Used Evaporator for sale (377)

Condition: as good as new (ex-display), Falling-film evaporator – unused – Hnjdpfsd Hb Acox Agmjn The machine consists of three units that need to be connected in series: - Evaporator (58 pipes), Length: 12.000 mm - Condenser (19 pipes), Length: 15.000 mm - Condenser (48 pipes), Length: ca. 15.000 mm All units are unused and made of stainless steel (AISI 304 / 1.4301). The evaporator was designed for the production of protein powder (dairy industry) and represents the final element of a drying chain. It evaporates the remaining water in the dryer and thus leads to a high concentration of the end product. Since the units have never been in use, they are in excellent quality. Sale without electrical components or control panel.

Condition: good (used), Morgana PC42 Evaporator Twin fan, ceiling mounted Hnodpfx Aoqqhinogmsn

Condition: like new (used), Year of construction: 2017, functionality: unexamined, type of input current: AC, Double stage vakuum evaporator. Stainless steel, heat exchanger plates with cleaning brushes. For input dry solids contents up to approximately 10%. Volume flow 1-5m3/h. Heat absorption capacity, depending on the medium, 200-400kWth. Dimensions: 6000x4800x4500mm. The systems are stored and can be inspected and tested on-site if required. Hodpfew N N I Ijx Agmonn

Year of construction: 2024, condition: new, functionality: fully functional, Electric vaporizer Capable of vaporizing liquefied gas at any temperature. We utilize these units to vaporize liquid CO2 and store it in concrete. It can also be used for other applications, such as vaporizing nitrogen, oxygen, or other gases for use in end processes. New price 140,000 CHF. Hnedpfxex H R Rys Agmon

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, Equipment: compressor, Manufacturer: GEA Year of manufacture: 2012 Model: 2 MVR 1 Feed rate: 35,000 l/h with whey Evaporation capacity: up to 25,000 kg/h Type: MVR evaporator with TVR finisher (High-)concentrator: from 20 up to 60% DS Including pasteurizer via steam injection MVR compressor: PILLER MVR compressor power: 456 kW Steam consumption finisher: ~900 kg/h Hnedpfjyvrwtex Agmsn Steam consumption pasteurizer: 900 - 1,700 kg/h

Condition: good (used), Year of construction: 1985, functionality: fully functional, Equipment: compressor, Manufacturer: GEA / Laguilharre Hedpfxoyvrtuj Agmsnn Year of construction: ~1985 4 stages – 6 tube bundles MVR + TVR evaporator Use as a pre-concentrator from 6 to 32% DS Use as (high) concentrator 9 to 50% DS Feed rate: 20,000 l/h whey Evaporation performance: 15,000 l/h Including pasteurizer with steam injection Electrical power of MVR compressor: 140 kW TVR steam consumption: 850 to 1,000 kg/h Pasteurizer: 300 kg/h

Condition: used, Year of construction: 2018, Overview  This vacuum evaporator was manufactured in 2018 by Italian manufacturer REDA. The machine is designed for gentle concentration of musts, juices, and other liquid products at low temperatures to preserve aromas and product quality. It is almost new and offered for sale as it was intended for a project that did not proceed. The system features an automated, CIP‑ready design. Technical data  Capacity: 100 L/h evaporation capacity at +22/+24 °C Application: Concentration of musts, juices, and liquid products Operating modes: Recirculation mode or direct concentration mode Max. concentration: 55–70 °Brix Daily output: 2,400 L evaporated / 24,000 L enriched to 10% Utilities: Electrical supply: 25 kW, 380 V / 3Ph / 50 Hz + PE Water: +12/+18 °C (low consumption) Compressed air: 6–8 bar Connections: DN40 DIN, 50 mm hoses Control system: PLC automation, IP65 control cabinet, digital temperature indicators Scope of Delivery  Vacuum evaporator | REDA | CM100 | 2018 | Complete AISI stainless-steel construction Evaporation chamber | Stainless steel, full inspection access Heat exchanger | AISI 316L tubular exchanger Vacuum pump | Liquid-ring system with cooling recirculation Refrigeration group | Heating 75,000 kcal/h, cooling 60,000 frig/h, 2 × 12.5 HP Copeland compressors Pumps | Stainless-steel centrifugal and mono volumetric discharge pump Vapor condenser | Stainless-steel surface condenser Instrumentation & tanks | Flowmeters, cold and hot water stainless-steel accumulation tanks Hnedjykrdbjpfx Agmon

Condition: ready for operation (used), Year of construction: 2020, functionality: fully functional, input voltage: 400 V, type of input current: three-phase, temperature: 35 °C, operating pressure: 75 bar, energy consumption: 64 kWh, Industrial plant for the treatment and concentration of process water as well as for nutrient recovery. The plant combines a double-pass reverse osmosis (RO) system with a thermal evaporator unit and was originally developed for biogas production to recover ammonium-containing fertilizer from process water and digestate. The plant was never commissioned due to the operator's insolvency and is in a preserved condition. The system is suitable for operators from the industrial, environmental technology, or agricultural sectors who are looking for a rapidly available solution for water treatment, ZLD (Zero Liquid Discharge), or nutrient recovery. Technical data System type: RO Double Pass + Evaporator Model: SIMPEC RO Double Pass 8000 44 8 Evaporator 57 000 Year of construction: 2020 Permeate output: Stage 1: 7.5 m³/h Hnsdpsyr H Anefx Agmsn Stage 2: 6.7 m³/h Permeate quality:

Condition: used, Used Pfaudler Balfour approximately 4.64 m2 stainless steel wiped film evaporator. Evaporator body approximately 700mm diameter X 2100mm straight side. Internal 1460 litre capacity rated full vacuum/1 bar design pressure at 0-160 °C. Jacket 250 litre capacity rated full vacuum/6 bar (5 bar with full vacuum) design pressure at 0-160 °C. Rotor belt driven by 5.5 kw 415 volt 3/50 1440 rpm motor via Flender model ZF80A gearbox rated 10.29/1 reduction ratio. Hjdpoyh Na Eofx Agmonn

Condition: like new (used), Features: * System: Forced circulation rising film. * Number of effects: 3 * Tower water consumption: 625 m³/h approximately 500 m³/h with a temperature differential of 10 ºC. Hjdpfsyn Hm Sox Agmonn Includes: * 2 SIHI vacuum pumps *Flashcooler * Refractometer. * Mono PCM pump Production may vary depending on the product. Tomato input production at 5ºC Brix: 700 Tn/24 h. Production of tomato concentrate output at 28º/30ºC Brix: 4,600 kg/h.

Condition: excellent (used), Available 8 evaporation for glycol water Ideal for cold storage warehouses and fruit and vegetable cold rooms Hnjdpfjw Ulxtox Agmjn

Year of construction: 2023, condition: ready for operation (used), Production capacity: 2x120kg, inlet connection (liquid phase): 22mm/RWS22, outlet connection (gas phase): DN50 PN25, optional (unregulated gas phase): RWS28, vent line (safety release): RWS22, separator drain: RWS12, connected load: 40kW, output: 3000kWh. Machine dimensions X/Y/Z: approx. 1900mm/1600mm/400mm. Documentation available. On-site inspection is possible. The machine is unused and still in its original packaging. Hedpfx Aeuwrwusgmenn

Condition: like new (used), Year of construction: 2017, functionality: fully functional, We are offering this as-new REDA CM/200 vacuum evaporator, year of manufacture 2017. Hodpfx Aeydfg Njgmonn Manufacturer: REDA S.p.A. Model: CM/200 Serial number: 4142.031 200-054A Year of manufacture: 2017 Machine type: Vacuum evaporator Condition: As new If you have any questions or need further information, please feel free to contact us.

Year of construction: 2005, condition: used, functionality: fully functional, Evaporation station for apple concentrate with an input juice capacity of 24,000 liters Hnsdpfx Aexn Ugfsgmon

Condition: used, Evaporation station for apple concentrate with a capacity of 12,000 liters juice inflow. In 2014, it was completely modernized by B&P Przeworsk, which is now Bucher Unipektyn. Hnsdpfx Agexn Uq Domsn

Condition: good (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: P281560766/3, power: 2.35 kW (3.20 HP), Single outlet roof top air coolers in good condition including their fans. AVAILABLE the following codes : DEA 093DL-DEB 081D-DEB 094DL-DEBE 072D-DEBE 081D-DEBE 082D-DPA 032S-DPA 041S-DPA 042S-DPA 043S The posted price is per piece. Hnodpfxeul U Auo Agmon

Year of construction: 2008, condition: like new (used), We sell a package of 26 cooling systems - Alfa Laval brand evaporators, all of which work on the glycol cooling system. The systems are powered at 220V or 380V or have an interchangeable power supply system according to the user's needs. The year of manufacture of the systems is 2008. We can sell also piece by piece not only as a package upon request. Commercial unit coolers designed for use in small and medium cold rooms from 10 up to 400 m³. Models designed for easy maintenance with immediate access to inspection areas. This series is available as a DX evaporator and brine unit cooler. Finned coil - H(C)FC Inner grooved Cu tubing ø 12 mm, triangular tube pitch - Brine Smooth Cu tubing ø 12 mm, triangular tube pitch - Corrugated Alu-fins - Fin spacings 4, 5.5, 6, 7, 8, 10 and 11 mm. Hedpfxsg N Db Ho Agmsnn • 1 to 4 AC fans, ø 250 mm up to ø 500 mm, drawing through the coil. Fan motors 230V/50-60Hz/1ph or 400V/50-60Hz/3ph in two noise levels (H/L). Motors with dynamically and statically balanced external rotors, manufactured in accordance with VDE 0530/12.84. • Corrosion resistant materials: coil frame AluZinc, casing strong and durable sheet metal, powder-coated RAL 9002. • Hinged drip tray and side covers for easy installation and maintenance. • Sufficient space for mounting of expansion valve inside the casing. • Mounting brackets allow flush ceiling mounting. • Fitted with schräder valve on the suction connection for testing purposes. • Pumped system available on request. • Stickers indicate fan direction and refrigerant in/out. • Delivery in mounting position. Coolers are mounted on wooden beams. Installation can take place with the use of a forklift. 1 AlfaCubic series (BL, GL, RL) 2 Refrigerant system (E = dry expansion, W=water/glycol, 3 Noise level (H=high, L=low) 4 Fan diameter (25=250, 35=350, 40=400, 50=500 mm) 5 Number of fans (1 to 4) 6 No. of tube rows (A=4, B=6, C=8) 7 Phases (S= single-phase, D= 3 phases Δ connection) 8 Motor voltage (230V, 400V) 9 No. of circuits 10 Packing (CR=crate) 11 Casing material (AP= powder coated, SS= stainless steel) 12 Defrost system (A= air, E= electric defrost, HG= hotgas) 13 Fin material/coating (AL=aluminium, EP= epoxy coated aluminium) 14 Fin spacing (4, 5.5, 6, 7, 8, 10 and 11 mm) 15 Tube material (Cu=copper) The evaporator coils of these units are high performance and are built-in 1/2 ”fluted copper tube and fin corrugated aluminium with gaps of 3.5, 6 and 8mm. The frame, made of aluminium sheet, is provided with protection collars. This frame has the application of thermostatic expansion valves. Regarding their exterior structure, they are manufactured in aluminium painted in high resistance RAL-9018 polyester colour. The vibrations in these machines are avoided thanks to the fact that their entire structure is compact and highly rigid. All its parts are easily removable for maintenance. These evaporators are fitted as standard with helical fans with high-performance protection grilles and are equipped with 315 or 350mm motors. diameter. Single-phase for 230V 50Hz, with a degree of protection IP-54, with external rotor and low consumption. All motors are connected to a watertight general box, according to IP-55 regulations. Finally, defrosting is carried out with 230V electric heaters built in armoured stainless steel tubes. Its vulcanized ends avoid derivations and are inserted inside the battery and the tray. They are connected to a watertight junction box. Application: Lo

Year of construction: 2012, condition: like new (used), Used 3 fans cooling evaporator DELTA TECHNICS model DKP61 The DKP series is specifically designed for room cooling [e.g. cold kitchens and processing areas] and is applicable to the most common refrigerants. Default the DKP models are equipped with a fin spacing of 3.2 mm; - Turbulated aluminium slats. Hnsdpfxjg Ugcwe Agmon - Copper pipes 1/2'' ; cuproclima. - Displaced geometry. - Aluminum housing, painted white. - Removable side panels. - Fans are pre-wired and connected in a central junction box - Blowing air direction. Used DKP61, Kw: 2,2 ; refrigerant: freon; number of fans: 3 x fans; electric; Sizes: (LxWxH); Remarks |: 1000 m3/h, / 1350 RPM / Ø = 300 mm (fan diameter); Price Euro 1.000 Euro + VAT, FCA: Oradea/Romania Irrtum, Anderungen und Zwischenverkauf vorbehalten / Subject to errors, changes and prior sale / Ne rezervăm dreptul la greșeli, modificări și vânzare prealabila. We speak English. /Wir sprechen Deutsch./ Beszélünk magyarul. /Nous parlons français/Vorbim romana

Condition: excellent (used), Year of construction: 2007, machine/vehicle number: 2514070/0200/2007/15128743/1, Used evaporator GEA KÜBA, typ CA.E.06-1X1F, serial no. 2514070/0200/2007/15128743/1 Year of manufacture 2007 Casing Self-supporting construction, fan sections individually partitioned. Ventilator extremely silent (E)• Casing and legs from galvanized sheet steel • Temperature- and UV-radiation resistant powder coating RAL 7032 pebble gray • Lifting hangers standard Heat exchanger Standard tube arrangement lengthwise, staggered, in special copper. • Tubing: Tubes: Ripple Fin, SF-Cu Fins: High performance aluminum fins with Al studs for increased heat transfer Fin spacing: 2,2 mm. • Multi-circuiting possible. • Fluid connections Brazed copper connection vertical (can be used with vertical and horizontal airflow). 3. Axial fans Compact unit without external pressure, corrosion proof and weather resistant: Motor with fans, Fan guard in accordance with DIN 31001/24167 and assembly brackets. • Fan blades ø 650 mm, balanced in two levels according to a VDI 2060 standard. • Motors, threephase current 400±10%V, 50 Hz, 2 speeds, ∆-Y-connections, Protection: ø 650, IP66 • variable speed control by reduction of voltage. • Proof to frequency changes (maximum fan pitch dU/dt=500V/µs; Standard protection of motor by thermocouples. • For outdoor installation and ambient motor temperatures of -30°C up to +60°C. CA. 05 – 06 • 400V±10%V-3 with speed reduction ∆-Y-change-over • Protection CA.06: IP66 • Range of application: –30°C to +60°C • 230V±10%V-1 on request Maximum permissible 60 starts per hour. Fan motors have to be operated for at least two hours per month. • Other motors will change performance and Sound Pressure Levels quoted. The standard fans are recommended for frequency converters with a: • clock frequency: < 16kHz • voltage speed increase : , dU/dt < 1000V • frequency: f < 60Hz For reduction of peak voltages, speed voltage increase and motor noise (at reduced speed) manufacturers of frequency converters recommend the use of sinus filters at the output, especially when using motor cables longer than 50 m. For shorter motor cables dU/dt motor reactors can be used for this purpose. If several motors are connected, the total of all cable lengths has to be considered. Taking electromagnetic compatibility guidelines into consideration, power chokes or input filters are to be used at the input side (and shielded cables having a proper ground connection are to be used) LxBxH: 141 х 115 х 114 cm; Colant R typ Very good condition Price Euro 1200 Euro + VAT, negotiable, FCA: Oradea/Romania Irrtum, Anderungen und Zwischenverkauf vorbehalten / Subject to errors, changes and prior sale / Ne rezervăm dreptul la greșeli, modificări și vânzare We speak English. /Wir sprechen Deutsch./ Beszélünk magyarul. /Nous parlons français/Vorbim romana Hodpfjip Utaex Agmjnn

Condition: excellent (used), Year of construction: 2007, Used, draw through water/glycol cooler, brand Alfa-Laval type INR W S 6777D/Y. YOM: 2007, SN: 2190988. Hnjdpfx Aeucnzwjgmsn Max DN = 57 mm; Vn = 3҇230/400V, fluid group 2, coil TS 110/-40°C, F = 50 Hz, PT = 10 bar, PS = 9 bar, own weight: 604 kg. This, in very good condition draw through water/glycol cooler is equipped with: 2 pieces Ziehl Abegg ventilators 07078866, FC063-4DS6KV7, each Ø500, 1,19 kW, 1360/1000RPM; COSY 085, surface more than 90 m2, aluminium casing/aluminium fins Mentioned cooling capacity is with a water/glycol mixture of 30% at a water/glycol basis. Sales price: 2.960 Euro + VAT, negotiable, FCA Oradea, Romania Irrtum, Anderungen und Zwischenverkauf vorbehalten / Subject to errors, changes and prior sale / Ne rezervăm dreptul la greșeli, modificări și vânzare prealabila. We speak English. /Wir sprechen Deutsch./ Beszélünk magyarul. /Nous parlons français/Vorbim romana

Year of construction: 2007, condition: excellent (used), Evaporator GOEDHART, type VRZ 126310-GFP - 2 identical pcs. in stock. PJV071924-01 and PJV071924-02 Qo=39.3kW, Vo.x=25750 m3/h, F=262m2, 2 fans with diameter 630mm, s=10mm, dimensions of the cooler: LxBxH: 286 х 126 х 111 cm; Coolant (NH3) Very good condition Price Euro 1800 Euro + VAT per piece, negotiable, ExWorks: Oradea/Romania Hedpsip Ungjfx Agmonn Irrtum, Anderungen und Zwischenverkauf vorbehalten / Subject to errors, changes and prior sale / Ne rezervăm dreptul la greșeli, modificări și vânzare We speak English. /Wir sprechen Deutsch./ Beszélünk magyarul. /Nous parlons français/Vorbim romana

Condition: excellent (used), Year of construction: 2016, Evaporators SS/AL (Sequential Defrost) / number of coils: 3 from M7 freezing tunnel Refrigerant: CO2 Unit name: 3xGCO K/16/16/.../2920/G/V/V/3 Unit serial number: 404429274/32.01317 Volume (V): 284,9 l Hnjdpfx Aox H Sacegmen Year of manufacture: 2016

Condition: excellent (used), functionality: fully functional, Evaporative Condenser Baltimore Aircoil International VXC-250 Hedpfxoxpxias Agmenn Manufacturer: Baltimore Aircoil International Model: VXC-250 Serial Number: H160220703 Dimensions: 3600 × 3530 × 5000 mm The BAC VXC-250 evaporative condenser is a high-performance unit designed for industrial cooling and HVAC systems. It operates based on the principle of evaporative cooling, which provides low energy consumption and efficient heat dissipation even under heavy loads. Robust construction and optimized fan efficiency ensure reliable operation and long service life. The VXC-250 model is adapted for operation in demanding industrial environments, offering high performance in a compact size.

Condition: good (used), The Buchi R-210 Rotavapor with B-491 Heating Bath offers you a complete solution with vacuum controller, vacuum pump and recirculating chiller all in a small foot-print. Features include: easy to operate, long-life seals for maintenance-free operation, vapour ducting to prevent cross contamination, compact design, maximum safety, and wireless contact on the heating bath. Specifications, Rotavapor: Dimensions 21.65" W x 16.34" D x 22.64" H(55 x 41.5 x 57.5 cm) Weight 35-40 lbs. (16-18 kg.) Power 100-240 V Rotation Speed 20-280 rpm Flask size 50-4000 mL Max Flask Capacity 3kg Hsdema A Ivepfx Agmjnn Specifications, Heating Bath: Dimensions 11.22" W x 11.81" D x 9.45" H (28.5 x 30 x 24 cm) Weight 8.82 lbs. (4 kg.) Operating Voltage 100–120 Flask size Up to 4000 mL Controlled Temp Range 20–180°C Temperature Deviation ±2°C Bath Capacity 4 L

Condition: used, functionality: fully functional, Polymer Laboratories PL-ELS 1000 Evaporative Light Scattering Detector. Laboratories is a completely new design of high sensitivity Evaporative Light Scattering (ELS) Detector for HPLC, microHPLC and GPC/SEC. This ELS detector has replaced the RI for the detection of solutes with no UV chromophore, giving enhanced performance with the benefits over an RI of improved sensitivity, excellent baseline stability, gradient compatability, and providing a positive response for all solute/solvent combinations. Features: -Small footprint for laboratory convenience -Improved sensitivity -Low dispersion -Excellent baseline stability -Wide gradient compatibility -Rapid equilibrium -Detection of even relatively volatile compounds Hedet Uk Dmjpfx Agmsnn -The PL-ELS 1000 from Polymer Good working condition. Please check out our other listings as well.
