Surface grinding machine

FUM Fabianice FUP 25

Condition: excellent (used), grinding diameter 155 mm grinding length 400 mm centre height 80 mm Q U O T A T I O N We are pleased to offer you ex our stock, subject to prior sale, and error in technical data : STUDER (CH) Universal Precision Cylindrical Grinding Machine Model S 20-12 Year Height of centers / Grinding Ø 80 / 160 mm Center distance / Grinding length Z-axis 400 / 420 mm Internal Grinding Ø mm Workpiece weight flying / between centers max. 5 / 20 kg Table speeds 0,1 – 3,5 m/min Table way automatic, min. 1 mm Table swivable max. 30 ° Universal Grinding Head cross way max 170 mm Rapid infeed way 30 mm Infeed way 1,9 mm Feeds 0,001 – 0,04 mm/Ø Swivable 10 / 30 ° Grinding wheel dimension : bore x width x Æ 127 x 30 x 300 mm Internal Grinding device separately mounted mm Dkedpfx Aszbczxskvsr Workhead Fitting taper/conus MK 2 Speeds 60 – 1.200 rpm Spindle drive 2,2 kW Total electric load approx.. 5 kW - 400 V – 50 Hz Weight approx. 1.000 kg Accessories / Special Features: • Electrohydraulic conventional control with PHILIPS Digital Readout for the infeed (x-axis) • Preinstalled automatic cycles for plunge-in grinding, traverse grinding, internal grinding with roughing, finishing, fine-finishing, spark-out • Separately mounted Internal Grinding Device with belt-driven internal grinding spindle • Workhead with Quck-release collet chuck, swivable 90° • (right now the machine is not equipped with a tailstock, an original STUDER tailstock; used can be supplied for approx.. EUR 5.000,--) • Wet grinding equipment with coolant filtration unit, separate electric cabinet, manuals Condition : Very good ! Universal machine for all sorts of grinding tasks ! Video : ! Delivery : immediately available, FCA Metzingen Payment : 100 % Net, before loading

Condition: new, Year of construction: 2024, carrying capacity per cantilever arm: 500 kg, shelf height: 3,200 mm, total length: 2,100 mm, total height: 3,200 mm, axle spacing: 1,000 mm, load capacity per stand: 2,500 kg, Cantilever rack in hot-dip galvanized design: Scope of delivery: 3 rack stands, height 3.2 m with base section, 1.8 m usable depth (2 m total depth) 12 cantilevers with 1.8 m usable depth (for chipboard with approx. 2.1 m depth) Longitudinal and diagonal struts for 4 m rack length (distance 1.3 m) Fastening material (screws, nuts and washers) Net price: €2,490.00 plus VAT Detailed description: - Stable steel construction made of IPE profiles (screw system) - Rack height 3,200 mm - Load capacity per stand 2,500 kg - Base section and cantilevers with 1,800 mm usable depth - (for 2,100 mm chipboard depth) - Cantilevers height adjustable in 100 mm increments - 4 screwable screws per stand Cantilever arms, standard (= 5 storage levels) - Load capacity per cantilever arm 500 kg - Including longitudinal and diagonal braces for 1,000 mm spacing - Shelf length = 2,100 mm - Including fastening material (without ground anchors) - With assembly instructions and load plates C4 in accordance with DIN standard Dedpfeqt Dmyjx Akvekr - Made in Germany - Short delivery time Our cantilever racks are produced exclusively in Germany. We offer reliable freight with registration before delivery. The material is sensibly packed to enable easy unloading. Delivery for stock items can take place in approx. 1 week after receipt of the order. When installed outdoors, the load-bearing capacity is reduced by the wind and snow load. The subsurface must be made of concrete, level and dowel-capable and must be able to bear the loads. The condition of the soil and load-bearing capacity as well as any official permits required must be checked and guaranteed by the customer. The shelf supports must be anchored to the floor on site; anchoring to the wall is not necessary and not recommended. According to the trade association, it is recommended that the shelf supports on the top storage level have a projection of at least 500 mm above the top edge of the supports.

Condition: used, Year of construction: 1979, SKF cylindrical grinding machine with internal grinding attachment, hydraulically operated. Dkodpfx Aksgt Ea Rjvor

Condition: good (used), Year of construction: 1984, max. wheel diameter 250 mm gear width 275 mm max. module 6 weight of the machine ca. 5,5 t The gear hobbing machine ZFWZ 250 is suitable for the economical production of all hob-processable cylindrical gear types, such a: - spur and helical gear, wormgears and worms, splined shafts, keyed shafts, serrated profiles, chain wheels and ratchet wheels,as well as conical and crowned spur and helical gears. Interchangeable wheels and milling accessories Technical data: - Workpiece diameter (max): 250 mm - Module (max): 6 mm - Axial feed travel (max): 275 mm - Tangential feed travel (max): 100 mm - Tooth helix angle (max): 45 degrees - Milling cutter diameter (max): 145 mm - Milling cutter length (max): 170 mm - Table clamping surface (min): 195 mm - Table clamping surface (max): 470 mm Dodpfx Aksv T Nqasvjkr Power Milling cutter speeds - Stepped in 2 ranges: 56 ... 250 rpm - (Standard version): 90 ... 400 rpm - Infinitely variable in 2 ranges: 63 ... 180 rpm - (special version DC motor): 140 ... 400 rpm Weights - Machine net: approx. 5000 kg - Electrical cabinet: approx. 800 kg - Hydraulic unit + coolant tank + chip transport: approx. 700 kg Overall dimensions (with oil mist filter) - Length: Standard version: 3950 mm DC drive: 3450 mm (or 3350 mm according to table) - Width: 3300 mm - Height: Machine: 1980 mm Machine with DC drive: 2150 mm Electrical cabinet: 2200 mm

Condition: as good as new (ex-display), Year of construction: 2025, Offered is a conventional universal cylindrical grinding machine EMAG Weiss Eco 200. The super compact machine is targeted to users who do not require a CNC control unit, but still set the highest requirements for machining quality. Dkedetmqcwepfx Akvjr The machine is easy to operate and access, which allows for fast machine tooling. TECHNICAL DATA Workpiece diameter: max. 200 mm Workpiece lenght: max. 400 mm Center height: 100 mm Workpiece weight: 30 kg Workpiece headstock - socket: MK4 Tailstock - socket: MK3 Grinding wheel diameter: max. max. 350 mm Price, delivery time and equipment of the machine according to agreement.

Condition: good (used), BSTA 30 / 600 spm Bruderer Feed BBV 120/60 Press force max. 300 KN Power consumption from 1.5 to max. 5.5 KW Technical Air 6-10 bar Operator’s instruction Bed opening 250 mm +/-20mm Stroke: 8-40 mm Strokes per minute.: Max. 600 spm variable from 100-600 spm With Automatic central lubrication Main shaft cooler Pneumatic clutch and pneumatic brake Three working mode Programmable speed and number of strokes, Reverse flywheel mode Feeding of strip from left to right or right to left Strip pushing or pulling Roll feed BRUDERER BBV Strip width ca. max. 190 mm Feeding pitch ca. max. 60 mm Strip max. thickness 3,5 mm Distance between columns 325 mm Dedpfx Aksda Ha Nevjkr Table height from floor 1000 mm Table surface area 540 x 300 Hole in the table 315 x 110 mm Ram surface dia. 250 mm Weight ca. 3.000 kg Dimension ca. 1100 x 1.400 x 2.200 mm Feed pitch up to max. 60 mm adjustable, highly accurate(tol. 0.02 mm) Emergency stop and all other CE safety guards and relays Indexing per minute, infinitely variable Automatic in feed, fully synchronized with punching moment More high speed presses on stock made by Bruderer models BSTA 18, 20, 30, 200, 50 and Schaal and Mabu presses

Condition: good (used), Grindable, largest diameter: 200 mm Dkodpfxelz Nxws Akvor Center distance: 450 mm Weight of the machine approx: 2, 2 t Machine dimensions:

Condition: excellent (used), Year of construction: 1978, grinding length 500 mm Dkodpfxozbczro Akvor grinding width 200 mm

Condition: reconditioned (used), functionality: fully functional, ram adjustment: 40 mm, installation height: 2,500 mm, pressing force: 30 t, stroke length: 40 mm, High Speed Automatic Punching Press. Machine with CE certificate and EUR1 certificate of European origin. Equipped with twin synchronized double rolls feeds for strips widths from 5 mm – 150 mm. PLC touch screen logical interface control. Numerically controlled stamping process (NC). With stroke and speed counter, programmable length, auto stop. Three working modes: Manual, One stroke and Automatic. Pneumatic clutch and brake. Operator’s instruction manual in English. Stroke power: 300 [KN] (30 [tons]). Adjustable stroke: 8-40 [mm]. Table: 540 x 300 [mm]. Adjustable speed 100 – 600 strokes per minute up to 10 in one second. Maximum strip thickness 2.5 [mm]. Dodovkfmrspfx Akvskr Central lubrication. Power consumption 5.5 [kW] Technical Air 5-10 [bar]. Warranty: 1 year. Two feeders are used when you need to stamp very thin, soft strip or very heavy strip, to secure precise feeding. All specifications non-binding , subject to change without notice.

Condition: refurbished (used), functionality: fully functional, Studer S20 Favorit (latest version with updated PLC/automation) High-precision cylindrical grinding machine for external and internal grinding. Dkodpfx Akszcytbjvsr - Distance between centers: 400 mm - Height between centers: 100 mm - Currently undergoing a complete reconstruction (retrofit) to deliver performance and precision comparable to a new machine. - Equipped with renewed components and adjusted to ensure maximum reliability and precision. - A wide range of accessories is available upon request. - Delivery time: please inquire - The photographs show a reference machine of the same model, which was reconditioned by us. Project reference: OP26-003
