Turning automatic lathe

CITIZEN Cincom M332-III

Condition: new, Year of construction: 2025, spindle speed (max.): 8,000 rpm, spindle speed (min.): 8,000 rpm, 1 multispindle TORNOS SAS16-DC in rebuilding - new electrical cabinet SIEMENS or FANUC, to choose – pick-up with brake – adjustable stop with counter operation – 3 independent feeding system – several tool-holders and drillings – drum bar with support – Options :automatic bar loader IEMCA PRA, numerical tapping, CNC cross slides, etc... Cedpfeugl S Iox Afmegw Contact us.

Condition: used, TECHNICAL DETAILS - Number of axes : 4 MILLING SPINDLE - Tool holder type : BT30 - Spindle power : 4,9 [kW] - Spindle speeds : 16.000 [rpm] LINEAR AXES - Travels on X/Y/Z axes : 700 x 400 x 300 [mm] - Rapid traverses rates (X/Y/Z) : 50 / 50 /56 [m/min] - Cutting feed rates (X/Y/Z) : 1 - 30.000 [mm/min] - Distance table / spindle nose (min./max.) : 330 - 630 [mm] TOOL CHANGER Codpoxzu T Sefx Afmjgw - Auto. Tool Changer type : Parapluie - Tool magazine capacity : 21 - Tool exchange time : 0,8 [sec] TABLE - Table dimensions : 800 x 400 [mm] - Maximum weight upon table : 250 [kg] POWER SUPPLY - Supply voltage : 220 [V] - Total installed power : 9,5 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2.050 x 2.220 [mm] - Machine height : 2.497 [mm] - Machine weight : 2.400 [kg] MACHINE HOURS - Number of hours under power : 23.456 [h] - Number of working hours : 16.703 [h] EQUIPMENT - CNC : Brother CNC-C00 - Interface : Ethernet / USB - Electronic handwheel - CNC option : extanded Memory 500 Mo - CNC option : High accuracy mode BⅡ - Type of divisor : 4e axe CNC intégré * manufacturer : YUKIWA * model : DRC170-EU * travel 4th axis : 360 [°] * indexing precision 4th axis : 0,001 [°] * clamping diameter : 140 [mm] * center height : 135 [mm] * with counter bearing * Coolant tank : 150 [l] * with high-pressure pump : 15 [bars] * With cabin washing - Coolant through spindle - Tool probe - Electric transformer

Condition: used, TECHNICAL DETAILS - Number of axes : 7 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 20 [mm] - Max. machining length : 205 [mm] - Spindle speeds : 10000 [rpm] - Spindle power : 3.7 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 20 [mm] - Spindle speeds : 8000 [rpm] - Spindle power : 2.2 [kW] - C axis indexing precision : 1 [°] - Number of guide bush holders : 1 GUIDE BUSH HOLDER 1 - Number of positions : 10 - Number of motorized positions : 4 END ATTACHMENT - Number of positions : 7 SECONDARY OPERATION - Number of positions : 4 - Number of motorized positions : 4 - Live tools speed : 8000 [rpm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 7 [kW] WEIGHT & DIMENSIONS - Machine floor space : 2200 x 1200 [mm] - Machine height : 1700 [mm] - Machine weight : 2200 [kg] MACHINE HOURS - Number of hours under power : 27854 [h] - Number of working hours : 20213 [h] - Number of spindle hours : 13158 [h] EQUIPMENT - CNC : Fanuc 30i-model A - HFT (High Frequency Turning) - Rotating guide bush - Parts catcher - Parts conveying strip - Ejection of workpiece - Coolant tank Cjdjxlum Hopfx Afmjgw - Bar loader : FMB turbo 3-26 / 3200 A

Year of construction: 1996, condition: ready for operation (used), Turning length: 450mm, spindle clearance: 65mm, speed: 4000rpm, main spindle/counter spindle power: 18.5kW/11kW, tool positions: 10, driven tools: 10, hydraulic capacity: 150l, hydraulic pressure: 60bar, connected load: 39kW. Rapid traverse X1/X2: 15m/min, feed force: 5000N, feed path: 140mm. Rapid traverse Z1/Z2: 30m/min, feed force: 8000N, feed path: 450mm. Rapid traverse Y1: 6m/min, feed force: 8000N, feed path: +/-35mm. Machine dimensions X/Y/Z: approx. 4150mm/2000mm/1800mm, weight: approx. 4750kg, control: Traub System TX 8F, operating hours: 78825h. Documentation available. On-site inspection is possible. Cjdjv Scrhjpfx Afmogw

Condition: used, Year of construction: 1987, Technical details: number of spindles: 8 spindle passage: 51 mm Article: multi spindle automatic lathe Manufacturer: Schütte Type: AF51 Yob: 1987 eight main spindles max. bar diameter D=51mm control SIEMENS SIMATIC S5 pick up in pos. 7, for rear machining thread cutting drive independent feed in positions 2/3 electronical trip dog control “Balluff” clear text display Wöhrle coolant pump magnetic cartridge filter oil running incl. bar loader IEMCA PRA 40/37/F, yob 1987, (bundle type) Cjdpfeiay Sfex Afmogw Painting in light blue and light grey The configuration of tooling will be different like pictures. Please, contact us for getting more information and pictures on mail(at) or *

Condition: ready for operation (used), Year of construction: 2018, spindle speed (max.): 5,000 rpm, travel distance X-axis: 195 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 380 mm, spindle motor power: 15,000 W, overall weight: 8,000 kg, controller manufacturer: MITSUBISHI, controller model: M730VS, number of axes: 8, This 8-axis Citizen BNE-51MSY was manufactured in 2018. It features a maximum bar diameter of Ø 51 mm and a spindle speed of 5,000 min-1. The machine includes 12 turret stations and a slide stroke of 195 mm in the X1 direction. If you are looking to get high-quality turning capabilities, consider the Citizen BNE-51MSY horizontal turning machine we have for sale. Contact us for further details. • Maximum Bar Diameter (SP1): Ø 51 mm • Maximum Bar Diameter (SP2): Ø 51 mm • Spindle Speed (SP1/SP2): 5,000 min-1 • Spindle Motor (SP1): 15/11 kW (15min./cont) • Spindle Motor (SP2): 7.5/5.5 kW (15min./cont) • Turret Stations: 12 ST. (HD1) / 12 ST. (HD2) • Revolving Tool Motor: 2.2 kW • Revolving Tool Torque: 20 Nm • Revolving Tool Speed: Max. 6,000 min-1 • Slide Stroke (X1/Z1): 195 mm / 380 mm • Slide Stroke (X2/Z2): 195 mm / 175 mm • Slide Stroke (Y1): 80 (± 40) mm • Slide Stroke (B): 450 mm • Rapid Feed Rate (X1/Z1): 18 m/min / 20 m/min • Rapid Feed Rate (Y1): 12 m/min • Power Supply Capacity: 44 KVA • Voltage: AC 200/220 V • Coolant Tank Capacity: 350 L Cgsdpfoywy Shox Afmjw • Barfeeder included Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: good (used), Year of construction: 2007, functionality: fully functional, turning length: 320 mm, spindle speed (min.): 8,000 rpm, bar passage: 32 mm, Machining Data Maximum bar capacity: 32 mm Maximum turning length: 320 mm Maximum drill diameter (front): 12 mm Maximum tapping size (front): M12 Main spindle speed: up to 8,000 rpm Sub spindle speed: up to 8,000 rpm Number of tools: 25 to 27 Dimensions & Weight Dimensions (W x D x H): 2,860 mm x 1,465 mm x 1,900 mm Weight: 4,300 kg Cjdpfx Aoxb R R Hefmegw 10-position turret Rotating tools for complex machining operations FMB Turbo 3-36

Condition: good (used), CHIRON FZ 08 KS Magnum is a 5‑axis machining center engineered for precision, high accuracy and reliable production. Travels X450×Y270×Z310 mm; drilling 12 mm; tapping M8. Tool magazine 24 pos., tool Ø max 47 mm (100 mm free), length 160 mm, tool wt 1.2 kg. Spindle HSK‑A40 0–36000 rpm; spindle motor 7 kW; rapid 75 m/min; 3×400V 50Hz; air 6 bar; installed power 14 kW (19 kVA); machine ≈3400 kg; dims 2308×1405×2447 mm. Features: tool‑break control, RS232, switch‑cabinet air‑con, status light. Delivers tight tolerances for automotive, aerospace, medical, watchmaking. Cgsdpfx Aoyxn Hcjfmjw

Condition: ready for operation (used), Year of construction: 2014, spindle speed (max.): 8,000 rpm, number of axes: 9, This 9-axis TRAUB TNL 32 swiss type turning machine was manufactured in 2014. It features a TX8i-s control with a 64-bit RISC CNC/PLC processor, color TFT display, and electronic handwheel. The main spindle supports a 32 mm bore, and the machine includes a sub-spindle with a C-axis. It offers a dual-driven upper tool turret and a lower turret with nine tool holders. Consider the opportunity to buy this TRAUB TNL 32 swiss type turning machine. Contact us for more information. • Control: TRAUB TX8i-s CNC/PLC with 64-bit RISC processor and fiber-optic PC; color TFT flat-panel display; electronic handwheel • Software/extensions included: Polyform (C-axis programming), Helical (3D Y-axis interpolation), tapping without compensating chuck, parting tool breakage monitoring, parting tool ejection monitoring, axis shutdown, T-ATC • Main spindle: Motor spindle with hollow clamping system; 32 mm bore/bar capacity; C-axis max speed 8,000 rpm • Max stroke: 305 mm (L version) / 127 mm (K version) Cedex D Drcspfx Afmogw • Sub-spindle: Partial hollow clamping, C-axis; cleaning unit mounted on lower tool turret • Upper tool turret: X/Y/Z/H/B axes; 10 tool holders; dual drive • Lower tool turret: X/Y/Z/H axes; 9 tool holders; combined drive; separate counter-spindle operation • Measuring/feedback: Glass scales on X-axis (upper and lower turrets); rotary encoder on C-axis • Back working: 8-position back table with combined drive for up to 3 tools; prepared for internal coolant supply • Clamping: Clamping direction reversal device and counter clamping pressure device on main and counter spindles • Coolant system: Standard system with 3-bar and 8-bar pumps (50 Hz) in a 500-liter tank; additional 28-bar pump (50 Hz), 19 l/min flow rate • Extraction: Connection D 150 mm for central extraction Additional equipment • None specified (no robots, bar feeder, chip conveyor, or external automation listed)

Condition: ready for operation (used), Year of construction: 2023, A Keyence optical 3D coordinate measuring machine with a 360° 3D scan is available. Measuring accuracy: +/-10µm, repeatability: 2µm, resolution: 0.1µm, point density: 16 million, measuring diameter (low magnification): 300mm, measuring diameter low magnification/composite: 200mm/500mm, rotation range: 360°, tilt range: 45°, max. table load: 50kg. Machine dimensions X/Y/Z: approx. 1000mm/1000mm/1000mm, weight: approx. 65kg. Documentation available. On-site inspection is possible. Cgodpfx Afowx Rcyemew
