Used Cnc Turn Mill Center for sale (24,129)

Condition: good (used), Year of construction: 2008, functionality: fully functional, Technical details turning diameter 800 mm turning length 1500 mm control Siemens 840 D swing over bed 1000 mm swing diameter over slide rest 800 mm max. workpiece weight between centres 2000 kg main spindle speeds: 2000 U/min main drive 62 kW transmission ratio 4 milling spindle drive 37 kW milling spindle turning speed range: 25 - 10000 U/min total power requirement 82 kVA weight of the machine ca. 28 t dimensions of the machine ca. 8,2 x 5,3 x 3,6 m Additional information UniCen Series – for large complex components With the Monforts machine tools from the UniCen Series 1000 you can work with large, complex components up to 1500 mm diameter and 1000 mm swing diameter entirely, process capably and cost effectively in one set-up. Great flexibility results from the five interpolating axis. The B axis swivelling drill-mill head with a swivel range of 190 deg. directs the tools to the workpiece in almost every position and every angle. Additionally, the tool head can be loaded fully automatically by 60 tools from a separate chain magazine. Thus, even complex freeform surfaces with high surface finish quality are possible. Advantages > Wear free Monforts Hydrostatic > Optimal vibration damping > Long-term accuracy > Long life and highest machining performance > Complex five axis machining via the B axis swivelling drill-mill head > Turning, drilling, milling and thread-cutting on one machine > Precision ball-screw with preloaded double nut Extensive partial overhaul since November 2023: - All ball screws including bearings overhauled: X1/X2/Y1/Z1/Z2 - All cylinders overhauled - All Siemens motors overhauled: main spindle, tailstock, magazine, tool 1+2, X/Z/Y/B/C/U/W - Siemens control panel replaced, control module and LT module repaired - Clamping elements/ATC renewed: Ortlieb collet, clamping package incl. pull rod - Tailstock quill renewed - All wipers replaced and covers reworked - Drive belts and safety windows renewed - Various cables renewed * CNC Control SIEMENS 840 D * Swivelling milling head at the top (B axis), interpolating, HSK-A 63 * Y axis * C axis * 8-station turret at the bottom, for driven tools * 60-station tool changer * NC-controlled tailstock, quill diameter 150 mm, max. quill stroke 180 mm Fsdpfjx D U Hwex Ag Depr * Hydrostatic longitudinal guide in the Z-axis * Coolant system with paper belt filter * Chip conveyor * Oil-cooler, make SCHIMPKE * Extraction system * Power chuck, make FORKARDT, diameter 500 mm

Condition: like new (used), Year of construction: 2022, operating hours: 800 h, functionality: fully functional, turning length: 610 mm, turning diameter over cross slide: 500 mm, turning diameter: 725 mm, spindle speed (max.): 5,000 rpm, spindle bore: 65 mm, travel distance X-axis: 260 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 610 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 15 m/min, rapid traverse Z-axis: 30 m/min, feed length X-axis: 260 mm, feed length Y-axis: 80 mm, feed length Z-axis: 610 mm, torque: 250 Nm, bar passage: 65 mm, Equipment: documentation/manual, rotational speed infinitely variable, For sale: As-new EMCO MAXXTURN 65-G2 SMY (Year 2022) featuring Siemens Sinumerik ONE with ShopTurn control! CNC turning center for complete machining of turned/milled parts. Equipped with integrated spindle motors, water-cooled counter-spindle (preloaded roller guides), and Y-axis for both main and sub-spindle operations. Latest control technology: SINUMERIK ONE with ShopTurn conversational programming. Main spindle: - Max. bar capacity: 65 mm - Max. torque: 250 Nm - Speed range: 0-5,000 rpm Counter-spindle: - Power output: 22 kW - Max. torque: 130 Nm - Speed range: 0-7,000 rpm Tool turret: - 12-station VDI 30 radial turret with directional logic for up to 12 driven tool holders - Max. drive power: 6.7 kW - Max. torque: 25 Nm - Max. speed: 5,000 rpm Y-axis: - Travel: +/- 40 mm Additional features: - Hollow clamping cylinder incl. drawtube - C-axis for main/counter spindle - Sinumerik ONE / OPERATE control - 22" multi-touch display - SHOPTURN - 3D simulation - Residual material detection - USB interface - Electrical cabinet air conditioning - Coolant system incl. coolant pump (3.5 bar) - Chuck flushing (additional pump 3.5 bar) - Parts ejector and flushing via the counter spindle - Hydraulic unit - Interface for chip conveyor - Full documentation and CE certificate Control languages: German/English Electronic handwheel EMCO TOOL BREAKAGE AND WEAR MONITORING/SINUMERIK ONE Alternating spindle speed Counter spindle as tailstock: This cycle allows the use of the sub-spindle with a live center for supporting workpieces, enabling shaft machining even on machines without a tailstock. Maximum contact force limited to 50% of axis force. Fodpfxjx E Dncj Ag Depr EMCO PROFI-NET ROBOT INTERFACE Interface for adding robots (HARTING connector; signal exchange via Profinet; safety signals 2-channel/potential-free). Digitization package for Sinumerik: - Condition monitoring - SIEMENS ONE INTERFACE for connecting to MDE/BDE systems Included standard information: • Machine ON/AUX ON • Automatic mode • Production mode – program active • Program running and override between 95–105% • Piece count pulse (M30) • Programmable pulse (M300) 3D MACHINE DATA / MT65-G2 - 3D data model of the machine - Pneumatically operated finished part catcher for gentle unloading; finished parts can be transported to a collection box (standard) or conveyor belt (option) - Max. finished part length: 175 mm - Max. finished part diameter: 65 mm - Max. finished part weight: 4.5 kg INTERFACE SL1200 HT65-DT/TT + MT65-1000 - For connecting the EMCO SL1200 short bar feeder. ...and more. The machine is immediately available!

Condition: good (used), Year of construction: 2019, functionality: fully functional, HYPERTURN 65-1300 (SM2Y2) DUOTURN with 2 turrets including milling drive and 2 Y-axes High-productivity CNC turning/milling center for complete machining of turned and milled parts with 1300 mm spindle distance Integrated spindle motors (ISM) on the main and sub-spindle (liquid-cooled), preloaded roller guides. Drive power: Main spindle – 29 kW, Sub-spindle – 29 kW Speed range: Main spindle: 0 - 5000 rpm Sub-spindle: 0 - 5000 rpm Spindle interface (DIN 55026): Main spindle: KK 6 (Max. bar capacity ø 77 mm) Sub-spindle: KK 6 Y-axis on both turret slides: • Travel range: +/- 50 mm Includes: • Hollow clamping cylinder incl. draw tube • Parts ejector and flushing through the sub-spindle • Sinumerik 840D-sl/OPERATE control system o emcoNNECT/app-based user interface o 22" multi-touch display o IPC with 240 GB o SHOPTURN dialog programming o USB interface o Network drive/Ethernet o 3D simulation and more • 2x 12-position BMT tool turrets, mounted radially with direction logic for up to 2x 12 driven tool stations! Swing speed adjustable with feed override switch. o Performance data: Fpedpfex Auyzsx Ag Djr o Max. 6.7 kW at 2650 rpm o Constant torque: 25 Nm o Speed range: 0-5000 rpm o C-axis for main and sub-spindle o TRANSMIT software for easy C-axis programming • Chip conveyor Chip conveyor 2 pcs. high-pressure pumps with 14 bar 2 pcs. coolant pumps with 3.7 bar • Control cabinet cooling unit • Hydraulic power pack • Machine light • 230 V socket at control panel • 5 pcs. leveling elements • Documentation MT65/HT65 BigBore77-LEFT Bar capacity 3 inches (ø76.2 mm) instead of ø65 mm (main spindle). Draw tube connection: M85 x 2 Spindle interface (DIN 55026): A2-8 Max. speed: 4000 rpm Max. torque: 250 Nm Max. power: 29 kW Max. chuck size: ø250 mm MT65/HT65 BigBore77-RIGHT Instead of the 65 mm sub-spindle, the 76 mm sub-spindle with spindle interface KK8 incl. parts ejector is installed. Draw tube connection: M85 x 2 Spindle interface (DIN 55026): KK8 Max. speed: 4000 rpm Max. torque: 250 Nm Max. power: 29 kW Max. chuck size: ø250 mm BMT turret (top right) with direct drive for HT65DT/HT65TT/MT65 The VDI30 standard turret is replaced by a BMT turret with BMT55P precision interface. Max. speed: 12000 rpm Max. drive power: 10 kW BMT turret (bottom) with direct drive for HT65-DT/-TT/HT65PM The VDI30 standard turret is replaced by a BMT turret with BMT55P precision interface. Max. speed: 12000 rpm Max. drive power: 10 kW Available immediately

Condition: excellent (used), Year of construction: 1989, I am selling a CNC lathe Mazak QuickTurn 20N. Lathe in bdb condition. Equipment: MAZATROL T-2, control MAZATROL CAM-T-2. Fsdpfxju U R E Ao Ag Depr

Condition: ready for operation (used), Year of construction: 1985, functionality: fully functional, machine/vehicle number: 31201, travel distance X-axis: 600 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 500 mm, Selling a fully functional Nakamura Superturn 3 at short notice due to lack of space. Feel free to contact us with any questions. Fsdpfexyk Rwjx Ag Dopr

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Multifunctional CNC Turning, Boring and Milling Centre / Manufacturer: WFL Type: M120 MILLTURN x 3000 / Year of construction: 2008, Overhauld in 2025 TECHNICAL DATA: Working range: - Centre distance / turning length (depending on clamping device): 3.000 mm Fodpfxjxt Uqhe Ag Depr - Swing diameter over bed (max. nominal dimension): 1.220 mm - Swing diameter over top of slide: 1.140 mm Accessories / Equipment: - Siemens SINUMERIK 840D CNC control pl - Turning/drilling/milling unit - NC tailstock - External tool magazine, 90-positions - Pick-up station - Cooling system - Chip conveyor - Further extensive equipment ... Detailed technical data sheet and information on equipment available on request. There is no guarantee for correctness and completeness of the technical details and accessories. - Subject to prior sale -

Condition: ready for operation (used), Year of construction: 2002, operating hours: 20,204 h, functionality: fully functional, turning length: 1,025 mm, turning diameter: 530 mm, travel distance X-axis: 475 mm, travel distance Z-axis: 1,170 mm, quill stroke: 150 mm, controller model: Okuma OSP-E100L, TECHNICAL DETAILS Distance between centers: 1,000 mm Swing over bed: 550 mm Fsdpfexvzp Aex Ag Depr Maximum machining diameter: 530 mm Maximum workpiece length: 1,025 mm Travels X-axis: 475 mm Y-axis: ±80 mm Z-axis: 1,170 mm C-axis: 360° (continuous) B-axis indexing angle: 1° Main spindle Spindle speed: 5,000 rpm Spindle nose: JIS A2-6 Taper bore diameter: 62 mm Bearing diameter: 100 mm Sub spindle Spindle speed: 6,000 rpm Spindle nose diameter: 140 mm Taper bore diameter: 43 mm Bearing diameter: 80 mm Milling spindle Speed range: 6,000 rpm Feed rates Rapid traverse X-axis: 30 m/min Rapid traverse Y-axis: 26 m/min Rapid traverse Z-axis: 40 m/min Automatic Tool Changer (ATC) Number of tools: 84 Maximum tool length: 250 mm Maximum tool diameter: Ø120 mm (with adjacent stations empty) Maximum tool weight: 5 kg MACHINE DETAILS Control: Okuma OSP-U100L Dimensions (L x W x H): 3,820 × 2,645 × 2,900 mm Weight (without tool magazine): 12,500 kg Main switch-on hours: 20,204 h EQUIPMENT Automatic tool change system High-speed M-spindle with coolant supply 360° C-axis for continuous machining Robust B-axis with 1° indexing Precision sub spindle for second machining side Stable turret with ATC system

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, For sale: Well-maintained EMCO Hyperturn 665 MC Plus with IEMCA Master 880MP-E bar loader, chip conveyor, and high-pressure coolant pumps! Machine was exclusively used for machining brass parts! CNC Turning and Milling Center | EMCO Hyperturn 665 MC Plus with main and sub-spindle, C and Y axes, dual turrets each with 12 driven tool stations! Technical Data: Swing diameter over bed: 600 mm Swing diameter over cross slide: 500 mm Control: Siemens Sinumerik 840D Max. turning diameter: 430 mm Max. turning length: 744 mm Max. bar capacity: 65 mm Travel - X: 270 mm Travel - Z: 750 mm Travel - X2: 205 mm Travel - Z2: 750 mm Travel - Y: 100 (+/- 50) mm Main spindle speed: 0 - 5,000 rpm Sub-spindle speed: 0 - 7,000 rpm Tool turret: 2x 12 positions, all driven! Tool holder: VDI 30 Upper turret: X, Z, Y axes Lower turret: X, Z axes Sub-spindle traverse (left/right): Z3 axis C11 spindle: 65 mm diameter (hollow chuck cylinder) C12 spindle: 45 mm diameter (solid chuck cylinder) with part ejector Tool turret type: Sauter 2x 14 bar high-pressure pumps Accessories: Complete tooling cabinet with driven and static toolholders as well as carbide inserts and tool holders Collet chucks for main and sub-spindle Full documentation Fjdpfx Agoxzq Nce Djpr etc. Machine available immediately! Ready for operation! Loading will be handled by us! Transport can be organized upon request!

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, machine/vehicle number: RLX10110, MACHINE SPECIFICATION Height of centres 240mm Distance between centres 1250mm Maximum cutting length 1080mm Swing over bed 480mm Fsdoxt E Nnjpfx Ag Djpr Swing over cross slide 257mm Swing in gap 700mm Gap width from faceplate 170mm Cross slide travel 230mm Spindle bore 80mm Spindle nose Camlock D1-8 Spindle speeds 25 to 2500rpm Main motor 7.5kW Tailstock quill travel 160mm Tailstock quill taper No. 5 MT Approximate weight 2950Kg Dimensions W x D x H 2600mm x 1460mm x 1810mm MACHINE EQUIPPED WITH Prototrak RLX CNC control TRAKing Auxiliary output 3 jaw chuck Quick change toolpost and toolholders Enclosed guarding Coolant system Lighting

Condition: good (used), Year of construction: 2006, operating hours: 21,437 h, functionality: fully functional, machine/vehicle number: 122574, Controller: OSP P200 L  Remarkably few spindle hours.    Max. turning diameter ø 720mm  2.000 mm distance between spindles  Spindle speed 3.500 rpm  Spindle power 30 kW  Sub-spindle; spindle speed 3.800 rpm  Spindle power 22 kW  Fpedpfx Agourfz Ie Der Spindle speed aangedr. Ger 5.000 rpm  Spindle power aangedr. Ger. 22 kW  Number ger. Under 12 Turret  Upper mill spindle HSK100 ATC 32 HSK 100   Y-axis 250 (+125 / 1-125) mm  Floor space: 6150 x 3073

Condition: ready for operation (used), Year of construction: 1999, Mazak Super Quickturn 200M (1999) C Axis and Milling Fpedpfx Ajw Rl Ugjg Djr 8" Chuck Cylinder Mazak tool length measuring system Full set of manuals Parts Catcher Tailstock Mazatrol & EIA programming Swarf Conveyor Bar feeder preparation No bar feeder included This item is physically in stock and can be seen in full working order, at our showroom. Delivery and installation can be arranged at extra costs.

Condition: used, Year of construction: 2000, max. turning diameter 580 mm turning length 1500 mm control OSP 7000 L greates pass round over bed 610 mm swing diameter over slide rest 580 mm turning speed range - main spindle 12 - 2.800 min/-1 spindle bearing diameter 150 mm spindle bore 110 mm spindle nose JIS A2-11 power capacity - main spindel 37 (30) kW C-Axis 0,001 ° x-axis 598 mm y-axis 230 mm z-axis 1.660 mm rapid traverse X / Y: 12.000 mm/min rapid traverse Z: 20.000 mm/min rapid traverse C: 100 min/-1 cutting feed speed X / Z / Y: 0,001 - 1.000 mm/U type H2 ATC number of toolpositions 2 (1x L-Tool / 1x M-Tool) pos. driven statition stufenlos / stepless Spindle speed - driven tool stations 40 - 3.000 min -1 tool shank height 25 mm Fsdpfx Aoxmaf Rog Djpr Boring bar shank diameter 50 mm diameter of quill 120 mm quill stroke 170 mm taper of center MT 5 number of toolpositions 50 pos. tool taper MAS BT 50 max. tool diameter 170 mm max. tool length 350 mm max. tool weight 20 kg drive of magazin 3,2 kW total power requirement 53 kVA weight of the machine ca. 18,5 t dimensions of the machine ca. 6,0 x 3,2 x 3,0 m CNC - Turning- and MillingCenter OKUMA - MacTurn 50

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, machine/vehicle number: 0014, turning length: 1,500 mm, turning diameter over cross slide: 610 mm, travel distance X-axis: 598 mm, travel distance Y-axis: 230 mm, travel distance Z-axis: 1,660 mm, TECHNICAL DETAILS Travel Distances X-axis travel: 598 mm Y-axis travel: 230 mm Z-axis travel: 1,660 mm C-axis: 0.001 Turning Length: 1,500 mm Swing diameter over cross slide: 610 mm Swing diameter: 580 mm Spindle Spindle motor power: 30,000 W Spindle speed (min.): 14 rpm Spindle speed (max.): 3,200 rpm Spindle bore: 90 mm Spindle bearing diameter: 130 mm Spindle nose: JIS A2-11 Rapid Traverse Rapid traverse (Z-axis): 20 m/min Rapid traverse (X/Y): 12,000 mm/min Rapid traverse (C): 100 min^-1 Cutting feed rate X/Z/Y: 0.001 - 1,000 mm/rev Tools Tool magazine positions: 32 pos. Tool holder: MAS BT 50 Max. tool diameter: 170 mm Max. tool length: 350 mm Max. tool weight: 20 kg Turret type: H2 ATC Tool stations: 2 (1x L-Tool / 1x M-Tool) Driven tool stations: stepless Spindle speed – driven tool stations: 40 - 3,000 rpm Tailstock Quill diameter: 120 mm Quill stroke: 170 mm Centre taper: MT 5 MACHINE DETAILS Fpsdoxqyikjpfx Ag Dor CNC Control: OSP 7000L Total power requirement: 53 kVA Dimensions & Weight Dimensions (L x W x H): 5.3 x 3.2 x 3.0 m Machine weight: 18,500 kg EQUIPMENT Chip conveyor

Condition: new, Year of construction: 2025, Z-MaT DT500E-S, Siemens 828 D ShopTurn 15" Touch CNC Turning Center, with Sub-Spindle, Driven Tools, and True Y-Axis, 35° Slant Bed Max. Swing Diameter: 650 mm Max. Turning Diameter: 320 mm Max. Turning Length: 550 mm Linear Roller Guides on All Axes Rapid Traverse X/Z/Y: 20/20/12 m/min Y-Axis Travel: 140 mm, +/- 70 mm Turret: 12 Stations BMT55 — 12 Driven Positions Max. Turret Speed: 4000 rpm, 3 kW Main Spindle: Chuck Diameter: 254 mm Spindle Nose: A2-8 Max. Bar Capacity: 75 mm Spindle Bore Diameter: 86 mm Spindle Drive Power, Direct Drive: 15/16 kW Max. Spindle Speed: 3500 rpm Sub-Spindle: Chuck Diameter: 152 mm Spindle Nose Standard: A2-5 Max. Bar Capacity: 46 mm Drive Power: 11 kW Max. Speed: 3000 rpm Fsdpfxewwvldj Ag Dopr Dimensions (W x D x H): 3.1 x 2.0 x 2.25 m Weight: 5.3 t Standard Equipment: Parts Catcher (Preparation) Hinged Belt Chip Conveyor Oil Skimmer Coolant System 3-Color Warning Light Work Area Lighting Centralized Lubrication System Programmable Tailstock Set of Soft Jaws Tools and Toolbox CE Conformity Operating Manual The machine will be exhibited at EMO, Hall 12/D10 and will be available immediately afterwards. A wide range of automation options is available, such as bar loaders and loading robots.

Condition: like new (used), Year of construction: 2018, Technical Data: • Swing diameter over cross slide: 430 mm (max. turning diameter 220 mm) • Turning length: max. 670 mm • Spindle bore (clearance diameter): 45 mm • HS spindle interface DIN 55026 A2-5 • Main drive power: 13 kW • Max. torque: 78 (100) Nm • Speed range: 0–6300 rpm • Counter spindle interface: DIN 55026 A2-4 • Number of tools: 12 driven tools, max. speed: 0–6000 rpm • Tool holder: VDI 25 • Pressure boost station E45 for central coolant system; centrifugal pump 14 bar; lifting pump min. 1.5 bar • Chip conveyor: hinge belt conveyor, discharge height 1200 mm • Swing loader Emcoturn E45 with loading and unloading system; 2-finger parallel gripper / 90° rotating module • Belt conveyor for RT parts feeding: length 1300 mm / width 567 mm; chain pitch 27.1 mm (1800L) • Control: Siemens 828 D Fedpswl Uu Hsfx Ag Dspr ⸻ • Connected load: approx. 46 kVA • Voltage: 400 V / 50 Hz • Weight: approx. 4,300 kg • Space requirement: approx. 15 m²

Condition: ready for operation (used), Year of construction: 2008, operating hours: 56,089 h, Swing diameter over bed/cross slide: 820mm/550mm, distance between centers: 2666mm, max. turning diameter: 610mm, max. workpiece length: 2500mm, travel X/Z: 410mm/2560mm, travel Y: -80mm/100mm, max. workpiece weight without/with tailstock: 500kg/1500kg, tool positions: 12, rapid traverse X/Z/Y: 24m/30m/12m/min, feed force X/Z/Y: 17kN/20kN/17kN. Machine dimensions X/Y/Z: approx. 5500mm/2250mm/2550mm, weight: approx. 15000kg, operating hours: approx. 56089. Documentation available. An on-site inspection is possible. Expected to be available from mid-2026. Fpjdpfsw Dfhusx Ag Djr

Condition: used, Year of construction: 2008, greates pass round over bed 600 mm swing diameter over face slide 500 mm control Siemens Sinumerik 840 PL max. turning diameter 430 mm Max. Turning length 744 mm max. bar material dia. 65 mm travel -x axis 270 mm travel -z axis 750 mm travel -x2 axis 205 mm travel -z2 axis 750 mm travel -y axis 100 (+/- 50) mm main spindle speeds 0 - 5.000 U/min Subspindle speed 0 - 7.000 U/min number of tapers in turret head 2x 12 tool taper VDI 30 CNC Turning- and Milling Center | EMCO - HYPERTURN 665MCPlus with main and counter spindle, C and Y axis, 2 turrets aligned for driven tools, and equipped with a bar feeder Irco Profimat as well as a coolant system Knoll SF 1000/Turbo- 1. The machine has approximately 26,710 hours of production operation. Scope of delivery / Equipment: + 2 spindles: main and counter spindle with C-axis + 2 turrets for driven tools (each with 12 stations) + Upper turret equipped with Y-axis + Internal cooling + Chip conveyor + Bar feeder Irco Profimat + Driven tools (straight and angled) + Chucks for main and counter spindle + Extraction system + Workpiece discharge device with conveyor belt + Coolant system Knoll SF 1000/Turbo-1 + Various holders, approx. 80 pieces VDI 30 + Boring bar holders + Jaw holders The machine is in well-maintained condition. Please refer to the offer for further technical details. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Fedev Rgzkspfx Ag Djpr #Tags: HYPERTURN665 | HYPERTURN-665 | EMCO-HYPERTURN

Year of construction: 1999, condition: good (used), turning diameter 580 mm turning length1.500 mm Fedpfoiicllox Ag Djpr X/Z 568/1660 mm Y-axis C-axis spindle 3.200 min-1 driven tools 3.000 min-1

Condition: new, Year of construction: 2024, functionality: fully functional, spindle motor power: 9,000 W, Are you looking for a Dutch made CNC machine for your hobby or your business? Are you looking for a user-friendly machine that is also affordable? Then take a quick look at the photos or visit our website for the possibilities that our machines offer. Fodpfernmwljx Ag Dopr Functional design: the design is based on experiences of our customers No assembly, the machine is delivered complete Universal accessories such as vacuum systems, automatic tool changer, dust extraction, milling motors, measuring instruments, various safety systems, end machining, drilling units and much more (see website). Machine working range: 1300x2500mm to 2100x4000mm or customization (larger possible) For more information, see our website. If you are interested, please make an appointment at our workshop in Schiedam, the Netherlands.

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, turning length: 300 mm, TECHNICAL DETAILS Turning length: 300 mm Fpodpjxz Apbofx Ag Der Distance between centers: 800 mm MACHINE DETAILS Control: FANUC 16T EQUIPMENT 3 turrets Sub-spindle

Condition: ready for operation (used), Year of construction: 2012, operating hours: 3,006 h, functionality: fully functional, turning length: 1,540 mm, travel distance X-axis: 495 mm, travel distance Y-axis: 125 mm, travel distance Z-axis: 1,560 mm, swing diameter over bed slide: 660 mm, controller model: MSX-711 (MAPPS IV), Partially overhauled machine with only approximately 3,000 spindle hours! TECHNICAL DETAILS Turning length: 1,540 mm Max. turning diameter: 610 mm (Turret 2: 274 mm) Swing diameter over bed: 660 mm Swing diameter over cross slide: 660 mm (Turret 2: 300 mm) Turning/Milling Spindle X-axis travel: 495 mm Y-axis travel: 125 mm Z-axis travel: 1,560 mm B-axis: 120 degrees Spindle speed: 12,000 rpm Drive power: 18.5/11 kW (10 min./continuous operation) Tool Magazine Magazine positions: 76 Fpedpfjx An Uxex Ag Der Tool holder: Capto C6 Lower Turret Number of tool stations: 10 Tool change time: 0.19 s Main Spindle Spindle speed: 5,000 rpm Main spindle drive power: 22/18.5 kW (30 min./continuous operation) Sub Spindle Spindle speed: 5,000 rpm Sub spindle drive power: 22/18.5 kW (30 min./continuous operation) MACHINE DETAILS Control system: MSX-711 (MAPPS IV) Operating hours Spindle hours: 3,006 h Operating hours: 4,526 h EQUIPMENT Spindle 2 with tailstock option Electronic handwheel Interface for high-pressure coolant system Chip conveyor Air nozzle for chuck and tool tip Automatic tool measurement system for upper and lower positions Bar feeder interface Hobbing function

Condition: good (used), Year of construction: 2006, functionality: fully functional, The used SPINNER TC77 SMCY counterspindle Y-axis motorized cnc lathe is a robust CNC tilting lathe with ASA 8" size flat guideways, with BARUFFALDI automatic 2-speed gear-driven range change, equipped with a counterspindle and spindle both with "C" axis and a motorized Y-axis turret with 120mm travel (+60/-60 mm) VDI 50. Completing the configuration is the FANUC i-series cnc with color lcd and Manual Guide i conversational programming, ethernet interface, RS 232 port and memory card for program entry, chip evacuation, 315mm BB 3-jaw hydraulic chuck, a set of motorized toolholders (10 pieces) and several fixed ones, and a large set of clamps. Main features: Maximum turning diameter 690 mm Max. standard turning diameter 500 mm Max. workpiece length 800 mm Fpedpeuizukefx Ag Dor Max. main spindle bar diameter 77 mm Max. secondary spindle bar diameter 52 mm Main spindle chuck self-centering 315mm Secondary spindle chuck chuck 210mm Max. x-axis travel 360mm Max. Y-axis travel 120 mm (-55/+65) Max. z-axis travel 980 mm Main spindle ASA 8" 26kW main spindle up to 1030 Nm torque and max. 4000 rpm. ASA 6" 18kW secondary spindle ASA 6" up to 113 Nm torque and rpm of maximum 4000 rpm. 12-position VDI 50 tool changer turret (rotating 4,000 rpm). Machine weight: approx. 6,000 kg Year of construction 2006, installed 2008, with about 5,800 working hours; "CE" compliant complete with manuals.

Condition: excellent (used), Year of construction: 2015, operating hours: 11,100 h, functionality: fully functional, machine/vehicle number: NTX1150102, Year 2015 with F31iB5 control and CELOS Country of manufacture: JP Voltage: 380V/50Hz/3ph Dimensions: 4169x2543x2543 mm Net machine weight: 10,000 kg TECHNICAL SPECIFICATIONS Control: Fanuc F31iB5 with CELOS Main spindle: X1 axis: 455 mm Y axis: +/- 105 mm Z1 axis: 800 mm (+165 for ATC) B axis: 240° Turret 2: X2 axis: 160 mm Z2 axis: 730 mm Spindle 1 / Spindle 2: C axis: 360° / 360° Tailstock: A axis: 820 mm Max. distance between centres: 1,050 mm Fpodpfxsw T Snfj Ag Djr Max. turning diameter Main spindle: Ø 430 mm Turret 2: Ø 274 mm Max. turning length: 800 mm Bar diameter: Ø 52 mm . Ø 65 mm Unless otherwise specified or in case of errors or omissions, the technical data is provided without commitment.

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, turning length: 480 mm, turning diameter: 200 mm, controller model: FANUC 31, TECHNICAL DETAILS Turning length: 480 mm Fedpfxjxzz U Ne Ag Dspr Turning diameter: 200 mm MACHINE DETAILS Control: FANUC 31 EQUIPMENT 3 turrets Sub spindle

Condition: excellent (used), Year of construction: 2020, operating hours: 4,800 h, functionality: fully functional, machine/vehicle number: NL154200702, Manufacturing origin: JP Voltage: 380 V / 50 Hz / 3-phase Net weight: 5,400 kg Customs tariff number: 8458.9100 TECHNICAL DATA Maximum turning diameter: 350 mm Turning length: 515 mm CNC control: M730UM MAPPS Celos Swing over bed: 923.8 mm Swing diameter above carriage: 755 mm Standard turning diameter: 260 mm Bar capacity: 34 mm Main spindle: Spindle speed range: 100 – 8,000 rpm Spindle motor power: 11 / 7.5 kW C-axis resolution: 0.001° Chuck diameter: 210 mm Subspindle: Maximum speed: 8,000 rpm Spindle nose: A2-5 Axis travels: X-axis travel: 260 mm Z-axis travel: 580 mm Y-axis travel: 100 mm (±50 mm) Turret: Number of turret stations: 20 Driven stations: 20 Tool shank diameter: 25 mm Maximum driven tool speed: 10,000 rpm Driven tool motor power: 5.5 / 3.7 kW Feed rates: Rapid traverse X-axis: 30 m/min Rapid traverse Z-axis: 30 m/min Rapid traverse subspindle: 30 m/min Rapid traverse Y-axis: 10 m/min Rapid traverse C-axis: 400 rpm Total power requirement: 31 kVA Fpodpfx Aew T Sn Eeg Dor Approximate machine weight: 5.4 t Approximate machine dimensions: 4.0 x 3.0 x 3.2 m Errors and omissions excepted – data provided without obligation.
