Used Worm Gear for sale (6,622)

Condition: good (used), Year of construction: 2002, operating hours: 14,449 h, functionality: fully functional, machine/vehicle number: 0290, Used CNC gear hobbing machine Manufacturer: Liebherr Model: LC150 Pjdpfx Ahoyiyhxsvjpp Year of manufacture: 2002 Serial No.: 0290 With loading portal

Condition: good (used), max. wheel diameter 1600 mm gear width 250 mm max. module 30 min. module 8 range of tooth size 58 mm tooth width 250 mm weight of the machine ca. 42,3 t Ppjdpfx Ahou Dbucsvep dimensions of the machine ca. 4,45 x 6,00 m - Cone spacing in mm. for spiral angle 30° minimum: 150 maximum: 800 - Taper angle, in degrees minimum: 5 maximum: 85 - Tooth angle minimum: 0° maximum: 45° - Number of teeth to be cut minimum: 10 maximum: 150 The machine is complete, fully functional and in good condition. Equipment / accessories: - complete set of change wheels - 4 pcs. cutter heads - various milling cutters - Operating instructions in English

Condition: used, Year of construction: 2003, grinding wheel diameter: 400 mm, helix angle: 45 °, wheel diameter: 1,500 mm, Used Höfler Rapid 1500, built in 2003 Psdpsv U D Tfjfx Ahvopp Mahr measuring system Interlit oil preparation system Location: Australia

Condition: excellent (used), Year of construction: 2020, max. wheel diameter 400 / 320 mm Ppodsyrh Aispfx Ahvep gear width 370 mm max. module 10 min. module 1 Control Siemens 840 Dsl spindle turning speed - stepless 1 - 1500 U/min tangential adjustment 350 mm total power requirement 53 kW weight of the machine ca. 19,5 t dimensions of the machine ca. 4,5 x 2,9 x 3,3 m

Condition: excellent (used), Gear motor, electric motor, electric gear motor, worm gear motor, parallel shaft gear motor -Condition: Gear motor is unused -Manufacturer: SEW-Eurodrive, gear motor with brake, parallel shaft gear unit series F -Type: FH87/G DRS132S4BE5HF/TF -Speed: 68 rpm -Power: 5.5 kW -Protection class: IP54 -Hollow shaft: Ø 60 x 280 mm Pjdpjvvbnpsfx Ahvopp -Brake: 28 Nm -Number: 2x motor available -Price: per piece -Dimensions: 760/335/H530 mm -Weight: 155 kg/piece

Condition: like new (used), functionality: fully functional, nominal power: 5.5 kW (7.48 HP), Bevel gear shaft-mounted geared motor Model: KUA70A 3B 132S-04E-TH Psdpsyrckhofx Ahvopp Hollow shaft diameter: 45 mm 5.5 kW electric motor For further data, see the nameplates

Condition: used, Year of construction: 1998, Technical details: grinding diameter: 250 mm grinding length: 2710 mm max. module: min. module: total power requirement: 45 kW weight of the machine ca.: 15 t space required L x W X H: 7,1 x 4,7 x2,7 m max. wheel dia.: 450 mm Pjdpfxeudf E As Ahvspp Spindle drives Arena Siemens For Worm grinding we have not module, but pitch. Pitch is freely programmable from 0.001 to big value i.e. 500mm *

Condition: used, Year of construction: 2014, Infeed and outfeed chain conveyor, with tool holders, chip conveyor, hydraulic unit and air conditioning. Podpfxextbmij Ahvepp *

Condition: used, functionality: fully functional, For sale is an Oerlikon bevel/worm gear unit of the E 37 EX 2 series, serial number 828499L01.1. The unit comes from a fully functional installation and is suitable for test benches, special purpose machines, and industrial drive applications. Technical specifications (general): Manufacturer: Oerlikon Psdpfx Asypb Iyshvepp Type: E 37 EX 2 Design: Bevel/worm gear unit Application: Test bench technology, mechanical engineering, industrial drives Condition: used, functional

Condition: used, Year of construction: 2007, max. wheel diameter 380 mm gear width 540 mm max. module 7 Control SINUMERIK 840 D Axial travel 600 mm table diameter 317 mm table speeds 100 U/min milling head -swivable + / - 35 Grad milling spindle drive 27,00 kW milling spindle speeds (infinitely variable) 1500 U/min diameter of hob 160 mm cutter length max. 330 mm cutter speeds max. 3000 1/min hob dia. - max. 160 mm swarf cutter lenght - max. 330 mm tangential travel max. 300 mm 10.000 mm/min tangential speed max. 3000 mm/min 7.500 mm/min Pedjyt Rvhepfx Ahvepp oil volume 100 l coolant capacity 780 l Counterholder movement 540 mm total power requirement 50,00 kW weight of the machine ca. 16,00 t dimensions of the machine ca. 6,00 x 4,50 x H3,50 m for the following processes: axial hobbing, individual part milling, Worm wheel milling, roofing, deburring; NC tailstock

Condition: used, Year of construction: 1951, Oerlikon Spiromatic 2 with Fiat Mammano cutter head Setting device for cutter head Complete cabinet with change gears Ppodoyt Ha Aspfx Ahvop Several cutting tools for cutter head

Condition: like new (used), Lot includes: Approx. 500 metres of chains Approx. 650 sprockets Approx. 270 conveyor rollers Approx. 40 geared motors Some items are in sealed packaging (new parts) Full inventory available upon request Additional photos available Total footprint: approx. 13 pallets (800 x 1200 mm format) Ppedpfx Ajyt E S Rehvsp For more information, please feel free to contact us. Visible near Burnaupt le Haut Delivery + unloading by MID possible at extra cost Contact: Christian LEMBLE 06 80 05 35 75 Price excl. VAT Industrial gear reducer / Gearbox / Drive shaft / Mechanical component / Drive part / Drive motor / Gear housing / SEW-Eurodrive / USOCOME / Nord Drivesystems / Bonfiglioli / Siemens / Flender / Sumitomo Drive Technologies / ABB / Baldor / Lenze / STM Team / Motovario / Renold / David Brown Santasalo / Hansen Industrial Transmissions / Manufacturing industry / Conveyor drives / Presses / Machine tools / Mining and quarrying / Crusher feed / Material handling systems / Power generation / Turbine drives / Generators / Pumping systems / Marine industry / Power transmission for propulsion and handling systems / Construction and heavy equipment / Integration in cranes / Drilling rigs / Other construction machinery / Spare parts / CNC machine tools / Lathes / Milling machines / Machining centers / Heavy industrial equipment / Presses / Conveyors / Production machinery / Railway / Material handling / Speed and torque adaptation to specific machine requirements / Enhanced mechanical component service life / Optimized energy consumption / Turbines and Archimedean screws / Winches / Lifting systems / Industrial mixers / Stone / cement / waste crushers / Belt conveyors / Quarries / Mines / Factories / HBM / CORMAK / HOLZMANN / Conveyor / Dual sprocket conveyor roller / Mechanical equipment roller / Gravity roller / Handling roller / Chain / Belt / Geared motor / Screw conveyor / Agriculture / Food industry / Pharmaceutical sector / Construction / Inclined conveying / Easy maintenance / Material conveying / Helical drive in tube or trough / Fine materials, powders, granules, cereals / Flour / Helical screw / Rotation / Helix / Grain / Sugar / Cement / Pellets / Salt / Sieve / Screen / Tube / Trough / Gear motor / Bearings and supports / Hopper / Powder products / Grain auger

Condition: good (used), Year of construction: 2002, Clampable cutter head type (max.) 460 mm Cutter head weight (max.) 150 kg Mounting disc diameter for cutter heads (Ø) 360 mm Mounting cone for cutter heads Nominal diameter Ø 58,227 mm travel -z axis 200 mm diagram-drawing enlargement ±10 - ± 500 µm weight of the machine ca. 2,3 t dimensions of the machine ca. 2 x 1,5 x 2,03 m In the manufacturing process for spiral-toothed bevel gears, the quality of the gear cutting gear cutting tools used plays a decisive role. Particularly in high gear cutting quality and a long service life can only be achieved with precisely can only be achieved with precisely adjusted cutterheads. Psdpfx Aew N S E Ajhvjpp The Oerlikon cutterhead setting and testing device CS 200 enables quick and easy setting of the individual knives and simple adjustment of the individual knives, it checks the position and documents the measurement results. The measuring sequence on the CNC-controlled testing device is partially automated: The individual actions for carrying out the actions for carrying out the sequence are displayed on the screen via the operator guidance. The positioning of the individual knives in the cutter head and the height of the knife tips is largely automatic thanks to a special sequence and is simultaneously documented by means of a run-out diagram. A subsequent measuring sequence checks the radial position of the inner and outer cutting edges of all knives in the cutterhead. If individual test parameters on the knives do not correspond to the the tolerance specifications, this can be individually repositioned. The combination of semi-automated setting sequence, operator-guided set-up actions and automatic operator-guided set-up actions and automatic measuring sequence, cutterheads can be can be set conveniently, quickly and with high precision. Operator-guided setting and test sequence - Graphic display of the cutter head design and the measurement results with tolerance check - Instructions for the operator in plain text Instructions for the operator in plain text (without coded information) - Simple assignment of the measurement results to the knives - Documentation of the setting and measurement results via printer- Setting and test sequence suitable for ARCON®, RSR, Spirapid, SPIRON®, TRI-AC® types - Interface for neutral data

Condition: used, Year of construction: 2006, functionality: fully functional, workpiece weight (max.): 25,000 kg, wheel width: 3,000 mm, feed length X-axis: 1,000 mm, LIEBHERR L3002 CNC Internal and External Gear Hobber Built 1982, Modernized 2006 CNC SIEMENS 840 D. Max Wheel diameter 3,000 mm. Max helical angle 45° Pedpfxewdmy Eo Ahvepp Internal and external Head. 44/50 kW.

Condition: excellent (used), functionality: fully functional, Gear hobbing machine ZFWZ 800x10/1 Year of manufacture: 1983 The machine is dismantled and in good condition. Specification: Max. workpiece diameter: 800 mm Max. gear width: 410 mm Max. module: 10 Max. hob diameter: 195 mm Table diameter: 700 mm Pjdjytimlspfx Ahvopp Table speed range: 40-280 rpm Power capacity: 12.5 kW Voltage/Frequency: 220/50 V/Hz Axial feed: 0.2-8 mm/min Radial feed: 0.1-2 mm/min Tangential feed: 0.1-2 mm/min Weight: 9 tons

Condition: ready for operation (used), Year of construction: 1980, Gleason Hypoid cutter Sharpener 13A -1 pcs Milling diameter 89-500 mm Grinding wheel dimensions 305x19x102 mm Feed 0,05-0,18 mm Grinding wheel drive motor - 1800 rpm (60 Hz) - 1500 rpm (50 Hz) Ppoder Elpvjpfx Ahvep Floor space 1240x2310 mm Height 1422 mm Machine weight 4083 kg Gleason 19 revacicle cutter checking machine - 1 pcs

Condition: ready for operation (used), Gear hobbing machine type FD320, FD500 and FD 800 Cugir Maximum module 6 to 10 mm Ppsdpfscrd Nmex Ahvjp Max. working diameter 320 to 800 mm

Condition: used, Year of construction: 2018, Nominal power in kilowatts 7,7 MW Maximum power 8,47 MW Nominal turning speed 1150 1/min Maximum turning speed 2200 1/min Nominal torque 63940 Nm Maximum torque 70330 Nm Pjdpfxerr Ammj Ahvepp 8 MW test bench for gears, closed loop

Condition: used, Year of construction: 1969, max. wheel diameter 160,175 mm gear width 355 mm max. module 4,5 spindle bore 75 mm centre distance 410 mm min. number of teeth 2, 3 Podpfx Ahevzhf Sjvepp cutter diameter max. 115 mm cutter length max. 105 mm axis distance between cutter and workpiece - max. 138 mm axis distance between cutter and workpiece - min. 30 mm milling head -swivable 120 ° milling spindle speeds 70 - 400 U/min axial-feeds 0,25 - 4,0 mm/U radial feeds 0,09 - 1,5 mm/U total power requirement ca. 9,5 kW weight of the machine ca. 3,5 t dimensions of the machine ca. 1730x1400x1440 mm Equipment/accessories: - Interchangeable wheels - Milling arbors - Clamping devices - Documentation

Year of construction: 2007, condition: used, gear hobbing diameter - external 1200 mm gear hobbing diameter - internal 1200 mm gear hobbing width -max. 260 mm control Liebherr PC-NC max. workpiece diameter 1500 mm table diameter 900 mm table bore diameter 320 mm max. table load 95 kN power capacity 30 kW coolant pump 120 l/min Axial distance between thrust spindle - table 0-820 mm Shaping spindle diameter 125 mm tool taper SK 45 DIN Ppodpfx Asw Rf S Eohvjp weight of the machine ca. 26 t dimensions of the machine ca. 8,073 x 6,183 x 4,375 m Strokes: - Stroke length min./max. - 0 mm / 270 mm - Stroke length adjustability - 270 mm - Stroke rate (double strokes) - 10 to 270 DH/min Equipment/accessories: - Chip conveyor - Cutting wheel holder SK 45 DIN - Cooler - Technical documentation

Condition: used, Year of construction: 2008, tip circle diameter 650/800 mm workpiece length - max. 1100 mm max. module 20 (25) mm Ppodpsw Rrbyofx Ahvsp min. module 0,5 mm control Siemens Sinumerik 840 D total connected load 62 kVA helical angle -45 / + 120 ° weight of the machine ca. 10 t

Year of construction: 2009, condition: used, gear hobbing diameter - external 1200 mm gear hobbing diameter - internal 1200 mm gear hobbing width -max. 260 mm control Liebherr PC-NC max. workpiece diameter 1500 mm table diameter 900 mm table bore diameter 320 mm max. table load 95 kN power capacity 30 kW coolant pump 120 l/min Axial distance between thrust spindle - table 0-820 mm Shaping spindle diameter 125 mm tool taper SK 45 DIN weight of the machine ca. 26 t dimensions of the machine ca. 8,073 x 6,183 x 4,375 m Strokes: - Stroke length min./max. - 0 mm / 270 mm - Stroke length adjustability - 270 mm Pedpow Rf R Usfx Ahvspp - Stroke rate (double strokes) - 10 to 270 DH/min Equipment/accessories: - Chip conveyor - Cutting wheel holder SK 45 DIN - Cooler - Technical documentation

Condition: used, Year of construction: 2007, x-travel 900 mm y-travel 300 mm z-travel 1000 mm control Siemens Sinumerik 840D max. workpiece diameter 1600 mm Ppodpew Rrb Hofx Ahvjp max. module 20 mm tip circle diameter 350 mm Milling arbour diameter 375 mm Total closing value 80 kVa weight of the machine ca. 33,5 t dimensions of the machine ca. 10,530 x 6,375 x 4,680 m Feed rate: - X-axis 1 to 3000 mm/min - Y-axis 1 to 3000 mm/min - Z-axis 1 to 4000 mm/min Spindle speeds in rpm: - Tool 26 to 265 - Workpiece table 0 to 8 Equipment/accessories: - M 2 motor milling head - Milling mandrels - Oil cooler - Technical documentation

Condition: used, Year of construction: 2007, max. dia. of teeth cutting 2000 mm workpiece dia. 2700 mm Pjdpsxylm Hsfx Ahvopp max. module 22 mm Ring thickness for internal gearing max. 500 Control Siemens 840D table diameter 1500 mm table hole 500 mm Table rpm 3,5 1/min table load 200 kN Stroke length 30-330 mm no. of strokes doubel-strokes per min. 10 - 200 1/min. axis distance 70 ... 1220 mm max. radial velocity 3000 mm/min weight of the machine ca. 38000 kg Equipment/ accessories: - Intermediate plate between head and column: Center distance modified min. 0 mm max. 1500mm - column increased for axial stroke 1200 mm max. - Shaping head drive power 30 kW - spindle diameter 160mm - max. tool diameter 300mm - max. cutter wheel speed 10 1/min - Cutting speed 5 ... 45m/min - max. lateral offset 50mm - coolant device coolant tank capacity 2500 l - documentation

Condition: used, Year of construction: 2007, workpiece diameter nominal 2400 mm max. workpiece diameter 2800 mm max. module 30 mm control Siemens Sinumerik 840 D dividing plate diameter 2200 mm Psdjw Rf S Sopfx Ahvspp table diameter 2500 mm Table hole Diameter / depth 800 / 875 mm max. table load 40000 kg Table rpm 4,5 min-1 clamping length max. 375 mm clamping diameter max. 350 mm cutter diameter max. 2800 mm Cutter arbor cone HSK-B160 swivelling range milling head + 30/-45° Distance Cutter - Workpiece 615 / 1600 mm weight of the machine ca. 57 t Slide drives: - Feed & rapid traverse speed: - axial 4000 mm/min - radial 3000 mm/min - tangential 3000 mm/min Equitment/Accessories: - IFK2 internal milling head - Milling arbor with spacers - chip conveyor - Oil mist extraction - technical Documentation
