Used Facing Lathe for sale (6,068)

Condition: excellent (used), Weisser Heilbronn Senior Lathe with Accessories: - special machine - motor can regulate the speed of spinning to perfection Hsdpsh Ad N Uefx Ak Djl - center to center - 1500 mm - turning diameter over bed - 800 mm - turning diameter over support table - 500 mm - weight - 7 tons. - dimensions - 200 mm lenght; 1700 mm wide; 2100 mm height - accessories included - check pictures.

Condition: good (used), VDF HEIDENREICH & HARBECK Lathe 4000/700 mm Machine Dimensions (LxWxH): 6000x1700x1500 mm Weight: 4000 kg Accessories included Hsdpfx Aeiau E Tjk Dol

Condition: excellent (used), Year of construction: 1997, Romanian Lathe SARO SPS 1250x9000, Manufacturer: Saro Targoviste, Year of Manufacture: 1997. Chuck diameter: 1250 mm, Maximum swing over bed: 1250 mm, Spindle diameter: 250 mm, Distance between centers: 9000 mm, Maximum swing over slide: 920 mm, Maximum workpiece weight between centers: 15,000 kg. Grinding attachment available! Video of the machine under power available. Weight approximately 25 tons. Hjdpfx Aey Icbaok Djl

Condition: good (used), Year of construction: 1990, functionality: fully functional, machine/vehicle number: 93200, turning length: 500 mm, turning diameter: 270 mm, spindle bore: 70 mm, spindle speed (max.): 3,600 rpm, spindle speed (min.): 36 rpm, travel distance X-axis: 180 mm, travel distance Z-axis: 510 mm, overall weight: 4,200 kg, Working length 500 mm Max. working diameter 270 mm Swing over bed 440 mm Spindle speeds 36 - 3600 rpm Spindle bore 70 mm Number of tools 8 pcs Hedpfx Akoy Ibipj Djl X-axis travel 180 mm Z-axis travel 510 mm Control MAZATROL T - 32

Condition: excellent (used), Year of construction: 2012, Haas ST20 SSY 2012 C-axis Hodoy Ibfdspfx Ak Djl Y-axis Live tooling Programmable tailstock Part catcher Tool setter Haas bar feeder Tooling included Low hours! Excellent condition!

Condition: excellent (used), Year of construction: 1967, Swing over bed: 800mm Hsdpfx Akoy Iai Uj Dol Swing over support: 450mm Turning length: 2800mm Workpiece weight: 5000kg

Condition: used, Year of construction: 2007, functionality: fully functional, turning diameter over cross slide: 432 mm, turning length: 864 mm, turning diameter: 432 mm, spindle bore: 76 mm, overall weight: 7,200 kg, The machine is in good technical condition; inspection and testing are possible by prior arrangement. Hjdpfxsy H U Nte Ak Del

Condition: used, Year of construction: 2006, functionality: fully functional, machine/vehicle number: M301809, Technical characteristics: Work Area # Maximum turning diameter: 270 mm # Maximum machining diameter: 215 mm # Maximum workpiece length: 780 mm # Distance between spindle noses: min. 250mm/max. 1100mm # X1/X2 axis travel: 195 mm / Rapid traverse X: 30 m/min # Z1/Z2 axis travel: 780 mm / Rapid traverse Z: 30 m/min # Y-axis (Upper Turret) travel: +/- 60 mm / Rapid traverse Y: 30 m/min # B-axis travel (Right Spindle): 850 mm / Rapid traverse B: 30 m/min Spindles # Spindle DIN 55026: Size A26 # Max speed: Left 4,500 rpm / Right 4,500 rpm # Power with 100% ED: Left – 15 kW / Right – 15 kW # Main spindle feature: Optional dual-stage clamping cycle # Bar capacity: Left spindle - 80 mm / Right spindle - 80 mm Tool Holder with Driven Tools # Tool interface: BMT55 # Number of positions: 12-station disc turret, all positions driven # Max speed: 3,600 rpm, Milling drive power: 5.5 kW Electrical Equipment # Operating voltage: 400V 3-phase, fuse 217A GL # Connected load: 71.9 kVA Dimensions Hsdsxxv A Aopfx Ak Dol # Machine dimensions (L×W×H): 4,059 × 2,314 × 2,225 mm # Weight: 14,000 kg Main Features and Capabilities: # Horizontal design: Optimal chip evacuation and straightforward loading/unloading # CNC Control: Fanuc 18i-TB 2CPU, 2-channel control # Upgraded hydraulic unit: Hazabal S.L. GH1018/008 # Chip conveyor # Bar feeder interface # Automation interface available # Documentation: Electronic and hard copy available Machine status: Operational (in production)

Condition: repair required (used), Year of construction: 2006, functionality: not functional, machine/vehicle number: M301302, Technical characteristics: Work Area - Maximum turning diameter: 270 mm - Maximum machining diameter: 215 mm - Maximum workpiece length: 780 mm - Distance between spindle noses: min. 250 mm / max. 1100 mm - X1/X2 axis travel: 195 mm / Rapid traverse in X: 30 m/min - Z1/Z2 axis travel: 780 mm / Rapid traverse in Z: 30 m/min - Y-Axis (Upper Turret) travel: ±60 mm / Rapid traverse in Y: 30 m/min - B-axis travel (Right Spindle Stroke): 850 mm / Rapid traverse: 30 m/min Hodpfx Asxxvy Uek Djl Spindles - Spindle standard: DIN 55026, size A26 - Maximum spindle speed (Left/Right): 4500 rpm - Power at 100% duty cycle (Left/Right): 15 kW - Main spindle feature: Optional dual-stage clamping cycle - Bar capacity (both spindles): 80 mm Tool Holder with Driven Tools - Tool holder interface: BMT55 - Number of positions: 12-station turret, all driven positions - Maximum speed: 3600 rpm - Milling motor power: 5.5 kW Electrical Equipment - Operating voltage: 400V 3-phase, 217A GL fuse - Connected load: 71.9 kVA Dimensions - Machine dimensions (L×W×H): 4,059 × 2,314 × 2,225 mm - Weight: 14,000 kg Main Features and Capabilities: - Horizontal design: Optimized for chip evacuation and easy loading/unloading - CNC control: Fanuc 18i-TB, 2CPU, 2-path control - Enhanced hydraulic unit: Hazabal S.L. GH1018/008 - Chip conveyor - Bar feeder interface - Automation interface available - Documentation: Electronic and printed manuals available Machine status: NOT WORKING - Servo drive failure on lower turret - Lifetool reduction gearbox on lower turret broken – requires replacement

Condition: used, Year of construction: 2013, functionality: limited functionality, machine/vehicle number: 105032, Technical characteristics: Work Area - Maximum clamping plate diameter: 160 mm - Maximum turning diameter: 160 mm - Maximum machining diameter: 100 mm - Maximum workpiece length: 150 mm - X-axis travel: 700 mm / Rapid traverse in X: 60 m/min - Z-axis travel: 375 mm / Rapid traverse in Z: 30 m/min - Standard integrated automation (number of loading nests by workpiece diameter: 14/(80...200), 18/(30...160), 30/(30...85)) Main Spindle - Spindle according to DIN 55026: Size A5 - Maximum spindle speed: 6,000 rpm - Spindle power (100%/40% duty cycle): 18.1 / 13.9 kW - Spindle torque (100%/40% duty cycle): 77 / 59 Nm Tool Turret with Driven Tools - Tool holders according to DIN 69880: 12 positions - BMT65 - Maximum tool length including holder: 190 mm - Maximum tool speed: 6,000 rpm - Maximum torque: 27 Nm (10% duty cycle), 14 Nm (100% duty cycle) Electrical Equipment - Operating voltage: 400–480 V, 80 A Hedpfx Aexxwztsk Dsl - Connected load: 27 kVA Dimensions - Overall dimensions: Length = 4,350 mm (with chip conveyor), Width = 1,600 mm, Height = 2,500 mm - Weight: 5,500 kg Main Features and Capabilities: - Vertical Design: Optimised for chip evacuation and easy loading/unloading - Control: GE Fanuc FS 32i B - High Precision: Positioning accuracy on X and Z axes ±0.001 mm, Haidenhain linear scales - Main Spindle: High power output and wide speed range - In-process Control: Marposs T25 measurement probe - Automated Loading/Unloading: Parts are automatically loaded and unloaded by integrated automation - Live Tooling: Capable of drilling and milling with driven tools - Tool Life Monitoring with Sister Tool Management - Chip Conveyor, Coolant System, Switchable Dual Cartridge Filter, High Pressure Pump (15 bar) - Fully Enclosed Work Area, Work Area Lighting - Documentation: Electronic available; paper manual not complete Machine Condition: WORKING - Operator panel safety switch is broken

Condition: used, Year of construction: 2016, functionality: fully functional, machine/vehicle number: MW141, Technical characteristics: Work area # Maximum turning diameter: 300 mm # Maximum workpiece length: 276 mm # X-axis travel: 250 mm / Rapid traverse X: 24 m/min # Z-axis travel: 460 mm / Rapid traverse Z: 24 m/min # W-axis travel: 520 mm / Rapid traverse W: 24 m/min Main Spindle # Spindle mount: A2-8 Hjdjxxifkepfx Ak Dol # Maximum spindle speed: Left 3000 rpm # Continuous power (100% duty cycle): Left - 15 kW / Right - 7.5 kW # Max workpiece diameter over bed: 520 mm # C-axis indexing accuracy: 0.001° # Bar capacity: Left spindle - 80 mm / Right spindle - 53 mm Counter-Spindle: # Spindle speed: 6000 rpm # Max bar diameter: 53 mm # C-axis indexing accuracy: 0.001° # Travel: 520 mm Motorized Tool Turret # Tool interface: Okuma interface # Number of stations: 12-position lower turret, all stations powered # Maximum speed: 4500 rpm, Milling motor power: 4.5 kW Electrical equipment # Supply voltage: 400V 3-phase # Connected load: 22.5 kVA Dimensions # Machine dimensions (L×W×H): 3200 × 2200 × 1900 mm; Weight: 5500 kg Main features and capabilities: # Horizontal design: optimal chip evacuation, parts catcher + custom parts conveyor belt # Additional coolant tank with 10 bar pressure for cutting tool cooling # CNC control: OSP-P300L-R # Chip conveyor # Fire protection system # Tool measuring system (Q SETTER) # Broken tool detection: Load force auto-learning analyzer managed by OSP-P300L-R # Workpiece detection on counter-spindle: Low-pressure compressed air sensors # Spindle cooling system # Documentation: Available electronically and as hardcopy Optional: Bar feeder: FMB model Turbo 10-72XT/3200/A # Bar feeder dimensions (L×W×H): 3500 × 800 × 1200 mm; Weight: 1500 kg Machine status: In operation

Condition: repair required (used), Year of construction: 2015, functionality: not functional, machine/vehicle number: MW137, Technical characteristics: Work Area - Maximum turning diameter: 300 mm - Maximum workpiece length: 276 mm - X-axis travel: 250 mm / Rapid traverse in X: 24 m/min - Z-axis travel: 460 mm / Rapid traverse in Z: 24 m/min - W-axis travel: 520 mm / Rapid traverse in Z: 24 m/min Main Spindle - Spindle nose: A2-8 - Maximum speed: Left 3,000 rpm - Continuous power (100% duty cycle): Left - 15 kW / Right - 7.5 kW - Maximum swing over bed: 520 mm - C-axis indexing accuracy: 0.001° - Bar capacity: Left spindle - 80 mm / Right spindle - 53 mm Counter-Spindle - Spindle speed: 6,000 rpm - Maximum bar diameter: 53 mm - C-axis indexing accuracy: 0.001° - Travel: 520 mm Tool Turret with Driven Tools - Tool interface: Okuma interface - Number of positions: 12 lower turret stations, all driven - Maximum speed: 4,500 rpm; Milling spindle power: 4.5 kW Electrical Equipment - Operating voltage: 400V (3-phase), fuse protection: 151A - Connected load: 22.5 kVA Dimensions - Machine dimensions (L×W×H): 3,200 × 2,200 × 1,900 mm; Weight: 5,500 kg Main Features and Capabilities: - Horizontal design: Optimal chip evacuation, parts catcher + custom-made conveyor belt - Additional emulsion tank with 10 bar pressure for cutting tool cooling - CNC control: OSP-P300L-R - Swarf (chip) extraction conveyor - Fire suppression system - Tool measuring system (Q SETTER) - Broken tool detection: Load monitoring with auto-learning analyzer via OSP-P300L-R - Workpiece detection on counter-spindle: Low-pressure compressed air gauges - Spindle cooling system - Documentation: Electronic and print manual available Hedpfx Ajxxh Udjk Dol Optional: - Bar feeder: FMB Model: Turbo 10-72XT/3200/A - Bar feeder dimensions (L×W×H): 3,500 × 800 × 1,200 mm; Weight: 1,500 kg Machine status: NOT OPERATIONAL - X-axis encoder: faulty

Condition: repair required (used), Year of construction: 2008, functionality: not functional, machine/vehicle number: M234205, Technical Specifications: Work Area - Maximum turning diameter: 250 mm - Maximum machining diameter: 250 mm - Maximum workpiece length: 555 mm - X1/X2-axis travel: 195 mm / X-axis rapid traverse: 30 m/min - Z1/Z2-axis travel: 600 mm / Z-axis rapid traverse: 30 m/min - Y-axis (Upper Turret) travel: ±41 mm / Y-axis rapid traverse: 30 m/min - B-axis travel (Right Spindle Travel): 620 mm / B-axis rapid traverse: 30 m/min Main Spindle Hedpfjxxvw Hex Ak Del - Spindle interface to DIN 55026: Size 6 - Max. speed: Left 4500 rpm / Right 5000 rpm - Power at 100% duty cycle: Left - 15 kW / Right - 7.5 kW - Bar capacity: Left spindle - 65 mm / Right spindle - 51 mm Tool Carrier with Driven Tools - Tool interface: BMT55 - Number of stations: 12-station disc turret, all stations driven - Max. speed: 6000 rpm; Milling motor power: 3.7 kW Electrical Equipment - Operating voltage: 200V 3-phase, fuse 217A GL - Connected load: 75 kVA Dimensions - Machine dimensions (L×W×H): 4,059 × 2,314 × 2,225 mm - Weight: 6,000 kg Key Features and Capabilities: - Horizontal design: Optimized chip removal and easy loading/unloading - CNC control: Fanuc 18i-T - Chip conveyor - Bar feeder interface - Documentation: Electronic not available / Paper manual available Machine condition: NOT OPERATIONAL - B-axis not functional - Lower turret not functional

Condition: repair required (used), Year of construction: 2008, functionality: not functional, machine/vehicle number: M232102, Technical characteristics: Work Area # Maximum turning diameter: 250 mm # Maximum machining diameter: 250 mm # Maximum workpiece length: 555 mm # X1/X2-axis travel: 195 mm / Rapid traverse X: 30 m/min # Z1/Z2-axis travel: 600 mm / Rapid traverse Z: 30 m/min # Y-axis (Upper Turret) travel: +/-41 mm / Rapid traverse: 30 m/min Hsdpfx Asxxvv Ask Del # B-axis travel (Right Spindle Travel): 620 mm / Rapid traverse: 30 m/min Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: Left 4500 rpm / Right 5000 rpm # Continuous power (100% duty cycle): Left 15 kW / Right 7.5 kW # Bar capacity: Left spindle - 65 mm / Right spindle - 51 mm Tool Holder with Driven Tools # Tool interface: BMT55 # Number of positions: 12-station disc turret, all driven positions # Maximum speed: 6000 rpm, Milling motor power: 3.7 kW Electrical Equipment # Operating voltage: 200V, 3-phase, fuse 217A GL # Connected load: 75 KVA Dimensions # Machine dimensions (L×W×H): 4,059 × 2,314 × 2,225 mm # Weight: 6,000 kg Main Features and Capabilities: # Horizontal design: Optimal chip evacuation and easy loading/unloading # CNC control: Fanuc 18i-T # Chip conveyor # Bar feeder interface # Documentation: Electronic not available / Book available Machine Status: NOT WORKING # Fault not specified. Complete electrical rewiring performed in 2018 and linear guides renewed.

Condition: used, Year of construction: 2009, functionality: fully functional, machine/vehicle number: 3XR2L03, Technical Specifications: Hedsxxtu Aepfx Ak Dsl Work Area - Maximum turning diameter: 89 mm - Maximum workpiece length: 80 mm - Chuck size: 152 mm, hydraulic drive - Maximum workpiece weight: 0.7 kg x 2 - X-axis travel: 245 mm / Rapid traverse X: 20 m/min - Z-axis travel: 240 mm / Rapid traverse Z: 24 m/min Main Spindle - Spindle mount: ASA 6 - Maximum spindle speed: 60–6000 rpm - Continuous power (100% duty cycle): 7.5 / 5.5 kW Turret with Driven Tools - Tool interface: 20 mm square / 25 mm hole diameter - Number of positions: 12-position lower turret, 6 driven stations - Max speed: 4500 rpm / Milling motor power: 4.5 kW - Turret indexing time: 0.2 s Electrical Equipment - Operating voltage: 200V, 3-phase - Connected load: 21 kVA Dimensions - Machine dimensions (L×W×H): 2,100 × 1,555 × 1,680 mm - Weight: 4,000 kg Key Features and Capabilities: - Horizontal design: Optimal chip evacuation, parts catcher, custom-made parts conveyor strip - CNC Control: Fanuc Series 21i-TB - Chip removal conveyor included Machine Condition: Operational

Condition: used, Year of construction: 2012, functionality: fully functional, machine/vehicle number: LZ1R0503, Technical Specifications: Work Area - Maximum turning diameter: 89 mm - Maximum workpiece length: 80 mm - Chuck size: 152 mm, hydraulic drive - Maximum workpiece weight: 0.7 kg x 2 - X-axis travel: 245 mm / Rapid traverse X: 20 m/min - Z-axis travel: 240 mm / Rapid traverse Z: 24 m/min Main Spindle - Spindle mount: ASA 6 - Maximum spindle speed: 60–6000 rpm - Continuous power (100% duty cycle): 7.5 / 5.5 kW Turret with Driven Tools - Tool interface: 20 mm square / 25 mm hole diameter - Number of positions: 12-position lower turret, 6 driven stations - Max speed: 4500 rpm / Milling motor power: 4.5 kW - Turret indexing time: 0.2 s Electrical Equipment - Operating voltage: 200V, 3-phase - Connected load: 21 kVA Dimensions - Machine dimensions (L×W×H): 2,100 × 1,555 × 1,680 mm - Weight: 4,000 kg Key Features and Capabilities: Hjdoxxr Dvopfx Ak Djl - Horizontal design: Optimal chip evacuation, parts catcher, custom-made parts conveyor strip - CNC Control: Fanuc Series 21i-TB - Chip removal conveyor included Machine Condition: Operational

Condition: used, Year of construction: 2015, functionality: limited functionality, machine/vehicle number: MW130, Technical characteristics: Work Area - Maximum turning diameter: 300 mm - Maximum workpiece length: 276 mm - X-axis travel: 250 mm / Rapid traverse X: 24 m/min - Z-axis travel: 460 mm / Rapid traverse Z: 24 m/min Hsdpfx Aexxrbbok Djl - W-axis travel: 520 mm / Rapid traverse W: 24 m/min Main Spindle - Spindle nose: A2-8 - Maximum speed: Left 3,000 rpm - Continuous power (100% duty cycle): Left – 15 kW / Right – 7.5 kW - Maximum swing over bed: 520 mm - C-axis positioning accuracy: 0.001° - Bar capacity: Left spindle – 80 mm / Right spindle – 53 mm Counter-Spindle: - Spindle speed: 6,000 rpm - Maximum bar diameter: 53 mm - C-axis positioning accuracy: 0.001° - Travel: 520 mm Turret with Driven Tools - Tool interface: Okuma interface - Number of stations: 12-station lower turret, all positions driven - Maximum milling speed: 4,500 rpm - Milling motor power: 4.5 kW Electrical Equipment - Operating voltage: 400V, 3-phase, fuse: 151 A - Connected load: 22.5 kVA Dimensions - Machine dimensions (L×W×H): 3,200 × 2,200 × 1,900 mm - Weight: 5,500 kg Main Features and Capabilities: - Horizontal construction: Optimal chip evacuation, parts catcher + custom parts conveyor belt - CNC control: OSP-P300L-R - Chip conveyor - Fire protection system - Tool measuring system (Q SETTER) - Broken tool detection system: Load monitoring auto-learning analyzer controlled by OSP-P300L-R - Workpiece detection on counter-spindle: Low-pressure compressed air gauges - Spindle cooling system - Documentation: Available electronically and as a hard copy Machine status: Operative only with main spindle – sub spindle requires repair Optional Equipment - Bar feeder: TopAutomazione model FU352 - Bar feeder dimensions (L×W×H): 3,500 × 800 × 1,200 mm - Weight: 1,500 kg

Condition: repair required (used), Year of construction: 2005, functionality: not functional, machine/vehicle number: LZ1R0725, Technical specifications: Work Area - Maximum turning diameter: 89 mm - Maximum workpiece length: 80 mm - Chuck size: 152 mm hydraulic Hedpfx Aksxxkn To Dsl - Maximum workpiece weight: 0.7 kg (per piece, 2 pieces) - X-axis travel: 245 mm / Rapid traverse X: 20 m/min - Z-axis travel: 240 mm / Rapid traverse Z: 24 m/min Main Spindle - Spindle nose: ASA 6 - Maximum speed: 60–6000 rpm - Power at 100% duty cycle: 7.5 / 5.5 kW Tool Turret with Motorised Tools - Tool interface: 20 mm square / 25 mm hole diameter - Number of positions: 12-station lower turret, 6 driven stations - Max. speed: 4500 rpm, Milling motor power: 4.5 kW - Turret index time: 0.2 sec Electrical Equipment - Operating voltage: 200V (3-phase) - Connected load: 21 kVA Dimensions - Machine size (L×W×H): 2,100 × 1,555 × 1,680 mm - Weight: 4000 kg Main Features and Capabilities - Horizontal layout: Optimum chip evacuation, parts catcher, custom-made parts conveyor belt - CNC control: Fanuc Series 21i TB - Chip conveyor Machine Status: NOT WORKING - Servo drive defective - Main spindle motor defective

Condition: used, Year of construction: 2017, functionality: limited functionality, machine/vehicle number: MW149, Technical specifications: Work Area - Maximum turning diameter: 300 mm - Maximum workpiece length: 276 mm - X-axis travel: 250 mm / Rapid traverse in X: 24 m/min - Z-axis travel: 460 mm / Rapid traverse in Z: 24 m/min - W-axis travel: 520 mm / Rapid traverse in Z: 24 m/min Main Spindle - Spindle nose: A2-8 - Maximum speed: Left spindle 3000 rpm - Continuous power (100% duty cycle): Left spindle – 15 kW / Right spindle – 7.5 kW - Maximum swing over bed: 520 mm - C-axis indexing accuracy: 0.001° - Bar capacity: Left spindle – 80 mm / Right spindle – 53 mm Sub-Spindle (Counter Spindle) - Spindle speed: 6000 rpm - Maximum bar diameter: 53 mm Hjdpfx Akjxxiiio Dsl - C-axis indexing accuracy: 0.001° - Travel: 520 mm Turret with Driven Tools - Tool interface: Okuma interface - Number of stations: 12-position lower turret, all driven stations - Maximum speed: 4500 rpm, Milling motor power: 4.5 kW Electrical System - Operating voltage: 400V 3-phase, fuse protection 151A - Connected load: 22.5 kVA Dimensions - Machine dimensions (L×W×H): 3200 × 2200 × 1900 mm - Weight: 5500 kg Main Features and Capabilities: - Horizontal design for optimal chip evacuation - Parts catcher and custom-made parts conveyor strip - Additional emulsion tank with 10 bar pressure for cutting tool cooling - CNC control: OSP-P300L-R - Chip conveyor - Fire protection system - Tool measurement system (Q SETTER) - Broken tool detection: Load force auto learning analyzer, controlled by OSP-P300L-R - Part detection at sub spindle with low-pressure compressed air gauges - Spindle cooling system - Documentation: available electronically and as manual Option: Bar feeder: TopAutomazione FU352SX - Bar feeder dimensions (L×W×H): 3500 × 800 × 1200 mm - Weight: 1500 kg Machine status: Machine operational only with main spindle – sub spindle requires repair.

Condition: used, Year of construction: 2016, functionality: limited functionality, machine/vehicle number: MW127, Technical characteristics: Work Area - Maximum turning diameter: 300 mm - Maximum workpiece length: 276 mm - X-axis travel: 250 mm / Rapid traverse X: 24 m/min - Z-axis travel: 460 mm / Rapid traverse Z: 24 m/min - W-axis travel: 520 mm / Rapid traverse Z: 24 m/min Main Spindle - Spindle nose: A2-8 - Max. speed: Left spindle 3000 rpm - Power at 100% duty cycle: Left spindle - 15 kW / Right spindle - 7.5 kW - Max. swing over bed: 520 mm - C-axis indexing accuracy: 0.001° - Bar capacity: Left spindle - 80 mm / Right spindle - 53 mm Counter-Spindle: - Spindle speed: 6000 rpm - Max. bar diameter: 53 mm - C-axis indexing accuracy: 0.001° - Travel: 520 mm Tool Holder with Driven Tools - Tool interface: Okuma interface - Number of tool stations: 12-position lower turret, all positions driven - Max. speed: 4500 rpm / Milling motor power: 4.5 kW Electrical Equipment - Operating voltage: 400V 3-phase, fused at 151A - Connected load: 22.5 kVA Machine Dimensions - Dimensions (L×W×H): 3200 × 2200 × 1900 mm - Weight: 5500 kg Main Features and Capabilities - Horizontal design: optimized chip evacuation, parts catcher and custom-made parts conveyor - Additional emulsion tank with 10 bar pressure for cutting tool cooling - CNC control: OSP-P300L-R - Chip conveyor Hedpfx Asxxihfok Del - Fire protection system - Tool measuring system (Q Setter) - Broken tool detection: Load force auto-learning analyzer controlled by OSP-P300L-R - Part detection at counter spindle: low-pressure compressed air gauges - Spindle cooling system - Documentation: Available electronically and in printed format Machine Status: Currently operating with main spindle only - sub spindle requires repair OPTIONAL: Bar feeder: TopAutomazione model Fu352 SX - Bar feeder dimensions (L×W×H): 3500 × 800 × 1200 mm - Weight: 1500 kg

Condition: repair required (used), Year of construction: 2016, functionality: not functional, machine/vehicle number: MW144, Technical characteristics: Work Area - Maximum turning diameter: 300 mm - Maximum workpiece length: 276 mm - X-axis travel: 250 mm / Rapid traverse in X: 24 m/min - Z-axis travel: 460 mm / Rapid traverse in Z: 24 m/min - W-axis travel: 520 mm / Rapid traverse in Z: 24 m/min Main Spindle - Spindle nose: A2-8 Hjdpsxxidaefx Ak Dol - Maximum speed: Left 3000 rpm - Power at 100% duty cycle: Left – 15 kW / Right – 7.5 kW - Maximum swing over bed: 520 mm - C-axis indexing accuracy: 0.001° - Bar capacity: Left spindle – 80 mm / Right spindle – 53 mm Sub-Spindle: - Spindle speed: 6000 rpm - Maximum bar diameter: 53 mm - C-axis indexing accuracy: 0.001° - Travel: 520 mm Tool Turret with Driven Tools - Tool interface: Okuma interface - Number of stations: 12-position lower servo turret, all stations driven - Maximum speed: 4500 rpm - Milling motor power: 4.5 kW Electrical Equipment - Mains voltage: 400V 3-phase - Connected load: 22.5 kVA Dimensions - Machine dimensions (L×W×H): 3200 × 2200 × 1900 mm - Weight: 5500 kg Main Features and Capabilities: - Horizontal design: optimized chip evacuation, parts catcher + custom parts conveyor belt - CNC control: OSP-P300L-R - Chip conveyor - Fire protection system - Tool measurement system (Q SETTER) - Broken tool detection: Load monitoring and automatic force analysis via OSP-P300L-R - Workpiece detection at sub-spindle: Low-pressure compressed air monitoring - Spindle cooling system - Documentation: Electronic / Hard copy available OPTIONAL Bar feeder: TOP Automazione, model FU 352 - Bar feeder (L×W×H): 3500 × 800 × 1200 mm; Weight: 1500 kg Machine Condition: NOT WORKING - Turret disassembled for repair - X-axis ballscrew to be replaced - Heat exchanger / lubrication unit to be replaced - Hydraulic unit to be replaced - Sub-spindle to be repaired - Spindle position encoder to be replaced - Chip conveyor to be repaired - Set of bar clamping guide and accessory kit - Set of bearings for pusher head

Condition: used, Year of construction: 1997, functionality: fully functional, machine/vehicle number: W301002, Technical characteristics: Work Area # Maximum turning diameter: 270 mm # Maximum machining diameter: 215 mm # Maximum workpiece length: 265 mm # Distance between spindle noses: 1080 mm # X1/X2-axis travel: 195 mm / Rapid traverse in X: 12 m/min # Z1/Z2-axis travel: 265/780 mm / Rapid traverse in Z: 24 m/min # B-axis travel (right spindle): 850 mm / Rapid traverse in Z: 24 m/min Spindles # Spindle as per DIN 55026: Size A2-6 # Maximum speed: Left & Right 50–5000 rpm Hjdpfx Aksxw Uh Ij Djl # Power at 100% duty cycle: Left 11 kW / Right 11 kW # Main spindle special feature: Optional dual command clamping cycle for 2-stage chuck clamping # Bar capacity: Left spindle 51 mm / Right spindle 51 mm Two Tool Turrets # Tool interface: BMT55 # Number of stations: 12-position disc turret Electrical Equipment # Operating voltage: 200/220VAC +10%/–15%, single-phase, 50/60 Hz # Connected load: 54 kVA (connection 61 VA) Dimensions # Machine dimensions (L×W×H): 3645 × 1875 × 1970 mm # Weight: 10,800 kg Main Features and Capabilities: # Horizontal construction: Optimal chip evacuation and easy part handling # CNC control: Fanuc 6i-TT # Chip conveyor # Automation interface for gantry loader available # Main spindle fitted with Autoblock Chuck 265 TXS # Each turret equipped with 2 external tool holders # Documentation: Electronic not available / Hardcopy available Machine status: RUNNING/IN OPERATION

Condition: good (used), Year of construction: 2015, functionality: fully functional, machine/vehicle number: 15KX239200001, Technical specifications: Work Area - Maximum turning diameter: 210 mm - Maximum machining diameter: 200 mm - Maximum workpiece length: 220 mm - X1/X2 axis travel: 220 mm / Rapid traverse in X: 24 m/min - Z1/Z2 axis travel: 220/770 mm / Rapid traverse in Z: 36 m/min - Y1/Y2 axis travel: +/-40 mm / Rapid traverse in Y: 12 m/min Automation: - Axis strokes: X - 210 mm; Y - 680 mm; Z - Left 2080 mm / Right 3360 mm; α 270˚ - Maximum speeds (m/min): X - 35; Y - 120; Z - 160; α 270˚/1.5 sec - Load/unload gripper specifications (pneumatically powered): Outer diameter up to Ø170 mm; jaw stroke 30 mm; gripping force: external 128 kgf / internal 138 kgf Main Spindle: - Spindle nose: A8 - Maximum speed: Left 5000 rpm / Right 5000 rpm - Power at 100% duty cycle: Left - 15 kW / Right - 7.5 kW - Bar capacity: left spindle - 65 mm / right spindle - not available Tool Turret with Driven Tools: - Tool interface: BMT55 - Number of positions: 15 upper / 12 lower station turret, all driven positions - Maximum speed: 4500 rpm; Milling motor power: 4.5 kW Electrical Equipment: - Operating voltage: 200V, 3-phase, 151A fuse - Connected load: 55 kVA Dimensions: - Machine dimensions (L×W×H): 3200 × 2200 × 3500 mm Hedsxwuhuepfx Ak Dsl - Weight: 10,500 kg Main Features and Capabilities: - Horizontal design: Optimal chip removal, gantry loading/unloading from conveyors - Automation includes: Gantry robot + 2 loading/unloading conveyors - CNC control: Fanuc FS31i Model A Series - Chip removal conveyor - Coolant filtration 40 bar max: Filber S.L. FTH5/10, 200 l/min - In-process control: Marposs T25 - Broken tool detection system: Peek tool menu Murata/Fanuc feature enabled - Part detection through spindle: Low pressure compressed air sensors - Bar feeder interface max Ø65 mm - Documentation: Electronic and hard copy available Machine condition: OPERATIONAL

Condition: good (used), functionality: fully functional, Vertical lathe BERTHIEZ Brand: BERTHIEZ Table diameter: 2550 mm Max. turning diameter: 2800 mm Hodpey Egb Ssfx Ak Dol Machinable height: 2300 mm Max. load: 25 t Speeds: 1 - 160 rpm Floor dimensions: 4000 x 4000 mm

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, Chip conveyor Hedpfeyf Dtqjx Ak Dol High-pressure pump Parts catcher Bar feeder interface Tooling
