CNC Machining Center

TBI MVC 1890

Condition: excellent (used), Year of construction: 2008, operating hours: 40,255 h, functionality: fully functional, For sale is a DMG DECKEL MAHO DMF 220 linear, a 5-axis universal travelling-column machining center. The machine was built in 2008 and was modernized / totally retrofitted in 2022 with Siemens Sinumerik 840D Solution Line control. Equipped with 5-axis simultaneous machining license, Siemens Sinamics drive technology, Siemens OP15 Black Operator Panel, MCP control panel and electronic handwheel. Technical data: Manufacturer: DMG DECKEL MAHO Type: DMF 220 linear Machine type: 5-axis universal machining center / travelling-column machining center Year of manufacture: 2008 Control: Siemens Sinumerik 840D Solution Line Modernization / Total Retrofit: Siemens CNC / drive modernization in 2022 5-axis simultaneous operation: License available Serial number: 15115223244 Machine number: 2499093 Travel X: 2,200 mm Travel Y: 560 mm Travel Z: 720 mm Tool taper: SK 40 Table load: 2,500 kg Main spindle speed range: 20 - 14,000 rpm Connected load: 80 kVA Max. rated current: 115 A Fuse protection: 125 A Supply voltage: 400 V Frequency: 50 Hz Fsdpjyuzg Hjfx Akvjpk AC control voltage: 230 V DC control voltage: 24 V Power-on hours: approx. 40,255 h Spindle / working hours: approx. 13,082 h CNC / drive technology: X-axis: Siemens Sinamics 160 A, 2 x SMC20 encoder module Y-axis: Siemens Sinamics 50 A, 2 x SMC20 encoder module Z-axis: Siemens Sinamics 80 A, 2 x SMC20 encoder module B-axis: Siemens Sinamics 25 A, 2 x SMC20 encoder module A-axis: Siemens Sinamics 25 A, 2 x SMC20 encoder module Spindle axis: Siemens Sinamics 26 kW, 2 x SMC20 encoder module Operator panel: Siemens OP15 Black Operator Panel MCP control panel: Siemens Electronic handwheel: Siemens Magazine technology: Magazine A: 400 W servo drive, 400 W servo motor, 10 m power cable, 10 m encoder cable Magazine B: 400 W servo drive, 400 W servo motor, 10 m power cable, 10 m encoder cable Magazine C: 400 W servo drive, 400 W servo motor, 10 m power cable, 10 m encoder cable Software / licenses: 5-axis simultaneous machining license Axis licenses Operator software license Equipment: Integrated swivelling table / trunnion-type table setup Paper band filter unit Coolant / filter unit Electrical cabinet Full enclosure Working area lighting Siemens control panel Condition: Machine in well-maintained condition Modernized Siemens control and drive technology 5-axis simultaneous machining available

Condition: excellent (used), Year of construction: 2014, x-travel 2500 mm y-travel 3000 mm z-travel 1250 mm Control HEIDENHAIN iTNC530 spindle turning speed - stepless 22000 U/min c-axis +-300° milling-head swivable +/- +-110° tool taper HSK 63 A tool change unit 50 Pos. total power requirement 130 kW weight of the machine ca. 53,5 t dimensions of the machine ca. 7,6 x 7,3 x 5,7 m This ZIMMERMANN FZ33c is available immediately and in good condition. - NEW spindle received 6 months ago Description: Technical specifications of the machine and working ranges X-axis 2500 mm Y-axis 3000 mm Z-axis 1250 mm A-axis ± 110 ° C-axis ± 300 ° Includes vibration sensor Includes bearing temperature sensor Includes rotary joint for internal tool magazine feed (IKZ) 5-axis path control: Heidenhain iTNC 530/handwheel HR520, 15” TFT colour display Extraction system LTA Industrial Air Cleaning Machine room canopy 50-position tool changer, chain magazine, behind the machine Chip conveyor, ejection 60° to the left, front-facing No probe available!!! Blum Laser tool measurement ‘Control NT-Micro’ Clamping table Fodpfjzak Hgsx Akvjpk Length x width x height 2500 x 3250 x 400 mm Table load 8000 kg/m² (max. 16000 kg) T-slots, arranged longitudinally 18H12 T-slot spacing 250 mm Dimensions, weights Footprint (excluding peripheral equipment) approx. 7600 x 7300 x 5650 mm Total weight approx. 53500 kg Electrical connection data Voltage (three-phase) 400 V Frequency 50 Hz Compressed air connection (to be provided by customer) Required air pressure 6 bar Average air consumption approx. 15 m³/h (depending on machine configuration) Linear axis drives Feed rate X, Y, Z axes 60 m/min Axis acceleration X, Y, Z axes up to 5 m/s² Rotary axis drives – VH30 Feed rate A- and C-axis 360 °/s Axis acceleration A- and C-axis 700 °/s² Resolution A- and C-axis 0.0001 Accuracies of linear axes – in accordance with VDI / DGQ 3441 Positioning accuracy X-axis P= 0.026 mm Y-axis P= 0.028 mm Z-axis P= 0.020 mm Repeatability X-axis Ps= 0.015 mm Y-axis Ps= 0.016 mm Z-axis Ps= 0.010 mm Resolution of measuring systems (interpol) A-, C-axis 0.0001° Accuracy of rotary axes – VH30 Positioning accuracy A- and C-axis P= 12" = 0.0033° Repeatability A- and C-axis Ps= 8" = 0.0022° VH30 milling head 2-axis milling head: VH30, Siemens Weiss milling spindle Spindle power S1 (100% duty cycle) 60 kW, Spindle speed 22,000 rpm, 95 Nm, HSK-A63 External dimensions of fork head L x W approx. 500 x 600 mm Nominal torque of rotary axes Control loop A: min. 1,200 Nm C: min. 1,047 Nm Clamped A and C axes: 3,000 Nm (Continuous grease lubrication with automatic relubrication system) Swivel axis – spindle nose 326 mm Tool holder HSK 63 A Tool clamping Spring clamp Tool unclamping Hydraulic Permissible tool weight 4.5 kg (manufacturer’s specification) Coolant supply External and internal Coolant/lubricant supply (emulsion) at the front of the milling spindle with belt filter system Volume 1500 l Pump 1: 40 l/min at 20 bar Pump 2: 20 l/min at 40 bar, Air blow at the front of the milling spindle

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, spindle speed (min.): 16,000 rpm, spindle motor power: 5 W, number of spindles: 3, number of slots in tool magazine: 21, input voltage: 380 V, 4 units CNC Brother models S500X1/S700X1. Year of manufacture 2014 1 unit with 3 axes Fpedpfxoyap R Do Akvek 1 unit with 4 axes with hydraulic station without vapor filtration system 1 unit with 4 axes with hydraulic station with vapor filtration system

Year of construction: 2004, condition: used, bar material dia. 6 - 120 mm Bar length 100 - 1.600 mm bar weight max. 63 Kg feed length 1.000 mm Fjdpeyhhriefx Akvspk longitudinal adjustment 600 mm machine weight ab. 600 kg dimensions of the machine ca. 2,2 x 1,5 x 1,5 m Current operating hours display: 4867 hours

Condition: good (used), Year of construction: 2008, functionality: fully functional, turning length: 750 mm, turning diameter: 590 mm, spindle bore: 78 mm, spindle speed (max.): 3,000 rpm, Equipment: documentation/manual, Centre distance: 750 mm Swing: 590 mm over bed / 375 mm over slides Spindle speeds: 25 - 3.000 rpm Spindle bore: 78 mm Revolver: 10 Platze Controller: Siemens 810D Shopmill Featured with: - Double footpedals - Chipconveyor - Machine manuals Fedpfjxmvzujx Akvopk Country of origin: Z. Korea Motor power: 25 kW Machine weight: 6.000 kg Machine LxWxH: 300 x 180 x 190 cm

Condition: used, Year of construction: 1998, Turning length 322 mm Max. swing over bed ways 510 mm Fpsdpfsx N A N Hsx Akvjk Max. turning dia. 279 mm Spindle speeds 60-6000 rpm Spindle bore 53 mm Turret w/12 stations Control: Fanuc 21 T Equipped with: Magazine bar feeder Hatec Rapid Load 12 Tail stock Various tool holders & collets 3-jaw chuck

Condition: good (used), travel distance X-axis: 3,500 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 800 mm, table load: 12,000 kg, total height: 3,900 mm, total length: 7,200 mm, total width: 5,200 mm, table length: 1,800 mm, table width: 1,600 mm, feed rate X-axis: 8,000 m/min, feed rate Y-axis: 8,000 m/min, feed rate Z-axis: 8,000 m/min, rotational speed (max.): 2,000 rpm, Table type boring mill TOS VARNSDORF - WHN 13 CNC MACH-ID 9612 Make: TOS VARNSDORF Type: WHN 13 CNC Control: Heidenhain TNC415 X - Travel: 3500mm Y - Travel: 2000mm Z - Travel: 800mm W - Travel: 1000mm Table Length: 1800mm Table Width: 1600mm Table load: 12 Speeds / ranges:2000Rpm Power: 37kW Spindle Taper: ISO50ISO/Bt/Mk Feed rate X-Axis:8000mm/min. Fjdpfjy H Dahex Akvepk Feed rate Y-Axis:8000mm/min. Feed rate Z-Axis:8000mm/min. Feed rate W-Axis:8000mm/min. Length: 7200mm Width: 5200mm Height: 3900mm Weight: 34500kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: excellent (used), Year of construction: 1997, Romanian Lathe SARO SPS 1250x9000, Manufacturer: Saro Targoviste, Year of Manufacture: 1997. Chuck diameter: 1250 mm, Maximum swing over bed: 1250 mm, Spindle diameter: 250 mm, Distance between centers: 9000 mm, Maximum swing over slide: 920 mm, Maximum workpiece weight between centers: 15,000 kg. Grinding attachment available! Video of the machine under power available. Weight approximately 25 tons. Fjdpfjy Icbaex Akvjpk

Condition: good (used), Year of construction: 1995, roller (top) diameter: 330 mm, sheet thickness (max.): 23 mm, Manufacturer: IMCAR Type: SIHR Year of manufacture: 1995 Extended end for profile bending rolls (Pipe & T-Angle) Central lubrication Digital readout position side rolls Fully hydraulic machine Hydraulic drop end Hardened rolls Specifications Metric US Standard Roll width: 3100 mm Sheet thickness at 3 x top roll Ø: 18 mm Sheet thickness at 5 x top roll Ø: 23 mm Sheet thickness for initial bending: 20 mm Top roll Ø: 330 mm Side roll Ø: 310 mm Number of rolls: 3 Bending speed: 0 - 5 Side roll adjustment: 200 mm/min. Number of driven rolls: 2 Power: 15 kW Dimensions (estimated) Length: 5250 mm Width: 1700 mm Height: 1700 mm Weight: 11900 kg Fpodpfx Ajwpku Djkvsk Please note: The information on this page has been provided to the best of our knowledge, and wherever possible, from the manufacturer. The information is given in good faith, but accuracy cannot be guaranteed. Accordingly, it does not constitute representation or contractual terms. We recommend you check all critical details.

Condition: good (used), Year of construction: 2003, travel distance X-axis: 1,060 mm, travel distance Y-axis: 710 mm, travel distance Z-axis: 710 mm, feed rate X-axis: 15,000 m/min, feed rate Y-axis: 15,000 m/min, feed rate Z-axis: 15,000 m/min, total height: 2,800 mm, total length: 3,200 mm, total width: 2,900 mm, table width: 800 mm, table length: 1,500 mm, table load: 550 kg, rotary table diameter: 800 mm, spindle motor power: 20,000 W, Chip conveyor 3D measuring probe Paper filtration IKZ 15 Bar Under power X - Travel: 1060mm Y - Travel: 710mm Z - Travel: 710mm A - Axis: 360000° B - Axis: - 30 to + 120° Table Length: 1500mm Table Width: 800mm Table load: 550 Table Ø: 800mm Feed rate X-Axis: 15000mm/min. Feed rate Y-Axis: 15000mm/min. Feed rate Z-Axis: 15000mm/min. Spindle Taper: 40ISO/Bt/Mk Power on spindle: 20kW Speeds / ranges: 12000Rpm ATC / revolver: 32 Coolant through spindle / Bar:15 Number of controlled axis: 5 Chip conveyor: Yes Coolantsystem: Yes Length: 3200mm Width: 2900mm Height: 2800mm Weight: 9500kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details! Fpsdpfx Aeym Sdyjkvsk
