Automatic bar lathe

Maier ML 32 D ProLine

Condition: excellent (used), functionality: fully functional, 1 Used Haeger 412 Insertion Machine Sheet Metal Inserts Stud & Nut Self Clinching For Sale Hsdpewbhipefx Adaeh With tooling and J shape lower tool

Condition: used, Year of construction: 2013, controller manufacturer: Siemens, controller model: 840Dsl, _____ Description: Year of manuf. : 2013 Control : Siemens 840Dsl Turning diam. : 430 mm Turning length : 744 mm Mainspindle: Technology:Motorspindle Speed:5.000 rpm Power (max.):29 kW Torque (max.):250 Nm Barcapacity:65 mm Workpiececlamping:Collet chuck, Hainbuch Spanntop nova Kombi Axzug Gr. 65 Subspindle: Technology:Motorspindle Speed:7.000 rpm Power (max.):22 kW Torque (max.):130 Nm Workpiececlamping:3-Jaw chuck, SMW Autoblok KNCS-N-225-66 Ejector:Pneumatic Movement in Z:750 mm Toolcarrier I (X/Y/Z): Technology:Turret with 12 stations Taper:VDI30 Tooldrive:4.000 rpm, 6,7 kW, 25 Nm Movement in X/Y/Z:270/100/750 mm Eilgang in X/Y/Z:24/10/30 m/min Toolcarrier II (X/Z): Technology:Turret with 12 stations Taper:VDI30 Tooldrive:4.000 rpm, 6,7 kW, 25 Nm Hedpew Tg Adofx Adajh Movement in X/Z:205/750 mm Eilgang in X/Z:24/30 m/min Equipment/Accessory: Chipmanagement:Chip conveyor Coolingmanagement:Internal coolant pumps with High-pressure, 14 bar Rawmaterialfeed:Barloader, EMCO LM 1200 Finishedpartremoval:Workpiece unloading device (pneumatic) with conveyor belt Oilmistseparation:Mechanical extraction, Absolent Toolholder:Misc. static and driven toolholder Further Accessory:Spindlechiller

Year of construction: 2001, condition: excellent (used), Multispindle lathe Schütte AG20 Hedpshrihyofx Adajh

Condition: as good as new (ex-display), Various designs such as round, hexagonal or square and in smooth Hjdoh Dmamopfx Adash smooth version, cross-grooved version or with longitudinal and transverse grooves. A current list of available new and as-new SK32/SK42/SK52/SK65/SK80/SK100 expansion chucks can be found on our homepage. We look forward to your inquiry. STALEX Machine Tools GmbH

Condition: used, Year of construction: 2000, max. working diameter 20 mm max. working lenght 320 mm passage of spindle 24 mm Spindle speed 200 - 10.000 min -1 control MITSUBISHI Turning Automatic Lathe - swiss lathe | CITIZEN - M-20 equipped with bar feeder. The machine is in very good condition. Please refer to further technical details in the attachement of the offer. Hsdpfx Adovnwfzjajh - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: M20 | M 20

Condition: used, Year of construction: 1998, machine/vehicle number: 98BE510071, turning length: 90 mm, spindle speed (min.): 4,000 rpm, spindle motor power: 11 W, overall weight: 6,300 kg, bar passage: 51 mm, 12 position upper turret (6 are driven) -10 position lower turret (5 are driven) - sub spindle - 2 x C axis - equipped with Lns Sprint S2 bar loader with front magazine, fixed and driven tool holders, manuals - Fanuc 18T Control Hjdowidp Iopfx Adajh

Condition: good (used), Year of construction: 2004, CNC long-turning automatic machine Manufacturer: CITIZEN Type: C16 VII Year of manufacture: 2004 with: Mitsubishi Meldas control Synchron spindle Driven tools Back machining High pressure pump Oil mist extraction system Fire extinguishing system Bar loader magazine IEMCA GENIUS 118 Hsdpjwnr Rwjfx Adajh

Condition: good (used), functionality: fully functional, Year of construction: 1997, installation height: 535 mm, pressing force: 85 t, Bending length [mm] 2050.00 Pressing force [t] 85 Control Delem DA 69 Operating hours [h] 76807 Standard equipment: - Upper drive concept in two-cylinder design Y1/Y2 - Electro-hydraulic ram drive in proportional valve technology - Ram travel measuring system with spring compensation via glass scales - Modern block hydraulics - Spherical suspension and inclination of the pressure beam - CNC back stop system - Safe finger adjustment from the front - Self-centering, manual, hardened upper tool holder for vertical tool change - Hardened, manual lower tool holder - Program-controlled lower tool displacement (I-axis) for 2 positions - Flat front cover - Modern protective cover Hedowld R Dspfx Adaoh + 6-axis back stop system + Hydraulic upper tool clamping + Hydraulic lower tool clamping

Condition: used, pressure 50 t chamfer lenght 1500 mm distance between columns 1220 mm Control Cybelec DNC 1200 closing speed 95 mm/min working feed 1-10 mm/sec work stroke 156 mm Hedpfsra Rrhox Adash overrun time 59 ms tracking travel 6 mm throat 200 mm distance table - lower edge of ram 301 mm table width 160 mm table height 850 mm x-axis 550 mm travel R-axis +/- 50 Number of axles 3 (Y, X, R) St. weight ca. 3600 kg a lot of lower and upper tools incl. work light new control in 2003: Cybelec DNC 1200

Condition: used, TECHNICAL DETAILS - Number of axes : 7 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 20 [mm] Hsdpfx Adsuha Nweajh - Max. machining length : 210 [mm] - Spindle speeds : 12000 [rpm] - Spindle power : 3.7 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 20 [mm] - Spindle speeds : 12000 [rpm] - Spindle power : 3.7 [kW] - C axis indexing precision : 0.001 [°] - Number of guide bush holders : 2 GUIDE BUSH HOLDER 1 - Number of positions : 8 - Number of motorized positions : 3 - Live tools speed : 8000 [rpm] GUIDE BUSH HOLDER 2 - Number of positions : 5 - Number of motorized positions : 2 - Live tools speed : 8000 [rpm] END ATTACHMENT - Number of positions : 5 SECONDARY OPERATION - Number of positions : 4 - Number of motorized positions : 4 POWER SUPPLY - Supply voltage : 400 [V] MACHINE HOURS - Number of spindle hours : 18849 [h] EQUIPMENT - CNC : Fanuc 31i-model A - Rotating tool motor on : S11,S21,S51 - Rotating guide bush - Parts catcher - Parts conveying strip - Ejection of workpiece - Chips conveyor - Coolant tank * with high-pressure pump : 20 [bars] - Bar loader : TORNOS SBF320 - Electric transformer - Number of turning tool holders : 5 - Double turning/milling tool holder : 1
