Used External Grinding Machine for sale (67,997)

Condition: used, Year of construction: 1998, grinding length 2000 mm grinding width 600 mm total power requirement 17 kW Iisdpfsv S Ip Ejx Aa Esd weight of the machine ca. 10 t

Condition: excellent (used), Description to follow! Iodpfx Ajw U U Ikoa Eeid

Condition: used, Year of construction: 1973, grinding diameter max. 30 mm regulating wheel width 12 mm max. width of grinding wheel mm total power requirement kW Iijdpot Hwwwjfx Aa Ejd weight of the machine ca. t dimensions of the machine ca. m

Condition: excellent (used), Year of construction: 2015, grinding length 500 mm grinding width 250 mm Iiedpsxy S Dxsfx Aa Ejd

Condition: used, Year of construction: 1980, max. wheel diameter 1010 mm gear width 0 mm max. module min. module total power requirement 15 kW weight of the machine ca. 9,5 t dimensions of the machine ca. m Max. depth of tooth 10 mm Max. workpiece Ø (for clearance) 1,010 mm Max. external Ø of coupling 610 mm Sliding base withdraw 216 mm Max. distance from grinding wheel to workpiece nose 90 - 430 mm Max. weight of workpiece, including clamp 500 kg No. of teeth 32 to 150 Grinding wheel Ø, approx 152 - 320 mm Grinding wheel speeds, infinitely variable 0 - 3,600 rpm Work spindle bore 60 mm Total electrical load, approx. 15 kW - 380 V - 50 Hz Weight, approx. 9,500 kg Accessories / Special Features * Automatic roughing and finishing process via pre-settable counter and built-in feed cam. * Counter for number of teeth. * Counter for number of dressing cycles. * 2 built-on dressing units with three dressing diamonds for radius dressing, side dressing and wheel end dressing. * Built-on index plate for 48 teeth. Iiodpfst Hwniox Aa Eod * Separate coolant device with band filter. * Separate hydraulic unit. * Separate TRION oil mist exhaust. * Various small parts.

Condition: used, Year of construction: 1977, max. grinding diameter 400 mm grinding width 0 mm max. module min. module total power requirement 3 kW weight of the machine ca. 4,2 t dimensions of the machine ca. m Shaver cutter Ø, min./max. 64 - 320 mm Module range 1 - 12 Shaver cutter width, max. 40 mm No. of teeth 13 - 240 Pitch block Ø 73 - 320 mm Speeds of workpiece slide 5 / 20 / 30 / 40 teeth per min. Grinding slide speed 690 rpm Grinding slide Ø 762 mm Grinding wheel swivelling (pressure angle) 5 - 21 ° Grinding slide swivelling (helical angle) 2 x 35 ° Grinding slide adjustment, vertical 240 mm Cutting speed 1 / 0.5 / 0.25 m/min Spindle drive 1.1 kW Total electrical load, approx. 3 kW - 500 V - 50 Hz Weight, approx. 4,200 kg Accessories / Special Features Iedpfxet Hwnvj Aa Eeid * Machine is suitable for grinding internal and external shaver cutters. It is also suitable for master gears as well as cutters for gear shapers. Unfortunately the machine does not have many accessories. It would therefore be a good investment as a second machine if you already have suitable accessories available.

Condition: used, Year of construction: 1981, drill diameter 32 mm drilling length 0 mm Universal Drill Bit Grinder lots of accessories Iisdpst Hwn Aefx Aa Esd

Condition: used, Year of construction: 1997, max. wheel diameter 215 mm gear width 40,65 mm max. module total power requirement 20 kW weight of the machine ca. 10 t Max. external Ø of workpiece 215 mm Tooth profile, height x width 16 x 40.65 mm No. of teeth 5 - 200 Max. tooth ratio 1 : 10 Grinding wheel Ø 51 - 190 mm Grinding wheel speeds 1,000 - 6,000 rpm X Axis (horizontal) 152 mm Y Axis (vertical) 178 mm Z Axis (slide base plate) 304 mm Distance from middle of machine to middle of workspindle 115 mm Axial speed 125 mm/sec Workpiece speeds 0 - 30 rpm Workspindle bore, conical 3 29/32 inch Total electrical load 20 kW - 380 V - 50 Hz Weight, approx. 10,000 kg Accessories / Special Features * FANUC CNC Control, Model 150 MB, for 7 axes, with monitor and direct input. Automatic calculation of all workpiece and grinding parameters. * Extensive coolant equipment with filter system, band filter, etc. Iijdpfxet Hwxhs Aa Ejd * Driven grinding wheel dressing device with CNC dressing control for automatic compensation of form and diameter after every dressing. * Gear grinding is effected either in single component operation using a conical cup wheel (Gleason 30°), or with a cylindrical cup wheel. These grinding wheels can be made of CBN, or of traditional "dressable" aluminium oxide material (question of cost). Grinding with a conical grinding wheel is of advantage with regard to heat build-up and quality of tooth contact pattern. Therefore these pairs of bevel gears (for automotive industry) can be generated in high quality with consistent accuracy, economically, and with short set-up times. Condition : Very good - machine can be inspected here under power Delivery : Ex stock, as inspected Payment : Net, after conclusion of contract Thank you for your interest. We always have a good selection of gear machines available. Please let us know what you need.

Condition: used, Year of construction: 1969, grinding height 60 mm grinding width 120 mm grinding wheel diameter 600 mm grinding length mm workpiece height 60 mm total power requirement 50 kW weight of the machine ca. 7000 kg dimensions of the machine ca. m D I S K U S (Germany) Double Side Vertical Spindle Surface Grinder, C-Frame Design, with Rotary Workpiece Feeding System and Automatic Dressing Device Model DDS 600 CR-A Year 1969 Serial-No. 6672 _____ Grinding wheels Ø x bore, each 600 mm Grinding wheels height x width, approx. 60 mm Workpiece dimensions: Grinding height x grinding width, approx. 60 x 120 mm Vertical adjustment of each grinding head 150 mm External Ø of workpiece carrier disk, approx. 810 mm Feeds of rotary workpiece feed system 14 – 145 mm/sec Grinding wheel speeds, each, infinitely variable 765 rpm (24 m/s) Grinding spindle drive, each 22 kW Total electrical load, approx. 50 kW - 380 V - 50 Hz Isdpet Hw N Hofx Aa Esid Total weight, approx. 7,000 kg Accessories / Special Features: * Rotary workpiece feed system with infinitely variable speed adjustment prepared with workpiece carrier disk approx. dia. 800 mm with relevant workpiece shaped pockets and after the grinding the parts will be automatically sorted out and collected in a collector box. * IONIC – Size Control Unit Model Nr. 9 So with measuring probe for the ground workpieces and with signal for the hydraulic infeed of the grinding wheel when size is not in order. * Automatic Dressing Device for the grinding wheels, hydraulically operated and with the automatic return of the grinding wheels after dressing cycle to the previously adjusted position and to continue the working cycle. Dressing cycle can be presetted by a timer or a manual release. * Manually operated infeed device of the Spindle slide to optimal workpiece thickness. * Spindle drives controlled by Ampere-Meters. * Separate switch cabinet. * Separate hydraulic unit. * Various carrier disks, etc. * Safety covers. * Central lubrication. * Large Coolant device with paperbandfilter This machine is ideal for double-sided simultaneous grinding of parallel workpiece surfaces by continuous method, for maximum output and accuracy in mass production (e.g. Piston rings, washers, hydraulic parts, and other punched parts.) Condition : Good . Machine can be inspected under power. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract.

Condition: used, Year of construction: 2000, grinding diameter 360 mm grinding length 1600 mm centre height 180 mm internal diameter 0 mm grinding depth 0 mm swing diameter 0 mm total power requirement 40 kW weight of the machine ca. 10000 kg dimensions of the machine ca. m K A R S T E N S (Germany) Universal “CNC” - Cylindrical Internal and Face Grinding Machine also for grinding excentric and cam profiles and polygons and even suitable for Threadgrinding Model K 51 – 1500 Year 2000 Serial No. 99 093 Height of centres 180 mm Distance between centres / grinding length 1,700/1.600 mm Cylindrical Grinding: Grinding Ø, approx. 5 - 360 mm Grinding wheel: Ø x width x bore 500 x 100 x 127 mm Grinding spindle speeds (35 m/s / 50 m/s) 1.900 / 2.200 rpm Drives of cyl./int/face spindle units 7.5/4,0/7,5 kW Iijdpfxjt Hw Rdo Aa Eod Grinding Wheelhead: 3 Positions = B-Axis Head swivels in 3 positions = 240 ° / 17,5 degree X-axis adjustment in total 360 mm Increments for infeed 0,001 – 125 mm Workpiece wheelhead = C-Axis Spindle speeds steplessly adjustable 10 – 1.000 rpm Spindle taper / Spindle bore MK 4 / 24 mm Table speeds 0,01 – 10.000 mm/min Total electrical load 40 kW - 400 V - 50 Hz Weight, approx. 10,000 kg Accessories / Special Features: * Very versatile CNC Grinding Machine for almost all grinding purposes like External/Internal and Face grinding as well as for Excentric- / Cam- / Polygone Grinding and even for Thread Grinding * Free programmable CNC System make BWO Model 900 C with many grinding cycles and for easy input of the work-parameters. Graphic support, any many more features. * 3 position wheelhead with 3 Grinding spindles as B-Axis, one with measuring feeler (Z - Position) * MOVOMATIC Measuring Device Model ES 400 for diameter control, Probe head CR 60, to be mounted on table. * MPM Automatic Grinding wheel balancing Device, Dressing devices with diamantflees mounted on table surface and also motorized Diamantroll Profile dresser on table (for thread profiles, etc.) * Workhead and tailstock can be easily moved on table by air cushion. Hydraulic quill on tailstock. * No Coolant Device available ! Condition : Good to very good. Machine can be inspected under power. Delivery : Ex stock as inspected. Payment : Net, after conclusion of contract.

Condition: excellent (used), Year of construction: 1981, Description to follow! Isdpfxjynmn Ae Aa Esid

Condition: excellent (used), Year of construction: 1994, internal diameter 300 mm grinding depth 450 mm Ijdpfx Ajyrtwrja Ejid swing diameter 660 mm

Condition: excellent (used), Control SIEMENS 840D Iiodpfx Aasyrhl Re Eod

Condition: excellent (used), Year of construction: 1965, grinding length 600 mm Isdpfx Aaexy S D Eo Esid grinding width 250 mm

Condition: used, Year of construction: 1985, thread dia. 254 mm grinding length 350 mm thread pitch 51 mm Control SIEMENS S 8 total power requirement 12 kW weight of the machine ca. 5000 kg dimensions of the machine ca. m B A H M Ü L L E R Automatic Internal Thread Grinding Machine Model IPE 12 i.S. Year 1985 Serial No. 103174 _____ workpiece Ø, max. 300 mm workpiece length, approx. 350 mm height of centers (WP spindle/grinding spindle) 300 mm table stroke approx. 450 mm thread diameter ground max. approx. 254 mm thread diameter ground min. approx. 25,4 mm Iedpfx Aaot Hw U Ae Eoid thread length ground in one setting max. 250 mm Lead range, max. 51 mm Lead angle max. 10 ° Total electrical load, approx. 12 kW - 380 V - 50 Hz Weight, approx. 5,000 kg Accessories / Special Features * This is a programme controlled (SIEMENS S 8) internal thread and internal worm grinding machine , suitable for the grinding of ball screw nuts. * All movements are controlled by the SIEMENS programme control * Automatic infeed for grinding depth. * Automatic diamond roll profile dressing device, motorized by hydraulic motor,and device can be swivelled and mechanically adjusted lengthwise. * FISCHER Internal grinding spindle up to 30.000 rpm with oil and air lubrication and with Infinitely variable grinding spindle speeds. • 4-jaws chuck approx.. Ø 250 mm * Separate switch cabinet, separate hydraulic unit, oil drip pan, etc. Condition : Good. Machine can soon be inspected under power. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract.

Condition: used, Year of construction: 1998, grinding length 800 mm grinding width 500 mm workpiece height 425 mm total power requirement 15 kW weight of the machine ca. 4,5 t Q U O T A T I O N We are pleased to offer you ex our stock, subject to prior sale, and error in technical : GEIBEL & HOTZ CNC Cycle Controlled Precision Surface Grinding Machine model FS 850 GT SL year 1998 Serial no 1012580698 _____ Grinding length max. (table movement 900 mm) 800 mm Grinding width max. (cross movement 500 mm) 500 mm Mounting height under new grinding wheel 425 mm size of magnetic plate 800 x 500 mm Max. table load 1.100 kg Table speed 2 – 28 m/min Cross feed intermittend 3 – 60 mm/stroke Cross-/Vertical quick feed 4.000 mm/min Grinding wheel measurements 400 x 100 x 127 mm Grinding spindle-drive approx. 9 kW Total electrical load approx. 22 kW - 400 V - 50 Hz Weight approx. 4.500 kg Accessories / Special Features: • Dialog-guided GEIBEL & HOTZ automatic CNC cycle control model SL for 3 axes. Graphically supported data input in absolute dimensions or via teach-in procedures for preprogrammed grinding and dressing cycles. SIEMENS LCD display with softkeys for setting all parameters and easy monitoring axis movements and work progress. • Electronic handwheel for 3 axes X, Y, and Z, feed rate switchable from 0.01 / 0.1 / 1 mm/rev. • table movement is effected by a rolling ring thread drive (GT), which allows both very high and very low table speeds with constant torque and very high efficiency. • cross and vertical movements are effected by a ball screw drive with incremental glass scale. • Single-point diamond dresser mounted on the table for aut. dressing cycle and aut. compensation • MPM automatic grinding wheel balancing device. • Mounted electromagnet plate 800 x 500 mm with adjustable holding force • Wet grinding facility with universal fleece belt filtration unit • Complete enclosure of the working area with electronically safeguarded sliding doors • sep. switch cabinet, sep. mobile control panel, various accessories, manuals , etc. Condition : very good, with the wide grinding wheel for large surface grinding ! Please click here to view soon a video of the machine running : ! Delivery : immediately available, FCA Metzingen Payment : 100 % Net, after conclusion of contract, before loading Isdst Hxamepfx Aa Eoid We do always have a large selection of Grinding machines in stock – please let us know your requirements !

Condition: used, Year of construction: 1979, workpiece diameter 320 mm threading length 300 mm thread pitch mm total power requirement 90 kW weight of the machine ca. 12000 kg dimensions of the machine ca. m Thread and worm grinder for steering worms Iiedjt Hwnpjpfx Aa Eod

Condition: used, Year of construction: 1975, workpiece diameter 8-125 mm grinding depth 130 mm clamping length 50-1100 mm max. workpiece diameter 0 mm min. workpiece diameter 0 mm workpiece length mm total power requirement 1 kW weight of the machine ca. 500 kg dimensions of the machine ca. m T E C H N I C A (Switzerland) Centre Hole Grinding Machine Model ZSM 1000 Year approx. 1975 Serial No. J 1400 _____ Distance between centres 50 – 1,100 mm Height of centres 145 mm Workpiece Ø 8 – 125 mm Max. centre hole taper Ø 2 – 50 mm Max. centre hole taper angle 60 ° Clamping range of vice 4 – 150 mm Stroke of grinding head 130 mm Stroke of grinding tool on workpiece 0.75 – 5 mm Grinding tool Ø 15 – 60 mm Grinding spindle speeds 13,000 – 45,000 rpm Workpiece drive 0 rpm Total electrical load, approx. 0.5 kW - 380 V - 50 Hz Iedpot Hwuvjfx Aa Eoid Weight, approx. 500 kg Accessories / Special Features: * A cone shaped grinding wheel is employed, but it is only in line contact with the centrehole surface, in addition it is reciprocating simultaneously along this line. * The workpiece remains stationary, enabling the procuction of perfect centre holes. * To clamp cylindrical Workpieces one uses a height adjustable 2 jaw chuck which gives three point contact and always coincides with the center of the grinding spindle. * Height-adjustable workpiece centering tool with carbide inserts. Manual adjustment of appropriate workpiece diameter with a rachet coupling. * Manual dressing device, mounted on the side of the grinding spindle, stroke approx. 40 mm, for producing a geometrically exact conical form. * Pre-centering device for Workpiece only partially available. * Height-adjustable tailstock and bore in machine base allow longer workpieces. Condition : average to good/should be reconditioned. Machine can be inspected under power. Delivery : Ex stock, as inspected Payment : Net, after conclusion of contract

Condition: used, Year of construction: 1999, max. wheel diameter 280 mm Iiedpfx Aajt Hwu Ao Eod gear width 330 mm max. module 5 min. module 1 Control LIEBHERR CNC total power requirement 28 kW weight of the machine ca. 12 t dimensions of the machine ca. m

Condition: used, Year of construction: 1993, max. wheel diameter 330 mm gear width 180 mm Iijdpfx Ast Hwyfsa Eed total power requirement 12 kW weight of the machine ca. 7500 kg

Condition: used, Year of construction: 2013, grinding length 800 mm Iiedpfx Ajwd Tx Isa Eod grinding width 400 mm workpiece height 375 mm Control Siemens 840 D total power requirement 18 kW weight of the machine ca. 2,6 t Q U O T A T I O N We are pleased to offer you ex our stock, subject to prior sale, and error in technical data : GEIBEL & HOTZ CNC horizontal surface & profile grinding machine model FS 840 KT CNC year 2013 Serial no 38040513 _____ Grinding length max. (table movement 850mm) 800 mm Grinding width max. (cross movement 400mm) 450 mm Mounting height under new grinding wheel 375 mm Distance table – center of spindle min / max 140 – 525 mm Standard size of magnetic plate 800 x 400 mm Max. table load 700 kg Table speed 5 – 35.000 mm/min Cross-/Vertical quick feed 5 – 4.000 mm/min Grinding wheel measurements 300 x 50 x 76,2 mm (350 x 100 x 76,2) Cutting spped max. 45 m/s Grinding spindle-drive approx. 9 kW Total electrical load approx. 18 kW - 400 V - 50 cycles Weight approx. 2.600 kg Accessories / Special Features: • Machine is equipped with a simple to use but freely programmable SIEMENS CNC control model 840 D SolutionLine with additional GEIBEL&HOTZ grinding software. User friendly interface, supported by dialog and graphics, simple programming, also of complex grinding wheel profiling and easy connecting of all the usual grinding cycles. • electronic handwheel for 3 axis. • Table movement is actuated by ball screw drive (KT), which allows both very high and very low table speeds and is also ideal for profile grinding. • Cross feed (Z) and infeed (Y) effected by ball screw drive with incremental glass scale. • Diamond dressing device mounted on the left side of the table (also for profile dressing); additional driven diamond roller dressing device (table-mountable) with automatic dressing cycle, including compensation. • HOFMANN balancing device EasyBalancer EB3100 (with installed rpm & vibration sensor) • Unfortunately currently only a small magnet 110 x 200 mm available. • Separate band filter coolant filtration unit • Complete enclosure of the working area with electronically safeguarded sliding doors, separate switch cabinet, lamp for working area, various accessories, manuals, etc. Condition : very good, universal machine for all sorts of grinding tasks ! Please click here to view a video of the machine running : ! Delivery : immediately available, FCA Metzingen Payment : 100 % Net, after conclusion of contract, before loading We always have a large selection of surface grinders – CNC or conventional - available. Please let us know your requirements.

Condition: excellent (used), Year of construction: 1996, grinding length 600 mm grinding width 350 mm total power requirement 7,5 kW Q U O T A T I O N We are pleased to offer you ex our stock, subject to prior sale, and error in technical data : GEIBEL & HOTZ CNC horizontal surface & profile grinding machine model FS 635 - Z CNC year 1996 Grinding length max. (table movement 660 mm) 600 mm Grinding width max. (cross movement 360 mm) 350 mm Mounting height under new grinding wheel 375 mm Distance table – center of spindle min / max 140 – 525 mm Standard size of magnetic plate 600 x 350 mm Table size 820 x 350 mm Max. table load 400 kg Table speed 5 – 35.000 mm/min Cross movement, intermittently 3 – 40 mm Cross-/Vertical quick feed 5 m/min Grinding wheel measurements 300 x 50 x 76,2 mm Grinding spindle speeds, variable 1.000 – 3.000 rpm Grinding spindle-drive approx. 7,5 kW Total electrical load approx. 15 kW - 400 V - 50 Hz Weight approx. 2.600 kg Accessories / Special Features: • SIEMENS CNC control model 840 D with comprehensivel GEIBEL&HOTZ grinding software. User friendly interface, supported by dialog and graphics, simple programming also of complex grinding wheel profiling and easy linking of grinding cycles. • All standard grinding-programms and cycles as surface and multiple surfaces grinding with roughing-finishing-sparkout- return, plunge in grinding, automatic dressing cycle with compensation, etc. • electronic handwheel for 3 axis; cross feed (Z) and infeed (Y) effected by ball screw drive. • Table movement is actuated by belt drive (Z), which allows both very high and very low table speeds and is also ideal for profile grinding. • Hydraulically upwarding diamond dressing device mounted on the left side of the table (also for profile dressing); additional fixed dresser with automatic dressing cycle, including compensation. • Mounted sinus tilting magnetic plate 600 x 200 mm, fine pole division. • Separate paper band coolant filtration unit, separate switch cabinet, lamp for working area, various accessories, manuals, etc. Condition : very good, universal machine for all sorts of grinding tasks ! Please click here to view a video of the machine running : ! Delivery : immediately available, FCA Metzingen Payment : 100 % Net, after conclusion of contract, before loading We always have a large selection of surface grinders – CNC or conventional - available. Please let us know your requirements. Iodpfxsx Harye Aa Esid

Condition: excellent (used), Year of construction: 1985, internal diameter 300 mm Iisdoyrtvzspfx Aa Ejd grinding depth 450 mm swing diameter 660 mm

Condition: excellent (used), grinding diameter 155 mm grinding length 400 mm centre height 80 mm Q U O T A T I O N We are pleased to offer you ex our stock, subject to prior sale, and error in technical data : STUDER (CH) Universal Precision Cylindrical Grinding Machine Model S 20-12 Year Height of centers / Grinding Ø 80 / 160 mm Center distance / Grinding length Z-axis 400 / 420 mm Internal Grinding Ø mm Workpiece weight flying / between centers max. 5 / 20 kg Table speeds 0,1 – 3,5 m/min Table way automatic, min. 1 mm Table swivable max. 30 ° Universal Grinding Head cross way max 170 mm Rapid infeed way 30 mm Infeed way 1,9 mm Feeds 0,001 – 0,04 mm/Ø Swivable 10 / 30 ° Grinding wheel dimension : bore x width x Æ 127 x 30 x 300 mm Internal Grinding device separately mounted mm Workhead Fitting taper/conus MK 2 Speeds 60 – 1.200 rpm Spindle drive 2,2 kW Total electric load approx.. 5 kW - 400 V – 50 Hz Weight approx. 1.000 kg Accessories / Special Features: • Electrohydraulic conventional control with PHILIPS Digital Readout for the infeed (x-axis) • Preinstalled automatic cycles for plunge-in grinding, traverse grinding, internal grinding with roughing, finishing, fine-finishing, spark-out • Separately mounted Internal Grinding Device with belt-driven internal grinding spindle • Workhead with Quck-release collet chuck, swivable 90° Iijdpezbczxofx Aa Ejd • (right now the machine is not equipped with a tailstock, an original STUDER tailstock; used can be supplied for approx.. EUR 5.000,--) • Wet grinding equipment with coolant filtration unit, separate electric cabinet, manuals Condition : Very good ! Universal machine for all sorts of grinding tasks ! Video : ! Delivery : immediately available, FCA Metzingen Payment : 100 % Net, before loading

Condition: excellent (used), Year of construction: 2001, Description to follow! Iijdpfszd E Tzjx Aa Ejd
