Used Heesemann Lsm 8 for sale (10)

Condition: ready for operation (used), Year of construction: 2002, General Data Lodpfxoxp Spyj Ab Usah Measurements width 2300 mm Measurements depth 3850 mm Measurements height 2500 mm Machine weight 9200 kg This HEESEMANN LSM 8 belt sander was manufactured in 2002. It features a sanding width of 1300 mm and accommodates workpiece thickness from 3 to 80 mm. Equipped with a vacuum transport belt and variable feed speed of 5–25 m/min, it ensures efficient material handling and flexibility in sanding operations. Consider the opportunity to buy this HEESEMANN LSM 8 belt sander. Contact us for more information about this machine. Application Types Sanding

Condition: good (used), working width: 1,350 mm, HESEEMANN LSM8 Lajdpfxexcg Scj Ab Ush

Condition: used, machine/vehicle number: 006530, Max. machining width: 1300 mm Min. machining thickness: 3 mm Working Table: Fixed pass height Vacuum feed belt: yes No. Operating units: 8 Nr Lodpswcybmofx Ab Uoah

Condition: ready for operation (used), Year of construction: 1994, Operating voltage: 380V Frequency: 50Hz Weight: 7500 Current consumption: 172 A Year of manufacture: 1994 Lasdpfxst Dk Sis Ab Ujh Calibration: Standard: 1350 x 2620 mm Cross-grinding: Standard: 5400 x 150 mm Longitudinal grinding: Standard: 1350 x 2620 mm Machine dimensions Working width: 1300 mm

Condition: used, Year of construction: 2012, operating hours: 60,000 h, functionality: fully functional, feed rate X-axis: 12 m/min, workpiece weight (max.): 50 kg, working width: 1,350 mm, total length: 62,000 mm, total height: 2,800 mm, total width: 3,200 mm, type of input current: AC, working height: 120 mm, input voltage: 400 V, suction capacity: 36,000 m³/h, input current: 800 A, input frequency: 50 Hz, power: 440 kW (598.23 HP), compressed air connection: 6 bar, complete lacquering line: 1x Heesemann sander (LSM 8, 2006.10.251, 2006, 2x roller / 2x pads, ) Laedpfxov T Ttxj Ab Ujh 2x Safo brushing machne (2006, DCSF 135 2W) 1x Cefla lacquering spray Cabin (2012, Roctre D/HS) 3x Cefla hot air drying tunnel (2012, Aquadry LA ) 1x Cefla cold air drying tunnel (2012, Aquadry RLA) 1x UV lamp dryer ( 3lamps, UV-R SPM3/2500s) 2x hydraulic lifters (200-900mm height)

Condition: used, Year of construction: 2004, - Cutting width (mm): 1300 Lodpfx Aott Slceb Uoah - Workpiece thickness max. (mm): 3 -140 - Brushing device: Brush roller diameter 150 mm - Drive for brush-off device (kW): 1.5 - Transport bed: 3.0 kW FU 4.0 kW - Feed speed (m/min.): 5 - 25 - Workpiece conveyor belt suction clamping system (kW): 7.5 - Total weight (kg): approx. 7500 - Total power connection (kW): approx. 73

Condition: used, Year of construction: 2006, operating hours: 100,000 h, functionality: fully functional, feed rate X-axis: 30 m/min, workpiece weight (max.): 50 kg, working width: 1,400 mm, suction capacity: 48,000 m³/h, type of input current: three-phase, total height: 2,800 mm, total length: 68,000 mm, total width: 2,600 mm, working height: 75 mm, power: 720 kW (978.93 HP), input frequency: 50 Hz, input current: 1,800 A, operating pressure: 6 bar, workpiece width (max.): 1,250 mm, compressed air connection: 6 bar, complete lacquering line: Ledpfev Ta Tfox Ab Uoah 2x Heesemann sanders (LSM8 2006.12.141, 3rollers-3pads/ LSM8 2006112.151, 2pads) 2x Heesemann cleaning mach. (EA8 2006.12.142 / EA8 2006.12.152) 1x Cefla hot air drying tunnel (FEV EU2/8 6 IRM / TNSL) 4x UV lamps dryer ( 2lamps, UV 2000 M2+CRU+TN 4000/HT / 4lamps UV 2000 M2+CRU+TN 5000/HT / 2lamps / 4 lamps) 2x stain roller coaters ( Smartcoater M-EVO / model M) 2x heavy putty roller coaters (Smartcoater SP / SP1-EVO) 3x lacuer roller coaters (Smartcoater MF) 10x belt/roller conveyors 2x hydraulic lifters (200-900mm height)

Condition: reconditioned (used), Year of construction: 2000, functionality: fully functional, working width: 1,350 mm, overall weight: 10,000 kg, input current: 153 A, Heesemann LSM8 Surface Sanding Machine QLkLBw Sanding width: 1350 mm CROSS/LONGITUDINAL/LONGITUDINAL Laedsxp Hvnopfx Ab Ueh Machine Base Conveyor unit with a single transport belt, adjustable feed speed from 3 to 15 m/min by frequency inverter, including transport belt cleaning device. Constant working height of 920 mm. Automatic adjustment for various workpiece thicknesses (3 - 80 mm) via motor-driven movement of the upper machine section. The lifting gear’s toothed belt is dust-protected, and its operation is monitored via the integrated control cabinet. 1. Cross Sanding Unit Belt dimensions: 5,400 x 150 mm Drive power: 13/17 kW Sanding belt with additional blast tube for belt cleaning, wear-resistant brake unit, pressure segment belt system, intermittent belt cleaning system, and belt alignment control. Includes a door with glass window. 2. Longitudinal Sanding Unit Belt dimensions: 2,620 x 1,350 mm Drive power: 13/17 kW Belt with double cleaning nozzles, wear-resistant brake unit, automatic belt length compensation, sanding belt operation counter to feed direction, intermittent belt cleaning, and infrared belt control. The front roller (steel) has an eccentric bearing for light calibrating, controlled from the operator terminal. 3. Longitudinal Sanding Unit Belt dimensions: 2,620 x 1,350 mm Belt speeds: 0.5 – 18 m/s Drive power: 17 kW with frequency inverter Continuously adjustable sanding belt speed, double cleaning nozzle setup, wear-resistant brake unit, automatic belt length compensation, counter-feed direction sanding, intermittent belt cleaning, and infrared belt control. 4. Brush Roller Unit Centrally height adjustable, includes extraction hood and press-on roller. Roller diameter: 150 mm Drive power: 1.5 kW Bristles: fiber 5. Workpiece Suction Device Ensures safe transport of workpieces shorter than 500 mm in the feed direction, with integrated extractor fan. Voltage: 400 V, 50 Hz Belt exchange: left Operator terminal: left 6. Ionization Bar (from above) Removes static electricity, including high-voltage transformer. 7. Workpiece blow-off device with rotating compressed air nozzles inside the frame. The machine is ready for operation at your facility after mechanical and electrical overhaul by an authorized Heesemann service partner. Fitted with a new conveyor belt. Commissioning and training at your site may be arranged subject to negotiation. Transport costs negotiable – loading included in the price. If you have any questions, feel free to contact me. Paweł Szczepański +48 795 517 258

Year of construction: 2004, condition: ready for operation (used), A 5-roller Heesemann wood sanding machine is available. Sanding belt dimensions: 2620 x 1350mm, sanding width: 1300mm, working height: 1000mm, roller diameter: 250mm, belt speed: 24m/s, suction volume: 89.5m³/min, suction nozzle diameter: 250mm + 180mm, air speed: 20m/s. Dimensions X/Y/Z: approx. 5200mm/2300mm/2300mm, weight: approx. 13000kg. Documentation available. On-site inspection is possible. Lajdpfx Abet Amc Uo Ush

Condition: excellent (used), Year of construction: 1997, total length: 4,400 mm, working width: 1,400 mm, height adjustment type: electric, input frequency: 50 Hz, input voltage: 400 V, Good day, We present for sale Heesemann LSM 8 wide-belt grinding machine in a system of four grinding units: transverse unit / longitudinal unit with calibration roller / longitudinal unit with reverser / longitudinal unit + dust collection brush. Machine after mechanical overhaul and inspection, checked and set up, ready to work. Year of construction: 1997 Feed speed: 5-25 m/min - infinitely adjustable from the control panel Working height: 880 mm Ljdpfxju Hlzfe Ab Usah Workpieces machined: 3-80 mm Energy demand: 107 kW - at full load Total weight: 10250 kg Control: control panel with physical buttons and display Controls: and side of abrasive belt change: right Single conveyor belts, perforated, perforated table with channel and vakuum fan - for safe transport of short workpieces. Part pressure: rubberized rollers fi 70 mm. Abrasive belt Q aggregate: 5400 mm x 150 mm Motor power: 13/17 kW - two-speed motor - belt speed: 12 m/s / 24 m/s Belt "sergeant": 4850 mm x 141 mm Longitudinal belts L aggregate: 2620 mm x 1450 mm Motor power: 16.5 kW / 21 kW - two-speed motors - 10 m/s / 20 m/s Pressing: Pressure beams with computer-controlled selective pressure control - CSD® system with infinitely variable pressure adjustment of individual pressure elements for trouble-free multi-row loading. Reading control roller distance: 16 mm. The abrasive belts have a cleaning system - blow-off and dust extraction. Workpiece tolerance compensation to a maximum of 2 mm by maintenance-free pressure electromagnets. Working width, as well as the beginning and end of the grinding of the pressure bar electronically controlled. Cleaning of the abrasive belts by means of blow-off tubes, dust extraction by means of integrated exhaust channels, activation of the blow-offs automatic, upon detection of workpieces in the machine. At the end, a cleaning/deblasting brush fi 150 mm with an exhaust duct for dust removal. Additional blow-off rotors at the exit of the machine with an exhaust channel. Commissioning at the new site and initial training in operation - to be agreed. Price negotiable on request, machine available immediately.
