Offset printing press, web-fed

GOSS M 600 C

Condition: ready for operation (used), Year of construction: 2012, input voltage: 380 V, Description about the machine: 2-sided, sheet fed, thin film, thermal laminator for short runs Max sheet size: 53 x 75 cm Chsdpjwrxqljfx Ab Tsf Min sheet size: 32 x 22.5 cm Max speed: 25 m/min 135 gsm to 450 gsm Quick make-ready Easy operation Small footprint Heavy-duty build quality Feeder Heidelberg-Stahl suction drum Bottom separation, continuous run, top loading Air inflates the sheets from the sides, allowing them to float on a bed of air Operator replenishes sheets on the run, thus providing continuous feed Laminator Electrically heated laminating roller Digital temperature controls up to 120°C (248°F) Rubber counter-pressure roller Choice of manually adjustable hand-cams or pneumatics for nip pressure Film mounted on a quick-change bar Film roll perforating mechanism Sheeter Integral steer & pull separator runs in-line Features include in-feed hold rollers, adjustable anti-curl bar, and variable speed belts Delivery into vibrating jogger table with under-sheet adjustable air control Perfector Sheets are laminated top and bottom in one pass Rubber counter-pressure roller becomes electrically heated Additional heated roller, quick-change bar, and perforating mechanism for 2nd roll of film

Condition: good (used), Year of construction: 2008, OMET FLEXY S330 Year of Manufacture: 2008 _____ Technical Specifications: - Number of Colors: 8 - Web Width: 350 mm - Print Width: 330 mm - Drying System: o UV drying on all stations Chedpfx Aou St R Esb Tsf o 3 additional hot air dryers Unwinder: Single Rewinder: Double _____ Additional features: - 3 Corona Treaters - 1 turn bar - Material thickness: Min. 50 μm, Max. 350 μm - 1 Turn Bar for cold foil lamination - 2 Cutting Stations - 1 Laminating Unit for varnishing and self-adhesive lamination - Coldfoil - Camera Inspection _____

Year of construction: 2025, condition: new, Specification: Maximum sheet size 740 x 1060 mm Minimum sheet size 330 x 400 mm Max. cutting pressure 3.0 MN Maximum number of strokes per hour 9.000 sh/h Suitable for following material Paper to a minimum weight of 80 g/m² Carton board up to a maximum thickness of 2.000 g/m² Corrugated board up to a maximum thickness of 4 mm Equipment: Non-Stop-feeder Manual Non-Stop device for the feeder Stripping station including auxiliary pile for Non-Stop delivery Cedpslyp Emjfx Ab Tehf Centerline operator platform 1 tool set Machine delivery time: 6-8 month after order

Year of construction: 2006, condition: used, Gaemmeler KL 540 Compensating Stacker with attached blocking device VM 500 The compensating stacker KL 540 is equipped with the proven Gaemmerler LiftPack technology. The KL 540 is suitable for bundle heights up to 300 mm. Nummerous options allow to meet the individual customer requirements. Condition: cleaned and ready for production Technical Data: Cycle time ≥ 1,5 sec. (depending on the copy) ≥ 1,2 sec. with Servo pusher (depending on the copy ) Pagination Chsdpfx Ajh Nrh Uob Tof 4 – 96 Heatset / Gravure Formats A 105 – 330 mm (with rear-eject 105 – 310 mm) B 140 – 500 mm D max. 560 mm Layer height max. 200 mm Bundle height max. 300 mm Weight: 1.500 kg approx. Gaemmerler VM500 blocking unit Cycle time: (approx. 6.7 sec) per pack with a pack height of 300 mm and a blocking time of 2 sec. The cycle time per pack increases when the blocking time is increased and the pack height is reduced. The cycle time is also strongly influenced by the output speed of the compensating stacker and thus by the product (surface, format). Sizes: Width: 140 to 500 mm - 5.5" to 19.7" Length: 105 to 330 mm - 4.13" to 13" Pile height: 55 to 400mm - 2.16 to 15.7" Inlet height: 890 mm - 35" Outlet height: 890 mm - 35" Connected load: 16A (2KW, 380/480 Volt, 3 phases, neutral) Air requirement: 1000 standard l/min, 6 bar; unoiled, dry air Weight: approx. 500 kg

Condition: good (used), Size max 510 x 305 x 60 mm Size min 140 x 100 x 3 mm Cover size max 642 mm Cover size min 203 mm Codpfx Abed R Ecpo Tjhf Speed max 12.000 c/h Equipment gathering machine • 18 stations • 18 feeders 3661-210 SF intermediate elements • spiral race away • jogging element perfect binder • 25 clamps • clamp pitch 24" • milling and roughening station • hot melt spine gluing unit • hot melt side gluing unit • premelter • SF stream cover feeder • SF cover nipping and pressing station • lay down device

Year of construction: 1986, condition: good (used), Built in: 1986 Size: 460 x 310 x 60 mm Speed: 6.000 c/h Chededymnbjpfx Ab Tef Equipment: • hand fed • 18 clamps • resting table • milling station • equalizing-leveling • hotmelt spine gluing unit • gauzing station • pile cover feeder • four line scoring • cover pressing station

Year of construction: 2003, condition: ready for operation (used), A total of seven injection molding machines Arburg are available. 1) Arburg 320C 600-250, year of manufacture: 2001, operating hours: 83365h, clamping force: 600kN, screw diameter: 30mm, shot weight: 97g, max. injection pressure: 2470bar, injection volume: 106cm³, centering: 125mm/125mm, max. opening stroke: 550mm, plate distance: 550mm, plate dimensions X/Y: 446mm/446mm, tie bar distance: 320mm/320mm, core pulls: 2, temperature control units: 6, machine dimensions X/Y: approx. 4000mm/2300mm. Including Multilift handling unit. 2) Arburg 420C 1000-250, year of manufacture: 2001, operating hours: 90769h, clamping force: 1000kN, screw diameter: 30mm, shot weight: 97g, max. injection pressure: 2470bar, injection volume: 106cm³, centering: 125mm/125mm, max. opening stroke: 750mm, plate distance: 750mm, plate dimensions X/Y: 570mm/570mm, tie bar distance: 420mm/420mm, core pulls: 2, machine dimensions X/Y: approx. 4700mm/2350mm. Including Multilift handling unit. 3) Arburg 270C 300-100, year of manufacture: 1999, operating hours: 78784h, clamping force: 300kN, screw diameter: 20mm, shot weight: 28g, max. injection pressure: 2500bar, injection volume: 31cm³, centering: 110mm/110mm, max. opening stroke: 550mm, plate distance: 550mm, plate dimensions X/Y: 446mm/446mm, tie bar distance: 270mm/270mm, core pulls: 1, temperature control units: 6. Including Geiger handling unit. 4) Arburg 320C 300-100, year of manufacture: 2000, operating hours: 78784h, clamping force: 300kN, screw diameter: 20mm, shot weight: 28g, max. injection pressure: 2500bar, injection volume: 31cm³, centering: 125mm/110mm, max. opening stroke: 350mm, plate distance: 350mm, plate dimensions X/Y: 446mm/446mm, tie bar distance: 320mm/320mm, core pulls: 1, temperature control units: 6. 5) Arburg 220C 250-60, year of manufacture: 2001, operating hours: 86595h, clamping force: 250kN, screw diameter: 22mm, shot weight: 27g, max. injection pressure: 2340bar, injection volume: 30cm³, centering: 110mm/110mm, max. opening stroke: 425mm, plate distance: 425mm, plate dimensions X/Y: 400mm/400mm, tie bar distance: 221mm/221mm, core pulls: 1, temperature control units: 6. 6) Arburg 270C 300-100, year of manufacture: 2007, operating hours: 59885h, clamping force: 300kN, screw diameter: 20mm, shot weight: 28g, max. injection pressure: 2500bar, injection volume: 31cm³, centering: 110mm/110mm, max. opening stroke: 550mm, plate distance: 550mm, plate dimensions X/Y: 446mm/446mm, tie bar distance: 270mm/270mm, core pulls: 2, temperature control units: 6, machine dimensions X/Y: approx. 3750mm/2400mm. Including Multilift handling unit. 7) Arburg 220S 250-60, year of manufacture: 2001, operating hours: 57504h, clamping force: 250kN, screw diameter: 18mm/22mm, shot weight: 18g/27g, max. injection pressure: 2500bar/2340bar, injection volume: 20cm³/30cm³, centering: 110mm/110mm, max. opening stroke: 425mm, plate distance: 425mm, plate dimensions X/Y: 400mm/400mm, tie bar distance: 221mm/221mm, core pulls: 1, temperature control units: 6, machine dimensions X/Y: approx. 3300mm/1100mm. Documentation available. An on-site inspection is possible. Chedpfx Ajtyyn Hob Tof

Condition: used, Casing-In / Bucheinhängemaschine - Buchformpresse / Book Forming Press Kolbus EMP - FE Chjdpfxsvuaqys Ab Tef Year 1966 Block size min. 125 x 100 x 6mm / max. 370 x 270 x 80mm Case size min. 125 x 210mm / max. 370 x 62 mm Speed up to 36 cycles per minute Online-Video-Inspection by WhatsApp - MS Zoom - Telegram On Stock Emskirchen/Nürnberg - Available Immediately - Can be test

Condition: excellent (used), Year of construction: 2007, MBO K 800.2/6 SKTL AUT with pallet feeder and ASP 66 ME delivery included Parallel break with automated pocket (6 pieces) and roller adjustment MBO slitter shaft cassette Cross and triple fold with pneumatic knife control + pocket is fully automated (can be rotated 180° in a few simple steps) Sword folding unit with rotating three-fold knife LEFT and RIGHT plus Parallel buckle plate in the RIGHT and LEFT knife folding unit The main computer including touch-screen display was renewed in 2022! Cjdpfsrwzmwsx Ab Tehf

Year of construction: 2014, condition: good (used), Year of Construction: 2014 Description: Transforms the shingled stream behind a web press into counted and compensated stacks for further processing or distribution. No. of products per layer / stack are easily programmable. Details as shown below. - Performance/Speed: 55.000 cph (product permitting) Chodpfeh Itciox Ab Tsf - min format product (head/foot x spine): 102 mm x 152 mm (4.00" x 6.00") - max format product (head/foot x spine): 321 mm x 500 mm (12.63" x 19.68") - max pagination: 64p tab & magazine, 32p digest & delta - Product orientation: Spine leading - Low Infeed - Infeed height (min/max in mm): 500-1000 mm - Waste gate - Stream Aligner / Jogger - Single squeeze roller - Laser Counter, model: Scatec-2 - Upper bin height in mm: 127 mm - Upper Bin with Flipper Fingers - Turntable with compression plates - max Stack height in mm: 330 mm - Pneumatic turntable - Pneumatic pusher - Delivery Direction to the right - Delivery height in mm: 876 mm (34.50“) - Delivery Table included - Over all length equipment: 2514-2759 mm - Over all width equipment: ~700 mm - Over all height equipment: ~1800-1950 mm - Input Power: 3 kVA - Voltage: 400 V, 3 Ph, 50/60 Hz - Air requirement: 110 l/min 5.5 bar (6 cfm 80 psi) - Weight: 900 kg (2000 lb) - Equipment at warehouse Helmstedt, airports: Hannover (~1 hr), Berlin (~2 hrs) - Condition: cleaned & in working conditions
