Hüttmann Werkzeugmaschinen GmbH

Condition: used, Year of construction: 2009, operating hours: 6,000 h, Functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, controller model: Heidenhain iTNC530, spindle speed (max.): 36,000 rpm, GF Mirkon XSM600U X: 800 Y: 600 Z: 500 A: +30/-100 degrees C: 360 degrees continuous HSK50 spindle: max. 36,000 rpm, 25 kW HR410 handwheel Itelswa R A Nohccqkjf 60-station tool changer Rotary table including 3R clamping system Chip conveyor Coolant system with 20 bar internal coolant supply Blum laser tool measurement M&H 3D probe Pallet automation with 21 pallets - the pallets are not included in the scope of delivery This machine is offered on a customer order basis!

Condition: good (used), Year of construction: 2021, operating hours: 7,200 h, Functionality: fully functional, travel distance X-axis: 1,150 mm, travel distance Y-axis: 620 mm, travel distance Z-axis: 600 mm, number of spindles: 1, number of slots in tool magazine: 32, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Travel paths: X-axis: 1,150 mm Y-axis: 620 mm Z-axis: 600 mm Rapid traverse in all axes: 30 m/min Spindle data: Spindle speed: 10,000 rpm Spindle mount: SK40 Spindle motor: 19 kW / 119 Nm Control: Siemens 840DE with 19" monitor Ijlhccjv Epxboqkotf -SHOPMILL - 3D simulation -Residual material detection - DXF reader Equipment: - 32-way tool magazine - Universal chip conveyor - Direct position measuring systems in all axes - Portable handwheel - Paper belt filter with 22 bar IKZ - Blum spindle measuring probe

Condition: as good as new (ex-display), table length: 500 mm, table width: 300 mm, Flat grinding machine Ziersch Z35 - demonstration machine unused - Ijlhcevvwf Dscqkstf Grinding area: 500mm x 350mm Dresser Permanent magnet Belt filter system with magnetic separator

Condition: as good as new (ex-display), Functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 410 mm, travel distance Z-axis: 450 mm, controller model: Heidenhain, rotational speed (max.): 12,000 rpm, Vertical machining center YCM NXV600A - demonstration machine Control: Heidenhain TNC620 Spindle: 12,000 rpm SK40 17kW Coolant system with IKZ20 bar Handwheel Tool changer: 24-way Chip conveyor Itelhccovvuh Asqkef The machine is located at our location in Soltau and can be viewed in operation at any time!

Condition: as good as new (ex-display), travel distance X-axis: 1,020 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain, rotational speed (max.): 12,000 rpm, Vertical machining center YCM NSV106A - demonstration machine Control: Heidenhain TNC620 Spindle: 12,000 rpm SK40 17kW Coolant system with IKZ20 bar Handwheel Ijlhccqevvug Ssketf Tool changer: 30-way Chip conveyor The machine is located at our location in Soltau and can be viewed in operation at any time!

Condition: as good as new (ex-display), travel distance X-axis: 800 mm, travel distance Y-axis: 730 mm, travel distance Z-axis: 800 mm, Equipment: chip conveyor, YCM NH500A - demonstration machine - unused!! Control: Fanuc MXP300FB Spindle: 15,000 rpm / 244 Nm BBT40/SK40 Tool changer: 60-way Switch table Itjlhccevvudwoqkef Coolant system with 70 bar IKZ 3D probe Blum tool breakage control Glass scales Chip conveyor The machine is located at our location in Soltau and can be inspected at any time.

Condition: refurbished (used), Functionality: fully functional, travel distance X-axis: 475 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 400 mm, workpiece weight (max.): 200 kg, rotational speed (max.): 42,000 rpm, table diameter: 450 mm, 5-axis Röders Tec RXP800DS -completely overhauled- Ijlhcjvvlmcecqkotf The machine is completely overhauled, checked and measured in our company. The machine again meets the new machine tolerance! Working area: - X-axis: 475 mm - Y-axis: 600 mm - Z-axis: 400 mm - Clearance height: 500 mm Tool changer: 52-way Spindle: HSK40E max. 42,000 rpm Tool measuring laser for tool measurement Handbox Minimal quantity lubrication Prepared for extraction system (e.g. for graphite) Spindle compensation Accuracy package Control: Röders RMS6 in current version A viewing of the machine in operational condition is possible at any time. You are also welcome to find out more about the type and scope of our reconditioned machines on our website or on our Hüttmann YouTube channel.

Condition: refurbished (used), Functionality: fully functional, travel distance X-axis: 320 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 200 mm, spindle speed (max.): 50,000 rpm, overall weight: 3,800 kg, workpiece weight (max.): 200 kg, space requirement width: 2,000 mm, space requirement length: 1,800 mm, space requirement height: 2,000 mm, Equipment: documentation/manual, Röders RXP300 -overhauled- The machine is completely overhauled, checked and measured in our company. The machine again meets the new machine tolerance! Itslhccqevvigmokef Working area: X-axis: 320 mm Y-axis: 300 mm Z-axis: 200 mm (height) The clearance height is 390 mm above the machine table without chuck. Machine table: Size: 370 mm x 350 mm Workpiece mass: Maximum 200 kg Axis drives: Highly dynamic linear motors in all axes with integrated cooling. Feed rates: 0 - 40,000 mm/min in all axes. Spindle: HSK25E 50,000 rpm Tool changer: 42-way Automatic 3D probe Control: Röders RMS6 in current version (2024) A viewing of the machine in operational condition is possible at any time. You are also welcome to find out more about the type and scope of our reconditioned machines on our website or on our Hüttmann YouTube channel.

Condition: as good as new (ex-display), Year of construction: 2023, operating hours: 15 h, YCM UV650 Spindle: SK40 / 15.000 rpm, 17kW toolchanger places: 60 control: Heidenhain TNC640 travel: X:620mm Y:520mm Z:460mm B:-50 / +110 C:360 spindle cooling system Blum laser for tool length measurement 3D probe el. hand wheel Ijlouxbcishccqketf Emulsion cooling ICS 20bar outer cooling cooling gun chip conveyor machine dimensions: L:4250mm W:2310mm H:2.560mm weight: appr. 12.500kg

Condition: as good as new (ex-display), Year of construction: 2022, operating hours: 150 h, travel distance X-axis: 1,270 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 630 mm, Hartford HCMC 1270 machining center Working area: X-axis, longitudinal: 1,270mm Y-axis, transverse: 650mm Z-axis, vertical: 630mm Spindle: SK50/ 25kW / 644Nm / 6,000rpm Tool changer: 32-way Iolhccqjuxa Ecsketf Control: Heidenhain TNC640 Equipment: IKZ 20 bar, external coolant supply Chip conveyor in hinged belt design, chip flushing, flushing gun, compressed air gun, machine light, closed work area, electronic handwheel, CE standard The attached YouTube video shows a comparable machine - Hartford HCMC1682. This machine is slightly larger in comparison and has 979Nm spindle power instead of 644Nm. The structure of the machine is identical, however.

Condition: as good as new (ex-display), Year of construction: 2023, CNC - turning center Iolott Dhvjhccqkjtf YCM NTC2000LSY control : Fanuc TXP100FBTXP100FB+ main spindle : A2-6 / 5.000 rpm, hole through spindle: Ø80mm, hole through draw bar: Ø66mm sub spindle : A2-5 / 6.000 rpm, hole through spindle: Ø55mm, hole through draw bar: Ø45mm Turret Capacity: 12 Max. Turning Diameter : Ø310 mm Max. Turning Length : 570 mm X travel: 160mm Z travel: 570mm Y travel: 90mm (-50 / +40mm) LSY (Y axis, BMT55 turret 12T High performance coolant pump 8 bar coolant gun interface for bar feeder automatic Renishaw HPMA tool length measuring system main spindle Parts collection system Counter spindle

Condition: refurbished (used), Functionality: fully functional, travel distance X-axis: 425 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 240 mm, spindle speed (max.): 42,000 rpm, table load: 60 kg, overall weight: 6,000 kg, 5-axis HSC milling machine Röders RXP500DS with linear direct drives in all axes and torque drives in the rotary axes. The machine is completely overhauled, tested and measured in our company. The machine meets the new machine tolerance again! Travel paths: X455mm, Y400mm, Z240mm Distance spindle/table: approx. 315mm Iolhott Atwjccqketf - Linear direct drives in all axes - wear-free - 42-way tool changer - High-precision cooling device for the entire machine (hysteresis +/- 0.15K) - Measuring laser for fully automatic measurement of milling tools (length/diameter/contour/cone angle) and wear monitoring including tool cleaning before measuring - Handbox - Remote maintenance - Automatic 3D probe including calibration ball in the tool changer - Minimum quantity lubrication - HSK40E spindle with max. 42,000 rpm - Erowa ITS100 zero point clamping system integrated in the machine table - Automation package for retrofitting the machine with a pallet changer - Handbox A tour of the machine in Ready-to-use condition is possible at any time. You are welcome to find out more about the type and scope of our overhauled machines on our website or on our Hüttmann YouTube channel.

Condition: refurbished (used), Year of construction: 2010, Functionality: fully functional, travel distance X-axis: 450 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 240 mm, overall weight: 6,000 kg, spindle speed (max.): 42,000 rpm, 5-axis HSC milling machine Röders RXP500DSC with linear direct drives in all axes and torque drives in the rotary axes. Travels: X450mm, Y400mm, Z240mm Spindle / table distance: approx. 315mm - Linear direct drives in all axes - wear-free Specification: - Tool changer places: 19 - Cooling unit for drives, motors, spindle and cable cabinet - Measuring laser for the fully automatic measuring of milling tools (length / diameter / contour / cone angle) as well as wear monitoring including tool cleaning before measuring - Handbox - Remote maintenance - Automatic 3D probe including calibration ball in the tool changer - Minimal quantity lubrication - emulsion cooling - Spindle HSK40E with max. 42.000 rpm - Spindle compensation - Zero point clamping system Erowa integrated in the machine table - manual operating of chuck clamping - Automation package for retrofitting the machine with a pallet changer - Handbox Islhccett Argoqkstf The machine is overhauled in our house and is now in almost new condition. The machine can be inspected and tested under power after completion at our site. Please make an appointment with us!

Condition: refurbished (used), travel distance X-axis: 800 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 400 mm, feed rate X-axis: 60,000 m/min, feed rate Y-axis: 60,000 m/min, feed rate Z-axis: 60,000 m/min, spindle speed (max.): 36,000 rpm, table load: 800 kg, overall weight: 12,000 kg, Equipment: documentation/manual, Used HSC machine RXP800 -overhauled- Working area: - X-axis: 800 mm - Y-axis: 600 mm - Z-axis: 400 mm The clearance height between the spindle nose and the machine table is 565 mm. Drives of the linear axes: Islhett Agyeccqkjtf - Linear motors in all axes. Feed rates 0 - 60,000 mm/min in all linear axes. Spindle: - HSK-E50 - Spindle speed rpm: 36,000 - Tool changer positions: 30 Equipment - Network connection: - Handbox - Tool measuring laser: Diameter and contour measurement, wear monitoring and breakage control of the milling tools. - 3D measuring probe - Remote maintenance Team Viewer - Workpiece cleaning - Simulation RMSCut with cut-out function - Minimum quantity lubrication - Emulsion cooling - Extraction Transport dimensions of machine: W 2,830 x L 4,100 x H 3,050 mm Weight: approx. 13,000 kg The machine is completely checked, measured and overhauled in our company. Please arrange a viewing appointment with us.

Condition: new, Year of construction: 2024, Functionality: fully functional, 5-axis travelling column machining centre - SAMAG SFZ3500- with swivel head and internal rotary table (Ø:1000mm, interference Ø:1300mm) X:3500mm Y:1000mm Z:1000mm Spindle: SK50 max. 12,000rpm 54kW Tool changer: 60 Control: Heidenhain TNC7 Itolhccottv Haeqksf Coolant system with paper belt filter Internal coolant supply: 40bar (max. 80bar) Internal air supply through the spindle 3D touch probes Collision monitoring (DCM) Kinematics Opt The machine is available at short notice and can be inspected and tested at the factory.

Condition: new, operating hours: 15 h, YCM NXV1020A, spindle: SK40/12,000 rpm, control: Siemens 828D, tool changer: 30-fold, X:1020mm Y:520mm Z:540mm, coolant system: IKZ20bar, chip conveyor Islorutazehccqkstf

Condition: reconditioned (used), travel distance X-axis: 310 mm, travel distance Y-axis: 294 mm, travel distance Z-axis: 210 mm, overall weight: 3,000 kg, spindle speed (max.): 50,000 rpm, used HSC machine RXP800DS - overhauled - Workspace: - X axis: 200 mm - Y-axis: 294 mm - Z axis: 200 mm - Drives of the linear axes: Linear motors in all axes. - Drives of the rotary axes: Highly dynamic direct drives with integrated cooling. - Feeds 0 - 40,000 mm / min in all linear axes. - Network connection: - Tool measurement laser: Diameter and contour measurement, wear monitoring and breakage control of the milling tools. - Chuck control, 1 chuck - Emusion cooling with Oil-mist-suction - RMS Main Job manager - Spindle max. 60,000 rpm HSK 25 - Tool changer: 24 chain changer, able to operate while machining - High precision option - Remote maintenance via Teamviewer - Transport dimensions machine: W 2,425 x L 1,925 x H 2,700 mm - Weight: approx.3,000 kg Iolhccqslzhhksketf The machine is completely checked, measured and overhauled in-house. Please arrange a viewing appointment with us.

Condition: reconditioned (used), travel distance X-axis: 310 mm, travel distance Y-axis: 294 mm, travel distance Z-axis: 210 mm, overall weight: 3,000 kg, spindle speed (max.): 50,000 rpm, Used HSC machine RXP400DS/ RXD5 -overhauled- The machine is completely overhauled, tested and measured in our company. The machine again meets the new machine tolerance! Working area: - X-axis: 200 mm - Y-axis: 294 mm - Z-axis: 200 mm - Drives of the linear axes: Linear motors in all axes. Itslhjlzhhcsccqkof - Drives of the rotary axes: Highly dynamic direct drives with integrated cooling. - Feed rates 0 - 40,000 mm/min in all linear axes. - Network connection: - Tool measuring laser: Diameter and contour measurement, wear monitoring and breakage control of the milling tools. - Chuck control, 1st chuck - Emulsion cooling with mechanical oil mist extraction -RMS Main Job Manager - Spindle max. 60,000 rpm HSK 25 - Tool changer 12-way row, optional tool changer conversion to chain - High-precision option - Remote maintenance via Teamviewer - Transport dimensions of machine: W 2,425 x L 1,925 x H 2,140 mm - Weight: Approx. 3,000 kg A viewing of the machine in operational condition is possible at any time. You are also welcome to find out more about the type and scope of our overhauled machines on our website or on our Hüttmann YouTube channel.
