Machining center

Masterwood Project 351L

Masterwood Project 351 L 3-Axis CNC machine

Description
Aircooled 3-axis milling motor 17,5HP (HSK-63F)
Static frequency inverter for programming speed 1.500-24.000 t.p.m.
Toolchanger with 22 positions
6 pneumatic countersinkable panel guides for loading/positioning heavy parts
Prepared for install. clamps
2 horizontal clamps for beamwood
6 zero points over X-axis (positioning of panels at backside of the supports
8 zero points over X-axis (positioning of panels half-way the supports)
Full reference at rightside over Y-axis
Full reference at leftside over Y-Axis
2 workingfields
1 x 100m³ vacuumpump
24 vacuumcups
Remote control with digital read-out
Auto tool measuring system
Transport waste belt
Drill unit with 19 spindles (32mm center distance) 2,2kW
- 7 vertical drillspindles in X-direction
- 6 vertical drillspindles in Y-direction
Crodpfx Afovu U Ite Ioh
- 4 horizontal drillspindles in Y-direction
- 2 horizontal drillspindles in X-direction
(all drill spindles independently programmable)
Control unit with PC
SINCRO Software CAD/CAM MASTERWORK

Technical specifiactions
Working range in X - 5.130mm
Working range in Y - 1.550mm
Speed in X-Y 80 mtr./min.
Speed in Z 25 mtr./min.
Max. workpiece thickness 200mm
Milling motor power 17,5 HP (S1)
RPM milling motor 1.500 - 24.000
Drill unit 3HP
Toolholdersystem HSK63-F
Toolchanger 22 positions
Vacuumpump 100m³
Dustextraction 250mm
Aircapacity 4.500m³/h
Airspeed 30 mtr./sec.
Compressed air 7 bar
Compressed air consumption 300-500ltr./min.
Fuse value 40 Amp.
Weigth 7.000kg

(All changes, mistakes in technical data, info and prices reserved. Availability subject to prior sales. No guarantee on printed data!)
(Alle Änderungen und Irrtümer in den technischen Daten, Angaben und Preisen sowie Zwischenverkauf vorbehalten! Keine Garantie auf gedruckte Daten!)
