Used House Connection Column for sale (23,486)

Condition: used, Year of construction: 2001, Technical details: pressure: 250 t throat: 360 mm distance table/ram: 800 mm Kjdpfjxna Uzjx Afisdu max. ram stroke: 500 mm ram speed - reverse: 390 mm/sec. ram speed - forward: 450 mm/sec. hydraulic-pressure: 280 bar connected load: 43 kW work speed: 11....50 mm/s operating pressure: 20 MPa total power requirement: 20,5 kW weight of the machine ca.: 17 t dimension machine xH: 3,9 x 1,9 x 4,0 m

Condition: used, CNC Travelling Column Drilling and Milling Machine ANAYAK Type HVM-3800-P Bed milling machine, design similar to a plate boring mill with fixed table Machine No.: M-20021203 Year of manufacture: 2002 Travel (X/Y/Z): 3200 mm / 1200 mm / 1500 mm Table size: 3800 x 1200 mm T-slots: 8 pieces, 22 mm width, 130 mm pitch Table load capacity: max. 25 tons (fixed table - virtually unlimited load) Kdedpoxcgtgjfx Afiou Spindle taper: ISO 50 (DIN69871-A) (drawbar DIN 69872-B) Spindle speed: 60-4,000 rpm, infinitely variable Feed rate: up to 10,000 mm/min, infinitely variable Rapid traverse X + Y: 20 m/min Rapid traverse Z: 10 m/min Spindle drive: 22 / 30 kW Power supply: 400 Volt, 50 Hz, 50 kVA - Automatic tool changer for 30 tools - Spindle drive with 2 speed ranges - With automatic tool changer and tool magazine - Orthogonal milling head with hydro-mechanical tool clamping - Orthogonal milling head, fully automatic swivelling in two 45° planes - B+C axis - HEIDENHAIN iTNC 530 control, with electronic handwheel - Prepared for wireless measuring probe (probe and receiver not included) - Additional HF spindle 18,000 rpm - for mounting - Free-standing electrical cabinet - Chip conveyor positioned between the travelling column bed and machine table - 32,078 operating hours recorded - Coolant system - Free-standing hydraulic power unit - Operating manuals with circuit diagrams Machine footprint: L x W approx. 1,000 x 700 cm Machine height: approx. 410 cm Weight (complete): approx. 33 tons Good condition Available immediately, ex location Kassel, loaded free of charge

Condition: like new (used), Gillardon column drilling machine type GB 30 V, speed 60-1800 rpm, automatic feed, very good condition Kdedpfx Aoxpxbcsfieu

Condition: used, Year of construction: 1990, Technical details: Pressure: 63 t distance between columns: 200 mm stroke: 150 mm dayligth: 430 mm no. of strokes: 400 Hub/min T-slots H 12 650: 18 mm hole in table: 420x160 b x l mm ram surface area: 650 x 450 mm control: Wanske Tronicpress CNC passage of columns: 550x540 mm tank: 200 l stroke of ram - fixed: 100 mm ram diameter: 40 mm table height over floor: 1000 mm table: 600x450 mm table height over floor with metal base stand: 880 mm total power requirement: 30 kW weight of the machine ca.: 3,9 t Hydraulic automatic punching press for precision work (high-speed press) - for punching, drawing, pressing, minting, bending, riveting, straightening, assembling - with hydraulic gripper feed type HS 150 and 7-roller straightener (moving) - Normal strips of approx. 0.4mm - 2.5mm thickness x approx. 160mm width, as well as narrow strips up to approx. 4mm can be processed. Feed length can be adjusted as required via the control unit. - with ram round column guide - with automatic central lubrication - High-speed: up to 400 strokes min-1 - motorized adjustable fixed stop (bottom can be adjusted by hand/motorized) - Operating modes such as continuous stroke and/or single stroke Equipment: - 1x hydraulic unit - 2x control cabinets Kodpfju Icxqex Afiedu *

Condition: used, Technical details: pressure: 63 t distance between columns: 900 mm no. of strokes: ca. 75 Hub/min ram adjustment: 80 mm stroke adjustable from - to: 3-100 mm Table dimensions: 900 x 600 mm throat: 310 mm dayligth: max. 350 mm drive power: 11 kW voltage: 380/220/24 V frequency: 50 Hz operating pressure: ca. 150 bar oil volume: 500 l safety distance: 150 mm passage opening in table: 200 mm Kedpeu Nfnksfx Afijdu total power requirement: 11 kW weight of the machine ca.: 4,0 t space requirements of the machine approx.: L:1,8 x B:1,8 x H:3,7 m DIFFERENTIAL PATH PRESS HIGH SPEED PRESS - High-speed press, C-stand - Compressed air connection: approx. 5 bar Condition. Press is not under power, without switch cabinet, sale as is. - Documentation available i.D. *

Condition: used, Year of construction: 1980, Technical details: pressure: 400 t stroke: 40 - 140 mm strokes / minute continous: 32 throat: 400 mm dayligth: min/max: 450/590 mm ram adjustment: 125 mm table-size: 1250x750 mm height over floor: 1130 mm total power requirement: ca. 31,5 kW weight of the machine ca.: 23,0 t machine dimensions LxWxH: 3,7 x 1,7 x 3,9 m dimensions electric cabinet LxWxH: 1,0 x 0,7 x 2,1 m Kedpju N A Uusfx Afisdu further details: - clamping plate : L x W x H : 1260 x 760 x 100mm - with draw cushion device force 250kN, travel approx. 83mm - control via panel i.D. *

Condition: used, Year of construction: 1980, Technical details: Pressure: 160 t Ksdpsu N A U Iofx Afiodu stroke: 20-160 mm throat: 400 mm ram adjustment: 120 mm no. of strokes: 71 Hub/min daylight dimension : table/slide up: 720 (bei Hub 160mm) mm daylight dimension : table/slide low: 560 (bei Hub 160mm) mm ram surface area: 900 x 660 mm distance between columns: 500 x 450 mm table surface area: LxBxØ: 1200 x 750 x 100 mm total power requirement: ca. 23.0 kW weight of the machine ca.: ca. 15,0 t dimension machine xH: 2,7 x 1,5 x 3,45 m dimensions electric cabinet LxWxH: 2,0 x 0,65 x 2,15 m Operation via control panel/operator stand/foot control and hand-held control unit The press can be offered with two options. 1st option: Sold as is, not connected, not complete, not functional. 2nd option: The baler will be refurbished, all parts will be exchanged, replaced and puddled. The press will be set up again. For inquiries about this press, please select your offer option! in progress. *

Condition: used, Year of construction: 1991, Technical details: Kdjdew D Awmopfx Afieu Pressure: 160 t stroke: 500 mm throat: 360 mm max. ram stroke: 500 mm distance table/ram: 800 mm clamping plate on table: 1250 x 630 x 100 mm passage opening in table: 4x D=62 mm ram speed - forward: 200 m/s ram speed - reverse: 125 m/s ram surface area: 450 x 850 mm mortise hole in ram: 49 mm height over floor: 810 mm total power requirement: 17 kW weight of the machine ca.: 7200 kg dimension machine xH: 2,1 x 1,4 x 3,4 m manual counter *

Condition: used, Technical details: pressure: 40 t distance between columns: - mm stroke: 500 mm throat: 360 mm distance table/ram: max. 800 mm Kdedsw Smukopfx Afiju daylight dimension : table/slide up: 600 mm ram stroke: 500 mm ram speed - forward: 0,100 m/s ram speed - reverse: 0,450 m/s Table dimensions: 750 x 500 mm passage inside table: 200 mm surface area of ram: 360 x 450 x 72 mm mortise hole in ram: 40 x 75 mm height over floor: 700 mm total power requirement: 13 kW weight of the machine ca.: 3,2 t dimension machine xH: 1,75 x 1,15 x 2,95 m Operation via two-hand control panel. (and one-hand operation) *

Condition: used, Technical details: Pressure: 2,3 t stroke: 280 mm throat: 155 mm max. ram stroke: Vorlauf: 0,08 m/sec daylight dimension with clamping plate Slide/ up: 355 mm distance table/ram: max. 355 mm clamping plate on table: 280 x 280 mm passage opening in table: Ø 100 mm ram speed - forward: 0,08 m/s ram speed - reverse: 0,32 m/s mortise hole in ram: Ø 20 x 45 mm height over floor: 725 mm total power requirement: 1,1 kW weight of the machine ca.: 0,5 kg dimension machine xH: 0,6 x 0,7 x 1,6 m Press with mechanical 2-hand operation. Pressure test up to 2,3to performed. Good condition. Kodpfju Nfwlex Afiedu *

Condition: used, Year of construction: 1986, Technical details: pressure: 63 t no. of strokes: 65 / 130 Hub/min throat: 315 mm ram adjustment: 60 mm ram stroke: 10 - 105 mm distance between table / ram: 335 mm distance between columns: 355 mm clamping plate: 800 x 610 x 85 mm ram surface area: 450 x 280 mm compressed air: 9 bar control voltage: 24V / 50Hz V total power requirement: 7,5 kW weight of the machine ca.: 5,9 t dimension machine xH: 1,42 x 1,8 x 2,6 m Ksdou N Dafepfx Afisdu Control via foot pedal *

Condition: used, Technical details: pressure: 25 t distance between columns: 360 mm stroke: 500 mm daylight dimension : table/slide up: 800 mm throat: 360 mm ram stroke: 500 mm ram speed - forward: 0,200 m/s ram speed - reverse: 0,45 m/s Ksdou U D I Ropfx Afiedu Table dimensions: 630 x 500 x 71 mm passage inside table: Ø 182 mm surface area of ram: 450 x 360 mm mortise hole in ram: Ø 32 x 72 mm ram diameter: Ø 125 mm height over floor: 710 mm total power requirement: 12,5 kW weight of the machine ca.: 2,4 t dimension machine xH: 1,7 x 1,1 x 2,95 m Operation via two-hand control panel (and one-hand operation in set-up mode) Continuous and single stroke TÜV until 05/2024 *

Condition: used, Technical details: pressure: 90 t throat: 320 mm no. of strokes: 90 Hub/min daylight dimension : table/slide up: ca. 380 mm ram adjustment: max. 65 mm ram surface area: 600x55 mm clamping plate on table: 800x640x80 mm passage: 260x160 mm adjustment of stroke: 60 fest/fixed mm total power requirement: 5,5 kW weight of the machine approx.: 4500 kg space requirement approx.:: L:1,8xB:0,82xH:2,42 m - single / continous stroke - manual not available - normal maintennance has been executed, overhauled 2010 - at the moment without electric cabinet, without control, without air pressure tank i.D. Kdodpfxou Nfg Ho Afiju *

Condition: used, Year of construction: 1964, Technical details: pressure: 125 t stroke: 28 mm number of strokes: 56-225 Hub / Min distance between columns: 1000 mm ram adjustment: 60 mm distance table/ram: 376 mm Table dimensions: B.950xT:720 mm passage opening in table: 400x130 mm height over floor: 1120 mm ram surface area: 920x540 mm Kdodpfsu Nfibox Afisu mortise hole in ram: Dm 65 x 120 mm column travel -side: 250 mm total power requirement: 30 kW weight of the machine ca.: 15,5 t dimensions of machine: 3,1x1,34x3,6 m dimensions electric cabinet LxWxH: 0,64x0,22x1,2 m This press is a high-performance press for mass production /series production. - Contains left side a material feed via automatic feed (mechanic) and right side a waste cutter. Feed = 0-200mm, roll width =250mm Partial documentation as a copy available. Machine is not functional and is on sale as is! *

Condition: used, Year of construction: 1983, Technical details: pressure: 100 t stroke: 20 fest mm Ksdpfx Afou Nfi Uoiedu no. of strokes: 55 Hub/min table surface area: 900x640 mm throat: 355 mm ram adjustment: 150 mm mortise hole in ram: Ø 36 mm clamping surface ram: 500x415 mm height over floor: 800 mm biggest distance between table & ram: 390 mm passage opening in table: Ø 330mm mm total power requirement: 11 kW weight of the machine ca.: 7,5 t transport dimensions LxWxH: 1,9x1,6x3,1 m Press is without electric cabinet, optional construction of electric cabinet possible. *

Condition: used, Year of construction: 1974, Technical details: pressure: 30 t ram surface area: 450x250 mm ram adjustment: max. 50 (manual) mm strokes per minute: 20 - 120 stroke: ca./approx. 20 mm mm adjustment of stroke: nein/ no stroke adj. mm Kedpfou Icx Rox Afisdu dayligth: Arbeitsraum: 220 - 280 mm Table surface area useable: 600 x 600 mm total power requirement: 7,5 kW weight of the machine ca.: 5,0 t dimensions L x W x H: Maschine: 1,8 x 1,2 x 2,7 m Dimensions (LxWxH): Schaltschrank: 0,92 x 0,46 x 1,4 m Automatic punching press 4 columns mechanical with feed unit with control panel passage widths: Column opening front=350mm and side=258mm *

Year of construction: 1997, condition: used, Technical details: Kdodpfx Aou Nfn Rjfiou pressure: 250 t stroke: ca. 400 mm pass through width: 640 mm table above floor: 900 mm ram stroke speed: regulierbar/adjustable passage between the side columns: 470 mm table clamping surface LxW: 570x550 mm clamping area of ram: 570x550 mm total power requirement: 56 kW weight of the machine ca.: ca. 9,0 t dimension machine xH: 2,5x1,8x3,8 m transport dimensions LxWxH: 2,6x1,8x3,1 m - control manual and via automatic via SPS Allen Bradley - one hand and two hand control - ram guidance column, zero backlash - set up mode and automatic mode via SPS controlled - light curtain type "Sick" and safety curtains installed - no CE certification available i.D. *

Condition: used, Technical details: pressure: 80 t distance between columns: 880 mm dayligth: 200 mm Table dimensions: 880x300 mm height over floor: 1000 mm distance between columns: 800 mm total power requirement: ca. 12 kW machine weight ab.: 2855 kg space requirements of the machine approx.: T:1,4xB:1,65xH:1,9 m Embossing - Hot Embossing application area: - for example: for foils, plastics, paper, hardboard materials etc. - stamp plate size: 600x310mm equipment: - counter Kjdpfxju Icwtj Afiedu - hydr. tank Accessories: - Mounting plate (600x300x90mm) not heatable. Sale as is. *

Condition: used, Technical details: pressure: 100 t daylight dimension : table/slide up: 800 mm throat: 360 mm ram stroke: 500 mm Kodpfxovc Ax Nj Afijdu ram speed - forward: 200 m/s ram speed - reverse: 200 m/s Table dimensions: 750 x 560 x 90 mm passage inside table: Ø 26 mm clamping surface ram: BxT: 530 x 400 mm mortise hole in ram: Ø 50 mm cylinder diameter: Ø 250 mm height over floor: 720 mm total power requirement: 17,0 kW weight of the machine ca.: 5,5 t dimension machine xH: 1,8 x 1,2 x 3,2 m

Condition: used, Technical details: pressure: 160 t throat: 760 mm slide stroke: 32...140 mm distance between table / ram: 400 mm Kdsdpou Nfhqsfx Afieu ram adjustment: 100 mm no. of strokes: 50 Hub/min table:: 760x1000x95 passage opening in table: 400x350 mm clamping surface ram: 630x850 mm clamping plate: 760x1010x92 mm total power requirement: 15 kW weight of the machine ca.: 6,2 t dimension machine xH: 2,9x1,2x3,4 m dimensions electric cabinet LxWxH: 0,8x0,45x2,1 m - via two hand control - copy of documents digital available Machine can be demonstrated under power. *

Condition: used, Technical details: pressure: 80 t dayligth: 600 mm ram stroke: 200 mm Kodpju Nfnwjfx Afisdu pressure: 30 t dayligth: 680 mm ram stroke: 300 mm distance between columns: 1060 mm base plate surface area: 1060x600 mm table above floor: 720 mm ram stroke speed: Stößel/ Ram 1: 40 mm/sec ram stroke speed: Stößel/ Ram 2: 95 mm/sec base plate surface area: Dm=150 mm total power requirement: 13 kW weight of the machine ca.: 4,5 t space requirement approx.:: L:1,6xB:1,1xH:3,4 m - Press with two ram with 30 t + 80 t - foot control - documentation *

Condition: used, Year of construction: 1991, Technical details: pressure: 40 t daylight dimension : table/slide up: 450 mm throat: 375 mm ram stroke: max. 300 mm Table dimensions: 900 x 500 x 85 mm passage inside table: Ø 120 mm height over floor: 900 mm total power requirement: 15,0 kW weight of the machine ca.: 5,8 t dimension machine xH: 2,3 x 1,45 x 2,40 m Kdsdeu Nfp Iepfx Afieu further technical data: -size of the ram plate W: 900 x D: 500mm -pivot hole in ram Ø 40 x 75mm -Hydraulics: tank capacity approx. 500Liter; operating pressure 275 bar; pump capacity 22,9 l/min. Two-hand operation and/or control panel *

Condition: used, Year of construction: 1960, Technical details: Kdjdpfxsu Nfude Afiju pressure: 10 t throat: 255 mm max. ram stroke: 400 mm ram speed - reverse: 0,180 m/sec. m/sec. ram speed - forward: 0,080 m/sec. m/sec daylight dimension : table/slide up: 630 mm daylight dimension : table/slide low: 230 mm table clamping surface:: 420 x 400 mm passage opening in table: 220 mm surface area of ram: 200 x 200 x 65 mm total power requirement: 1,6 kW weight of the machine ca.: 1,1 t dimension machine xH: 1,1 x 0,5 x 2,1 m

Condition: used, Year of construction: 1985, Technical details: pressure: 100 t Kdedju Nfh Dspfx Afieu no. of strokes: 35-100 Hub/min throat: 360 mm ram adjustment: 20-130 mm ram surface area: 750x550 mm clamping plate on table: 1000x640 mm adjustment of stroke: 90 mm passage between the columns longitudinal/sideways: 610x500 / 440x550 mm daylight dimension : table/slide low: 300 mm total power requirement: 17,5 kW weight of the machine ca.: ca,7,0 t dimension machine xH: 1,9x1,4x2,7 m - there are 5 T-slots lengthwise on the ram plate - centre hole = 50mm This press is currently for sale without controls. Optional on customer request completion possible. i.D. *

Condition: used, Technical details: pressure: 25 t stroke: 500 mm daylight dimension : table/slide up: 800 mm throat: 360 mm ram stroke: 500 mm ram speed - forward: 0,100 m/s ram speed - reverse: 0,45 m/s Table dimensions: 630 x 500 x 75 mm Kdedpfx Aovc Awxefiju passage inside table: Ø 180 mm surface area of ram: 450 x 360 mm mortise hole in ram: Ø 32 mm height over floor: 710 mm total power requirement: 8,75 kW weight of the machine ca.: 2,2 t dimension machine xH: 1,7 x 1,1 x 2,95 m Operation via two-hand control panel. (and one-hand operation) *
