Used 2D Measurement Machine for sale (66,835)

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 1104104, measuring range X-axis: 1,205 mm, measuring range Y-axis: 2,005 mm, measuring range Z-axis: 1,005 mm, workpiece weight (max.): 2,000 kg, workpiece height (max.): 1,115 mm, The measuring table has been supplemented with milled aluminum plates. These plates are equipped with M6 holes in a 50 mm grid pattern, allowing for variable clamping options for workpieces. TECHNICAL DETAILS Measuring range X-axis: 1,205 mm Measuring range Y-axis: 2,005 mm Measuring range Z-axis: 1,005 mm Drive speed in CNC mode Traversing speed: 8–250 mm/s Measuring speed: 1–3 mm/s Drive speed in J/S mode High speed: 0–80 mm/s Low speed: 0–3 mm/s Fine speed: 0.05 mm/s Acceleration Acceleration per axis: 0.1 G Max. acceleration: 0.17 G Resolution: 0.0001 mm Lrodpfxjx U Sv He Ad Nsg Measuring table Material: Granite Working area: 1,408 mm x 2,980 mm Clamping threads: M8 x 1.25 Max. workpiece height: 1,115 mm Max. workpiece weight: 2,000 kg MACHINE DETAILS Dimensions & Weight Main unit dimensions (D x W x H): 3,230 x 2,150 x 3,585 mm Weight (incl. stand and control unit): 5,388 kg Compressed air supply Air pressure: 0.4 MPa Air consumption in normal operation: 100 L/min Air consumption from air source: 150 L/min Temperature conditions Ambient temperature: 16–26 °C Thermal fluctuation per hour: 2.0 K Thermal fluctuation per day: 5.0 K Thermal gradient vertical: 1.0 K/m Thermal gradient horizontal: 1.0 K/m Accuracy Accuracy to ISO 10360-2: E = 4.9 + 5L/1,000 Probing error Probing error ISO 10360-2 (TP2): R = 5.2 µm Probing error ISO 10360-2 (TP200): R = 5.0 µm EQUIPMENT Geopack Cosmos 2.3 software PH 10 probe head TP 200 Change rack Note: The machine was in operation until 2013, after which it was professionally dismantled by the manufacturer. The machine was then stored in an industrial hall. The last factory calibration was carried out in 2013. The calibration certificate is available as an attachment in the listing.

Condition: ready for operation (used), Year of construction: 2017, functionality: fully functional, machine/vehicle number: SVC5003396, measuring range X-axis: 500 mm, measuring range Y-axis: 450 mm, measuring range Z-axis: 300 mm, Equipment: documentation/manual, The machine was serviced by the manufacturer in August 2022! TECHNICAL DETAILS Lrjdpjyaq Hyofx Ad Njg Measuring range X-axis: 500 mm Measuring range Y-axis: 450 mm Measuring range Z-axis: 300 mm Total measuring range: 500 x 450 x 140 mm EQUIPMENT Documentation/Manual Calibration sphere Various probe extensions Renishaw 3-position probe change system ZONE3 training part Metrology software

Condition: used, Year of construction: 2011, machine/vehicle number: IntNr231473, KEYENCE Model Series IM-6020, Year 2011 For sale: Optical measuring system KEYENCE IM-6020, in good and fully functional condition. The IM Series is recognized for its rapid, high-precision and operator-independent measuring capabilities, making it the ideal solution for quality assurance, goods-in inspection, and in-process control applications. Technical specifications (excerpt): Model: IM-6020 Year of manufacture: 06/2011 Measuring principle: Optical / non-contact Measuring range (X/Y): approx. 200 × 200 mm Measuring range (Z): Height measurement via autofocus Ljdpfeycu U Tsx Ad Norg Measurement accuracy: up to approx. ±2 µm (depending on measurement conditions) Repeatability: Very high, operator-independent Camera: High-resolution CCD camera Illumination: Incident / transmitted / contour lighting Measurement functions: - Length, angle, radius, and diameter measurement - Contour and form measurement - Pass/fail comparison (OK/NOK) - Automatic dimension recognition Software: KEYENCE IM software for rapid program creation Measurement cycle time: several seconds per part (also for multiple features) Condition: - Used - Well maintained - Fully functional - Immediately ready for operation Machine dimensions: approx. 900 x 500 x 1500 [mm] Machine weight: approx. 32 [kg] Viewing under power is possible by prior appointment. Subject to prior sale and technical modifications or errors.

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, machine/vehicle number: 220708845GC, measuring range X-axis: 400 mm, measuring range Y-axis: 400 mm, measuring range Z-axis: 300 mm, Used demonstration machine, year of manufacture 2022 (TOP condition + fully functional) • OPTIV M 4.4.3 multisensor coordinate measuring machine (CMM) with Dual Z technology • Base frame • 10x CNC motorized zoom with digital color camera and 12-segment LED ring light • HP-S-X1C scanning sensor • 3x HP-S-X1C/H stylus holders (1x M3) • M3 stylus (R-5-SS-3-L50) • HR-X probe rack for HP-S-X1C/H (3 ports, l=400) • Sensor calibration unit without calibration artifacts • Glass standard • Setting ring 20 mm • Reference sphere Ø 25 mm • Measurement and evaluation software PC-DMIS CAD++ (version 2024.2) • Machine control unit (PC) • 2 monitors + mouse + keyboard + desk Lrodpfoycqa Sjx Ad Neg Delivery, commissioning, calibration on request

Condition: good (used), Year of construction: 2013, Ref. -No.: 10528 Lredpfx Adoycpxme Nog Manufacturer: RöMER Type: HEXAGON INFINITE 2.0 Year of construction: 2013 Storage location: Halberstadt Country of origin: Germany Measuring length: 2000 mm

Condition: used, Year of construction: 2010, Mobile articulating measuring arm, coordinate measuring machine (CMM), measuring device Manufacturer: Zett Mess Model: AMPG 2400 Precision Year of manufacture: 2010 - unused Measuring diameter: 2,400 mm 21126ä Ljdpfxewu E D Rs Ad Norg

Condition: excellent (used), Year of construction: 2021, Renishaw Type: Equator 500 Year of manufacture: 2021 Item description: For sale is a Renishaw Equator™ 500, a high-precision industrial 3D measuring and inspection system designed for series production and process control on the shop floor. The Equator 500 is not a traditional coordinate measuring machine (CMM), but a comparative measurement system developed specifically for fast, repeatable measurements directly in the production environment. It is ideal for mass production, in-process measurements, and automated inspection routines. The unit is perfectly suited for checking dimensional accuracy, geometric tolerances, and position tolerances of workpieces, and can provide feedback to CNC machines. The software loads correctly, system status as per display: "Started OK" (see photos). Features & Application Areas: - 3D measurement of workpieces - Comparative measurement principle (very fast inspection cycles) - High repeatability in the micrometer range - Real-time temperature compensation - Suitable for shopfloor use - Automation ready (e.g. robot loading) - Ideal for series production, spot-checks, and process control Typical Industries: - CNC manufacturing - Metalworking - Automotive / supplier industry - Mechanical and tool engineering Technical Data (manufacturer information / approximate values) Manufacturer: Renishaw Model: Equator™ 500 (H+150) Device type: Comparative 3D measuring system / CMM Measuring range: X / Y: approx. Ø 500 mm Z: approx. 150 mm Measurement principle: Comparative coordinate measurement technology Temperature-compensated measurement Accuracy: Very high repeat accuracy Measurement accuracy in the micrometer range (depending on application and strategy) Control & Software Controller type: Equator 500 Software version: 2.5.21.1 RRTLOS version: 5.1.12 Operation via PC-based Renishaw software Electrical Data: Supply voltage: 230 V AC Frequency: 50 / 60 Hz Power requirement: approx. 1 kW Dimensions (approx.) Total height: approx. 1,900 mm Footprint / diameter: approx. 1,200 mm Weight (approx.): 130 kg Condition: used Scope of delivery: (see photos) - Renishaw Equator™ 500 measuring system - Controller / industrial PC - Monitor - Keyboard and mouse - Base frame - Accessories as shown in the photos Ledpfsybbqxox Ad Norg (Subject to technical modifications and errors. All data provided without liability!) For further questions, we are happy to assist you over the phone.

Condition: like new (used), Year of construction: 2019, operating hours: 50 h, functionality: fully functional, measuring range X-axis: 1,000 mm, measuring range Y-axis: 1,200 mm, measuring range Z-axis: 600 mm, Machine description: ZEISS CNC coordinate measuring machine (CMM) in portal design - Measuring volume X = 1000 mm, Y = 1200 mm, Z = 600 mm - Table height TH = 850 mm (standard) - Prepared for tactile active sensors - VAST navigator measuring technology (tactile active scanning) ONLY 50 OPERATING HOURS – THEREFORE AS NEW EQUIPMENT ACCORDING TO ORDER CONFIRMATION – SEE ATTACHED PDF FILE Lrjdjw H Rfdspfx Ad Neg

Condition: used, functionality: fully functional, With this offer, you are purchasing a used Keyence VL-700 optical coordinate measuring machine. Item for sale: 1 x Keyence VL-700 with the following equipment: Lrodpfeyamwnox Ad Njg Includes laptop with application software Includes calibration plate Condition: This offer is for a used device, which may show signs of wear (minor scratches or yellowing). The device has been tested for functionality. Packaging and shipping: You are welcome to view the device during our business hours. Please make an appointment! Seaworthy packaging and worldwide shipping available on request! A functionality test will be recorded on video for you before shipping or collection. For more information, please feel free to contact us personally.

Year of construction: 2002, condition: used, x-travel 210 mm z-travel 350 mm max. loading 25 kg Distance C/Z-axis (mm) 270 mm max. test diameter (mm) 300 mm Rotation axis C (turntable) 0° 90° 180° 270° diameter of rotary table 150 mm Measuring path R-axis 170 mm required space L2,0 x B0,8 x H0,82 m Scope of delivery: - Form measuring system F1004/350 - Work table - Rotary table (rotation axis C) - All documentation - Software TURBO FORM 8.21 + licences - Accessories (see pictures) Condition: - As good as new - Functional Maintenance: - Last inspection on 03/08/2021 - Test report from Jenoptik available Lrjdsrxxc Hspfx Ad Neg

Condition: used, x-travel 500 mm y-travel 400 mm z-travel 400 mm MITUTOYO Euro-M 544 Coordinate measuring machine Measuring machine Size of the base plate: 850x850mm Information on the scope of delivery The package contains only the ordered product. Additional decorative items or other Lrodpfx Adetycuce Neg items shown in the product images are not part of the delivery.

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, measuring range X-axis: 4,000 mm, measuring range Y-axis: 1,600 mm, measuring range Z-axis: 2,100 mm, Hexagon Mercury DCC C1 Mfg date: 4/2014 Model: 40.16.21 Working area: 4000x1600x2100 mm System: B3CLC Head: TesaStar-m Sensor: TP20 Lredpoxy Iz Hefx Ad Njg Safely dismantled and prepared for transport directly by Hexagon Metrology.

Condition: used, functionality: fully functional, measuring range X-axis: 700 mm, measuring range Y-axis: 700 mm, measuring range Z-axis: 600 mm, Equipment: type plate available, Mitutoyo Coordinate Measuring Machine Type Crysta Apex C776 First installation: 2007 (precision measurement room) Temperature compensation for all axes Measuring range X-axis: 700 mm Measuring range Y-axis: 700 mm Measuring range Z-axis: 600 mm Measurement uncertainty: 1.9 + 3L/1000 (µm) Renishaw probe head PH10MQ Renishaw probe rack SCR200 Lsdpfx Adexnl Nke Norg Renishaw sensor TP200 Renishaw TP200 modules: 6 units Measuring software MCosmos-3 v3.4 including GEOPAK including CAT1000P including CAT1000S including SCANPAK including CAD converter PC system and monitor Reference sphere / calibration sphere Delivery free domicile (Germany) Including installation by qualified personnel Including calibration by qualified personnel Including on-site training at customer premises After-sales service (optional)

Condition: like new (used), Year of construction: 2013, functionality: fully functional, Equipment: type plate available, Mitutoyo Coordinate Measuring Machine Type Crysta Apex S544 Multisensor wiring (analog scanning) Temperature compensation for all axes Lsdpfx Adsvvlrlo Nerg Measuring range X-axis = 500 mm Measuring range Y-axis = 400 mm Measuring range Z-axis = 400 mm Measurement uncertainty = 1.7 + 3L/1000 (µm) Mitutoyo UC400 controller Renishaw PH6M probe head Renishaw SP25M sensor Renishaw SM25-1 module (scanning) MCosmos-3 v.3.4 measuring software PC system WIN10 and 27" monitor Reference sphere / calibration sphere Adapter clamping plate Optional software upgrade Optional hardware upgrade Full-service available on request

Condition: reconditioned (used), Year of construction: 2025, operating hours: 10 h, functionality: fully functional, measuring range X-axis: 200 mm, measuring range Y-axis: 200 mm, measuring range Z-axis: 200 mm, warranty duration: 12 months, travel distance X-axis: 200 mm, travel distance Y-axis: 200 mm, travel distance Z-axis: 200 mm, input voltage: 230 V, feed length X-axis: 200 mm, feed length Y-axis: 200 mm, feed length Z-axis: 200 mm, Equipment: documentation/manual, lighting, type plate available, Refurbished Multisensor Measuring Device Mahr MS 222 - LIKE NEW Including certification of acceptance prior to delivery Factory-refurbished premium multisensor measurement center with warranty and guarantee, rebuilt in 2024. INCLUDES the latest software update, 18 months of free software update service, free lifetime software hotline, and user support. Delivery Options: Factory service or worldwide shipping via freight forwarder. Demonstrations: Online or on-site demos available with customer-specific parts. Application consulting provided by accredited Profitech measurement laboratories during project planning. Comprehensive Service Package: – Delivery, setup, commissioning, accuracy verification according to standards, certification, and extensive acceptance documentation. – Tailored training programs available, including online courses. Flexible Payment Options: Rental, lease-purchase, or financing directly through Profitech—no financial institution required. The measuring device can be configured to meet individual customer needs. Specifications: Measurement Range: 200 x 200 x 200 mm Load Capacity: Glass plate 10 kg Scale Resolution: 0.1 μm Maximum Traverse Speed: 150 mm/s Dimensions: 900 x 750 x 950 mm Machine Weight: 170 kg Control Cabinet Weight: 90 kg Length Measurement Accuracy: According to VDI/VDE 2617-6 E2 (X,Y) = (3.2 + L/125) μm Lodpfx Adoglp Nqe Norg Probing System with Optional Probe Package: Renishaw TP20 probing system installed Retrofit: Updated in 2025 Includes PC and Software Illustrative Image by the Manufacturer

Condition: used, functionality: fully functional, Renishaw PH9 Mk2 Probe Head 180° Used item from laboratory stock, fully functional but with signs of use. Ledpfx Adjwrxk Ej Nsrg Optionally, this item can also be supplied with accessories or a probing system (TP2, TP20, TP200...) or preconfigured according to your requirements and availability. Shipping is possible throughout Europe (surcharge applies). As this is a used part, we sell this accessory to the best of our knowledge and belief, but without guarantee or warranty.

Condition: excellent (used), Keyence VL-350 optical coordinate measuring machine with control unit & software (plus VAT) For sale is a Keyence VL-350, a high-precision optical 3D coordinate measuring machine for industrial applications. Technical highlights: Manufacturer: Keyence Model: VL-350 Measuring principle: optical 3D scanning / coordinate measurement Lodpfx Adexpt Rfj Njrg Advantages: Contactless measurement – no deformation of the workpiece High-resolution 3D data acquisition Fast measuring cycles Intuitive operation via included software Scope of delivery: Keyence VL-350 main unit Control unit CD with product software Accessories as shown in the pictures The device is in excellent condition (see photos). Fully functional and ready for immediate use. The stated price is exclusive of statutory VAT. An invoice with separately shown VAT will, of course, be issued. Shipping or collection by arrangement.

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 133084, measuring range X-axis: 3,000 mm, measuring range Y-axis: 1,600 mm, measuring range Z-axis: 2,100 mm, Carl Zeiss Pro T compact 3D coordinate measuring machine TECHNICAL DETAILS Control: C99S / FW: 19:05 Measuring head: RDS CAA No. 165: TP20 Measuring software: CMM-OS 5.4.12 Calibration sphere: 13320 r=15.00000 Measuring range: 3,000 x 1,600 x 2,100 mm CMM expansion coefficient X: 11.9 x 10-6 K-1 CMM expansion coefficient Y: 11.9 x 10-6 K-1 CMM expansion coefficient Z: 10.4 x 10-6 K-1 Holos software version: Holos 2.10 SP23 Rev. 3712 Lodpfjyclnkjx Ad Nsrg CMM-OS software version: CMM-OS 5.4 MACHINE DETAILS Length: 3,500 mm Width: 2,030 mm Height: 3,600 mm Calibration certificate and maintenance schedule from 2022 available

Condition: excellent (used), Year of construction: 2017, Measuring range X 24, Y 18, Z 10 mm Lsdpfx Asu Erf Isd Njrg Magnification 12 - 25 - 38 - 50 x MARCELS MASCHINEN AG

Condition: used, Year of construction: 2002, functionality: fully functional, machine/vehicle number: GLOB000080, measuring range X-axis: 700 mm, measuring range Y-axis: 1,000 mm, measuring range Z-axis: 700 mm, total height: 2,280 mm, overall weight: 1,300 kg, input voltage: 230 V, compressed air connection: 8 bar, year of last overhaul: 2019, Equipment: documentation/manual, Hexagon / DEA Brown & Sharpe Global Image 07.10.07 – Bridge CMM (USED) – RC1 retrofit 2019 + PC-DMIS (env. 2021) We offer a fully functional 3D coordinate measuring machine DEA Brown & Sharpe Global Image 07.10.07 with Hexagon retrofit (2019). Key facts: - Measuring range (X/Y/Z): 700 × 1000 × 700 mm - Accuracy (ISO 10360-2): MPEE 1.7 + L/333 µm (verified by Hexagon, 01/2024) - Machine base: 2002 (mechanical platform) - Retrofit / controller & electronics: Hexagon RC1 (2019) - Software: Hexagon PC-DMIS (environment 2021) - Probe system: Renishaw PH10MQ motorized head + Renishaw TP200 touch probe - Stylus set: approx. 10 pcs included - Accessories: calibration sphere included What’s included: - CMM machine + RC1 controller - PC/workstation with peripherals (monitor etc.) - PC-DMIS license / software key included (details to be confirmed during handover) - TP200 + PH10MQ + stylus set + calibration sphere Condition & history: - Regularly maintained; long-term operation in a controlled metrology environment (high precision optics production). - Stable air bearing operation, granite base in good condition. Utilities: - Air supply: clean & dry compressed air, approx. 6–8 bar (dryer recommended) - Power: 230 V / 50 Hz (to be confirmed) - Weight: approx. ≤ 1.3 t Lrodpfxsycg Dyj Ad Nog Location / availability: - Located in Czech Republic (Přerov area) - Available immediately after agreement (within days) - Inspection / live demonstration possible by appointment. Optional services: We can arrange professional dismantling, loading, transport, installation, leveling, re-calibration and operator training (Hexagon / qualified partner) depending on buyer needs. If you need additional photos, video, or the latest verification protocol, please contact us.

Condition: ready for operation (used), Year of construction: 2017, A Mitutoyo height measuring device including granite plate is available. Granite plate dimensions X/Y/Z: 1000mm/630mm/100mm, max. plate load: 300kg, plate weight: approx. 190kg, measuring range: 630mm, resolution: 0.001mm, min. repeatability: 1.8µm. Machine dimensions X/Y/Z: approx. 300mm/300mm/1050mm, weight: approx. 30kg. Documentation available. An on-site inspection is possible. Lrodpsya Hx Eofx Ad Njg

Condition: excellent (used), functionality: fully functional, • Hexagon measuring arm with protective cover and plastic transport case • Table with grid holes and drawer base Lrsdpfx Adex Tvf Ae Neg

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, measuring range X-axis: 900 mm, measuring range Y-axis: 1,200 mm, measuring range Z-axis: 700 mm, controller model: C98 mit Bedienpult, The machine was retrofitted in 2019 and equipped with a new computer running Calypso software and the VAST Gold probe head! The last calibration was performed in June 2021! TECHNICAL DETAILS Measuring range X-axis: 900 mm Measuring range Y-axis: 1,200 mm Measuring range Z-axis: 700 mm MACHINE DETAILS Control: C98 with control panel EQUIPMENT Ljdpfjya Hfxjx Ad Nerg VAST Gold probe head 7-position probe change magazine Probe change rack Probe accessories Calibration sphere Technical documentation Workstation with monitor Calypso Basic software

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, measuring range X-axis: 500 mm, measuring range Y-axis: 500 mm, measuring range Z-axis: 500 mm, Equipment: type plate available, ZEISS DURMAX MEASURING MACHINE WITH MEASUREMENT ROOM EQUIPMENT: 1. Granite table 2. Calipers from 250-750 mm 3. Micrometers 4. Measurement rods and gauges 5. Scales for components 6. Surface roughness tester 7. Rockwell hardness tester 8. Gloss meter 9. Stereoscopic microscope with camera Ledpfxexqcx Ie Ad Norg

Condition: used, Year of construction: 2000, RAUHEIS Hommel TKLT 1000 ja weight of the machine ca. 200 kg +++++ Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Lodpjg Si Snjfx Ad Nerg Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. +++++
