Condition: excellent (used), Year of construction: 2018, Control Heidenhain ... TNC 640 Nkjlhcev Tlyqjcqtow Clamping table surface ... 350x350mm Axis X ... 500mm Y axis ... 600mm Axis Z ... 450mm Spindle speed ... 10-20000/min. controlled axes ... 5 cooling ... 80bar Spindle holder ... HSK-A63. Max. table load ... 200kg Axis A ... +91/-121° Axis C ... 360° Pallet change ... 7 Magazine spaces ... 120 Machine weight ... 13000kg L x W x H ... 4280x3920x3340mm The machine is in good condition, possible to test under power.

Condition: used, Year of construction: 2012, X - Axis : 510 mm Y - Axis : 400 mm Z - Axis : 350 mm Table Length : 600 mm Nkelhcev Th Rrjcqtsw Table Width : 400 mm Max. loading capacity : 100x2 kg Spindle taper : 7/24 Taper No : 30 Spindle speed : 8000 (4000) (12000) rpm

Condition: used, Year of construction: 2010, Axis X - 350 mm Axis Y - 250 mm Axis Z - 350 mm Table length - 502.9 mm Table width - 269.2 mm Spindle speed - 16000 rpm Spindle taper - BT30 Engine Power - 11.1 kW Weight - 2087.1 kg Type - CNC CNC - BROTHER CNC-A0 Nslhov Th Ahsccqtekw Length x width x height - 1397.0 × 2895.6 × 2235.2

Condition: good (used), Year of construction: 2022, spindle speed (min.): 12,000 rpm, Machine type: CNC-BAZ vertical Model: M1 Pro with 4th axis including tailstock Manufacturer: DMGMORI Control: Siemens 828 D Year of manufacture: 2022 Location: Germany Technical data Travel range X-axis approx. 550 mm Y-axis approx. 550 mm Nolhccov Tc Hueqtjkw Z-axis approx. 510 mm Table size approx. 850 x 650 mm Max. workpiece weight approx. 600 kg Max. speed approx. 12,000 rpm Spindle motor approx. 13/9 KW Number of tool positions approx. 24 Rapid traverse X / Y / Z approx. 24 m/min Holder taper approx. SK40 Footprint L x W x H approx. 3.1 x 2.7 x 2.9 m Machine weight approx. 5,600 kg Equipment Main spindle 12,000 rpm 13/9 kW - Separate electronic handwheel - 24-place chain magazine - SK40 - Coolant tank - IKZ pump 20 bar - Filter for coolant - Bed flushing switchable via M function - Coolant spray gun - Spindle blowing air switchable via M function - Cabin roof - Measuring probe - 4th axis (Errors in the technical data and information excepted)

Condition: ready for operation (used), Year of construction: 2016, General Data Measurements height 2390.1 mm Machine weight 2636 kg Control Unit Nolhccqsv S Nbpotekw Brand HURCO Model WinMax Main Drive Spindle speed range 8000 rpm Number of axis 3 Movement X-Axis Movement 457 mm X-Axis Rapid Traverse 19 m/min Y-Axis Movement 356 mm Y-Axis Rapid Traverse 19 m/min Z-Axis Movement 356 mm Z-Axis Rapid Traverse 19 m/min Table Table load 250 kg Tools Number of index 16 Max weight 7 kg Max tool diameter 90 mm Max tool length 200 mm Type of tool holder CAT/BT 40 This 3-axis Hurco VM5i vertical machining center was manufactured in 2016. It offers robust construction and precision engineering, ideal for a variety of machining tasks. Consider the opportunity to buy this Hurco VM5i vertical machining center. Contact us for more information about this machine. Application Types Milling

Condition: excellent (used), Year of construction: 1992, Functionality: fully functional, KIRA (Japan) KN 40 VS 2-Compartment Pallet Processing Center / Vertical Stock No: 07-07-183 -Year of construction 1992 (machine from first ownership, very well maintained) -2-compartment pallet change / round pallet change -Fanuc OM - Mate -Pallet size 500x300mm -Travel X440 Y280 Z315mm -Tool change 12-fold -Spindle speeds 200 - 4500rpm -Drive power 7.5 KW -Chip conveyor / flushing device / work area lighting Nkjlsv Sy Elshccqtsw Dimensions: LxWxH 2.4x1.7x2.3 meters / Weight 3500Kg

Condition: good (used), Year of construction: 2003, Ref. -No.: 10507 Manufacturer: BROTHER Type: TC 32 A Year of construction: 2003 Type of control: CNC Control: BROTHER Storage location: Halberstadt Country of origin: Japan Machine-No.: 112XXXX X-Travel: 450 mm Y-Travel: 320 mm Z-Travel: 410 mm Main spindle drive power: 7,7 kW Table surface: 550 x 350 mm Spindle Taper: BT30 Table Load: 300 kg Tool change time: 2,2 s Numbers Of Tools In Magazin: 30 Tool Piece Magazine With: 26 Pcs./pcs. Spindle Speed: 12000 RPM Distance between spindle nose and table: 200 - 610 mm Machine length: 3263 mm Machine width: 1848 mm Machine Height: 2360 mm Weight Of The Machine Ca.: 3,5 t Further information: - ROTARY HINGE - PNEUMATIC SYSTEM - REMOTE-CONTROLLED ELECTRONIC - HANDWHEEL - CHIP CONTAINER Machine can be inspected under power by arrangement. The machine is still in production. Nolov Sv Agshccqtokw

Condition: not inspected (used), Fanuc OM Control XYZ 600x400x460 Speed 45-6000 Taper ISO 40 Tool station 16 Table 920x320 Nkjlhccev Sunnsqtjw

Condition: used, Year of construction: 1996, Brother TC-229 +Tools included Nkslev Suh Ishccqtow +Index table +XYZ 480,360,270 +Speed 6000rpm +Engine 5-7 kW +SK 30 +table 600x300 +Speed XYZ, 36,36,30 m/min +14 tools station

Condition: good (used), Year of construction: 2001, Functionality: fully functional, travel distance X-axis: 420 mm, travel distance Y-axis: 330 mm, travel distance Z-axis: 240 mm, controller manufacturer: Siemens, controller model: Sinumerik 810D, table width: 325 mm, table length: 850 mm, rotational speed (min.): 10 rpm, rotational speed (max.): 5,000 rpm, spindle speed (min.): 10 rpm, spindle speed (max.): 5,000 rpm, EMCO VMC 300 Vertical Drilling and Milling Center with 4th Axis Year of Manufacture: 2001 Control: Sinumerik 810D Technical Specifications: Nkslhov Sm Nkoccqtjw Spindle Speed: 10 - 5,000 rpm Power: 5 kW Machining Torque: 100 Nm Tool Holder: SK 40 Number of Magazine Positions: 12 Travel Distances: X-Axis: 420 mm Y-Axis: 330 mm Z-Axis: 240 mm 4th Axis: 0.001° Accessories: - Emco Rotary Table - Coolant System Machine is fully operational

Condition: ready for operation (used), Year of construction: 1998, General Data Measurements width 2620mm Measurements depth 2025mm Measurements height 2670mm Control Unit Brand OKUMA Model OSP7000M-H Main Drive Spindle speed range 8000 RPM Number of axis 5 Movement X-Axis Movement 560 mm Y-Axis Movement 450 mm Z-Axis Movement 450 mm Tools Number of index 30 Nslhccqev Sfyhstekw This 5-axis Okuma VH-40 vertical machining center was manufactured in 1998. Ideal for complex and precise machining tasks, it offers enhanced flexibility and productivity for your workshop. Consider the opportunity to buy this Okuma VH-40 vertical machining center. Contact us for more information. Application Types Milling

Condition: good (used), Year of construction: 2009, Functionality: fully functional, travel distance X-axis: 450 mm, travel distance Y-axis: 270 mm, travel distance Z-axis: 310 mm, rapid traverse X-axis: 70 m/min, rapid traverse Y-axis: 70 m/min, rapid traverse Z-axis: 70 m/min, nominal power (apparent): 13 kVA, workpiece weight (max.): 100 kg, table width: 660 mm, table length: 350 mm, table load: 200 kg, rotational speed (max.): 15,000 rpm, overall weight: 3,600 kg, spindle speed (max.): 15,000 rpm, spindle motor power: 7,200 W, spindle nose: HSK-A40, number of spindles: 1, number of slots in tool magazine: 24, tool length: 160 mm, tool diameter: 100 mm, tool weight: 1,200 g, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, For sale: Chiron FZ 08W Magnum High Speed, a high-speed vertical CNC machining center, manufactured in 2009 and equipped with a Siemens 840D control. The machine is located in Armilla, Spain, and is in perfect working condition, ideal for precision machining and series production. Main Features: Brand / Model: Chiron FZ 08W Magnum High Speed Year of Manufacture: 2009 CNC Control: Siemens 840D (PCU 50 / NCU 572.5, 6 axes, 1 channel) Travel Distances: X-axis: 450 mm Y-axis: 270 mm Z-axis: 310 mm Spindle Speed: Up to 15,000 rpm Tool Holder: HSK-A 40 DIN 69893 Spindle Power: 7.2 kW (25% duty cycle) / 2.2 kW (100% duty cycle) Tool Magazine: 24 positions with automatic tool changer Tool Change Time (chip-to-chip): ~1.9 s Cooling System: Internal high-pressure cooling (up to 150 bar) High-pressure pump with dual-switchable 60 µm filter Coolant Filtration System: Automatic continuous paper filter (50 µm) 500-liter coolant tank Chip Conveyor: Chain conveyor with 100-liter chip container Automatic Loading Doors Table Size: 2x660x350 mm Maximum Table Load: 100 kg per side Rapid Traverse Speed: Up to 75 m/min (X, Y, Z) Axis Acceleration: X-axis: 1 g Y-axis: 1.5 g Z-axis: 2 g Additional Features: High-speed package (increased acceleration and faster tool changes) 0/180° Work Area Switching System with intermediate partition 3D Touch Probe Renishaw TS 27R Three-color signal light on the splash guard 230V power socket on the control panel Connection for portable handwheel ("Mini Handwheel") Integrated electrical cabinet cooling Additional Spare Parts Included: This machine comes with a spare parts package from another disassembled Chiron FZ 08W, making maintenance and repairs easier. The package includes: Complete Peiseler 180° table Complete tool changer system with motor Spindle head (without motor) Operator panel keyboards Doors Various electrical components Power supply for servo amplifiers 2 servo amplifiers Nslhccjv R Hlisqtskw Chip conveyor 2 spare motors Condition & Delivery: Machine is fully operational and ready for production. Available for testing at our facility. Regular maintenance performed. Video of the machine in operation available upon request. Location & Shipping: Location: Armilla, Spain Shipping and commissioning can be arranged upon agreement. For more information, contact us via phone or email. We are available to answer any questions and provide additional technical details.

Condition: good (used), Year of construction: 2001, Functionality: fully functional, Fanuc control, 14-station tool changer, Nkolhcjv R Eziecqtjw BT30 tool holder, 8000 rpm spindle speed, Nikken 4th/5th axis, internal coolant system, tool probe for tool measurement, coolant system

Condition: excellent (used), Year of construction: 2015, 2015 YOM with Touch probe X 548.64 mm Y 800.1 mm Z 609.6 mm SPECIFICATIONS: Travel Rapid / Feed rate X Axis 21.6” 1417 ipm / 787 ipm Y Axis 31.5” 1417 ipm / 787 ipm Dqyyp9 Z Axis 24.0” 945 ipm / 787 ipm A Axis Tilt 150 degree (+30 – 120 degree) C-Axis rotate 360 degree continuous MA Max workpiece envelop 19.6” x 11.8” Table size 16.1” Ø Table load 440 Lbs. Spindle motor 18 HP H/L shifting Spindle speed 12,000 rpm Spindle taper CT-40 BigPlus ATC 30 tools, side mount double arm type Nkjlhccev Rx Tfeqtew Machine Net Weight 8000 Kg

Condition: good (used), Year of construction: 2016, Functionality: fully functional, machine/vehicle number: 1125575, travel distance X-axis: 400 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 360 mm, rapid traverse X-axis: 100 m/min, rapid traverse Y-axis: 100 m/min, rapid traverse Z-axis: 100 m/min, nominal power (apparent): 8 kVA, torque: 10 Nm, controller model: HEIDENHAIN iTNC 530, workpiece weight (max.): 120 kg, table width: 450 mm, table length: 550 mm, table load: 120 kg, rotational speed (max.): 42,000 rpm, spindle speed (min.): 42,000 rpm, spindle nose: HSK-E63, input voltage: 400 V, Equipment: documentation/manual, rotational speed infinitely variable, Centrum obróbcze GF MASCHINNING MIKRON MILL S 500 zbudowane w 2016 roku, przeznaczone jest do ELEKTROD Z GRAFITU o wadze 120 kg. Gabaryt stołu 450mmx550mm.Maszyna posiada trzy numerycznie sterowane osie o posuwach odpowiednio 400 mm (X), 500 mm (Y) i 360 mm (Z) oraz posuwach przyśpieszonych 100 m/min. Wrzeciono z maksymalnymi obrotami 42 000 obr./min wyposażone w chłodzenie i stożek HSK-E63, dodatkowe urządzenie jakości, precyzję oraz główne skrócenie procesu frezowania. Maszyna wyposażona jest w sterownik CNC HEIDENHAIN iTNC 530, który umożliwia pełne działanie nad pracą maszyn. Całkowity ciężar frezarki wynosi 6800 kg. Centrum GF MASCHINNING MIKRON MILL S 500 wyposażone jest dodatkowo: odkurzacz do grafitu, sondę pomiarową BLUM, Nkslhccjv Rpidoqtew

Condition: used, Year of construction: 1998, Functionality: fully functional, CNC controller: HEIDENHAIN TNC426PB Axes Nelhev Rlw Reccqtokw X-axis travel mm: 500 Y-axis travel mm: 350 Z-axis travel mm: 610 Distance spindle nose - table surface mm: 94 - 704 Feed rates m/min: 20 Rapid traverse m/min: 20 Worktable Table dimensions mm: 920x380 Max. workpiece weight kg: 250 Spindle Spindle speed rpm: 50 - 18.000 Spindle drive power kW: 10,2 (60% ED) Spindle torque Nm: 70 (bis 1.240 rpm) Tool system Tool holder: SK30 Tool magazine slots: 24 Max. Tool Diameter With free neighboring places mm: 125 With occupied neighboring places mm: 63 Max. Tool Length mm: 280 Max tool weight kg: 3 Tool-to-tool time s: 6 Chip-to-chip time s: 8 Equipment Electronic Handwheel Tool breakage probe Mist collector Basic machine dimensions / weight Length mm: 2.000 Width mm: 1.700 Height mm: 3.000 Weight kg: 3.200

Condition: ready for operation (used), Year of construction: 2007, Functionality: fully functional, travel distance X-axis: 550 mm, travel distance Y-axis: 410 mm, travel distance Z-axis: 450 mm, controller model: Matsuura G-Tech 30i, spindle speed (max.): 20,000 rpm, swivel angle B-axis (min.): -220 °, swivel angle B-axis (max.): 220 °, TECHNICAL DETAILS X-axis: 550 mm Y-axis: 410 mm Z-axis: 450 mm B-axis: ±220° C-axis: 360° CNC control: Matsuura G-Tech 30i Spindle and tool Speed range: 20,000 rpm Tool holder: BT40 Tool length: 300 mm Tool diameter: 150 mm Tool weight: 10 kg Workpiece capacity Workpiece diameter: 300 mm Workpiece weight: 40 kg MACHINE DETAILS Machine dimensions (W x H x D): 3,032 × 5,120 × 2,705 mm Power consumption: 32 kVA EQUIPMENT - Internal cooling system - Automatic pallet changer - Automatic Tool changer Nkolhccqov Rb Hhotew - High-pressure cooling 20 bar - Chip conveyor - FSE chip control

Condition: used, Year of construction: 2012, Functionality: fully functional, machine/vehicle number: 215-12, Equipment: rotational speed infinitely variable, CNC machining center FZ 08 W M h.s. with integrated FANUC robot LR Mate 200iC A fully automated turnkey solution: CNC machining center and robot. A loading magazine for fully automatic operation is also integrated, of course! The machine is currently still connected to the power supply and can therefore be inspected in full working order. The machine ran smoothly until the end. Please note: the spindle concentricity is no longer within the specified range! No other errors or problems are known. Nslhccqjv Ra R Setjkw

Condition: ready for operation (used), Year of construction: 2012, Functionality: fully functional, machine/vehicle number: 1097497, number of slots in tool magazine: 20, Equipment: chip conveyor, Machine from the insolvency of an automotive supplier - machines are currently still in operation! EQUIPMENT - Chip conveyor - 20-station tool changer Further information according to the manufacturer - without guarantee X-axis travel: 508 mm Y-axis travel: 406 mm Z-axis travel: 394 mm Distance from spindle to table: 546 mm Spindle speed: 10,000 rpm Tool taper: BT 30 Table dimensions: 660 x 381 mm T-slot spacing: 125 mm Nelhjv N Hzhoccqtjkw T-slot width: 16 mm T-slot depth: 27 mm Number of slots: 3 Table load: max. 113 kg Tool changer: double gripper Tool diameter: 51 mm Tool length: 178 mm Tool weight: 2.5 kg Tool slots: 20+1 Machine dimensions: approx. 2.6 x 1.7 x 2.6 m Transport dimensions: 2.5 x 2.0 x 2.5 m Weight: approx. 2.4 t

Condition: used, Year of construction: 1991, x-travel 556 mm y-travel 356 mm z-travel 356 mm Control Ultimax 3 table surface area 765*349 mm Nelhov Nw Rgeccqtjkw tool magazin: 16 x spindle taper ISO 40 turning speeds 60 - 5.000 U/min total power requirement 7,5 / 15 kW weight of the machine ca. 3,5 t dimensions of the machine ca. 2,5*2,5*2,6 m

Condition: excellent (used), Year of construction: 2005, The used Bridgeport Hardinge VMC 600II vertical machining center is a small-sized 3-axis continuous numerical control machining center; table 750×510 mm strokes X 600, Y 510, Z 510mm, year of construction 2005, CE standards, with FANUC 0-MD CNC, Nolhjv Nbglsccqtskw It is equipped with a BT 40 milling spindle at 8,000 rpm from 13Wk, 20-position tool changer, and remote handwheel.

Condition: ready for operation (used), Year of construction: 2013, Functionality: fully functional, machine/vehicle number: 1108262, Equipment: chip conveyor, Machine from the insolvency of an automotive supplier - machines are currently still in operation! TECHNICAL DETAILS Equipment: Chip conveyor Further information according to the manufacturer - without guarantee Travel X / Y / Z: 406 x 305 x 254 mm Distance spindle to table: 356 mm Spindle speed: 10,000 rpm Tool taper: #40 Table dimensions: 730 (914) x 305 mm T-slot spacing: 110 mm T-slot width: 16 mm Number of slots: 3 Table load: max. 227 kg Tool diameter: 89 mm Tool length: 178 mm Tool weight: 5.4 kg Tool slots: 10 Machine dimensions: approx. 2.3 x 2.3 x 2.7 m Nksljv Natdshccqtew Weight: approx. 1.6 t

Condition: ready for operation (used), Year of construction: 2016, Functionality: fully functional, machine/vehicle number: 1131075, travel distance X-axis: 500 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, Equipment: chip conveyor, Machine from the insolvency of an automotive supplier - machines are currently still in operation! TECHNICAL DETAILS Nkslhccev Nakceqtjw X-axis travel: 500 mm Y-axis travel: 400 mm Z-axis travel: 400 mm EQUIPMENT - Chip conveyor - Tool changer - Part feed belt 100 x 3,000 mm Further information according to the manufacturer - without guarantee Distance spindle to table: 546 mm Spindle speed: 10,000 rpm Tool taper: BT 30 Table dimensions: 660 x 381 mm T-slot spacing: 125 mm T-slot width: 16 mm T-slot depth: 27 mm Number of slots: 3 Table load: max. 113 kg Tool changer: Double gripper Tool diameter: 51 mm Tool length: 178 mm Tool weight: 2.5 kg Tool slots: 20+1 Machine dimensions: approx. 2.6 x 1.7 x 2.6 m Transport dimensions: 2.5 x 2.0 x 2.5 m Weight: approx. 2.4 t

Condition: ready for operation (used), Year of construction: 1992, operating hours: 50,000 h, Functionality: fully functional, travel distance X-axis: 500 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 350 mm, rotary table diameter: 520 mm, overall weight: 6,000 kg, spindle speed (max.): 8,000 rpm, spindle nose: ISO SK30, number of slots in tool magazine: 12, Machine is fully functional and working in our production Nkjlhccqsv I Sk Eotjw

Condition: ready for operation (used), Year of construction: 1990, General Data Measurements width 1800 Nkelhccev I Hgzsqtow Measurements depth 2800 Measurements height 2900 Machine weight 3600 Control Unit Brand SIEMENS Model SINUMERIK 810M Main Drive Number of axis 3 Movement X-Axis Movement 550 mm Y-Axis Movement 300 mm Z-Axis Movement 425 mm Workpiece Workpiece weight 2 x 100 kg Tools Type of tool holder SK40 Media Chip conveyor Yes This 3-axis CHIRON FZ18W vertical machining center was manufactured in 1990. It features a SIEMENS SINUMERIK 810M control system, a spindle with a 70mm diameter in front bearing, and a SK40 tool holder. The machine has a rotary table diameter of 1050mm and can handle a maximum workpiece weight of 200 kg. If you are looking to get high-quality milling capabilities, consider the CHIRON FZ18W machine we have for sale. Contact us for more information about this machine. Application Types Milling
