Used Vertical Slicer for sale (7,573)

Condition: ready for operation (used), travel distance Z-axis: 508 mm, feed length X-axis: 1,016 mm, feed length Y-axis: 610 mm, controller manufacturer: Heidenhain TNC 410, total height: 2,600 mm, total length: 2,260 mm, total width: 3,280 mm, empty load weight: 6,000 kg, rotational speed of tool magazine (max.): 8,000 rpm, Tos -Mas MC100V X:1016 - Y:610 - Z: 508mm Table dimensions: 1080 x 580 mm Admission in spindle (ISO): ISO 40 Lodpjxp Slnefx Af Ejru Power on the spindle: 16 kW Toolchanger: yes Number of toolholders: 40x

Condition: used, Technical details: max. ram stroke: 250 mm workpiece diameter - max.: 80 mm max. workpiece length: max. 900 total power requirement: 1,5 kW Lsdpfx Ajw Au I Ijf Eeru weight of the machine ca.: 2,1 t

Condition: ready for operation (used), Type: 817 CLM Meetfout: 1,8 + L/600 µm (L in mm) Herhaalbaarheid: 0,5 µm Dynamisch meetsysteem: zorgt voor een hoge herhaalbaarheid Ledpfxexp Skks Af Eeru Luchtlagers: zorgen voor lichte en soepele bewegingen Gemotoriseerde meetwagen: vereenvoudigt meetritten Geïntegreerde oplaadbare batterij: biedt een lange gebruiksduur voor metingen die niet op het lichtnet zijn aangesloten Bedrijfstemperatuur: 10°C tot 40°C Gewicht: ongeveer 25 kg (55,15 lbs)

Condition: used, Year of construction: 1984, Milling Head vertical accessory for a milling machine Fritz Heckert FSS 400 - weight 255 kg - dimensions: LxWxH: 560 x 500 x 400mm Lodpfx Afju N E Abj Esru - swiveable 90° right / left - clamping area 500 x 400mm *

Condition: ready for operation (used), chuck outer diameter: 1,120 mm, total height: 4,100 mm, empty load weight: 16,500 kg, Type: Stanko 1512 Maximale werkstukhoogte: 1000 mm Verticale schuifmaat maximale horizontale verplaatsing: 775 mm maximale verticale verplaatsing: 700 mm Horizontale schuifmaat maximale horizontale verplaatsing: 630 mm maximale verticale verplaatsing: 1000 mm Dwarsbalk maximale slag: 660 mm Max turningdia -- passage: 1250 mm Power on the spindle: 30 kW Number of speeds: 5 > 250 rpm Long: 2750 mm Wide: 2975 mm Lrjdpoxp Slbefx Af Eju

Condition: used, Technical details: table diameter: 4500 mm faceplate diameter: 4500 mm operating hours: 0 h swing diameter: 5000 mm turning diameter: 5000 mm workpiece height max.: 2500 mm control: Sinumerik 840D SL x-axis: 300 Hub/ram Slide mm x-axis: 2850 Hub / ram travel mm x-axis: 2850 working without tool mm x-axis: 5000 with tool changer mm w-axis: 1800 Querwegelevating cross rail mm Lodpfxeu Ix H Dj Af Esru tool holder / places: 12 tool taper: HSK 100 (spindle) workpiece weight: 100 t table speed: 1 - 50 U/min T-slots: 8 Stück (36 H12) stroke speed: fräsen ram speed: 4000 U/min rapid power traverse in X-and Z direction: 8000 mm/min Torque: fräsen: 100.000 Nm Torque: drehen: 200.000 Nm total power requirement: 80 (2x40) kW weight of the machine ca.: 140 t dimension machine xH: 11,5 x 6,6 x 8,4 m CNC vertical lathe - vertical - NEW ( It is a demonstration machine on the photos) Application of the manufacturing processes: Turning, such as external longitudinal turning, internal and external facing and profile machining. Grooving, such as internal and external Drilling, such as short hole drilling and deep hole drilling Milling, such as face-corner profile and T-slot milling Thread cutting But also suitable for roughing and end machining. The machine bed, designed with a welded construction, absorbs extreme cutting forces. The table is made of high-strength meehanite cast iron. To withstand heavy loads, the part weight is supported by two high-precision tapered roller bearings. Furthermore, the table is equipped with hydrodynamic support for the workpiece. other features: automatic tool change jaw chuck (8 pieces with power clamping spindle and hardened jaws) incl. cooling system 40bar with filter unit hydraulic and lubrication equipment ATOS and Dropsa with measuring system of axes Heidenhain Renishaw NEW - with guarantee & service via WWM AG *

Condition: used, Year of construction: 1996, Technical details: x-travel: 2500 mm y-travel: 560 mm z-travel: 600 mm control: TNC 426 CA bore capacity in steel (diameter): 400 cm³/min Max. Milling-capacity: 400 cm³/min tool changer with: 34 Plätze Tool pull-in force: 12 kN spindle taper MT: SK 40 spindle throat: 580 mm Revolution per minute: 20...7500 steples U/min. max. torque on the spindle: 210 Nm distance spindle nose and table: 0 - 600 mm feed:: X/Y/Z = 1 - 24.000 steples mm/min. rapid traverse:: X/Y/Z = 24 steples m/min feed power: X/Y = 6 kN und Z = 8 kN kN table-size: 3300 x 500 mm table load capacity - central/maximum: 2500 kp interface: ja total power requirement: ca. 43 kW Weight approx.: 14,4 t dimension machine xH: 3,05 x 5,6 x 3,0 m Lsdpfx Afovad Hpo Esru dimension swarf conveyor LxWxH: 6.6 x 0,6 x 1,3 m VERTICAL DRILLING AND MILLING CENTER in travelling column design. with integrated coolant supply link belt chip conveyor MAN+HUMMEL with cooling water tank and pump cooling lubricant treatment ALLWEILER AG, size L:1550 x W: 1000 x H:1200mm; filter belt width 500mm; pressure 30bar Hydraulic unit *

Condition: used, Year of construction: 2017, Technical details: x-travel: 1625 mm y-travel: 813 mm z-travel: 762 mm control: HAAS Automation spindle hours: 3127 h number of spindle speeds: max. 12.000 U/min. max. torque on the spindle: max. 122 Nm tool changer with: 30 + 1 Plätze table-size: 1626 x 711 mm max. table load: 907 kg spindle taper MT: SK40 spindle drive: 22,4 kW feed range: X/Y/Z: max. 21,2 m/min. rapid traverse:: X/Y/Z: 30,5 m/min interface: ja control voltage: 440 V air-pressure connection: 6,9 bar total power requirement: 22,4 kW Weight approx.: 10,2 t dimension coolant device: 2,5 x 1,2 x 0,9 m dimension machine xH: 4,8 x 3,2 x 2,9 m High-speed machining center Ball screws with double anchoring all axes with high-performance servomotors, directly connected to ball screw 2-stage gearbox Operation via control panel and manual control unit Lrsdova Ar Depfx Af Eeu Chip conveyor/screw conveyor Cooling device Accessories: SK40 holder Ø finger cutter SK40 measuring finger and various small parts *

Condition: used, Technical details: x-travel: 762 mm y-travel: 382 mm z-travel: 419 mm table surface area: 1070 x 230 mm spindle taper: Iso 40 weight of the machine ca.: 1600 kg This machine is currently in the technical department. Lodpfx Ajva Evfsf Esru *

Condition: used, Year of construction: 2000, Technical details: x-travel: 500 mm y-travel: 400 mm z-travel: 400 mm b-axis: manuell positionierbar ° c-axis: manuell positionierbar control: Heidenhain TNC 124 tool changer with: nein Plätze spindle taper MT: SK40 Lrjdju Idffspfx Af Eou Revolution per minute: 4500 U/min. feed speeds infinitely variable: X/Y/Z: max. 14000 mm/min rapid traverse:: 5,0 m/min table-size: 700 x 500 mm total power requirement: 17 kVA Weight approx.: 2,91 t dimension machine xH: 2,0 x 2,0 x 2,5 m CNC universal vertical milling machine The machine has 5 axes. B- and C-axis manual with measuring system. B-axis table swivel -10° / +95° and C-axis table rotate 360° (not interpolatable, manually selectable via control). Cooling device (without pump) Operation via swiveling boom *

Condition: used, Year of construction: 1995, Technical details: x-travel: 500 mm y-travel: 200 mm z-travel: 300 mm spindle taper ISO: SK 40 spindle head swivable left - right: je 45 ° range of revolution per miute: 45...2000 U/min headstock: dist. table - spindle center: max. 300 mm Lodeu Ndfuopfx Af Eoru distance spindle nose and table: max. 300 mm feed:: 16...800 / 18 step mm/min table surface area: 1000 x 165 mm table swivelling to both sides: ja Grad control voltage: 380 V total power requirement: 4,6 kW machine weight approx.: 1540 kg dimension machine xH: 1,5 x 1,5 x 1,6 m The milling beam is slide adjustable with 580mm. Throat min. / max. 250/800mm *

Year of construction: 1948, condition: used, Technical details: max. ram stroke: 450 mm table diameter: 800 mm min. ram stroke: 65 mm workpiece height max.: 600 mm ram adjustment: 600 mm no. of ram strokes: 18; 22; 28; 35; 45; 56 Hub/min. cross feed of the table: 800 mm longitudinal feed of the table: 1000 mm table rotation: 360 ° feed: Tisch: pro Hub: 0,14 - 0,22 - 0,35 - 0,56 - 0,9 -1,4 mm/Hub total power requirement: 7,8 kW weight of the machine ca.: 6,25 t dimension machine xH: 2,8 x 1,9 x 3,0 m Lrjdpfsu Ng Tbox Af Esu other features: Ram: -the ram is adjustable in the projection of 900mm -throat of bed = 700mm Tool clamp by means of bracket clamp (dimensions 350 x 250mm) Accessories: 1piece 3-jaw chuck Ø 250mm *

Condition: used, Year of construction: 2007, Technical details: balancing body max.: 100 kg balancing body diameter: max. Ø 800 mm swing diameter: 630 mm Balancing revolution per minute: 120 - 1200 U/min drive power: 4 kW Weight approx.: 0,6 t dimension machine xH: 1,8 x 1,2 x 1,4 m dimensions electric cabinet: 650 x 700 x 1900 mm Ljdpsvc Apzofx Af Ejru Vertical balancing machine The balancing machine is used to measure and balance the static or dynamic unbalance of rotors. Unbalance static=2 and dynamic=3 Measuring device CAB 803 Display Screen Computer RS232C Basic system dynamic unbalance in 2 levels Operation via control panel on the switch cabinet / 2x foot switch *

Condition: used, Year of construction: 1999, Technical details: x-axis: 800 mm y-axis: 500 mm z-axis: 510 mm control: Siemens 840D number of spindle speeds: 36 - 10000 U/min. tool changer with: 42 tools tool clamping: 12000 N tool taper: SK40 max. torque on the spindle: 102 Nm feed continuous: X/Y/Z: min./max.: 1/10000 / 1/10000 / 1-10000 mm rapid traverse: X/Y/Z: 40/40/40 m/min voltage: 400 / 50 V / Hz total power requirement: 70 kW HIGH PERFORMANCE DRIVING COLUMN - MACHINING CENTER Lrodpfx Afju Id Rbe Eou Coolant system with paper band conveyor chip conveyor make Flender MC535/x=800 hydraulic aggregate make HAWE Loading system Promo cutting values: max. milling capacity=400mm max. drilling Ø 50mm max. thread Ø M30 1 motor each for main spindle 1 + 2: make Kessler; 21 kW; speed 15.000 rpm. 1 motor each for X / Y / and Z-axis: Make Siemens; for X/Y axis 14.0 Nm and Z axis 17.6 Nm torque; speed 3000 rpm. *

Condition: used, Year of construction: 2001, Technical details: x-travel: 630 mm y-travel: 560 mm z-travel: 560 mm Lredsu Idgcjpfx Af Esu c-axis: Tisch 360° ° b-axis: Spindel=rechts:90/links=10° manuell ° control: Heidenhain TNC 430 MillPlusM table-size: 1000x600 mm table load capacity: 400 kg tool taper: SK 40 Revolution per minute: 20 - 12 000 U/min. feed speeds infinitely variable: x/y/z= 20 - 10.000 mm/min tool changer: 2 Magazine tool changer with: 12 place pro Magazin spindle hours: 21 212 h operating hours - idle run: 49 845 h total power requirement: 20,6 kW Weight approx.: 6,7 t dimension machine xH: 3,0 x 2,0 x 2,15 m Equipment: - AC motors for x/y and z-axis - Tool clamping hydraulic/mechanical - Chip conveyor with separator (screw conveyor) - seperately working indexing head Ø 300mm with manual control unit for B-axis table tilting -10° / +95° and C-axis table turning 360° (not interpolable, electric selectable via manual control unit) - Coolant unit 8 m³/h (dimensions: L:1,1 x W: 0,54 x H:1,2m) - control unit *

Condition: used, Year of construction: 1979, Technical details: throat: 410 mm Ljdpfx Asu Niu Ujf Ejru dimension machine xH: 1,15m x 0,8m x 2,0m m Vertical band saw with saw band welding device. The table is tiltable. *

Condition: used, Year of construction: 1954, Technical details: max. ram stroke: 220 mm workpiece diameter - max.: 400-450 mm total power requirement: 1,5 kW work table:: 650x250 mm ram adjustment: 100 Manuell mm no. of ram strokes: 45/78/125 table adjustment: 400 längs mm Ledpfxev Ty R Dj Af Ejru table adjustment: 150-170 quer mm table adjustment: ca. 360 vertikal mm tool - head swivelling: +/- 10 Grad total power requirement: 1,5 kW weight of the machine ca.: 0,9 t dimension machine xH: 1,2 x 0,9 x 1,8 m

Condition: used, Year of construction: 1977, Technical details: honing diameter: 125 mm stroke: 500 mm throat: - mm grinding spindle speed: 26-1200 (12Steps) U/min honing diameter: 30 (min.) mm honing diameter: 165 (max.) mm table adjustment:: 800/150 (max.) mm table surface area: 500 x 1000 cm total power requirement: 4,22 kW Weight approx.: 0,15 t dimension machine xH: 1,30 x 1,20 x 2,70 m There is a movable table that moves lengthwise and crosswise. Lredpfx Afsw Rv Taj Esu *

Condition: used, Technical details: dimensions of saw-band: 3400 mm saw band length: min. 3200 mm saw band width: 20 mm band speed: 6 / 12 / 25 / 75 / 150 m/min cutting speed: 15 - 1500 / steples m/min Lrsdpov T Th Nefx Af Eou Table dimensions: 665 x 665 mm table height over floor: 1050 mm table swivelling to both sides: 15° / 30° Grad table feed: Länge: 250 mm total power requirement: 4,0 kW dimension machine xH: 1,2 x 0,9 x 2,2 m Steel and metal band saw with saw band cutting, welding and grinding device Saw band speed 2 steps, infinitely variable Infinitely variable table feed Tiltable table Machine lighting Stop bar *

Condition: used, Year of construction: 1993, Technical details: x-travel: 400 mm y-travel: 300 mm z-travel: 400 mm spindle revolutions per minute : 8000 U/min control: Fanuc OM clamping table: 500x300 mm magazine slots: 16 Stück tool taper: SK40 distance work spindle /surface of the table max.: 50-450 mm numbers of pallets: 2 Stück/part total power requirement: 10 kW weight of the machine ca.: 2,5 t dimension machine xH: 2,4x1,8x2,5 m transport measurements machine: 2,45x1,8x2,5 m Lrjdpfx Aou Idn Hof Eeu - E-cabinet - cooling device - chip conveyor manufacturer META (conveying height 1500mm; width 200mm) *

Condition: used, Year of construction: 1998, Technical details: x-travel: 760 mm y-travel: 550 mm z-travel: 300 mm control: Röders RMS 6 Vers. 2.70 spindle taper ISO: HSK E40 turning speed range: 42.000 stufenlos U/min spindle head swivable left - right: -52 ° / +5° (B-Achse) ° feed:: 0 - 30.000 mm/min Tool changer: 18-fach Werkzeuge + 2 places for Werkzeugvermessung Table dimensions: 860 x 550 mm table load capacity: 800 kp Lredeu Ndbpepfx Af Eju Number of working hours: siehe Foto h compressed air: 6,5 bar total power requirement: 20 kW weight approx.: 7000 kg dimension machine xH: 3,1 x 2,4 x 2,6 m dimension coolant device: ca. 0,6 x 0,8 x 0,7 m other features: Highspeed direct spindle digital axis drives AC servo motors ball screw spray cooling (microjet cooling jet and lubrication unit) working spindle Fischer MFW - 1230/42 up to 42.000 rpm tool measuring laser and probe system PS 25.00 Manual control unit Climatic cabinet Cooling water recooler Hyfra The machine can be demonstrated under power. *

Condition: used, Technical details: x-travel: 880 mm y-travel: 300 mm z-travel: 900 mm w-axis: 60 mm spindle head swivable left - right: 60 ° table surface area: 880 x 300 mm machine weight approx.: 1200 kg Lredpsu Ndfhjfx Af Eeu dimension machine xH: 1,3 x 1,4 x 1,9 m incl. accessories *

Condition: used, Year of construction: 1976, Technical details: table surface area: 1300 x 190 mm range of revolution per miute: 60 - 4000 Stufenlos U/min feed continuous: Pinole: 0,06 / 0,12 / 0,24 mm/U quill stroke vertical: 140 mm spindle taper: SK 40 spindle head swivable left - right: 90° und 45° ° total power requirement: 3,0 kW weight of the machine ca.: 1620 kg machine dimensions LxWxH: 2,7 x 2,3 x 2,4 m Milling machine with universal milling head Spindle run right/left Table specifications: X/Y/Z travel: 860/380/460mm. feed X/Y/Z: 40 - 400mm/min. continuous rapid traverse 400mm/min. max. workpiece weight 30kg Equipment 3-way measuring display Mitutoyo with beam machine lighting Coolant tank with pump X- and Y-axis feed adjustable Lrjdpfsu Sq Emjx Af Eju incl. accessories comparable to the picture *

Condition: used, Year of construction: 2006, Technical details: Ledpeu Idfrjfx Af Esru x-travel: 1000 / 600 mm y-travel: 570 mm z-travel: 570 mm control: Fagor 8055 MC tool changer with: 24 Plätze tool taper: SK 40 Revolution per minute: 10 000 U/min. spindle taper: SK40 feed speeds infinitely variable: X/Y/Z: 10 m/min. rapid traverse:: X/Y/Z: 24 m/min. operating hours - idle run: nicht einsehbar h table-size: 1200 x 500 mm table load capacity: 800 kg distance spindle nose and table: min./max. 100/670 mm interface: 232 total power requirement: 15 kW Weight approx.: 5,0 t dimension machine xH: 3,3 x 2,3 x 2,8 m Equipment: -Cooling device with feed to the spindle (no CTS cooling through spindle)) -operating panel with manual control unit -chip conveyor -E-cabinet cooling Rittal SK 3305500 *

Condition: used, Technical details: honing diameter: Ø 400 mm stroke: 600 mm throat: 390 mm table-size: 1.550 x 780 mm Lrsdpfx Aou Ngybjf Esu table surface area: 1.400 x 480 mm table:: fest total power requirement: 4,1 kW Weight approx.: 2,8 t dimension machine xH: 2,0 x 1,2 x 4,35 m Further technical details: - longitudinal travel of machine table approximately 500mm - cross travel of machine table approximately 200mm - working height 350mm (non-adjustable) - distance column / table 0 - 200mm Equipment: - oil tank Ø 300 x 600mm - control panel i.D. *
