Used 3 Axis Vertical Machining Center for sale (101,741)

Condition: repair required (used), Year of construction: 2016, functionality: not functional, machine/vehicle number: 7195-0022, travel distance X-axis: 440 mm, travel distance Y-axis: 140 mm, travel distance Z-axis: 170 mm, rapid traverse X-axis: 15 m/min, rapid traverse Y-axis: 15 m/min, rapid traverse Z-axis: 10 m/min, nominal power (apparent): 10 kVA, controller manufacturer: Fanuc, controller model: 310i-A5, Equipment: documentation/manual, Manufacturer: EWAG AG Model: Laser Line Ultra Machine type: 5-axis laser machining center Serial number: 7195-0022 Release: 5 Year of construction: 2016 Laser source: Coherent Hyper-Rapid 50 laser head Laser manufacturer: Coherent Kaiserslautern GmbH Laser manufacturing date: 28/01/2016 Machine laser classification: Laser system class 1 according to DIN EN 60825-1:2008-05 Bjdpfx Aasy E Ni Ss Dedb Axes: X, Y, Z, B, C CNC control: Fanuc 31i-5 Control Operating voltage: 3 × 400 VAC / N / PE Frequency: 50 Hz Control voltage: 24 V DC Rated current: 17.3 A Connected load: 12 kVA Maximum fuse protection: 25 A (slow-blow) Wiring diagram number: 100211907 Extraction: ULT LAS 200 extraction system Documentation: fully available Operating hours: 35,788.02 h Note: Laser unit is defective and needs to be replaced The associated FANUC LR Mate 200iD robot is currently dismantled and being refurbished; it is optionally available upon request Inspection under power possible

Condition: excellent (used), Year of construction: 1995, Heidenhain TNC 407 SK 40 Luft Wasser Kühlung Werkzeugwechsler 22 Plätze Bdedogydn Iopfx Aa Deb Verfahrwege 600x500x450 mm Spindeldrehzahlen 5-5000 U/min Vorschubgeschwindigkeit 0-10000 mm/min Antriebsleistung Hauptspindel 6 kW

Condition: good (used), Year of construction: 2003, x-Weg 1270 mm y-Weg 660 mm z-Weg 610 mm Steuerung Ultimax 4 Tischbelastung 1300 kg Drehzahl 10.000 U/min Bdsdpfx Asiv R Hlsa Dsb Werkzeugwechseleinrichtung 24-fach Werkzeugaufnahme SK 40 Antrieb 15 kW Tischgröße 1500x660 mm Gesamtleistungsbedarf kW Maschinengewicht ca. 9 t Raumbedarf ca. 4,8x4,5x2,95 m

Condition: ready for operation (used), Year of construction: 2006, A CNC vertical machining center Spinner is available. Travel X/Y/Z: 650mm/450mm/460mm, table dimensions X/Y: 710mm/450mm, max. table load: 500kg, speed: 8000rpm, tool holder: SK40, tool positions: 24, rapid traverse: 24m/min, feed: 10m/min, positioning accuracy: +/-0.01mm, repeatability: +/-0.005mm. Machine dimensions X/Y/Z: approx. 2400mm/2100mm/2600mm, weight: approx. 9500kg, control: Fanuc. Without vise and dividing head. The spindle was recently renewed and the hydraulic pump is currently being renewed. The rotary table is leaking oil. Documentation available. An on-site inspection is possible. Bsdpfx Aaoy Igbqo Dedb

Condition: reconditioned (used), Year of construction: 2012, functionality: fully functional, Equipment: chip conveyor, documentation/manual, Röders RXP600DSH - HSK63F spindle max. 30,000 rpm - 24-position tool changer Bdodpjx I A Imsfx Aa Djb - Emulsion cooling with 40 bar internal coolant supply (IKZ) - Extraction system - Laser tool measurement - 3D probe - Thermal package - Prepared for automation The machine is already at our facility in Soltau. We will upload pictures shortly.

Condition: refurbished (used), Year of construction: 2014, functionality: fully functional, travel distance X-axis: 700 mm, travel distance Y-axis: 855 mm, travel distance Z-axis: 500 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, spindle speed (max.): 30,000 rpm, spindle nose: HSK63, Equipment: chip conveyor, rotational speed infinitely variable, Röders RXU1000DSH X-axis: 700 mm Y-axis: 855 mm Z-axis: 500 mm The clearance height between spindle nose and machine table is 600 mm Bedpfx Aasy E Aa Dj Dsdb Spindle: HSK63F, max. 30,000 rpm Tool magazine: 24 slots – optionally expandable Equipment: - Automatic machine calibration for highest accuracy - Spindle compensation - Compressed air through spindle - Remote maintenance - Emulsion cooling with IKZ 40 bar - Emulsion mist extraction - Work area rinsing - Automatic 3D probe - Blum tool measurement laser - Workpiece cleaning with compressed air The machine is completely overhauled, measured, and inspected in our facility. It fulfils the original manufacturer's specifications regarding geometry!

Condition: like new (used), Year of construction: 2023, operating hours: 2,983 h, functionality: fully functional, travel distance X-axis: 540 mm, travel distance Y-axis: 635 mm, travel distance Z-axis: 400 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, controller model: RMS6, spindle speed (max.): 24,000 rpm, spindle nose: HSK63A, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Röders RXP601 DSH incl. Automation RCE2 X-axis: 540 mm Y-axis: 635 mm Z-axis: 400 mm Clearance table/spindle: 485 mm Spindle: HSK63A, 24,000 rpm MHT medium distributor incl. holders and nozzle bodies included Compressed air through spindle Machine table: Erowa UPC 320x320 Tool changer: 64 positions Preparation for emulsion cooling and high-pressure coolant (IKZ) Options package: - Thermo package for maximum precision - Spindle compensation - Blum measuring laser for tool measurement - Handbox with display - Workpiece cleaning with compressed air - Tool cleaning with spray medium - Automatic machine calibration for maximum precision even with fluctuating temperatures - UPS for machine control - Remote maintenance - 3D measuring probe, automatically thermostable cone - Oil mist extraction with mechanical filter - Emulsion machining, preparation for high-pressure 40 bar pressure stages - Medium distributor: 1 medium/3 delivery rates - Medium distributor operation with MV2 Bjdpoy Ez Utjfx Aa Dsdb - Front machine door as automatic lift door - Chuck control, dual pneumatic - Job manager RMSMain - Stainless steel internal cover - 3D machine model Automation RCE2: 10-position pallet changer for Erowa UPC pallets with max. dimensions 340x340 mm Maximum load per pallet: 300 kg

Condition: used, Year of construction: 2009, Doosan Mynx 750/50 4 Axis Vertical Machining Centre with Fanuc Series 21i-MB CNC Control, Kitagawa MR320RAE04 4th Axis Unit 310mm 3 Jaw Chuck, Table Size 1600mm x 750mm, 40 Tool ATC, BT50 Spindle Taper, Filtermist FX7002 Oil Mist Extractor, Kaukan Chiller Unit, Profluid MCF 20 Coolant Pressure Filter Unit, Machine Weight 13500kg. S/No. MYNX 7500373 (2009) Includes Work Bench, Vice and Various BT50 Spindle Tool Holders. Country of Origin: Korea Location: This lot is located in Birmingham, UK. A charge of £550 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchaser. Bdedpfx Ajy Ic Duea Dob

Condition: ready for operation (used), Year of construction: 2014, HAAS VF2 Year of manufacture: 2014 Bdsdpjy Icw Iefx Aa Djb

Condition: used, Year of construction: 2008, x-travel 600 mm y-travel 450 mm z-travel 300 mm Control Roeders RFM 600 DS table-size 700 x 550 mm spindle tunring speed 42.000 U/min tool taper HSK 40 Bsdey Ez Efepfx Aa Djdb number of tool places 20 Pos. In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice and errors. Prior sale is reserved.

Condition: used, Year of construction: 2010, Mazak VTC820/30 3-Axis Machining Centre. S/No. 200131 (2010) with Mazatrol Matrix Control, X/Y/Z Travels 3000/800/720mm, Table 3500mm x 820mm, Spindle Speed 18,000rpm, Spindle Taper BT40, B Axis Swivel Head +/- 110, Removable Centre Partition. Country of Origin: United Kingdom Please Note: There are no loading facilities on site, dismantling and loading will be at the cost of the purchaser. Location: These lots are located in Birmingham & Wolverhampton, UK. Please Note: There are no loading facilities on site, dismantling and loading will be at the cost of the purchaser. Bdedjy Ib Ryspfx Aa Deb

Condition: used, Year of construction: 2010, Mazak VTC 800/30SR 5-Axis Machining Centre. S/No. 215592 (2010) with Mazatrol Matrix Control, X/Y/Z Travels 3000/800/720mm, Table 3500mm x 820mm, Spindle Speed 18,000rpm, Spindle Taper BT40, B Axis Swivel Head +/- 110. Country of Origin: United Kingdom Bdedpfxsy Ib N No Aa Dsb Please Note: There are no loading facilities on site, dismantling and loading will be at the cost of the purchaser. Location: These lots are located in Birmingham & Wolverhampton, UK. Please Note: There are no loading facilities on site, dismantling and loading will be at the cost of the purchaser.

Condition: good (used), Year of construction: 2005, Hurco VMX 64/40T Year of manufacture: 2005 Bdjdoy Ia Rljpfx Aa Dob Control: Ultimax Travel: X-1630 mm, Y-860 mm, Z-760 mm Spindle speed: 10,000 rpm Spindle coolant Tool changer: 40 positions Chip conveyor

Condition: used, Year of construction: 2003, Technical details: x-travel: 800 mm Bjdpfx Aouqq Uqoa Dodb y-travel: 400 mm z-travel: 350 mm total power requirement: 44 kW weight of the machine ca.: 8,8 t dimensions of the machine ca.: 6,1 x 4,1 x 3,3 m tool taper: HSK63 number of spindle speeds: 36-12.000 Number of tools: 2 x 21 St. rotary table diameter: 1340 mm

Condition: repair required (used), Year of construction: 2007, functionality: not functional, machine/vehicle number: 191-89, Technical characteristics: - Machining workspace: X 550 mm; Y 400 mm; Z 360 mm - Axis configuration: 3 linear axes (X, Y, Z) + 1 rotary table axis A and 2 rotary divider head axes B, equipped with direct angular measuring system, max rotation speed 50 rpm, accuracy +/- 5" - Axis A swivel range: +/- 110° - Max. clamping/part dimensions: Ø 247 x 830 mm; max. weight 360 kg - Rapid traverse rate: X/Y/Z 40/40/40 m/min - Distance between divider heads B1/B2: 250 mm - Spindle speed: 1–10,000 rpm Bsdpfxexxi Rms Aa Djdb - Spindle interface: DIN69893-HSK-A63 (with internal coolant supply) - Automatic tool changer: 1x48 positions / chip-to-chip average 2.5 sec - Max. tool diameter: 82 mm / max. tool length: 250 mm / max. tool weight: 5 kg Electrical specifications: - Supply voltage: 3x400V/50Hz - Installed power: approx. 45 kVA / 80A Dimensions: - Installation space: approx. 4.4 x 2.3 x 3.1 m - Weight: approx. 8,500 kg Equipment includes: - CNC control: Siemens 840D Power Line - Chip conveyor: Spring Knoll - Oil cooling system - High-pressure oil filtration system (max. 80 bar): Knoll HL 450/1200 - Shaft cooling system, guideways and control cabinet - 2 oil lubrication units - Oil mist extraction/recovery: LTA - Fire protection: Kraft & Bauer - Part presence P/Y detection: with low-pressure air sensors - In-process inspection: Marposs T25 - Tool holder presence detection in spindle - Documentation: incomplete Machine status: NOT OPERATIONAL: Hydraulic power unit motor burned out.

Condition: repair required (used), Year of construction: 2009, functionality: not functional, machine/vehicle number: B-8024, Technical characteristics: # Machining Workspace: X 800 mm; Y 400 mm; Height from table surface to floor: 850 mm (max load 450 kg) # Number of T-slots: 3 / Distance between T-slots: 125 mm / Width of T-slots: 18 mm # Axis configuration: 3 LINEAR AXES (X, Y, Z) + 2 twin horizontal spindles + 4th axis # Rapid traverse rates: X, Y, Z – 30 m/min # Travel paths: Longitudinal (X-axis) 600 mm, Transverse (Y-axis) 400 mm, Vertical (Z-axis) 510 mm Headstock: Bdodpfx Asxxi Ewsa Dsb # Spindle distance: 200 mm # Max. distance from spindle center to table: 650 mm # Spindle interface: ISO 7388 (with internal coolant), Tool holder size: 40 # Speed range (standard): 100 – 8000 rpm, Maximum torque at 330 rpm: 85 Nm, 7.5 kW Automatic tool changer: # Number of tools: 20, Selection system: sequential/random, Max. tool diameter (adjacent): 85 mm, Max. tool diameter (non-adjacent): 135 mm, Max. tool length: 250 mm, Max. tool weight: 6.5 kg, Tool change time: 3 seconds Electrical connection: # Voltage: 3x400V / 50Hz # Installed power: approx. 30 kVA Dimensions: # Required floor space: approx. L 2.1 x W 3.5 x H 3 m # Weight: approx. 4200 kg Equipment included: # CNC control – GE Fanuc Series 31i MODEL A # Chip conveyor # Lubrication system # Cooling system # Electrical cabinet # Spindle chiller: HARBOR Model: HBO-750PTSB2 # Documentation: Digital and hard copy available Machine condition: NOT OPERATIONAL # Y axis motor defective – requires replacement (not repairable) # 2 tool changer units defective – require replacement (not repairable) # Spindles defective – require replacement (not repairable) # Hydraulic unit defective – needs replacement or repair

Condition: repair required (used), Year of construction: 2017, functionality: not functional, machine/vehicle number: P177ZG753, Technical characteristics: # Machining Workspace: X 500 mm; Y 400 mm; Z 330 mm # Axis Description: 3 LINEAR AXES (X, Y, Z) + 1 rotary table axis (A-axis) with index dividing head, direct angular measurement system, number of revolutions 50 min⁻¹, accuracy +/- 5" # A-axis Swivel Range: +/-170˚ # Maximum Clamping/Workpiece Dimensions: 650 x 400 mm; max. weight 300 kg # Rapid Traverse: X/Y/Z 54 m/min # Spindle Speed: 100–10,000 rpm, spindle motor power 11 kW # Spindle Taper: BBT30 (with internal cooling) # Automatic Tool Changer: 1x21 tools, chip-to-chip average time 1.5 sec # Maximum Tool Size: Ø40 mm / length max. 200 mm / 2 kg Bjdsxxt Ehepfx Aa Dodb Electrical connection: # Voltage: 3x400V/50Hz # Installed Power: approx. 20 kVA / 22A Dimensions: # Installation space: approx. 1.65 x 3.2 m (with chip conveyor) x 2.8 m # Weight: approx. 8,500 kg Equipment includes: # This 4-axis FANUC Robodrill α-D21LiB5 was manufactured in 2016. Ideal for precision machining, this vertical machining centre offers robust performance and reliability. # CNC Control: Model 31i model b5 # 4th axis and tailstock: Fanuc DDR-TiB 178DU039 2017/08 and TSUDAKOMA tailstock # Chip extractor & coolant filtration unit max. 40 bar: Mosnic model 1641/2010 # Spindle, Guideways, and Electrical Cabinet Cooling Systems # Oil Vapor Absorption/Recovery System: Bristol model B 1000 EF # Fire suppression: Kraft & Bauer # Part presence detection: with low pressure air sensors # Automation: Lateral door automatic and interface ready for automation # In-process inspection: Renishaw TRS2 # Documentation: incomplete Machine condition: NOT WORKING # Hydraulic unit defective # Two emulsion pumps # Guideway lubrication pump # Safety switch Euchner

Condition: used, Year of construction: 2017, functionality: fully functional, machine/vehicle number: P17XZG 044, Technical characteristics: # Machining workspace: X 500 mm; Y 400 mm; Z 330 mm # Axis description: 3 LINEAR AXES (X, Y, Z) + 1 rotary table axis A (indexing divider head) with direct angular measuring system, max. rotational speed 50 rpm, precision +/- 5 seconds # Axis A swivel range: +/-170˚ # Maximum clamping/workpiece dimensions: 650 x 400 mm; max. weight 300 kg # Rapid traverse speed (X/Y/Z): 54 m/min # Spindle speed: 100–10,000 rpm; spindle motor power: 11 kW # Spindle interface: BBT30 (with through-spindle coolant) # Automatic tool changer: 1x21 tools / chip-to-chip average time 1.5 sec # Maximum tool size: Ø40 mm / length max. 200 mm / 2 kg Bedsxxrb Ijpfx Aa Dedb Electrical connection: # Voltage: 3x400V/50Hz # Installed power: approx. 20 kVA / 22A Dimensions: # Installation space: approx. 1.65 x 3.2 (with chip conveyor) x 2.8 m # Weight: approx. 8,500 kg Equipment includes: # This 4-axis FANUC Robodrill α-D21LiB5 was manufactured in 2016. Ideally suited for precision machining, this vertical machining center delivers robust performance and high reliability. # CNC control: FANUC Series 31i-B5 # 4th axis and tailstock: FANUC DDR-TiB 178DU039 (2017/08) and TSUDAKOMA tailstock # Chip conveyor & high-pressure coolant filtration unit (max. 40 bar): Mosnic model 1641/2010 # Spindle cooling system, guideways and control cabinet cooling # Oil mist extraction/recovery system: Bristol model B 1000 EF # Fire suppression system: Kraft & Bauer # Part presence detection: with low-pressure air sensors # Automation: automatic side door and interface, automation-ready # In-process control: Renishaw TRS2 # Documentation: incomplete Machine status: WORKING

Condition: used, Year of construction: 2009, functionality: limited functionality, machine/vehicle number: B-8023, Technical characteristics: # Machining Workspace: X 800 mm; Y 400 mm; Height from table surface to floor: 850 mm (max load 450 kg) # Number of T-slots: 3 / Distance between T-slots: 125 mm / Width of T-slots: 18 mm # Axis configuration: 3 LINEAR AXES (X, Y, Z) + 2 twin horizontal spindles + 4th Axis # Rapid traverse speed: X, Y, Z – 30 m/min # Travel: Longitudinal (X-axis) 600 mm, Cross (Y-axis) 400 mm, Vertical (Z-axis) 510 mm Headstock features: # Spindle distance: 200 mm # Maximum distance from spindle to table: 650 mm # Spindle nose: ISO7388 (with internal cooling), Tool Holder (Size 40) # Speed range (standard): 100/8,000 rpm, Max torque: 85 Nm at 330 rpm, 7.5 kW Automatic tool changer: # Number of tools: 20, Selection system: Sequential/random, Max. diameter (adjacent tool): 85 mm, Max. diameter (non-adjacent tool): 135 mm, Max. tool length: 250 mm, Max. tool weight: 6.5 kg, Tool change time: 6 s. Tool change time (fastest): 3 s. Electrical connection: # Voltage: 3x400V/50Hz # Installed power: approx. 30 kVA Dimensions: # Required floor space: approx. L 2.1 x W 3.5 x H 3 m Bdsdpfxsxxi Sko Aa Dob # Weight: approx. 4,200 kg Equipment includes: # CNC control: GE Fanuc Series 31i MODEL A # 4th axis: Nikken CNC180 FA (2012) # Broken tool detection system: Blum Novotechnik # Chip extractor # Lubrication system # Electrical panel cooling system # Spindle cooling system: HARBOR Model HBO-750PTSB2 # Documentation: Electronic and hard copy available Machine condition: OPERATIONAL — with 1 spindle / 2nd spindle defective — can be repaired.

Condition: repair required (used), Year of construction: 2009, functionality: not functional, machine/vehicle number: 281-06, Technical Specifications: # Machining Workspace: X 550 mm; Y 400 mm; Z 360 mm # Axis Description: 3 linear axes (X, Y, Z) + 1 rotary axis (rotary table A) and 2 rotary axes (B, indexer head) with direct angular measuring system, maximum 50 rpm, accuracy +/- 5 seconds # A axis swivel: +/-110˚ # Max. clamping/part dimensions: Ø 247 x 830 mm; max. weight 360 kg Bdodjxxivcspfx Aa Djb # Rapid traverse rate: X/Y/Z 40/40/40 m/min # Distance between divider heads B1/B2: 250 mm # Spindle speed: 1–10,000 rpm # Spindle taper: DIN69893-HSK-A63 (with internal coolant) # Automatic tool changer: 1x48 tools / chip-to-chip time approx. 2.5 sec # Max tool diameter: Ø82 mm / max. length 250 mm / 5 kg Electrical connection: # Voltage: 3x400V/50Hz # Installed power: approx. 45 kVA / 80A Dimensions: # Installation area: approx. 4.4 x 2.3 x 3.1 m # Weight: approx. 8,500 kg Equipment includes: # CNC control: Siemens 840D Powerline # Chip conveyor: Spring Knoll # Oil cooling system # High-pressure oil filtration system, max. 80 bar: Knoll HL 450/1200 # Shaft, guideways, and electrical cabinet cooling system # 2 oil lubrication systems # Oil mist extraction/recovery: LTA AC3002 # Fire protection: Kraft & Bauer # Presence detection: with low pressure air sensors (part present) # In-process control: Marposs T25 # Tool breakage monitoring: Blum Novotech # Tool presence detection system in spindle # Documentation: incomplete Machine condition: NOT OPERATIONAL # Cover for tool magazine # Tool magazine presence sensor (BERU)

Condition: repair required (used), Year of construction: 2010, functionality: not functional, machine/vehicle number: B-8029, Technical Characteristics: # Machining Workspace: X 800 mm; Y 400 mm; Table surface to floor height: 850 mm (maximum load 450 kg) # Number of T-slots: 3 / Distance between T-slots: 125 mm / T-slot width: 18 mm # Axis description: 3 linear axes (X, Y, Z) + 2 twin horizontal spindles + 4th axis # Rapid traverse rate: X, Y, Z – 30 m/min # Travel: Longitudinal (X-axis) 600 mm, Cross (Y-axis) 400 mm, Vertical (Z-axis) 510 mm Headstock Capabilities: # Spindle distance: 200 mm # Max. distance from spindle to table: 650 mm Bdedpfx Aaoxxiy Ie Djb # Spindle nose: ISO7388 (with through-spindle coolant), Tool holder: Size 40 # Speed range (standard): 100–8000 rpm, Maximum torque / at 330 rpm: 85 Nm, 7.5 kW Automatic Tool Changer: # Number of tools: 20, Selection system: Sequential / random, # Max. diameter (adjacent tool): 85 mm, Max. diameter (non-adjacent tool): 135 mm, # Max. tool length: 250 mm, Max. tool weight: 6.5 kg, Tool change time: 6 s. # Tool change time: 3 s. Electrical connection: # Supply voltage: 3x400V/50Hz # Installed power: approx. 30 kVA Dimensions: # Required floor space: approx. L 2.1 x W 3.5 x H 3 m # Weight: approx. 4,200 kg Equipment includes: # CNC control: GE Fanuc Series 31i MODEL A # Chip extractor # Lubrication system # Cooling system # Electrical panel # Spindle cooling system: HARBOR Model: HBO-750PTSB2 # Documentation: Electronic and hard copy available Machine Condition: NOT WORKING # Tool changer: 1 unit broken – needs replacement (not repairable) # Spindles: broken – need replacement (not repairable) # Hydraulic unit: broken – needs replacement or repair

Condition: repair required (used), Year of construction: 2007, functionality: not functional, machine/vehicle number: 191-88, Technical specifications: # Working area: X 550 mm; Y 400 mm; Z 360 mm # Axis configuration: 3 linear axes (X, Y, Z) + 1 rotary table axis A and 2 rotary axes B with indexing head, direct angular measuring system, max. speed 50 rpm, accuracy +/- 5" # A-axis swivel: +/-110˚ # Max. clamping/part size: Ø247 x 830 mm; max. weight 360 kg # Rapid traverse rate: X/Y/Z 40/40/40 m/min # Distance between dividing heads B1/B2: 250 mm # Spindle speed: 1-10,000 rpm # Spindle interface: DIN69893-HSK-A63 (with internal coolant supply) # Automatic tool changer: 1x48 tools, tool-to-tool average 2.5 sec # Max. tool diameter: Ø82 mm / max. tool length: 250 mm / max. tool weight: 5 kg Electrical system: # Voltage: 3x400V/50Hz # Installed power: approx. 45 kVA / 80A Dimensions: # Installation footprint: approx. 4.4 x 2.3 x 3.1 m # Weight: approx. 8,500 kg Equipment includes: # CNC control: Siemens 840D Power Line # Chip conveyor: Spring Knoll # Oil cooling unit # Oil filtration system up to 80 bar: Knoll HL 450/1200 # Shaft, linear guide and electrical cabinet cooling system # 2 oil lubrication systems # Oil mist extraction/recovery unit: LTA AC3002 # Fire suppression: Kraft & Bauer Bedpfoxw Uplox Aa Dodb # Part presence check with low-pressure air sensors # In-process control: Marposs T25 # Tool support monitoring system at spindle # Documentation: incomplete Machine condition: NOT OPERATIONAL # Operator protection screen damaged – operator panel functional # Tool magazine chain # Ballbar X # Ballbar Y # Pullbar spindle # Axis drive power supply X # Axis drive power supply Y # Main drive power supply # Complete hydraulic unit defective

Condition: repair required (used), Year of construction: 2007, functionality: not functional, machine/vehicle number: 1830108, Technical specifications: # Machining workspace: X 300 mm; Y 650 mm; Z 400 mm # Axis configuration: 3 linear axes (X, Y, Z) + 1 rotary table axis (A-axis), 360° indexable dividing head (resolution 0.001°) # Number of pallets: 2; Maximum table load: 400 kg # Maximum clamping/part size: Ø 575 x 830 mm; maximum weight: 360 kg # Rapid traverse rate: X/Y/Z 75/75/75 m/min; Positioning accuracy Tp: 0.008 mm # Number of spindles: 2 / spindle spacing: 300 mm # Spindle speed: 1–10,000 rpm # Spindle interface: DIN69893-HSK-A63 (with internal coolant supply) # Automatic tool changer: 2 x 32 tools / chip-to-chip time approx. 2.5 s # Tool max. Ø75 mm / length max. 275 mm / max. weight 7.5 kg Bdsdpfoxw Ukvjx Aa Dsb Electrical connection: # Voltage: 3x400V/50Hz # Installed power: approx. 70 kVA / 125A Dimensions: # Installation footprint: approx. 3.9 x 3.2 x 3.1 m # Weight: approx. 10,500 kg Scope of supply: # CNC control: Fanuc 30i-Model A # Linear axis measuring system: Heidenhain linear scales # Chip conveyor: Knoll Type 550 K-1 # Oil cooling unit # High-pressure oil filtration system max. 40 bar: Knoll AE 1060 # Cooling system for spindle, guides, and switch cabinet # 2 oil lubrication units # Part present sensing (P/Y): with low-pressure air sensors # Broken tool detection: Blum Novotec Laser Light Probe # Tool support detection system in working spindle Machine condition: NOT OPERATIONAL # Magazine chain broken — REQUIRES REPLACEMENT

Condition: used, Year of construction: 2010, functionality: fully functional, machine/vehicle number: B-8044, Technical characteristics: # Machining workspace: X 800 mm; Y 400 mm; Height from table surface to floor: 850 mm (maximum load 450 kg) # Number of T-slots: 3 / Distance between T-slots: 125 mm / Width of T-slots: 18 mm # Axis configuration: 3 LINEAR AXES (X, Y, Z) + 4th axis # Rapid traverse: X, Y, Z - 30 m/min # Travel: Longitudinal (X-axis): 600 mm, Cross (Y-axis): 400 mm, Vertical (Z-axis): 510 mm Headstock specifications: # Maximum distance spindle to table: 650 mm # Spindle taper: ISO 7388 (with internal cooling), Tool holder: Size 40 # Spindle speed range (standard): 100/14,000 rpm, Max. torque: 63.7/89.4 Nm at 330 rpm Automatic tool changer: # Number of tools: 20 # Tool selection system: sequential/random # Max. tool diameter (adjacent): 85 mm, Max. tool diameter (non-adjacent): 135 mm # Max. tool length: 300 mm # Max. tool weight: 6.5 kg # Tool change time: 6 seconds (standard), 3 seconds (fast) Electrical connection: # Voltage: 3x400V/50Hz # Installed power: approx. 30 kVA Bdodpfxexw Tqzs Aa Deb Dimensions: # Floor space required: approx. L 2.1 x W 3.5 x H 3 m # Weight: approx. 4,200 kg Equipment included: # CNC Control: GE Fanuc Series 31i MODEL A # Chip conveyor # Lubrication system # Emulsion paper filtration system: Filber S.L. Model FTH5/10 – 200 l/min # Electrical cabinet cooling system # Spindle cooling system: HARBOR Model HBO-750PTSB2 # Documentation: Electronic and hard copy available Machine status: IN OPERATION

Condition: repair required (used), Year of construction: 2009, functionality: not functional, machine/vehicle number: 281-09, Technical Characteristics: # Machining Workspace: X 550 mm; Y 400 mm; Z 360 mm # Axis Description: 3 linear axes (X, Y, Z) + rotary table axis A and 2 rotary axes B, equipped with an index divider head with direct angular measuring system, max. rotation speed 50 min⁻¹, accuracy +/- 5" # Axis A swivel: +/-110˚ # Max. clamping/part dimensions: Ø 247 x 830 mm; max. weight 360 kg # Rapid traverse: X/Y/Z 40/40/40 m/min # Distance between divider heads B1/B2: 250 mm # Spindle speed: 1-10,000 rpm # Spindle interface: DIN69893-HSK-A63 (with internal coolant supply) # Automatic tool changer: 1x48 tools / chip-to-chip time approx. 2.5 sec # Max. tool diameter: Ø 82 mm / max. length 250 mm / max. weight 5 kg Electrical Connection: # Voltage: 3x400V/50Hz # Total installed power: approx. 45 kVA / 80A Dimensions: # Installation footprint: approx. 4.4 x 2.3 x 3.1 m # Weight: approx. 8,500 kg Equipment Includes: # CNC control: Siemens 840D Power Line # Chip extractor: Spring Knoll # Oil cooling system # High-pressure oil filtration system, up to 80 Bar: Knoll HL 450/1200 # Cooling system for spindle, linear guides, and control cabinet # 2 independent oil lubrication systems Bedpjxwmvkofx Aa Djdb # Oil vapor extraction/recovery system: LTA AC3002 # Fire suppression system: Kraft & Bauer # Part presence detection: with low-pressure air sensors # In-process measurement: Marposs T25 # Tool breakage detection: Blum Novotech # Tool holder detection system in spindle # Documentation: incomplete Machine Condition: NOT OPERATIONAL # Hydraulic oil leakage at Peiseler rotary table # New hydraulic pump available in stock
