L&Z lathe / DREHMA 410x1500

DREHMA D410x1500

Condition: good (used), Year of construction: 1984, Offer 24126 Motorized bar turning machine + ring and bending machine Technical data: - Bending process mot. with automatic or manual operation - Bending capacity square bars ST 37 up to approx. 30 mm - Bending capacity flat bars ST 37 up to approx. 30 x 8 mm - Bending length between the twisting units adjustable up to approx. 1200 mm - Min. twisting length 10 x material thickness (long side) - Bending time preselection / bending length preselection - Right - left rotation - Tailstock Dodpfx Aor Ik N Dsfnekg - Arch + ring bending device GRB 66 with various roller sets - Bending capacity - flat steel 60x10 mm high R 700 mm - Flat steel 70x12 mm flat R 500 mm - Round tube 1 ½" x 2 R 800 mm - Square tube 40x40x3 R 1500 mm - Angle 45x6 R 600 mm - Round tube roller sets steel 1 ¼" , plastic 1 ½" - Standard roller set - Space requirement approx. W 1850 x H 1300 x D 700 mm - Drive 400 V / 2.2 kW - Weight approx. 250 kg

Condition: new, Welding system for sliding tarpaulins, 2.7KW HF power. Operation via touch panel, automatic power control, with integrated quiet compressor on request, with table and guide rail. Also available without a table on request, e.g. when replacing existing systems such as Herfurth PLTR300/400, the guide is adapted to the table. (Image 2) Table frame made of aluminum profile, 30mm worktop, length as desired Dedpfxjvw S Sno Afnekg We currently have between 4 and 6 months of construction time Image 3 a mobile PSA150 system with 15KW power and Image 4 an SP45 for sliding with 4.5KW All data and inquiries are welcome by email

Condition: used, Year of construction: 2015, Vertical CNC machining center with 3 controlled axes and exceptional Y-axis machining capacity. It is equipped with a vacuum table clamping system that holds plates and sheets with the help of vacuum. This solution is particularly effective when machining thin parts that are difficult to fix using conventional clamping systems. The machining center is equipped with a set of valves that allow you to turn on or off different table zones, thus concentrating the vacuum in a specific area and optimizing the clamping of small components. Possibility of performing interpolated milling and drilling in composite panels, aluminum, steel or titanium sheets and aluminum profiles. Tekna provides user-friendly software that can be operated by both experienced CNC programmers and less experienced users. The TKE 783 is a machining center with 3 controlled axes for interpolated drilling and milling in composite panels, aluminum, steel or titanium sheets and aluminum profiles. Technical specifications: Model: Tekna TKE783 Year of manufacture: 2015 Power: 29 kW Dkedpfxov D A Imj Afneg Dimensions of the machining table: 2010 x 6300 mm Weight: 4842 kg Speed: X axis 70 m/min; Y axis 55 m/min; Z axis 30 m/min Software: Windows, Embedded, Teach-in software CAD/CAM 2D NC TOOL Made in: Italy Other: aluminum milling up to 4 mm was worked on. The machine is connected, you can see how it works and test it in Estonia. It will be ready for transportation in April-May. If you have any additional questions, we will be happy to answer them.

Condition: excellent (used), control: Heidenhain Positip 850; tool taper: SK 40; hydr. clamping; stroke: 100 mm; table: 800x480 mm travel: x-600 mm, y-400 mm, z-400 mm rapid motion feed: 63-800 mm/min (18 steps) spindle speed: 63-3150 rpm (18 steps) accessories: coolant equipment, collet chuck incl chucks Dkjdpfolkgvbjx Afnsg

Condition: used, Year of construction: 1968, roll diameter 500 mm throat 1050 / 485 mm workpiece height 300 mm saw band length 3920 - 4050 mm cutting speed 15 - 940 m/min Dkodeiqp Erepfx Afnsg table height 1040 mm table surface area 750 x 800 mm Table tiltable 15 Grad total power requirement 4,0 kW weight of the machine ca. 1750 kg dimensions of the machine ca. 2100 x 1000 x 2100 mm - Unique mitering range left/right up to 30° acute angle - Mitering adjustment via lockable detent every 15° - Adjustable saw blade for optimum cutting angle - Hydraulic clamping device on both sides - Electric blade breakage monitoring - Smooth-running saw carriage via preloaded recirculating ball bearings - Additional table 450 x 450 - Machine light

Condition: new, Year of construction: 2023, functionality: fully functional, type of input current: three-phase, overall weight: 1,030 kg, rotational speed (max.): 2,500 rpm, turning diameter over cross slide: 320 mm, bar passage: 56 mm, spindle motor power: 3,700 W, mount diameter: 16 mm, spindle bore: 56 mm, spindle speed (max.): 2,500 rpm, spindle speed (min.): 150 rpm, turning length: 750 mm, Equipment: rotational speed infinitely variable, Technical Specifications Center Distance 750 mm Center Height 160 mm Swing Diameter Over Bed 320 mm Swing Diameter Over Cross Slide 150 mm Bed Width 215 mm Spindle Bore 56 mm Spindle Mount A2-5 Speed Range, Continuously Variable 150 - 2500 rpm Dedowh Aiwepfx Afnjkg Travel X-Axis / Z-Axis 160 mm / 750 mm Rapid Traverse X-Axis / Z-Axis 4 / 7 m/min Number of Tool Positions 6 pcs. Tool Shank Dimensions 16 x 16 mm Positioning Accuracy ± 0.01 mm Quill Diameter 45 mm Quill Travel 100 mm Quill Mount MT 4 Motor Power 3.7 kW Machine dimensions (W x D x H) 1910 x 1150 x 1840 mm Weight approx. 1030 kg

Condition: new, Year of construction: 2023, Positioner powered by three-phase current Rotation of table and arm by means of hydraulic swivels Height adjustment of the arm by means of a hydraulic cylinder Controlling functions on the positioner housing Useful in positioning parts in: welding cleaning assembly Increasing work efficiency up to 40% The use of unlimited rotation in 2 axes and, in addition, vertical and horizontal movement, allows any positioning of the attached workpiece (also "overhead"). Dksdpfxjhtq Nze Afneg The 3-axis positioner provides a significant improvement in work culture compared to traditional pan/tilt positioners (optimal positioning of the workpiece, easy operation). Advantages and benefits: For the employer: increased labor productivity by up to 40% through optimum positioning of workpieces - resulting in short amortization time of the device increased production efficiency does not require additional space on the shop floor better quality of welded joints - always possible to weld in the sub-lower position robust design of the device ensures long-term, trouble-free operation For the operator: ensuring ergonomic posture for the working person minimizing the risk of accidents - no changes in the fixing of objects no interruptions in work caused by waiting for the crane easy installation and operation It is possible to fully automate welding by using Kawasaki welding robots. We also offer positioners with a robot and integrated control system. ADDITIONAL OPTIONS: REMOTE CONTROL WITH CABLE TO OPERATE THE POSITIONER PEDAL WITH CABLE FOR OPERATING THE TABLE ROTATION STEPLESS ADJUSTMENT OF THE SPEED OF TABLE ROTATION AND ARM ROTATION FUNCTION OF CONSTANT TABLE ROTATION LENGTH AND SHAPE OF THE ARM SIZE AND SHAPE OF THE TABLE ROTATIONAL MASS We can make the positioner according to the customer's individual guidelines.

Condition: used, Year of construction: 2009, functionality: fully functional, For sale is a used, fully functional semi-automatic miter band saw. 0° 330 mm 320 mm 450 x 320 mm + 45° 320 mm 300 mm 300 x 300 mm + 60° 210 mm 200 mm 200 x 200 mm - 45° 320 mm 300 mm 300 x 300 mm - 60° 210 mm 200 mm 200 x 200 mm Dsdpfx Aewigavofnskg Max. vise opening 455 mm Blade size 4500 x 34 x 1.1 mm Saw blade motor power 4.0 kW - three-phase Blade speed 15 - 100 m/min Accessories: 4.5 m roller conveyor, various saw blades

Condition: repair required (used), Fehlmann Picomax 60 M (5-axis universal milling machine) with Heidenhain TNC 426 x-axis 500 mm Dksdswmwrdepfx Afnjg y-axis 350 mm z-axis 610 mm Motor spindle 18,000 rpm Power 10.2 kW 24-position tool changer Weight 3,200 kg with 4 axes SK 30 tools approx. 40 tool holders The machine has the following problems: - Heidenhain 430 control system is defective (booting up is not always possible, crashes during machining)

Condition: good (used), Year of construction: 2009, For sale GIARDINA MOS/4PLUS paint line Dkjdpfotxnp Njx Afnsg
