Machining center

Hamuel Reichenbacher Vision II Sprint

Condition: excellent (used), SINGLE SIDE EDGE BANDER (Left) Edges (band in rolls) thickness (Min/Max) mm 0,3 / 3 Edges thickness in strips / lippings (min/max) mm 0,4 / 20 Panels thickness (min/max) mm 8 / 60 Numerical Control POWER CONTROL PC23 Powertouch / WoodCommander (TAPIO Ready) Feeding speed m/min 16-25 Top pressure system with rubber belt Spraying unit (Anti-sticking liquid) In-feed fence, adjustable by N.C. Pre-milling Unit (vertical joint trimmers) 2 x Kw 3 Lamps to heat the workpieces side Glueing Unit (Hot Melt + Quick Melt Unit) FE-MA-TECH + QA/PU + PU65 Band Pressure zone (N.C. adjustment) "C 7" Edge coils supporting unit (No. 2 reels) with SERVO-control edge feeding Snipping (end-cutting) unit PK 25 (2 x Kw 0,8) max 25 m/min Rough Trimming unit BF20 (2 x Kw 1,5) Fine Trimming unit (Multiprofile) MF21 (2 x Kw 0,55) swevelling 0°-20° Dedpfjzku Rpjx Aiiekw Multi Function Unit (Profile contour Trimming unit) FK 30/V20 (1 x Kw 0,7) adjustable by NC Milling-grooving units SF 21 (1 x Kw 5) 0°-90° Profile edge scraping unit MN 21 (Multiprofile, by N.C.) Glue scraping Unit FA 20 Buffing unit FA06 (2 x kW 0,18) + Free Space

Condition: excellent (used), SCM T130E Spindle Moulder with Glazing Bead Unit Spindle diameter: 35 mm Total spindle length: 140 mm Variable spindle speed via frequency inverter: up to 10,000 rpm Main motor power: 5.5 kW Unit for cutting glazing bead Unit power: 2.2 kW Electronic spindle height adjustment Electronic fence adjustment 4-roller feed Masterwood Dodpfxsxbnyre Aiiokw Feed speed adjustment via variator CE certified DTR technical documentation Year of manufacture: 2005

Condition: excellent (used), SINGLE-SIDE EDGE BANDER (LEFT-side) Edges (band in rolls) thickness (Min/Max) mm 0,3 / 3 - in stips / lippings mm max 1 Panels thickness (min/max) mm 14 / 60 (LASER - Max 50) Numerical Control ICOS Open Feeding speed (adjustable) m/min 6 - 30 Top pressure system with rubber belt Spraying unit (Anti-sticking liquid) In-feed fence, adjustable by N.C. Panels in-feed (servo) system A1 / 15 Pre-milling Unit (vertical joint trimmers) 08.378 (2 x Kw 4,5) adjustable by N.C. Glueing Unit (P.U.R. Glue + Quick Melt unit) 283.201 + 283.203 Glueing Unit (Thermofusion with Laser) Laser System LASERLINE Spraying Unit (for anti-release liquid) Band Pressure zone + Edge coils supporting unit (No. 36 + 12 reels) Snipping (end-cutting) 08.42 (Kw 0,2 x 2) work speed up to 30 m/min (0°-25°) Rough Trimming unit 08.0555 HS/LS1 (Kw 1 x 2) Fine Trimming unit (Multi-profile, by N.C. adjustment, for 4 profiles) 08.0587 (Kw 0,66 x 1) Multi-Profile Copying unit by N.C (fine + contour trimming) KFA 30 (Kw 0,5 x 1) max 30 m/min Profile Scraping unit (Multi-profile, by N.C. adjustment, for 4 profiles) 08.0516 Glue scraping unit 08.521 Dsdpfx Aoi Hn Srsiiekw Spraying Unit (for polishing liquid) Buffing unit 08.614 (Kw 0.25 x 4) No. 2 Milling grooving units 08.190 (Kw 4,5 x 2) swivelling 90°/180°/270° (adjustable by CN)

Condition: excellent (used), LOADER (BRIDGE-FRAME) WITH DOUBLE PICK-UP STATION Vacuum system (with its pump) N. 4 Vertical supporting columns of the top supporting beam N. 1 Horizontal top supporting beam (where the carriage slide on) Dkedpfx Aied Rg Dpjiew N. 1 Motorized sliding carriage with horizontal metal arms N. 2 Horizontal metal arms with vacuum cups, adjustables N. 2 Out-side rollers ways (on gound) to in-feed pile of panels to the Loader N. 1 Out-side motorized rollers table (which in-feed the panels to the Unloader), with also cross motorized conveyor belts (at 90°), dimensions mm 7232 (ca.) Separate electric and command panel Electronic Programmer OMRON Perimetral safety metal grids Working capacity (cycles/min) 16 - 20 (ca.) Min/Max panels thickness mm 10 - 50 (ca.) Min dimensions of the panels mm 250 x 320 (ca.) Max dimensions of the panels mm 1200 x 3200 (ca.) Total installed motor power Kw 23.3

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, Double table machining center Working range X 2,590 mm Working range Y 2,260 mm Working range Z 400 mm Number of milling spindles 2 Liquid-cooled spindle Main motor 19.2 kW Max rotational speed 24,000 rpm Aggregate heads 4 C-axis Tool clamping system HSK-F63 Tool change positions central magazine 24 Tool change on each head from 12 positions Boring heads vert. 20 (for each head) Horizontal boring heads X 8 Horizontal boring heads Y 8 Dodpfx Aieuqw E Njiokw Blade for grooves in X, in Y 2 Platens Number 4 360 m³/h vacuum pumps T Jet system for chip blowing Nesting Manual labeling Bar code reader Tool length measurement Software BIESSE BIESSEWORKS ADVANCED, BIESSE B_NEST Weight 17,900 kg

Condition: good (used), Year of construction: 2003, Head processing of posts, boards, and slats for splinter-free machining. Dsdpfx Aogmt Eroiiskw Equipped with a magazine that processes automatically. 2 milling spindles move independently from the outside towards the center, ensuring that there are no splinters.

Condition: new, Year of construction: 2026, Drilling machines for bottom hinges and window handles for precise and efficient drilling of windows. Short introduction: • No setup times between drilling of bottom hinges and window handles • The advantages of drilling from underneath • Accessory kit for bottom hinges • Drilling pattern according manufacturer (e.g. G-U, Roto , Maco, Siegenia Aubi, Winkhaus ... and other manufacturers) • Accessory kit for window handles Dkodedx R Hzspfx Aiisw • Massive precision drilling unit from GANNOMAT

Condition: new, Year of construction: 2026, Drilling machines for bottom hinges and window handles for precise and efficient drilling of windows. Short introduction: • Accessory kit for bottom hinges Dksdpfx Aisdx R Hcoiew • Drilling pattern according manufacturer (e.g. G-U, Roto , Maco, Siegenia Aubi, Winkhaus ... and other manufacturers) • Accessory kit for window handles • Massive precision drilling unit from GANNOMAT

Condition: new, Year of construction: 2024, Exhibition Machine Year of Construction: 2024 Equipment and Technical Data: Robust German engineering for trimming, cross-cutting, formatting, mitre cutting, etc. Dksdew I Ummjpfx Aiisw - Top-mounted control panel at eye level, swiveling, incl. fence guide - 7" touchscreen control for the electromotive positioning of cutting height, saw blade swivel adjustment, cut width stop and optionally for the height and side adjustment of the scoring saw Auto-EPS. Tool database for 50 saw blades and display of the current speed. - Electromotive height and swivel adjustment - Swivel range of the saw blade from 0 to 47° - APA saw blade quick clamping system - Speed of main saw blade 3000/4000/5000/6000 rpm - Protective device that can be swiveled away on both sides, safety guard with interchangeable insert wide/narrow for saw blades up to Ø 450 mm - Width stop with a cutting width of 1250 mm, electromotive - Trolley with a cutting length of 3200 mm and locking every 50 mm - Cross slide with support roller and adjustable extension in both directions. Length stop with mm scale and extension up to 3500 mm with 2 adjustable folding stops and 1 end stop, simultaneously usable as an angle mitre stop on both sides, infinitely adjustable from 0-46° with automatic length compensation and detent for 15°, 22.5°, 30°, 45° fixable. - Push-button control with electronic soft start (start/stop) - Electronic, maintenance-free motor brake - Cutting length 3200 mm - Cutting height max. 155 mm at 90°, 105 mm at 47° - Cutting width at the width stop 1250 mm, electromotive - Length stop on the cross slide extendable up to 3500 mm - Max. saw blade Ø 450 mm, saw blade Ø 400 mm can be lowered under the table - Table size of the cast iron table top 1200 x 665 mm - plus table extension 750 x 655 mm - Table extension 1430 x 940 mm - Table height / working height 900 mm - Extraction connection 120 mm on the machine body, 80 mm on the safety guard - Motor power 5.5 kW / 7.5 HP - Electrical voltage 400 V / 50 Hz - Trolley, length and width stop profiles anodized - Machine body and swivel arm powder-coated in anthracite RAL 7021, cladding sheet safety guard on top in violet blue RAL 5000, on the machine body in light gray RAL 7035 - Footprint: 7110 x 4150 mm - Weight: approx. 1050 kg depending on the model, up to 1250 kg - CE compliant, GS tested, BG-wood dust tested Special equipment: Incl. scoring unit 0.55 kW, electromotive positioning for side and height adjustment via LED display and memory function; when the scoring saw is switched on, the unit automatically moves to the set position values; when switched off, the unit automatically moves under the table into a lateral parking position, so that larger saw blades than Ø 350 mm can also be used without removing the scoring saw blades. Incl. THREE-PHASE MOTOR FOR THE MAIN SAW WITH 7.5 KW (10 HP) instead of 5.5 kW Incl. Quickstep scoring system: Tool-free manual adjustment of the scoring width From 2.8 to 3.8 mm by incremental adjustment by 0.05 mm per step, incl. 1 set of saw blades 125 x 2.8-3.8 x 50 mm Z = 12+12 Incl. SWIVELING DEVICE FOR THE CROSS SLIDE Quick and ergonomic sliding into the parking position Incl. Length stop with digital display mounted on each stop flap, adjustable to 0.1 mm, length max. 3300 mm

Condition: good (used), Year of construction: 2017, operating hours: 9,380 h, functionality: fully functional, machine/vehicle number: 4455, Numerically controlled machining center max. panel sizes: 4,000 x 2,300 mm Dksdpfx Aor E D Eaeiiew 1 Kuka KR420R3300 robot 1 Kuka KR200L140 robot 1 Kuka KRL140-3Comp robot Conveyor belt for removing the scrap metal Suction Ruwac Zone 22
