Used Groove Grinding Machine for sale (91,703)

Condition: used, Year of construction: 1982, Technical details: Lsdpfew Rktzex Af Eeru grinding diameter: 350 mm grinding length: 1000 mm centre height: 225 mm grinding length: max. 1600 mm centre distance: 1540 mm spindle bore: 38 mm max. swivability: 90 ° weight of the machine ca.: 6,0 t dimension machine xH: 4,4 x 2,45 x 2,3 mm Machine with CNC package and DFU connection Multi-range measuring head for interrupted surface Tailstock with cylinder error correction Final balance balancing device *

Condition: used, Year of construction: 1970, Technical details: grinding length: 1000 mm grinding width: 315 mm workpiece height: 390/455 mm feed: quer: 0,3-3,5 mm table adjustment: längs 1150 mm table speed: 2,5-25 m/min Table dimensions: 2120 x 600 mm magnetic plate size: 1000 x 315 x 100 mm table surface area: 1160 x 315 mm feed of spindle: 0,002 - 0,05 mm distance table - spindle center: max. 550 mm throat of the spindle nose: 200-580 mm grinding spindle speed: 1500 / 3000 U/min total power requirement: 10,5 kW weight of the machine ca.: 5,0 t dimension machine xH: 1,3x1,4x1,95 m dimension coolant device LxWxH: 0,7x0,7x0,55 m - coolant device (Tank with pumps) Lsdpfxeu Nggzj Af Esru - 2 pieces grinding disc intakes - 4 pieces machine base i.D. *

Condition: used, Year of construction: 1971, Technical details: grinding length: 700 mm workpiece height: 80 mm Table dimensions: 105 x 725 mm feed range: mechanisch total power requirement: 0,8 kW dimension machine xH: 0,7 x 1,3 x 1,4 m Application: Grinding of linear surfaces for shearing knives and div. tools. Grinding support: -Vertical adjustment travel 45mm hand crank. -speed 2840 rpm -rotate 20° right/left -swivel 40° back and forth table: -with stop bar 730mm -equipped with 2x clamps / 2x fences -grinding depth by manual adjustment 80mm -mechanical feed, adjustment travel approx. 0.3 mm/double stroke Ledpfx Afou Ngk To Eoru -swivel 5° - 25° via hand toggle -1x chucking groove centered accessories: Box with div. grinding wheels *

Condition: used, Year of construction: 1964, Technical details: shaft diameter: max. 120 mm work piece - max.: 800 mm height of profile: Tiefe: max. 90 mm grinding spindle speed: nicht bekannt U/min Lrjdpfsu Ngr Dox Af Eju Table dimensions: Ø 150 mm voltage: 380 V total power requirement: 1,1 kW weight of the machine ca.: 0,675 t dimension machine xH: 0,75 x 0,70 x 2,0 m Application: vertical internal cylindrical grinding of shafts face, and center grinding with shaft grinder. Spindle head technical details: -equipment shank grinder Ø 13mm 60°; clamping element Ø 6mm shank clamping head. -travel=vertical 950mm by handwheel and transversal 80mm by crank handle -abrasive device with diamond, adjustment crosswise= 80mm. Table other specifications: -with fixed tip holder 60°. -speed 63 / 125 rpm. -adjustment vertical 600mm, in height 1.100mm, operation manual. centering block: -prismatic guide accessories: -fixed tip L=180mm -fixed tip L=300mm -div. shank grinder -div. clamping and auxiliary tools *

Condition: used, Year of construction: 1996, Technical details: grinding diameter: 1,5 - 75 mm grinding wheel diameter: 400 mm grinding wheel width: 160 mm work stroke: 0 - 1 mm working feed: stufenlos/ continous mm/min grinding wheel speeds: 1300 U/min control for program: Num 1020 GC total power requirement: 14 kW weight of the machine ca.: 3,8 t dimensions of machine: 3,0x2,2x2,2 m dimensions electric cabinet LxWxH: 1,5x0,4x2,0 m CIRCULAR GRINDING MACHINE - alloyed round steels as well as (grooving process) throughfeed process. - In the plunge process, the plunge-cut length is max. 160mm. - Workpiece removal automatically via rail (its function or operation is not known to WMW AG) - grinding wheel with reshaping device, speed = 1300 rpm. - regulating grinding wheel with reshaping device, infeed angle right 0-6° and left 0-2°; wheel size 280x160mm - automatic grinding wheel balancing system accessories: various grinding and regulating wheels on request The machine is operating in manual mode! The control is in the Catalan language and none of our employees can control the machine or understand the language. Ljdpsu Ngyzsfx Af Eeru *

Condition: used, Technical details: grinding length: 1000 mm grinding width: 500 mm workpiece height: 500 mm table surface area: 1000 x 450 mm magnetic plate size: 1005 x 500 x 84 mm table speed: k.A. m/min table adjustment: längs: 1100 mm table adjustment: quer: 500 mm Lrodpfsvc Aw Eox Af Esu grinding spindle speed: 1420 - 2840 U/min grinding head vertical adjustable: 700 mm dimensions of grinding wheel: Ø 280 x 50 mm weight of the machine ca.: 2,7 t dimension machine xH: 3,1 x 2,0 x 2,4 m dimension coolant device LxWxH: 3,0 x 1,1 x 0,85 m dimensions of hydaulic: 750 x 600 x 850 mm dimension control panel: 0,65 x 0,85 x 1,3 m Equipment: Dressing device Holder for dial gauge Coolant filter system Hydraulic unit Manual control unit *

Condition: used, Technical details: grinding length: 1000 mm grinding width: 315 mm workpiece height: 390 mm table speed: 2,5-25 m/min table surface area: 250 x 1000 mm distance table - spindle center: 550 mm dimensions of grinding wheel: Ø max. 315 x 13-63 x Bohrung Ø 75 mm control voltage: 220 / 50Hz V/Hz total power requirement: 10,5 kW Lodpfxsu Ngn Ss Af Eeru weight of the machine ca.: 5,0 t dimension machine xH: 3,35 x 1,5 x 2,10 m Die Maschine befindet sich derzeit in der technischen Abteilung. *

Condition: used, Year of construction: 1981, Technical details: grinding diameter: 240 mm grinding length: 700 mm centre height: 125 mm table length: 1525 (schwenkbar) mm distance grinding spindle - table min./max.: 225/410 mm rpm speed range - grinding wheel: 1590 U/min grinding wheel dia. (unused wheel): 600 mm Lsdpfxeu Ng Avs Af Esru grinding wheel dia. (used wheel): 450 mm cutting speed: 50 m/s total power requirement: 13 kW weight of the machine ca.: 5,5 t space requirements of the machine approx.: L:2,8xB:2,2xH:1,8 m Cylindrical grinding machine, semi-automatic operation - grinding spindle head -adjustment 185mm - grinding spindle head-infeed 0,001-0,05 mm/min continuous - rotation workpiece 50-500 rpm continuous machine is equipped: - sleeve with hydr. retraction - cooling device - trueing device - grinding wheel balancing - transverse delivering device for grinding spindle head - hydr. adjustment of grinding table. Upper table swivable. Documentation i.D. *

Condition: used, Year of construction: 1993, Technical details: rotary table diameter: 2x700 mm grinding height: 200 mm grinding head - power requirement: 15 kW max. dia. of grinding wheel: 400 mm grinding spindle speed: 1400-2800 stufenlos /continous U/min automatic feeds: 0,001-0,02 weight of tools max.: 650 kg table speed: 5-10 m/min rotary table revolutions per minute : 5-10 stufenlos U/min rotary table: Querbewg. 0,2...10 m/min total power requirement: 49 kW Lredeu Ngp Nepfx Af Esu weight of the machine ca.: ca. 12,0 t dimension machine xH: 6,0x3,0x2,8 m dimensions electric cabinet LxWxH: 2,0x0,55x2,2 m ROTARY TABLE SURFACE GRINDING MACHINE - 2 magnetic rotary tables each Ø=700mm - diamond roller dressing device - without coolant unit i.D. *

Year of construction: 1971, condition: used, Technical details: max. wheel diameter: 300 mm max. module: 5 module min. : 0,5 max. workpiece weight: 60 kg weight of the machine ca.: 4,0 t machine dimensions LxWxH: 1,8 x 1,9 x 2,5 m dimensions electric cabinet LxWxH: Nr. 1: 1,95 x 0,4 x 1,95 m dimensions electric cabinet LxWxH: Nr. 2: 0,8 x 0,23 x 1,95 m dimensions:: Abluftanlage: 1,4 x 0,7 x 0,55 m Electronically controlled tooth flank grinding machine up to module 5 and a Ø of 240 - 300 mm feed speed per workpiece revolution infinitely variable 0.4 - 3.2 mm max./min. Number of teeth: 130 / 12 max./min. Pressure angle: 30° / 14°30` Lrsdpsvc An Dofx Af Esu max./min. Spiral pitch with 24 teeth: 6000 / 200 mm max. tooth helix angle, both sides: 45° Speed of the grinding worm: 1900 rpm without dressing device Equipment: approx. 69x change transmission wheels, pipe extensions and various tools Two of these machines are for sale. Both machines are supplied via two common control cabinets and an exhaust air system. *

Condition: used, Year of construction: 1998, Technical details: dimensions of grinding wheel: Ø 65 x 25mm (Topfscheibe) mm feed:: 0,05 - 0,40 U/min / 8 step U/min total power requirement: ca. 1,1 kW weight approx.: 1060 kg dimension machine xH: 1,1 x 1,1 x 1,4 m Brake Drum Grinding Machine - turning Ø max./min.: 800 / 320mm - brake drum holder: 63mm, quill stroke 120mm - turning support: longitudinal travel 380mm; transverse travel 200mm Lrjdju Ngauepfx Af Esu - steel holder holder: 180 x 140mm, steel holder 58mm, turning tool for insert holder 20 x 20mm - operation via control panel *

Condition: used, Year of construction: 1961, Technical details: grinding length: 600 mm grinding width: 200 mm workpiece height: 270 mm grinding length: mit Magnet: 500 mm Distance Spindlecenter - clamping surface area, min:: 350 mm grinding spindle speed: 1000...4700 U/min table surface area: 720 x 200 mm table load capacity: 60 kp magnetic plate size: 455 x 180 (Gleichstrom) mm magnetic-table: vertical kippen 90° längs Stück total power requirement: 2,0 (2,7 PS) kW weight of the machine ca.: 1600 + 176 kg Gleichrichter kg Lrjdpfx Afsu Ngg Uo Esu dimension machine xH: 1,4 x 1,8 x 1,7 m transport measurements machine: 1,4 x 1,8 x 1,6 m dimensions electric cabinet: L: 850 x B: 450 x H: 1.100 mm dimensions of grinding wheel: Ø 225 x 20 x Bohrung Ø 51 mm mm The magnetic plate (24V) is cooled. Grinding spindle: The grinding wheel infeed is electric, vertical 270mm, infeed z-axis 0,002 mm to unlimited inching infeed 0,001 - 0,010mm Peripheral speed max 35 m/sec. allowed equipped with coolant tank, pump and magnetic separator, as well as grinding wheel - size Ø 152 x 14mm plus various accessories (in the cabinet) like some grinding wheels and balancing flange The machine is pre-equipped for an exhaust system. *

Condition: used, Year of construction: 1984, Technical details: grinding diameter min/max: 8 / 40 mm number of spindle speeds: 3000 U/min total power requirement: ca. 1,2 kW Ledpfx Afju Ng Irj Ejru weight of the machine ca.: 0,24 t dimension machine xH: 0,7 x 0,9 x 1,3 m The grinding spindle is equipped with two hand levers: Working range left = manual grinding device for small shank drills. working range right = swiveling device of conical shank drills cutting angle max 180 Drill swivel arm small: clearance angle 5° - 9°; drill Ø 8 - 15mm manually adjustable; grinding wheel cup wheel Ø 200 x 40mm with holder Ø 32mm Drill swivel arm large: clearance angle 5° - 9°; drill Ø max 400mm; pitch 6x with index grid manual; grinding wheel currently clamped Ø 180 x 31mm with receptacle Ø 32mm Grinding modes: Normal grinding, DK grinding, center grinding, spiral countersink, multiple step drill. *

Condition: used, Year of construction: 1970, Technical details: grinding length: 1000 mm grinding width: 400 mm workpiece height: 500 mm Table dimensions: 2230 x 670 mm table surface area: 1340 x 400 mm magnetic plate size: 1000 x 410 mm table load: 450 kg throat of the spindle nose: max 330 mm grinding spindle speed: 1440 U/min total power requirement: 18,2 kW weight of the machine ca.: 3,5 nur Maschine t dimension machine xH: 1,9 x 3,3 x 2,25 m Ljdpfxju Nixao Af Eeru dimensions electric cabinet LxWxH: 1,0 x 0,4 x 1,4 m Precision surface grinding machine Possible surface grinding operations: -cross grinding; plunge grinding; face grinding and grinding with a straight grinding track Further specifications: -hydraulic table speed, infinitely variable 1...30 or 2...30 m/min. -Largest table stroke 1150 mm -Manual cross feed 0.01 mm -Manual vertical infeed of the grinding wheel 0.002mm and minimum infeed 0.001mm -Automatic infeed 0.001...0.1mm -Largest selectable total infeed amount 5.0mm -Coolant system (tank with pump) -hydr. aggregate -control cabinet *

Condition: used, Year of construction: 1987, Technical details: Lrjdpfx Afou Ngice Eeu grinding length: 600 mm grinding width: 350 mm workpiece height: 600 mm feed: 1 - 30 m/min magnetic plate size: 610 x 255 mm distance table - spindle center: min./max. 150 / 420 mm grinding spindle speed: 3000 U/min stroke of the table: min./max.: 200 / 650 mm total power requirement: ca. 4,0 kW weight of the machine ca.: 2,5 t dimension machine xH: 1,5 x 1,9 x 2,0 m dimension coolant device LxWxH: 0,63 x 0,40 x 0,65 m Headstock: -vertical travel Y = 0.002 - 0.06 mm -adjustment = 0,001 - 2mm Cross slide: -transverse travel Z = 360mm -feed adjustment = 1 - 60mm/stroke -rapid traverse = 1.2 m/min. Dressing manual Cooling water unit with capacity 140Liter Equipment: -3x support feet -machine lighting accessories: -alignment device for grinding wheel holder *

Condition: used, Year of construction: 1976, Technical details: grinding length: 600 mm grinding width: 200 mm workpiece height: 400 mm table speed: 2 - 18 m/min magnetic plate size: 600 x 200 mm Max. Table-movement horizontal: 700 mm Max. Table-movement across: 230 mm table adjustment: Quervorschub: 0,1 - 2 mm/Hub ° Lrjdpfsu Ngl Dex Af Eeu table speed: 2 - 18 m/min dimensions of grinding wheel: max. Ø 200 x 20 x Ø 51 mm grinding spindle speed: 2800 U/min feed of spindle: vertical 0,01 total power requirement: 3,0 kW weight of the machine ca.: 1,0 t dimension machine xH: 1,8 x 1,2 x 1,9 m dimension coolant device LxWxH: 0,8 x 0,4 x 0,2 m Currently there is a grinding wheel size Ø 160 x 18mm on the machine. There is a dressing device (without diamond) on the spindle. Magnetic clamping plate progress type FE 200/600; 220V / 110V coolant tank div. foot blocks Toothed rail 1000mm *

Condition: used, Year of construction: 1974, Technical details: grinding length: 600 mm grinding width: 200 mm workpiece height: 400 mm magnetic plate size: 630 x 200 mm Max. Table-movement horizontal: X-Richtung max. 710 mm Max. Table-movement across: Y-Richtung max, 250 mm table load capacity: 110 /1100N) kp table speed: 1,5 - 18 m/min dimensions of grinding wheel: max. 200 x 20 x Ø 51 mm grinding wheel dimensions:: gespannt: Ø 142 x 20mm grinding spindle speed: 2800 U/min feed of spindle: 0,01 mm total power requirement: 5,0 kW weight of the machine ca.: 1,0 t dimension machine xH: 1,8 x 1,2 x 1,9 m dimensions: Behälter Absaugung: 420 x Ø 350 x 680 mm Lsdeu Ngmbopfx Af Eeru The machine was used for dry grinding. -very good condition -without dressing device -dust extraction -machine lamp *

Condition: used, Year of construction: 1998, Technical details: height of profile: 180 mm max. dia. of grinding wheel: 200 / Topfscheibe mm grinding wheel hole diameter: k.A. grinding spindle speed: 2800 U/min Table dimensions: LxB: 500 x 160mm mm Lrodpfxeu Ngrqo Af Eeu voltage: 220 / 380 V total power requirement: 3,0 kW weight of the machine ca.: 0,57 t dimension machine xH: 1,1 x 1,0 x 1,7 m Application for face grinding Magnet mount: LxW = 680 x 200mm; tilt approx. 15°; swivel 360° via radial scale magnet: Type S2D; permanent magnet, clamping surface 300 x 150mm. Grinding wheel support: -adjustment vertical = length 180mm manual; swivel = approx. 45° right/left manual. Operation via control panel on machine. Coolant tank with pump and feed *

Condition: used, Year of construction: 1982, Technical details: dimensions of grinding wheel: Ø 150 x 20 mm grinding spindle speed: 3600 U/min height over floor: 900 mm current type: 220 V Lsdpfxju Ngxds Af Esru machine weight approx.: 27 kg dimensions L x W x H: 0,37 x 0,35 x 1,4 m Double sanding bench sitting on foot stand (foot Ø 353mm) Left side with drill grinding device (angle 90° - 180°), longitudinal adjustment 25mm incl. accessories *

Condition: used, Year of construction: 1994, Technical details: grinding diameter: 198 mm grinding length: 200 mm z-axis: längs:240 mm x-axis: quer: 340 mm control: Tschudin CNC E 9034B grinding wheel diameter: 500 mm centre height: 100 mm Distance between centres: 300 mm max. workpiece weight between centres: 100 kg interface: RS 232 Lredju Ng A Nspfx Af Esu total power requirement: 16 kVA weight of the machine ca.: 4,5 t space requirement of the machine approx.: L:3,1xT:3,2xH:2,0 m Plunge type grinding automatic technical specifications: - grinding spindle tool intake: 203,2mm - grinding spindle not swiveling - workpiece spindle swivelling : +30° to -90° - tailstock collet cone = MK 3 - control: ISO - and graphically programing equipment: - electronical balancing device : AB 100 T.K. - grindig wheel changing aid - grinding disc dressing device (also for grinding forms programable) - cooling system with paper filtering system - Measuring device (out of function, integrated measuring control not connected) *

Condition: used, Technical details: swing diameter: 200 mm centre distance: 450 mm cross travel: 245 mm longitudinal feed: 830 mm table speed: 0,05-4,5 stufenlos m/min revolution per minute: Schleifspindel 1780, 2050 U/min revolution per minute: Werkstückspindel 50-500 U/min dimensions of grinding wheel: 350x32x127 mm Table dimensions: 2200x280 mm table swivelling to both sides: 9°vor+10°zurück Grad total power requirement: 6,0 kW weight of the machine ca.: 2,2 t dimensions of machine: 2,2x2,05x1,6 m Universal Center Grinding Machine without internal grinding device! Lrodpfx Asu Ng Dgef Eju - for precision grinding of outer, inner such as cone surfaces - feed of grinding headstock via hydr. or manual possible - table feed hydraulic stepless - grinding spindle swivelable with 60 degrees - workpiece headstock 90 degress swiveable with tapper MK4 - tailstock tapper MK 3 equipment: - dressing device/extruder - coolant tank incl. pump and supply i.D. *

Condition: used, Technical details: grinding diameter: 180 mm swing diameter in the workpiece guard: 300 mm grinding depth: 200 mm stroke of the table: z-Achse: 300 mm control: Siemens 840D Longitudinal adjustment of grinding unit on table max.: 280 mm work piece spindle speed: 200-2000 U/min Load capacity at spindle head max.: 2000 N Passage hole: 55,5 mm Ledpfsu Ng D Hex Af Ejru Max. travel x-axis: 245 mm Schleifeinrichtung / grinding device rapid traverse adjustment max.: 15 m/min rapid traverse Z-axis: machine table: 15 m/min dressing device: x-axis / x-Achse Hub /stroke: 120 mm weight of the machine ca.: 4,5 t dimension machine xH: 3230x1820x2100 mm

Year of construction: 1984, condition: used, Technical details: Lrsdpfeu Ng Sdsx Af Eju material Ø max: 120 mm suitable for: Laborarbeiten feed:: Stufe 1: 0,05 Doppelhub mm feed:: Stufe 2: 0,1 Doppelhub mm air pressure - required: 5 - 6 bar Number of working hours: 2649 h connected load: 5 kVA machine length: 1200 mm machine width: 800 mm machine height: 1900 mm machine weight: ca. 850 kg Laboratory Test Grinding Machine - precision grinding machine for laboratory work (e.g., steel and ice samples for spectral analysis) - automatic grinding machine with electronic control (in electric cabinet) - automatic feeding of the grinding spindle - workpiece holder = electro-magnetic - 380V; 50Hz; 3 phases - pot grinding wheel Ø 200x 100mm and drill hole Ø 51mm - coolant device available *

Condition: used, Technical details: grinding length: 630 mm grinding width: 250 mm workpiece height: 300 mm Lodpfxou Ngkme Af Ejru Table dimensions: 2050 x 340 mm magnetic plate size: 600 x 250 (110V) mm feed range: Tisch: 0,005 - 0,045 mm/Hub feed of spindle: 0,001 - 0,045 mm/Hub dimensions of grinding wheel: Ø 220 x 46 mm total power requirement: 8,5 kW dimension machine xH: 2,1 x 1,8 x 1,9 m dimension coolant device LxWxH: 0,8 x 0,31 x 0,5 m -Longitudinal table stroke = 700mm -transverse travel of table = 800mm Coolant pump *

Condition: used, Year of construction: 1984, Technical details: grinding length: 500 mm grinding width: 250 mm workpiece height: 250 mm table surface area: 530 x 200 mm magnetic plate size: L:460 x B:150 x H:87 mm table speed: 2 - 32 m/min table adjustment: Längsweg: 550 mm table adjustment: Querweg: 300 mm feed of spindle: 0,001 mm/Hub grinding spindle speed: 3.000 U/min dimensions of grinding wheel: max. Ø 250 x B:25; Bohung Ø 76 mm total power requirement: 4,3 kW weight of the machine ca.: 2,2 t dimension machine xH: 2,3 x 1,8 x 2,2 m dimensions of hydaulic: L: 500 x B: 480 x H: 680 mm dimension coolant device LxWxH: 0,65 x 0,45 x 0,8 m Lrodpfx Afou Ngkyo Esu The machine is currently equipped with a grinding wheel Ø 240 x 22mm. On the table there is a permanent magnet plate with 30 induction fields, operated by a hand lever. Operation via swiveling control panel. no dressing device incl. oil collecting tank; grinding wheel holder and available documentation *
