide: 343 mm • Bar capacity: 65 mm • Spindle bore: 76 mm • Axis travels: X-axis: 195 mm Z-axis: 560 mm • Rapid traverse: X-axis: 30,000 mm/min Z-axis: 33,000 mm/min Spindle and Tooling • Spindle speed: 5,000 rpm • Spindle power: 15 kW Cjdezwhc Eepfx Albshb • Selectable threading start position • Through-tool coolant • Tool turret: 12 positions Indexing time: 0.17 sec / 1 step • Tailstock: MT5 Auto • Tool measuring arm: Yes • Parts catcher: Yes • Robot interface: Additional M-function (1 pair) • Smartshift BASE quick coupling: Yes • Chuck: SMW AUTOBLOK collet chuck Automation and Additional Equipment Integrated Automation Solution with UR5e • Model: Universal Robots UR5e (demo use only) • Type: Collaborative robot (cobot) • Year: 2021/01 • Condition: Fully integrated and operational with the Mazak Smart 200 • Payload: 5 kg • Reach: 850 mm • Repeatability: ±0.03 mm • Working envelope: 2.6 m³ • Max. TCP speed: 1,000 mm/s • Joint speed: 180°/s • Robot weight: 21 kg • Mounting: Floor, ceiling, wall, or inclined • Power supply: 100–240 V AC, approx. 200 W • Controller: UR control box (e-Series) • Programming: URScript + graphical block programming • Safety: ISO 10218-1, ISO/TS 15066, PLd Cat. 3 • Fieldbus: PROFINET, EtherNet/IP, Modbus TCP • Digital I/O: 16 inputs / 16 outputs • Analog I/O: 2 inputs / 2 outputs • Tool flange: ISO 9409-1-50-4-M6 Integration with Smart 200 • Smartshift BASE quick coupling • Additional M-function (robot interface) • Pre-programmed sequences • Quick changeover between manual and robot operation • Video available showing the robot and machine in operation • Fully tested and used in production Condition Description • The machine is fully operational and functions as it should. • No alarms or critical faults. • Smooth movement on all axes. • Spindle runs smoothly without vibration. • Linear guides and ball screws are in good condition. • Hydraulic and pneumatic systems operate normally. • Regular in-house servicing. • Lubrication system OK. • The machine has been used for light production (aluminium/plastic). • Robot and machine are fully integrated and tested.

Condition: ready for operation (used), Year of construction: 2004, operating hours: 11,298 h, functionality: fully functional, machine/vehicle number: 665001, travel distance X-axis: 700 mm, travel distance Y-axis: 550 mm, travel distance Z-axis: 450 mm, workpiece weight (max.): 2,000 kg, spindle speed (max.): 42,000 rpm, number of slots in tool magazine: 40, No minimum price – guaranteed sale to the highest bidder! Submitting a bid obligates you to collect the item within the period of September 21st to October 1st! TECHNICAL DETAILS Travel in X-axis: 700 mm Travel in Y-axis: 550 mm Travel in Z-axis: 450 mm Feed Axes Max. travel speed X, Y, and Z axes: 30 m/min Max. acceleration X, Y, and Z axes: 15 m/s² Positional accuracy TP according to DIN ISO 230-2: 0.005 mm Repeatability: 0.002 mm Work Table Table length: 850 mm Table width: 700 mm Number of T-slots: 5 T-slot dimensions: 18 H12 Table load: 2,000 kg Max. workpiece weight: 2,000 kg Distance spindle center – table: 550 mm Spindle Spindle mount: HSK-E 40 Spindle speed: 3,000 - 42,000 rpm Spindle power: 17 kW Tool Changer Tool magazine positions: 40 MACHINE DETAILS Machine type: CNC HSC machining center CNC control: Andronic Electrical Connection Data Supply voltage: 400 V Supply frequency: 50 Hz Fuse rating: 32 A (?) Dimensions and Weight Overall length: 3,300 mm Overall width: 2,300 mm Chedpfx Alozqupxjbsb Overall height: 2,300 mm Overall weight: 7,700 kg Operating Data Machine operating time: 275 d 5 h 13 min 39 s Spindle operating time: 11,297 h 20 min 11 s EQUIPMENT - Full enclosure - Dust and fluid-proof guides - Oil mist extraction - Compressor cooler - Frequency inverter - Heidenhain glass scales in X, Y, and Z axes - Work light in the interior - Technical documentation - Workbench - HSK-E-40 tool holders - Tools - Workbench dimensions: approx. 1,500 × 900 × 1,100 mm External Reference: Demo - Lot 2

Condition: used, Year of construction: 2003, - Workpiece length: 800 - 3000 mm - Workpiece width: 350 - 1400 mm - Workpiece thickness: max. 70 mm with edge / max. 80 mm for milling - Main spindle 12 kW - Tool changer, 18-position CNC machining center Manufacturer: Homag Type: PROFI BAZ20/30/16/V/D Year of manufacture: 2003 Technical data Homatic - CNC control CNC programming system WOODWOP Postprocessor Workpiece dimensions - Workpiece length: 800 - 3000 mm - Workpiece width: 350 - 1400 mm - Workpiece thickness: max. 70 mm with edge / max. 80 mm for milling - Edge band width: min. 120 mm - Weight: max. 150 kg Throughfeed table - Longitudinal console 1, fixed installation - Longitudinal console 2, manually adjustable via width adjustment in the Y-direction - 8 vacuum clamps 125 x 50 x 100 mm - Working height, bottom edge of workpiece: 950 mm Motor, width adjustment, longitudinal console, traversing table - For different workpiece widths via servo drive for throughfeed table - Per longitudinal console Chip conveyor - Chip and waste disposal via integrated chip conveyor under the longitudinal traverse Stop pins for top layer overhang - Stop pins with lifting-rotating mechanism for workpieces with max. 20 mm top layer overhang - Individually selectable, end position monitored, stroke 110 mm Chedpfx Aljzux Tpobeb - For manual placement of doors Vacuum pump 100/140 m3/h Unit for positioning the vacuum clamps - Mounted on the unit carrier with pneumatic extension console - For max. 4 vacuum clamps per longitudinal console Main spindle 12 kW - Tool holder HSK F63 - Extraction system for all tools and units - Three-phase asynchronous motor 12 kW at S1, water-cooled - Tool weight: max 6 kg incl. holder - Tool length: max. 200 mm from the motor spindle bottom edge - Tool diameter: max. 180 mm for milling tools / max 200 mm for sanding tools - Frequency converter: 15 kW - Speed range: 1500 - 18000 rpm, stepless, programmable - Full rated power from 12000 rpm Unit interface for the main spindle - For connecting the machining units - Pneumatic and swivel drive interface - C-axis with torque transmission and 3-point support Tool changer, 18-position For tools and units with HSK F63 Tool weight: 6 kg Tool length: max. 200 mm from the motor spindle bottom edge The following tool and unit configurations are possible - 18 x max. 130 mm - 9 x max. 180 mm and 9 x max. 70 mm - Tool diameter max. 200 mm for sanding tools - Tool changer can be raised for a moving pick-up station on the left side Drilling/milling unit, 4 spindles, for tool changer - For automatic changing in the main spindle - Collet holder ER25 up to max. 16 mm shank diameter - Tool protrusion max. 50 mm - Speed: max. 13500 rpm - Standard collet 10 mm - Infinitely swiveling via the C-axis - Without tool Lock case milling unit, 2 spindles, D=16/20 - With integrated blow-out nozzle - Two-sided spindle outlet with counter-rotating direction - Speed: 12000 rpm - Infinitely swiveling via the C-axis - Without tool 1x Weldon chuck: 20 mm - Reducing sleeve for tool 16 mm - Total tool length: 180 mm - Tool protrusion: max. 135 mm 1x ER16 collet with 10 mm - Total tool length: max. 70 mm - Tool protrusion: max. 40 mm Sawing/drilling unit, swiveling, for tool changer - For miter cuts and angled drilling - Manually swiveling 0 - 90 degrees - Mounting flange 30 mm with countersunk head screws - Tool diameter 52 mm - Prepared for miter saw: max. 180 mm - Drill chuck with Weldon chuck: D=10 mm - Speed: max. 9000 rpm - Infinitely swiveling via the C-axis -

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 34, spindle bore: 86 mm, overall weight: 16,000 kg, Turning and milling center acquired through business takeover Manufacturer: Mori Seiki / Model: MT 250S / 1500 / Year of manufacture: 2000 / Refurbishment for 200,000 euros Condition: good, Control: CNC Mori Seiki MSC 501 Technical data: See attached PDF Max. turning diameter: 570 mm Turning length: 1530 mm Max. swivel diameter: 800 mm Swivel diameter over cross slide: 420 - 860 mm Spindle distance: 1,828 mm Main spindle: Speed range: 35 - 3500 min.-1 Main spindle power: 18.5 kW / 15 kW Number of curve speeds: 2 Spindle nose: JIS A2-8 Max. bar capacity: 73 mm Spindle bore: 86 mm Spindle bearing diameter: 130 mm C-axis: 0.001° Counter spindle: Counter spindle speeds: 50 - 3500 min.-1 Counter spindle power: 11 / 7.5 kW Number of curve speeds: 2 Spindle nose: JIS A2-6 Max. bar capacity: 60 mm Spindle bore: 73 mm Spindle bearing diameter: 110 mm C-axis: 0.001° Milling spindle: Spindle speeds: 8000 min.-1 Power: 7.5 kW / 5.5 kW Tool taper: KM 63 Spindle bearing diameter: 80 mm B-axis: 120° / 105° Resolution: B 0.001° Number of tools: 42 Tool taper: KM 63 Cedezxg Suepfx Albjhb Max. tool diameter: 80 / 125 mm Max. tool length: 400 mm Max. tool weight: 8 kg Tool change time: 1.6 sec. X-axis: 635 mm / Y-axis: + / - 110 mm / Z-axis: 1595 mm / B-axis: 120° / 105° + Chuck: Rapid traverse (X/Y/Z): 24 / 24 / 30 m/min. Max. feed rate: 30,000 mm/min. / Total power: 72.3 kW / Weight: 22 tons / Dimensions: 7.0 x 3.5 x 3.5 m, steady rest

Condition: excellent (used), Year of construction: 1995, functionality: fully functional, Equipment: documentation/manual, CNC-controlled vertical machining center AXA VSC-3-3000-M Year of manufacture: 1995 Control system: Heidenhain TNC 407 Technical data: X-axis travel: 3000 mm Y-axis travel: 420 mm Z-axis travel: 480 mm Codpfx Aley U Hy Tjbehb Table size: approx. 3000 x 500 mm Spindle connection: SK40 Speed range: up to 6000 rpm 22-tool automatic tool changer Coolant system Heavy-duty frame construction Special features: Additional angular/universal milling head 4-/5-axis machining possible Flexible machining of complex workpieces Ideal for toolmaking, mechanical engineering and single-part production The machine is in good condition. Inspection under power is possible by arrangement.
