Surface Grinding Machine

ELB-Trade Star 2

Condition: excellent (used), functionality: fully functional, We are offering various used 3R systems here. The systems are in very good condition and fully functional. Inspection by appointment possible. Item 1 System 3R-203 Rotary Element WEDM 360° Item 2 System 3R-201J Adapter WEDM 90° Item 3 System 3R-201J Adapter WEDM 90° Item 4 System 3R-201J Adapter WEDM 90° Item 5 System 3R-202 MiniBlock Item 6 System 3R-202 MiniBlock Item 7+8 System 3R-204 Height Adjustment Adapter WEDM Item 9 System 3R-218/30S Holder Sets Item 11 System 3R-602.21 Manual Chuck Macro Item 12 System 3R-294.3 Vise Nedpfoxqn Ubsx Aa Dowg Item 15 System 3R-293.3 SuperVice Item 17 System 3R-200-4J-2 470mm System 3R-200-4J-2 470mm System 3R-200-4J-2 330mm System 3R-200-4J-2 138mm Item 18 System 3R-239–545 0006-V01 System 3R-239–495 Shipping and inspection possible!

Condition: good (used), Year of construction: 2000, CNC surface and profile grinding machine Fabr.Ziersch & Baltrusch Type:PROFITLINE ZB 62 NC Year of manufacture.2000 grinding range : 600X270mm Nwodpfxsfrbcko Aa Djg Electromagnet with continuous transverse pole pitch 600X200mm. P = 4 mm Wet grinding device, with automatic paper belt filter, machine trough. Complete machine documentation available.

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, workpiece weight (max.): 1,000 kg, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 310 mm, wire diameter (max.): 0.3 mm, workpiece height (max.): 310 mm, workpiece width (max.): 820 mm, workpiece length (max.): 1,050 mm, feed rate X-axis: 600 m/min, feed rate Y-axis: 1,000 m/min, table load: 1,000 kg, Equipment: compressor, fridge, FANUC Robocut α-C600iB Nwodpfxsyhb D Ee Aa Dsg

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 500 mm, Equipment: chip conveyor, rotational speed infinitely variable, DMG-MORI DMU 60 EVO linear Year 2014 Travel X/Y/Z: 600 mm x 500 mm x 500 mm Motor spindle SK40 with 18,000 rpm NC tilting rotary table, B and C axes Tool magazine with 60 stations Heat exchanger for spindle and table Dynamic package Control: Siemens 840 D SL with Shop-Mill Infrared probe Heidenhain TS 649 Blum laser tool measurement Scraper belt conveyor, HPC with paper band filter and 80 bar Oil mist emulsion separator Programmable coolant nozzles Electronic handwheel, mode 4 Turning and milling cycle Nwedpfx Aaexvhrwj Deg

Condition: refurbished (used), Measuring Range X/Y/Z = 900 x 1200 x 850mm Accuracy 4,0 + 4,5L/1000 (origin setup, now better after Retrofit) Completely refurbished 2018 with new Pantec Eagle Pro Controller Probesystem is Renishaw PH10MQ and SP25M Software Inspect3D Inca Premium actual version Computer is a HP z240 Option : Laserscanner (e.g. Kreon) Nodpfxodpak Re Aa Dswg Probe changer

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Equipment: type plate available, Fast precision coordinate measuring machine and gear measuring center. Moving gantry with patented TRICISION™ technology Nwjdpfx Aasv S Dk Ej Dog X 900 / Y 1500 / Z 700 B5 control system (retrofit 2021) High-resolution Leitz LSP-S2 3D measuring head Measurement uncertainty according to DIN EN ISO 10360-2: 0.9 + L/350 µm 8-position probe change system Large package with probe accessories PCDMIS CAD++ 2024 software 12-month warranty Computer, 32" screen Installation, commissioning, and acceptance according to DIN EN ISO 10360-2, 4, and 5

Condition: like new (used), CNC vertical jig boring machine WMW MIKROMAT Nsdegy E Dpspfx Aa Dswg Travel X: 1120 mm Travel Y: 710 mm Spindle travel Z: 315 mm Travel W: 630 mm Numerical Command: CNC NUM 1060 Spindle: Ø 125 mm Cone: SA40 Rotation: from 36 to 2240 RPM Table size: 1400 x 900 mm Distance between colums: 1080 mm Maxi distance spindle nose/table: from 0 to 900 mm max Maxi eligible load on table: 1000 kg max Separate electrical panel Machine renewed in 2000 with CN NUM1060 Voltage: 380 V Dimensions (L x W x H): 4000 x 2460 x 3030 mm Weight: approx. 9 T

Condition: used, functionality: fully functional, wheel width: 800 mm, module 1-6 diameter max 600mm Nwodpsxhck Sjfx Aa Dog digital reading Complete machine with documentation, tool holders, change gears,...

Condition: new, Year of construction: 2021, functionality: fully functional, Stock machine "NEW" – available at short notice! (Subject to prior sale) Control: Fanuc 0i-MF Plus, 10.4" with Manual Guide i & 2 MB NC memory LOOK-AHEAD function, 400 blocks Machine Table: Table size: 950 x 550 mm Load capacity: 800 kg Nwjdpfx Aajifn N No Djg T-slot width: 18 mm Number of T-slots: 3 Distance between T-slots: 150 mm Travel axes: Travel X/Y/Z: 860/550/550 mm Spindle nose to table surface: 150 – 700 mm Linear guides & speeds: Ball linear guides in X/Y axes Roller linear guide in Z axis Rapid traverse X/Y/Z: 40/40/30 m/min Feedrate during milling: 0 – 10,000 mm/min Smallest increment: 0.001 mm Tool magazine (CAM-Type) / changer: Number of magazine pockets: 30 System: random access Max. tool diameter: Ø 75 mm Max. tool diameter with adjacent pockets free: Ø150 mm (40 tools: Ø130 mm) Max. tool length: 300 mm Max. tool weight: 7 kg Spindle: Spindle taper: SK-40 Drive power (30min/cont.): 18.5/11 kW 15,000 rpm direct-drive spindle Spindle oil cooler Coolant, chip, and compressed air management: Coolant system incl. 300 liter tank and pumps External coolant around spindle Chip augers right and left in machine bed Compressed air nozzle at spindle (M32/M33) Compressed air through spindle (M38/M39) Compressed air and coolant gun Other features: Swiveling operator panel Electronic handwheel (wired) Central lubrication oil/air Full enclosure Work light Heat exchanger at control cabinet Auto power-off function Hand tool set Signal lamp Transformer 400 VAC, 50 Hz CE declaration of conformity according to European directives Electrical and pneumatic requirements: Electrical connection: 36 kVA Required pneumatic input pressure: 6 bar Dimensions: Machine size: W2,260 x D2,900 x H2,775 mm Required installation area: W3,160 x D3,000 x H3,000 mm (incl. chip conveyor ejection to the left) Machine weight: approx. 5,400 kg (net) Available special equipment: Spindle: - Direct-driven spindle SK-40, 15,000 rpm - Drive power (30min/cont.): 18.5 / 15 kW, (FANUC motor) Tool magazine / changer: - Drum-type tool magazine with 30 pockets, DIN69871, SK-40 Rotary or additional axes: - Preparation for 4th axis (FANUC controls), incl. wiring and Harting connector, without axis drive Coolant, chip, and compressed air management: - Bed flushing - Through-spindle coolant pump, 20 bar pressure, for direct-driven spindles - Includes cartridge filter - Belt-type chip conveyor including chip cart (chip discharge at front, to the left side of the machine) Measuring and monitoring systems: - RENISHAW OMP-60 probe with infrared transmission system for workpiece measurement, incl. probe holder, repeatability: 1μm - RENISHAW NC4+ tool laser measurement system and tool breakage monitoring in the machine, incl. bracket - Auto-door (side door) - Pneumatic interface for workpiece clamping - Clamping devices as shown With RoboJob Mill Assist 25kg (Year of construction 2025 – NEW) - Full enclosure - Double gripper Available immediately

Condition: excellent (used), Year of construction: 1999, CNC Lathe MAZAK SQT 200 MS Year of manufacture: 1999 Including indicated tools and sub-spindle Control: Mazatrol PC Fusion CNC 640T Technical specifications: Max. swing diameter: 525 mm Max. swing diameter over saddle: 350 mm Max. turning diameter: 300 mm Bar work up to max. diameter: 51 mm Main spindle: Speed range: 35 – 4,000 rpm Main drive power: 15 kW Max. torque: 350 Nm Spindle nose: A2 – 6 inch Spindle bore: 61 mm Spindle positioning C-axis: 0° - 360°/0.001° Second spindle: Speed range: 35 – 5,000 rpm Drive power: 7.5 kW Max. torque: 57 Nm Indexing: 72 positions/5° Tool turret: Number of tool stations: 12 (freely configurable with stationary and driven tools) Turret indexing time – 1st station: approx. 0.2 s Driven tools: Drive power: 3.7 kW Max. torque: 35 Nm Speed range: 25 – 4,500 rpm Travel: Turret travel: X-axis: 190 mm Z-axis: 575 mm B-axis: 585 mm Rapid traverse: X-axis: 30 m/min Z-axis: 30 m/min B-axis: 18 m/min Feed range: X/Z-axis: 0 – 5,000 mm/min C-axis: 1 – 2,000°/min Nsdpfx Asx Hgl Hsa Dswg
