Vertical lathe

EMAG VL5i

Condition: ready for operation (used), Year of construction: 2015, operating hours: 15,050 h, functionality: fully functional, travel distance X-axis: 660 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 200 mm, spindle speed (max.): 7,500 rpm, turning diameter: 220 mm, turning height: 175 mm, TECHNICAL DETAILS Turning diameter: 220 mm Swing diameter: 270 mm Turning height: 175 mm Control & axis travel Control: SIEMENS 840 D SL X-axis: 660 mm Y-axis: 300 mm Z-axis: 200 mm Iedpfjwynigox Ah Neht Spindle & tool change Max. speed: 7,500 rpm Tool changer: 12-station MACHINE DETAILS Total power requirement: 24 kW Machine weight: approx. 5.2 t Space requirement: approx. 2.5 x 1.6 x 2.3 m

Condition: used, Technical details: turning diameter: 626 mm turning length: 3000 mm Turning diameter: 600 mm spindle bore: 100 mm spindle turning speed range: 2800 U/min weight of the machine ca.: 18 t Machine overhold and retrofit in 2003 with SIEMENS 840 D control - NC steady rest - 12-fold revolving head - splash doors - tailstock Iedpfjvgmimjx Ah Njht - coolant device *

Condition: repair required (used), Year of construction: 2011, functionality: not functional, machine/vehicle number: 102920, Technical Characteristics: Work Area - Maximum diameter of clamping plate: 250 mm - Maximum turning diameter: 270 mm - Maximum machining diameter: 220 mm - Maximum workpiece length: 175 mm - X-axis travel: 660 mm / Rapid traverse in X: 60 m/min Iedexxiwyjpfx Ah Njht - Z-axis travel: 300 mm / Rapid traverse in Z: 30 m/min - Standard enclosed automation (number of loading stations by workpiece diameter: 14/(80...200 mm), 18/(30...160 mm), 30/(30...85 mm)) Main Spindle - Spindle according to DIN 55026: Size 6 - Max. speed: 4,500 rpm - Power at 100% / 40% duty cycle: 18 / 27 kW - Torque at 100% / 40% duty cycle: 202 / 303 Nm Turret with Driven Tools - Tool holders per DIN 69880: 12 x VDI40 - Number of positions: 12 - Max. tool length (including holder): 190 mm - Max. speed: 6,000 rpm - Max. torque at 10% duty cycle: 37 Nm, at 25%: 26 Nm, at 100%: 14 Nm Electrical Equipment - Operating voltage: 400 V - Connected load: 36 kW / 80 A Dimensions - Total dimensions: Length: 3,120 mm (4,185 mm with chip conveyor), Width: 2,266 mm, Height: 3,200 mm - Weight: 7,500 kg Main Features and Capabilities: - Vertical design: Enables optimal chip evacuation as well as easy loading and unloading - Control: Siemens 840D - High precision: Positioning accuracy in X, Z, and Y axes ±0.001 mm, Heidenhain linear scales - Main spindle: High power and broad speed range - Automated loading/unloading: Automated workpiece loading and removal via integrated system - Driven (live) tools: Supports live tooling for extended machining range, including drilling and milling - Part detection sensor with compressed air gauge through spindle: SMW Autoblock Linear Position Sensor LPS-X - In-process control: Marposs T25 - Chip conveyor - Coolant chiller: Texa TCW55PMSBXMF000, max. 30 bar input - Coolant filtration with paper belt filter: Micron filter EVO500Pro+KMT150, 550 liters, 80 l/min - Documentation: Digital & hard copy manuals available Machine Status: NOT WORKING - Lifetool motor - Slideways & carriages (X & Z axes) - Hydraulic pressure compensation block

Condition: used, Year of construction: 2011, functionality: fully functional, machine/vehicle number: 102821, Technical characteristics: Work Area - Maximum diameter of the clamping plate: 250 mm - Maximum turning diameter: 270 mm - Maximum machining diameter: 220 mm - Maximum workpiece length: 175 mm - X-axis travel: 660 mm / Rapid traverse in X: 60 m/min - Z-axis travel: 300 mm / Rapid traverse in Z: 30 m/min - Standard closed automation (number of loading nests by workpiece diameter: 14/(80...200), 18/(30...160), 30/(30...85)) Main Spindle - Spindle interface to DIN 55026: Size 6 - Maximum speed: 4,500 rpm - Power at 100% / 40% duty cycle: 18 / 27 kW - Torque at 100% / 40% duty cycle: 202 / 303 Nm Tool Turret with Driven Tools - Toolholders, cylindrical shank DIN 69880: 12x VDI40 - Number of stations: 12 - Maximum tool length including holder: 190 mm - Maximum speed: 6,000 rpm - Maximum torque at 10% duty cycle: 37 Nm, 25%: 26 Nm, 100%: 14 Nm Electrical Equipment - Operating voltage: 400 V - Connected load: 36 kW / 80 A Dimensions - Dimensions (L x W x H): 3,120 mm (4,185 mm with chip conveyor) x 2,266 mm x 3,200 mm - Weight: 7,500 kg Main Features and Capabilities: - Vertical design for optimal chip removal and easy access for loading/unloading - CNC control: GE Fanuc Series 32i Model A - High precision with X, Z, and Y axis positioning accuracy ±0.001 mm (Heidenhain linear scales) - Powerful main spindle with wide speed range - Integrated automation for part loading/unloading - Driven tools available for both milling and drilling operations - Workpiece detection sensor with compressed air gauge through spindle: SMW Autoblock Linear Position Sensor LPS-X Isdpjxxikgefx Ah Nsht - In-process gauging: Marposs T25 - Chip conveyor included - Documentation: Complete, both electronic and paper versions Machine status: IN OPERATION

Condition: used, Year of construction: 2000, functionality: fully functional, machine/vehicle number: 500358, turning length: 1,250 mm, turning diameter: 300 mm, spindle motor power: 43 W, spindle speed (max.): 5,000 rpm, spindle bore: 65 mm, INDEX G300L with Promot gantry loader. Machine is still in production and under power. The promot loader has 2 rotary indexing belts with approx. 30 pallet spaces each. The machine is equipped with high-pressure cooling lubricant (40 bar), paper belt filter and tool changer. For further information please contact us by mail. Ihedpfx Ahou Nmq He Nst

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, travel distance X-axis: 660 mm, travel distance Z-axis: 300 mm, TECHNICAL DETAILS Ihedpfx Aexy Hp Neh Nst X-axis travel: 660 mm Z-axis travel: 300 mm Chuck diameter: 250 mm Swing diameter: 270 mm

Condition: used, Year of construction: 2015, turning diameter 220 mm swing diameter 270 mm turning height 175 mm Control SIEMENS 840 D SL x-travel 660 mm y-travel 300 mm z-travel 200 mm turning speeds 7500 U/min tool change unit 12 fach Iodpfxovxwrcs Ah Noht total power requirement 24 kW weight of the machine ca. 5,2 t dimensions of the machine ca. 2,50 x 1,60 x 2,30 m

Condition: refurbished (used), Year of construction: 2007, functionality: fully functional, year of last overhaul: 2023, Offered is a VSC 250 vertical turning center, which has been mechanically and electrically overhauled by EMAG. The control system was upgrated to Siemens Sinumerik One. Depending on requirements, the machine can be equipped with various automation options (shuttle, O-type conveyor, L-type conveyor, turn around station) and other peripherals such as chip conveyors, coolant systems, etc. CONTROL Siemens Sinumerik One TECHNICAL DATA Workpiece diameter: 250 mm Workpiece height: 100 mm X-stroke: 860 mm Z-stroke: 200 mm MAIN SPINDLE power 28 kW Ihsdpfx Ahorq Dams Not TOOL CARRIER EMAG wheel turret, 12x VDI 40 Delivery time and additional equipment of the machine on request.

Condition: ready for operation (used), Year of construction: 2015, operating hours: 15,050 h, functionality: fully functional, travel distance X-axis: 660 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 200 mm, spindle speed (max.): 7,500 rpm, turning diameter: 220 mm, turning height: 175 mm, TECHNICAL DETAILS Turning diameter: 220 mm Swing diameter: 270 mm Turning height: 175 mm Control & axis travel Control: SIEMENS 840 D SL X-axis: 660 mm Iodpsxf Apvofx Ah Noht Y-axis: 300 mm Z-axis: 200 mm Spindle & tool change Max. speed: 7,500 rpm Tool changer: 12-station MACHINE DETAILS Total power requirement: 24 kW Machine weight: approx. 5.2 t Space requirement: approx. 2.5 x 1.6 x 2.3 m

Condition: used, TECHNICAL DETAILS - Number of axes : 2 - Number of turrets : 1 - Max. turning diameter : 220 [mm] Ihjdpfx Ahoxc N I Te Njt - Maximum workpiece height : 175 [mm] - X/Z stroke : 660/300 [mm] MAIN SPINDLE - Spindle speeds : 4500 [rpm] - Spindle power : 27 [kW] - C axis indexing precision : 0.001 [°] TURRET - Tool type : VDI40 - Number of positions : 12 POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 36 [kW] WEIGHT & DIMENSIONS - Machine floor space : 3120/2266 [mm] - Machine height : 3200 [mm] - Machine weight : 7000 [kg] MACHINE HOURS - Number of hours under power : 74809 [h] - Number of spindle hours : 30521 [h] EQUIPMENT - CNC : Fanuc 32i-A - Interface : Ethernet / RS232 / USB / PCMCIA - Coolant tank - Chips conveyor - Parts conveying strip - Chuck 3 jaws

Condition: used, Year of construction: 2001, workpice diameter max. 90 mm forward bearing diameter 140 mm Turning speeds mainspindle 4.200 U/min Power 35,5 KW Ijdpfxjvzcnbo Ah Nsht Control INDEX C 200-4 travel -x axis 1.500 mm travel -z axis 340 mm travel -y axis 180 mm b-axis 360 ° CNC turning and milling center vertical | INDEX - V300 equipped with a turret for driven tools as well as y- + B- axis. Further information: - direct measuring system on X + Z The machine is in good condition. For additional equipment information please refer to the original order confirmation which is included in the offer of this machine. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: V-300 | V 300

Condition: used, Year of construction: 2016, functionality: fully functional, machine/vehicle number: 103979, We offer for sale CNC vertical lathe EMAG, VL5i F., year of production 2016, used, preserved, functional. Still in production. Must see. EXW price incl. loading. Ihedpfx Asuyh Tdjh Not More information on request.

Condition: used, functionality: fully functional, We are offering a complete EMAG line consisting of 6 machines (VL3, VL5, and VL5i – see nameplates) including central chip conveyor and coolant supply. The machines are in operational condition and can be inspected under power at our facility in 47225 Kedzierzyn-Kozle, Poland. We are happy to sell internationally, but please note that special packaging will be required for overseas shipment. Disassembly and export packaging suitable for shipping overseas are the buyer’s responsibility. The listed price is for a single machine without chip conveyor and coolant supply. If you purchase the entire line, the price is EUR 120,000, including chip conveyor and coolant supply. Ihodpfx Aju U D E Njh Nst

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, TECHNICAL DATA MACHINE SPECIFICATION WORKING RANGE • Max chuck diameter. 260 mm • Max swing diameter. 260 mm • Max machining diameter. 220 mm • Max part length. 110 mm • Travel X axis. 570 mm • Working stroke Z axis. 250 mm • Travel Z axis. 200 mm CLOSED STANDARD AUTOMATION Isdpfjx Elf Aox Ah Nsht • Number of carrier frames for workpiece diameter 80 to 220 mm. 14 pieces • Number of carrier frames for workpiece diameter 30 to 160 mm. 18 pieces • Number of carrier frames for workpiece diameter 30 to 85 mm. 30 pieces • Max total load. 120 kg PICK UP SWITCH POINTS • Pressed. 1 mm • Over pressed. emergency stop. 5 mm • Pickup spring travel max. 30 mm CHAIN SYSTEM • Chain length. 182 inches • Chain pitch. 1 inch (25.4 mm) • Chain tension at 20 carrier frames. 400 N • Chain wheel. Z equals 30 • Gear ratio. i equals 100 • Motor revolution per belt revolution. 540 LOADING TIME • Loading time. 2 to 4 seconds MAIN SPINDLE • Spindle flange according to DIN 55026. Size 6 • Spindle bearing front diameter. 110 mm • Max spindle speed. 4500 rpm (5500 optional) MAIN DRIVE. AC ASYNCHRONOUS MOTOR. TYPE 1MB241H • Power at 100 percent duty cycle. 18 kW • Power at 40 percent duty cycle. 27 kW • Torque at 100 percent duty cycle. 202 Nm • Torque at 40 percent duty cycle. 303 Nm • Corner speed. 850 rpm FEED DRIVE • Rapid feed speed X axis. 60 m per minute • Rapid feed speed Z axis. 30 m per minute • Feed force X and Z. 5.5 kN • Ball screw diameter X and Z. 40 mm • Acceleration. 5 m per second squared TOOL CARRIER • Cylindrical tool shank mount according to DIN 69880. twelve positions • Shank diameter. 40 mm • Max tool length including holder. 190 mm • Max swing diameter. 740 mm TOOL CARRIER WITH DRIVEN TOOLS • Cylindrical tool shank mount according to DIN 69880. twelve positions • Shank diameter. 40 mm • Max speed. 6000 rpm • Corner speed. 3000 rpm • Max torque at 10 percent duty cycle. 45 Nm • Max torque at 40 percent duty cycle. 30 Nm • Max torque at 100 percent duty cycle. 15 Nm ELECTRICAL EQUIPMENT • Operating voltage. 400 to 480 V • Control voltage DC. 24 V • Control voltage AC. 230 V • Frequency. 50 or 60 Hz • Connected load. 42 kW • Supply fuse rating. 63 A • Electrical design standard. VDE 0113 DIMENSIONS AND WEIGHT • Length. 2680 mm • Length including chip conveyor. 3820 mm • Width. 2040 mm • Height. 2400 mm • Machine weight. approx 6500 kg NOISE EMISSION • According to DIN 45635. • Measured sound pressure level. 78 dB(A) during continuous cutting on a cylindrical test part.

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, For Sale: Used EMAG VL5i Vertical CNC Lathe (Year of Manufacture 2014) - High Precision and Efficiency We are offering for sale a used EMAG VL5i Vertical CNC Lathe from the year of manufacture 2014. This machine is designed for efficient and precise turning operations. Thanks to its vertical design and integrated automation, this machine is ideal for large-series production of components, ensuring high efficiency and repeatability. Main Features and Capabilities: • Vertical Design: Optimal chip evacuation and easy loading/unloading. • Integrated Automation: Standardly equipped with a closed automation system with a chain conveyor, enabling continuous operation and minimizing operator intervention. • High Precision: Rigid guides and precise servo drives ensure high machining accuracy. • Machining Versatility: The possibility of using live tools extends the machining range to include drilling and milling. Technical Data (EMAG VL5i): Working Area: • Max. chuck diameter: 250 mm • Max. swing diameter: 270 mm • Max. workpiece diameter: 220 mm • Max. workpiece height: 175 mm • X-axis travel: 660 mm • Z-axis travel: 300 mm Standard Closed Automation: • Number of transport arms for workpiece diameter (from...to) and max. workpiece weight: o 16 (80...220 mm) / 10 kg Ihjdpewqw Umjfx Ah Net o 22 (30...160 mm) / 8 kg o 37 (30...85 mm) / 4.5 kg • Max. permissible total load: 175 kg • Chain length: 224 inches • Number of chain links: 224 • Chain pitch: 1 inch (25.4 mm) • Loading time: 2-4 s Main Spindle: • Spindle flange according to DIN 55026: Size 6 • Spindle bearing, front diameter: 110 mm • Max. rotational speed: 4500 rpm • AC-asynchronous main motor: o Power at 100/40% ED: 18/27 kW o Torque at 100/40% ED: 200/300 Nm o Corner speed: 850 rpm Feed Drive: • Rapid traverse speed in X: 60 m/min • Rapid traverse speed in Z: 30 m/min • Feed force in X and Z: 10 kN • Ball screw diameter X / Z: 40 mm Tool Carrier: • Number of stations: 12 • Cylindrical shank holder according to DIN 69880 • Shank diameter: 40 mm • Max. tool length including holder: 190 mm • Max. swing circle diameter: 760 mm Tool Carrier with Live Tools: • Number of stations: 12 • Cylindrical shank holder according to DIN 69880 • Shank diameter: 40 mm • Max. rotational speed: 6000 rpm • Corner speed: 3000 rpm • Maximum power: 8.5 kW • Max. torque at 10% ED: 40 Nm • Max. torque at 40% ED: 24 Nm • Max. torque at 100% ED: 15 Nm Electrical Equipment: • Operating voltage: 400 V • Control voltage - DC: 24 V • Control voltage - AC: 230 V • Frequency: 50 Hz • Connected load with/without live tools: 36 kW • Main fuse: 80 A • Electrical execution: VDE 0113 Dimensions and Weight: • Length: 3120 mm • Length including chip conveyor: 4185 mm • Width: 2266 mm • Height: approx. 3200 mm • Machine weight: approx. 7500 kg
