Used Ctp Setter for sale (191)

Condition: ready for operation (used), Year of construction: 2019, operating hours: 12,055 h, functionality: fully functional, turning length: 760 mm, turning diameter: 420 mm, spindle motor power: 37,000 W, spindle speed (max.): 3,000 rpm, spindle bore: 102 mm, travel distance X-axis: 265 mm, travel distance Y-axis: 120 mm, travel distance Z-axis: 830 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 30 m/min, bar passage: 102 mm, overall weight: 6,900 kg, The Hyundai WIA L3000SY represents the flagship model in Hyundai WIA’s turning center lineup, designed for high precision machining, productivity, and long-term reliability. The machine is equipped with true direct-drive spindles (without belts), ensuring excellent torque transmission, high dynamic performance, and improved machining accuracy. Key technical features include: • Main spindle: 12” chuck with 37KW • Sub spindle: 6” chuck • True Direct Drive spindles (belt-free design for higher precision and reliability) • BMT65 turret with 24 positions and 12 driven tool stations Dwsdpfxsy T Iuij Al Aoc • Driven tools: up to 5,000 rpm with 7.5 kW power • Through-tool coolant system – 15 bar • Gun coolant system • Digital scales for improved machining precision • Pneumatic part pusher through the sub-spindle, including part flushing with M code • Part catcher on both main and sub spindle • Part extraction conveyor • Bar feeder connection • Bore-Max bar capacity: Ø102 mm • Chip conveyor • Automatic Q-Setter tool measuring system • Latest generation FANUC control • Oil mist / emulsion extraction unit with the machine • Hainbuch main spindle chuck The machine was installed at the customer site in 2020 and has been used only lightly. The current owner is changing production profile, which is why the machine has become available. This configuration offers an excellent opportunity to acquire a high-end multi-tasking turning center with very strong specifications and low operating hours. Machine has regular Maintenance done and machine is working! With box guide design – the most rigid solution used in turning centers.

Condition: ready for operation (used), Year of construction: 2010, operating hours: 20 h, functionality: fully functional, 2010 RYOBI 752P (Wide) Two-Color Reversible Printing Press Reversible Printing: 1+1 / 2+0 Maximum Sheet Size: 600 x 788 mm Maximum Speed: 15,000 Sheets Per Hour Paper Thickness: 0.04 – 0.6 mm Only 20 Million Impressions! Year: 2010 Equipped with: PCS-G Printing Control System Ryobimatic Dampening System Technotrans Alpha.d Refrigeration Unit IVS Ink Volume Setter Suction-Tape Feeder Table Semi-Automatic Plate Changer Automatic Roller Washer Automatic Blanket Washer Automatic Impression Cylinder Washer Automated Reversible Printing Unit Changeover Sheet De-Curler Steel Plate in Feeder and Delivery Grafix Digital 3000 Powder Spray Device High-Pile Delivery Cylinders are Damage-Free Dwjdpfx Aezxp Sqol Ajc Rubber Rollers in Very Good Condition Spare Parts List & Manual Machine Tools

Condition: like new (used), Year of construction: 2021, operating hours: 900 h, functionality: fully functional, Control: FANUC Series 32i Model B Swing over bed: 600 mm Max. turning diameter: 400 mm Max. turning length: 650 mm Spindle bore: D65 mm X-axis travel: 275 mm Z-axis travel: 700 mm C-axis: 0.001 degree Rapid traverses (X / Z): 15 / 24 m/min Spindle speed: 5,000 rpm Drive power: 34 kW Torque: 325 Nm Tool stations: 12 (all stations driven) Tool holder: VDI40 Dodpfezd Evcsx Al Aowc Speed of driven tools: 6000 rpm Weight: approx. 5800 kg Dimensions (L x W x H): 2800 x 1750 x 2090 mm Equipments, accessories: - Programmable C-axis - Driven tool turret - Chip conveyor - Coolant system - Static tool holders - Driven tool holders - Tool setter / Tool measuring arm - D200 mm hydraulic 3 jaws chuck - Tailstock - Manuals The machine is barely used and is in mint condition. Immediately available.

Condition: excellent (used), Year of construction: 2002, machine/vehicle number: 023910293, Speed: 20 plates /h Counter: 69'068 plates Format (cm): 50x70 Equipment / Additional information: With Server, Trueflow Software with integrated plate punch Dsdpfx Aerigkhol Ajwc with 40 laser diodes (individually replaceable) -Dismantling, packaging of the machine and securing (insurance of the machine during transport) were carried out by the manufacturer / Heidelberg.

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, CNC turning and milling center Okuma Multus B400 1SC-1500 Control system: OSP-P200L Year of manufacture: 11/2010 Internal machine number: 61 X-axis: 690 mm Y-axis: +115 / -115 = 230 mm Z-axis: 1,545 mm B-axis: up to 225°, positioning in 0.001° C-axis: 360° / 0.001° Turning length: 1,500 mm Turning diameter: 710 mm Spindle bore: 110 mm Tool holder: HSK 63 Tool magazine: 40 positions Dwjdpfezwl U Sox Al Ajc Equipment: - Chip conveyor - 3-jaw chuck SMW KNCS-N-340-117 - Paper band filter system ISF 540/6670 - One Touch IGF - Tailstock - Touch setter

Year of construction: 2023, operating hours: 500 h, condition: ready for operation (used), - USED - 3-AXIS CNC LATHE DISTANCE BETWEEN CENTRES: 640 mm MAX ROTATING DIAMETER: 600 mm MAX TURNING DIAMETER: 420 mm BAR CAPACITY: 75 mm Dedpfx Alsyy D I Ej Aewc SPINDLE: 3500 rpm; 15-18,5 kW; ASA A2-8 ; 254 mm X-AXIS TRAVEL: 210+30 mm Z-AXIS TRAVEL: 610 mm RAPID FEEDS X-Z: 18 - 24 m/min DRIVEN TURRET HEAD: BMT65 ; 12 POS; 4000 rpm; 4,5 kW CONTROL UNIT: FANUC 0i-TF WEIGHT: 6230 Kg OVERALL DIMENSIONS: 4017 x 1848 x 1819 mm ACCESSORIES: SWARF CONVEYOR ; FANUC MANUAL GUIDE-I ; ETHERNET PORT ; USB PORT NOTE: WITH No 7 FIXED TOOL HOLDERS; RENISHAW MANUAL TOOL SETTER

Year of construction: 2017, condition: used, REF: MM6447 1 x Camline Palletising Systems Ltd cartesian automated palletiser. The palletiser automates the stacking process of products and goods that can otherwise be labour intensive and expensive, putting undue stress on workers. Cartesian or ‘Pick and Place’ palletisers are characterised by the structural beams and axes which are used to ‘pick and place’ the items. They are very flexible machines and can move products in three directions, thus being used to create complex pallet patterns. Typically, one or two (sometimes more) products are collated on an infeed conveyor and collected with a gripping device, which then places them on to the pallet. Manufacturer – Camline Palletising Systems Ltd. Model – Compact Palletising System. Date of manufacture – 2017. Entry via conveyor and exit via manual removal of the pallet. Electrical requirements - 220 V / 50 hz / 1 phase. Dwjdpfx Alozbkl Ss Asc Power - 32 Amps. Air pressure - 6 Bar. Overall dimensions - 2m wide x 2.7m deep x 4.4m high (approx.).

Condition: as good as new (ex-display), Year of construction: 2024, functionality: fully functional, turning length: 1,073 mm, turning diameter: 380 mm, spindle speed (max.): 3,500 rpm, travel distance X-axis: 255 mm, travel distance Y-axis: 110 mm, travel distance Z-axis: 1,100 mm, bar passage: 81 mm, total height: 1,960 mm, total length: 3,805 mm, total width: 2,100 mm, overall weight: 5,800 kg, Equipment: documentation/manual, Hyundai WIA SE2600LSY is a high-performance CNC turning centre equipped with a Y-axis and sub-spindle for complete machining of complex components in a single setup. The machine features a FANUC i-Series control, BMT55 live tooling with speeds up to 6,000 rpm, and a maximum turning diameter of 380 mm. It is equipped with a 10" main spindle and 6" sub-spindle, providing excellent flexibility for both turning and milling operations. Optional equipment included: Dsdpfxez Izngj Al Ajwc Automatic tool setter 15 bar high-pressure coolant pump Chip conveyor with chip container Bar feeder interface Parts catcher Standard set of tool holders, including 2 + 2 live tool holders

Condition: used, Year of construction: 2022, functionality: fully functional, DOOSAN PUMA GT 3100 M – UNUSED, PRE-OWNED MACHINE WITH ROBOT CELL A Doosan Puma GT 3100 M, manufactured in 04/2022, which has never been used in production after commissioning by the supplier (February 13, 2023). 0 production hours, no workpiece contact, technically and visually in new condition. Includes a factory-installed robot cell for automated loading. Origin: Liquidation of a user's operations in the Nuremberg area. On-site or video call inspection possible. KEY FEATURES - 12″ main spindle, high power and high torque for steel and stainless steel machining - Driven tools VDI40/BMT 65P, milling, drilling and threading from the turret, complete machining in a single setup - Programmable tailstock with servo drive (Z2 axis) - Siemens Sinumerik 828D with 15″ touchscreen and ShopTurn workshop programming - 30° inclined bed, FEM optimized, cast iron - Halter LoadAssistant Universal Big 70 robot cell, mounted and ready for operation (see photos) FACTORY-INSTALLED SPECIAL EQUIPMENT (installed on the machine) - 24-tool turret BMT 65, Hirth gearing (1 s/position) - Automatic tool measuring arm (tool setter) - Tailstock programmable, hydraulic clamping, mount for rotating center - Auto-power-off after program end - Automatic door with servo drive - Three-jaw power chuck Ø 305 mm (12″) with hydraulic draw-in mechanism - 3x Eppinger driven tool holders (drilling/milling head, VDI40/BMT 65) - LNS hinged belt chip conveyor and LNS Turbo HB coolant filtration system - Dormatec ADF oil mist extraction system (filter level 99.97 %, 65 dB) - 20 kVA transformer separately wired - Absolute encoder on all axes HALTER LOADASSISTANT UNIVERSAL BIG 70 (Automation) A Halter robot cell with a Fanuc six-axis robot M-710iC/70 is mounted on the machine (see photos: robot arm with Halter lettering directly on the machine). Cell equipment: - Fanuc robot M-710iC/70, payload up to 70 kg - Workpiece placement via rotary table/loading tray - Workpiece-specific grippers for loading the main spindle - Safety enclosure The cell is designed for this machine and is ready for operation, eliminating the need for additional investment in automation. CONDITION Used machine, unused, no operating hours since installation at the original buyer. Sold "as is", warranty excluded (used machine). Inspection recommended before placing an order. OUR SERVICE Djdpfx Aozi Da Rjl Ajwc On-site or online inspection in the Nuremberg area, transport, installation and commissioning as a separate package upon request, direct German-speaking contact person for spare parts and support, financing possible via leasing/hire-purchase partners, member of the FDM, the German trade association for wholesale trade in machinery and tools. Since this is a single unit, subject to prior sale. Call or write to us, and we will arrange an inspection appointment as soon as possible.

Condition: excellent (used), Year of construction: 2013, operating hours: 60 h, functionality: fully functional, machine/vehicle number: NL254131163, spindle motor power: 18,500 W, spindle speed (max.): 4,000 rpm, travel distance X-axis: 260 mm, travel distance Y-axis: 50 mm, travel distance Z-axis: 795 mm, type of input current: three-phase, total height: 2,200 mm, total length: 5,000 mm, total width: 3,050 mm, overall weight: 6,100 kg, MORI SEIKI NLX2500Y-700 Turning Cente Dimensions • Machine Depth: 3056 mm • Machine Height: 2187 mm • Machine Weight: 6140 kg Movement • Number of Axes: 5 • X-axis Travel: 260 mm • Y-axis Travel: 50 mm • Z-axis Travel: 795 mm Technical Specification • Spindle Speed: 4000 RPM • Tool Stations: 12 Additional Information • Swing over bed 920 mm • Swing over the cross-slide 742 mm • Maximum cutting diameter :366 mm • "maximum cutting length: 705 mm • Bar capacity: 80mm • Spindle motor power: 18. 5/15kw • Milling motor power: 5. 5kw, speed 10000 rpm • Rapid feedrates: xyz: 30 x 10 x 30m/minute • Tool setter, parts catcher, swarf conveyor • 3 jaw chuck, interlocked guards, low volt light Spindle nose: ASA 8" Tailstock: MT5 Tailstock quill diameter: 80 mm Dwedpfx Alszukn Es Asc Tailstock travel: 734 mm Turret stations: 12 positions Motorized tool positions: 12 Turret tool coupling: BMT Turning tool size: 25 × 25 mm Boring bar capacity: 50 mm Maximum driven tool speed: 6,000 rpm Driven tool motor power: 5.5 / 7.5 kW C-axis0.001° indexing Additional equipment Chip conveyor

Condition: excellent (used), Year of construction: 2022, Turning diameter 376mm, Dwjdpozt Spnjfx Al Asc turning length 760mm, bar capacity 76mm, Y axis -/+ 52.5mm, C axis 0.001 degrees on both spindles, 24 station turret, 22KW Motor, Main spindle 4000rpm, sub-spindle 4500rpm, Fanuc I series, 3 jaw chucks, swarf conveyor, tool setter, LNS barfeed unit.

Condition: good (used), Year of construction: 2012, CNC Turning / Millingcenter Machine type: DMG CTX beta 500 V6 Control: Siemens 840 D Shopturn Year: 2012 Working hours: 42.067 h Spindle running time: 20.209 h SPECIFICATIONS Max. turning length: 500 mm Turningdiameter: 410 mm Max. swing over bed: 700 mm Spindle bore: 87 mm Bar capacity: 77 mm C-Axis: 0,01° Main Spindle: ISM 76 Max. revolution: 5.000 rpm Spindle power: 25 / 34 kW Torque: 280 Nm Djdpfxsz D Ug Is Al Aowc Collet chuck: Hainbuch Spantop Nova 65 Subspindle: ISM 52 Max. revolution: 5.000 rpm 3-jaw chuck: Berg KHL 200 mm Travel Y-Axis: mm Amount of turrets: 1 Tool: VDI 40 Driven Tools: 12 revolution driven tools: 4.000 drive power driven tools : 11,3 kW Equipment Chip conveyor Short Bar Loader: LNS QLS 80 S2 Direct linear scales: X,Y High pressure pumps Toggle filter Tool setter

Condition: repair required (used), Year of construction: 2015, functionality: not functional, machine/vehicle number: MW137, Technical characteristics: Work Area Dwsdoxxh Udspfx Al Ajc - Maximum turning diameter: 300 mm - Maximum workpiece length: 276 mm - X-axis travel: 250 mm / Rapid traverse in X: 24 m/min - Z-axis travel: 460 mm / Rapid traverse in Z: 24 m/min - W-axis travel: 520 mm / Rapid traverse in Z: 24 m/min Main Spindle - Spindle nose: A2-8 - Maximum speed: Left 3,000 rpm - Continuous power (100% duty cycle): Left - 15 kW / Right - 7.5 kW - Maximum swing over bed: 520 mm - C-axis indexing accuracy: 0.001° - Bar capacity: Left spindle - 80 mm / Right spindle - 53 mm Counter-Spindle - Spindle speed: 6,000 rpm - Maximum bar diameter: 53 mm - C-axis indexing accuracy: 0.001° - Travel: 520 mm Tool Turret with Driven Tools - Tool interface: Okuma interface - Number of positions: 12 lower turret stations, all driven - Maximum speed: 4,500 rpm; Milling spindle power: 4.5 kW Electrical Equipment - Operating voltage: 400V (3-phase), fuse protection: 151A - Connected load: 22.5 kVA Dimensions - Machine dimensions (L×W×H): 3,200 × 2,200 × 1,900 mm; Weight: 5,500 kg Main Features and Capabilities: - Horizontal design: Optimal chip evacuation, parts catcher + custom-made conveyor belt - Additional emulsion tank with 10 bar pressure for cutting tool cooling - CNC control: OSP-P300L-R - Swarf (chip) extraction conveyor - Fire suppression system - Tool measuring system (Q SETTER) - Broken tool detection: Load monitoring with auto-learning analyzer via OSP-P300L-R - Workpiece detection on counter-spindle: Low-pressure compressed air gauges - Spindle cooling system - Documentation: Electronic and print manual available Optional: - Bar feeder: FMB Model: Turbo 10-72XT/3200/A - Bar feeder dimensions (L×W×H): 3,500 × 800 × 1,200 mm; Weight: 1,500 kg Machine status: NOT OPERATIONAL - X-axis encoder: faulty

Condition: repair required (used), Year of construction: 2016, functionality: not functional, machine/vehicle number: MW144, Technical characteristics: Work Area - Maximum turning diameter: 300 mm - Maximum workpiece length: 276 mm - X-axis travel: 250 mm / Rapid traverse in X: 24 m/min - Z-axis travel: 460 mm / Rapid traverse in Z: 24 m/min - W-axis travel: 520 mm / Rapid traverse in Z: 24 m/min Dedpfxoxxidaj Al Ajwc Main Spindle - Spindle nose: A2-8 - Maximum speed: Left 3000 rpm - Power at 100% duty cycle: Left – 15 kW / Right – 7.5 kW - Maximum swing over bed: 520 mm - C-axis indexing accuracy: 0.001° - Bar capacity: Left spindle – 80 mm / Right spindle – 53 mm Sub-Spindle: - Spindle speed: 6000 rpm - Maximum bar diameter: 53 mm - C-axis indexing accuracy: 0.001° - Travel: 520 mm Tool Turret with Driven Tools - Tool interface: Okuma interface - Number of stations: 12-position lower servo turret, all stations driven - Maximum speed: 4500 rpm - Milling motor power: 4.5 kW Electrical Equipment - Mains voltage: 400V 3-phase - Connected load: 22.5 kVA Dimensions - Machine dimensions (L×W×H): 3200 × 2200 × 1900 mm - Weight: 5500 kg Main Features and Capabilities: - Horizontal design: optimized chip evacuation, parts catcher + custom parts conveyor belt - CNC control: OSP-P300L-R - Chip conveyor - Fire protection system - Tool measurement system (Q SETTER) - Broken tool detection: Load monitoring and automatic force analysis via OSP-P300L-R - Workpiece detection at sub-spindle: Low-pressure compressed air monitoring - Spindle cooling system - Documentation: Electronic / Hard copy available OPTIONAL Bar feeder: TOP Automazione, model FU 352 - Bar feeder (L×W×H): 3500 × 800 × 1200 mm; Weight: 1500 kg Machine Condition: NOT WORKING - Turret disassembled for repair - X-axis ballscrew to be replaced - Heat exchanger / lubrication unit to be replaced - Hydraulic unit to be replaced - Sub-spindle to be repaired - Spindle position encoder to be replaced - Chip conveyor to be repaired - Set of bar clamping guide and accessory kit - Set of bearings for pusher head

Condition: good (used), Year of construction: 2008, functionality: fully functional, CNC lathe Okuma LB 3000 EX MC 500 Control: OSP-P200L Year of manufacture: 2008 Internal machine number: 69 Turning length: 500 mm Turning diameter: 340 mm Swinging diameter over bed: 530 mm Spindle speed: 4,200 rpm Tool holder: BMT 60 Tool turret, 12 stations (powered) C-axis: 0.001 degrees Dwodpfx Aezwlw Tjl Ajc Equipment: - One-touch IGF - Chip conveyor - Touch setter - 3-jaw chuck Kitagawa B-210 - NC tailstock

Condition: used, Year of construction: 2006, Equipment - Heidelberg Suprasetter A52/A74 - Thermal CtP technology - Integrated plate punching system - Heidelberg MetaShooter software - Included: 3 prepress/workflow computers - Plate formats up to 745 × 605 mm - including Agfa Azura C85 plate processor Counters - Total plates: approx. 55,764 - Total exposures: approx. 56,673 - Total punchings: approx. 55,568 - Total imaging time: approx. 3,728 hours Software Dwodpsz Dh Rgjfx Al Aoc - RIP Prinect Meta Dimension - Heidelberg MetaShooter - Prinect Signastation - RIP/workflow system installed on the included computers Available at short notice

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, MAZAK vertical machining center VTC 530 Year 2019 Control unit: SMOOTH G X-axis travel: 1740 Y-axis travel: 760 Z-axis travel: 660 Table length: 2300 Table width: 760 Distance between top of table and spindle nose: 180 Maximum workpiece dimensions (length x width x height): 4100x905x790 Table surface: T-slot Maximum workpiece weight: 1400 Spindle speed: 12,000 rpm Spindle connection: ISO 40 Din Rapid traverse rate, X-axis: 42000 Rapid traverse rate, Y-axis: 42000 Dwjdpfx Aljzz Sute Asc Rapid traverse rate, Z-axis: 42000 Number of tools: 30 Coolant pressure: 15 Bar through the spindle Mayfran chip conveyor Air blow for dry machining Synchronized tapping Center partition for tandem machining Additional pre-setter Additional light Handwheel on remote cable

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, CNC turning machine Okuma LU 3000 EX-M2SC 1000 Control system: OSP-P300LA Year of manufacture: 2022 Internal machine number: 66 Turning length: 1,000 mm Turning diameter: 340 mm Spindle speed: 5 - 5,000 rpm Tool shank: VDI 40 2 tool turrets A-turret: 12 tool positions / all positions powered B-turret: 8 tool positions Dsdpfezwl Aijx Al Aowc - Tailstock - Hinged-belt chip conveyor - 3-jaw chuck Kitagawa B-212 Z220, bore in the chuck Ø 91 mm - Touch setter - One Touch IGF - Handwheel on the control panel - Tool monitoring system - Reinforced coolant pump, 8 bar

Condition: used, Year of construction: 2005, controller manufacturer: Fanuc, controller model: 21i-TB, _____ Description: Year of manuf. : 2005 Control : Fanuc 21i-TB Turning diam. : 730 mm Turning length : 750 mm In General: Year of manufacture:2005 Control system:Fanuc 21i-TB Dodpoz Am Scefx Al Aowc Max. speed:2,000 rpm Turning diameter:730 mm Turning height:750 mm X-axis:390 mm Z-axis:780 mm Chuck diameter:600 mm Tool turret:8 stations Equipment: Chip removal:Chip conveyor Coolant supply:Coolant pump Tool measurement:Renishaw tool setter Chuck:SMW Autoblok 3-jaw chuck

Condition: ready for operation (used), Year of construction: 2006, travel distance X-axis: 260 mm, travel distance Z-axis: 795 mm, overall weight: 6,100 kg, number of axes: 4, This 4-axis DMG Mori Seiki NL2500Y/700 was manufactured in 2006. It features a robust control unit, MORI SEIKI MSX-850, and includes an integrated mist extraction unit, chip conveyor, tailstock, turret, and tool setter. With a mass of 6100 kg, this turn-mill centre is designed for high-performance machining. If you are looking to get high-quality turning and milling capabilities, consider the DMG Mori Seiki NL2500Y/700 machine we have for sale. Contact us for further details. - Phase: 3- Frequency: 50 Hz- Voltage: AC 200 V- Full Load Current: 113 A- Current Rating of the Spindle Motor: 140 A- Interrupting Capacity: 5 kA- Short Circuit Rating: 1 kA- Rated Power: 39 kVA- Mass of Machine: 6100 kg- Control Unit: MORI SEIKI MSX-850- Additional Equipment / Attachments: Integrated mist extraction unit (SARA UC1 SDIV), chip conveyor / chute integration, tailstock, turret, tool setter / probe arm Dwsdpfx Aljz A Uz No Aoc Technical Specification Counter Spindle No Driven Tools Yes

Condition: ready for operation (used), Year of construction: 2017, - USED - 3-AXIS BRIDGE-TYPE VERTICAL MACHINING CENTRE       X-AXIS TRAVEL: 2500 mm Y-AXIS TRAVEL: 1800 mm Z-AXIS TRAVEL: 800 mm DISTANCE SPINDLE NOSE-TABLE: 250 - 1050 mm Dwsdpfxozlu S As Al Aec RAPID FEEDS X-Y-Z: 20 m/min SPINDLE: 10000 rpm; 24,5 - 63 kW; 117-300 Nm; ISO 50 - DIN TABLE SIZE: 2800 x 1700 mm MAX ADMITTED LOAD: 8000 Kg HIGH PRESSURE COOLANT: INCLUDED TOOL MAGAZINE: CHAIN-TYPE ; 60 POS MAX TOOL DIAMETER: 130 mm MAX TOOL LENGHT: 350 mm MAX TOOL WEIGHT: 15 Kg CONTROL UNIT: HEIDENHAIN WEIGHT: 29500 Kg OVERALL DIMENSIONS: 4200 x 7100 x 4500 mm ACCESSORIES: SWARF CONVEYOR ; PAPER FILTER ; TOOL SETTER ; LINEAR SCALES ; EXHAUST SYSTEM ; PORTABLE HANDWHEEL ; TOUCH PROBE NOTE: COMPLETO DI N.54 CONI ISO50

Condition: excellent (used), Year of construction: 2008, CNC lathe Okuma LU35-M-2ST-600 Control system: OSP-P200L Year of manufacture: 2008 Internal machine number: 25 Dwjdpfx Aoyliquol Aoc Max. turning diameter: 550 mm Max. turning length: 600 mm Bore diameter of spindle: 90 mm Spindle speed: 3,200 rpm Main spindle: 30 kW A-turret: 12 stations (all powered) B-turret: 10 stations Tool holder: VDI 50 Accessories Chuck Kitagawa N15 Chip conveyor Interlit Including external coolant system Door automation Touch setter

Condition: ready for operation (used), Year of construction: 2023, spindle motor power: 22,000 W, spindle speed (max.): 5,000 rpm, travel distance X-axis: 165 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 700 mm, total height: 2,250 mm, total width: 2,360 mm, controller manufacturer: FANUC, product length (max.): 3,880 mm, number of axes: 8, This 8-axis DN SOLUTIONS PUMA TT2100SYY was manufactured in 2023. As new, showroom model. It features a twin-spindle and twin-turret configuration, with a maximum spindle speed of 5,000 RPM and a bar capacity of 65 mm. The machine is equipped with 24 turret stations and high-rigidity linear roller guides for enhanced stability. If you are looking to get high-quality turning capabilities, consider the DN SOLUTIONS PUMA TT2100SYY turn-mill centre we have for sale. Contact us for further details. • Chuck size: 8" (204 mm) • Bar capacity: 65 mm • X1/X2 travel: 165 / 100 mm • Z1/Z2 travel: 700 / 700 mm • Y1/Y2 travel: 30 / 40 mm • Spindle motor power: 22 / 18.5 / 15 kW • Turret stations: 24 (12 + 12) • Turret interface: BMT 55 • Guideway type: High-rigidity linear roller guides • Spindle type: Integral motor spindle with wide speed range • Turret capability: Upper and lower turrets with Y-axis and 12 driven stations each • Structural design: Highly stable Y-axis design for high-volume serial production Additional equipment Dwodpfx Alsyrtbqs Aoc • Cooling and filtration: High-pressure coolant through turret; Oil skimmer • Sub-spindle features: Coolant supply through sub-spindle; Parts ejector • Parts handling: Parts catcher; Parts conveyor for both spindles • Calibration: Tool setter (auto-electric) • Automation and interfaces: Air conditioning (electrical cabinet); Bar feeder interface; 3-color tower light • Optional: Chip conveyor (hinge belt conveyor). Price on request Additional Information As new, showroom model Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, operating hours: 4,500 h, input voltage: 400 V, travel distance X-axis: 700 mm, number of slots in tool magazine: 21, controller manufacturer: fanuc, controller model: 31i model B5, rapid traverse Z-axis: 60 m/min, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, spindle nose: BT 30 big plus, spindle speed (max.): 10,000 rpm, operating hours of spindle: 4,500 h, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, FULL OPTIONAL TAPPING CENTER high torque/power version, complete with: spindle cone with BIG PLUS attachment FANUC DDR-T: continuous fourth axis (direct drive motor) with braked counter support and plate rotary joint for hydraulic feed to center table (for automatic workpiece clamping/unclamping) hydraulic power unit for workpiece clamping high-pressure refrigeration through the spindle chip conveyor evacuation automatic side poet robot interface Dedpfx Aleuby Sxj Aswc tool setter RENISHAW TS-27 perfect machine with only 4,500 spindle hours!

Condition: used, Year of construction: 2007, functionality: fully functional, Technical data of the VTC-100R: - Swing diameter 1,250 mm - Turning diameter 1,000 mm - Turning height 850 mm - Drive power 45/55 kW - Max. torque 582 kg/m - Rapid traverse rates (X/Z) 20 m/min - Max. workpiece weight 1,500 kg - Machine weight 23 t - Footprint 2,800 x 5,200 mm - Control system Fanuc 32i-TA (10.4" color LCD) - C-axis - 12-position Baruffaldi turret VDI60 - 6 positions for driven tools - Hydraulic chuck (32") with hard and soft jaws - Clamping cylinder - Hydraulic unit with draw tube - Coolant system - Work area protection - Telescopic guard X/Z - Foot switch for hydraulic chuck - Work area lighting - 3-color indicator light - Mounting elements Djdpfozmd Ucex Al Ajwc - Chip air blow-out system - Tool holder VDI 60 - Complete documentation Options (included): - Chip conveyor - Automatic door - Customer macro B - Automatic workpiece measurement - Oil mist extraction - Tool setter - Coolant high-pressure system - POLO filter system, 20 bar - Chip conveyor incl. hoses
