Rapidex Type 32
Cwgactzg
Masch.-Nr.: 2/69
Year 1969
long arm cardboard wire-stitcher -
length & cross stitching -
stitching arm length 500 mm,
Actually used with flat Wire No. 4
more
with conveyor belt. was used in the manufacture of packaging material made of paper and cardboard.
The machine schnippselt paper. Will be sold by buying new same type and size
3v0ciiwrt
more
AGFA APIS-Board 'UPAC' - for old and new PCs (3,3V and 5V) - for all AccuSets (800/1000/1500 normal & plus), all Avantras (20/25/30/36/44 - E/S/XT) and all Galileos (YAG/VS/Thermo)
K9uyf more
groove width 3-100 mm
Bqu8ivd
drawing length 1000 mm
working speed 2-20 m/min
return speed 40000 mm/min
clamping table 500x770 mm
cutting capacity 4080 kp
weight of the machine ca. 15 t
dimensions of the machine ca. 4,5x2x4 m
with indexing table, counter stay and other accessories.
more
spindle diameter 140 mm
x-travel 5000 mm
y-travel 3000 mm
spindle stroke 700 mm
ram: horizontal adjustment 500 mm
dimension of the ram 310 x 310 mm
spindle taper ISO 50
Ht8v2giu3
spindle turning speed range 2 - 2000 U/min
feed 5000 mm/min
rapid traverse 10 m/min
spindle motor 40 kW
semi-automatic operated SIEMENS 850
total power requirement 100 kW
weight of the machine ca. 42 t
dimensions of the machine ca. 9,5 x 3,8 x 5,95 m
- control SIEMENS 850 CNC
- floor plate approx. 5 x 2 m
- aero-s... more
groove width 125 mm
drawing length 1250 mm
pulling force - max. 5 t
stroke length max. 925 mm
table surface area 550 x 700 mm
workpiece weight 6000 kg
cutting speed 1 - 12 m/min
return speed 2 - 24 m/min
feed 0,219 mm/DH
total power requirement ca. 5 kW
weight of the machine ca. 4 t
dimensions of the machine ca. 1,5 x 1,5 x 3 m
- quick adjustment for the Feed
- automatic return adjustment
Gaaemc0i
- Oil Tank with pump
- 3 Tool Cabinets
- large set of toolings + accessories
Tools for drawing... more
bore capacity in steel (diameter) 32,0 mm
arm length 1000 mm
workpiece height max. 600 mm
turning speeds 100 - 1120 U/min
Esirty8z
table: 1200 x 580 mm
spindle taper MT 4 MK
quill stroke 140 mm
column diameter 200 mm
engine output 1,4 / 1,8 kW
feeds - fine adjustment 0,08 - 0,12 - 0,2 - 0,31 mm/min
weight 2,2 To.
range L-W-H 1,9 x 1,2 x 2,3 m
more
bore capacity in steel (diameter) 32 mm
arm length 1250 mm
workpiece height max. 1200 mm
spindle turning speed range 100 - 2000 U/min
table surface - upper 1200 x 510 mm
spindle taper MT 4
distance spindle /table 600 mm
Vgiu2lvix
total power requirement 3 kW
weight of the machine ca. 1,8 t
dimensions of the machine ca. 1,7 x 1,7 x 2,4 m
rapid radial drill with central clamping and back side clamping area.
- various tool holders, wrench
- thread cutting device
more
max. wheel diameter 400 mm
gear width 70 mm
Zbc7lg0aq
max. module 6
min. module 0,5
table diameter 400 mm
table hole 125 mm
table load capacity 1000 kp
strokes per minute 118 - 1000
spindle stroke 0 - 82 mm
stroke position adjustment 100 mm
distance spindle nose and table 250 mm
total power requirement 15 kW
weight of the machine ca. 6,3 t
dimensions of the machine ca. 3,0 x 1,8 x 2,2 m
Machine is with extension of 60 mm & outer steady, chip conveyor, handbooks, change gears
more
bore capacity in steel (diameter) 32,0 mm
arm length 900 mm
spindle taper MT 4 MK
turning speeds 100 - 1.120 U/min
table surface area 1200 x 580 mm
dayligth 600 mm
Blamp9a
total power requirement 1,4 / 1,8 kW
weight of the machine ca. 2.200 kg.
more
bore capacity in steel (diameter):23 mm
arm length:950 mm
workpiece height max.:500 mm
table surface area:1100 x 380 mm
speeds:115 - 1500 U/min
total power requirement:1 kW
weight of the machine ca.:1 t
Ssdxlk
dimensions of the machine ca.:1,4 x 1,8 x 2,2 m
more
max. wheel diameter 630 mm
gear width 180 mm
max. module 8
min. module 1
table diameter 600 mm
table hole 160 mm
electrics - voltage/frequency 380/50 V/Hz
Yos3amov8
total power requirement 15 kW
weight of the machine ca. 5,5 t
dimensions of the machine ca. 2,4x2,0x3,2 m
more
Vehicle data - make: Bolzoni - type: CTXAR-30J-12-G3 paper roll clamp anti-tip bracket - drive type:-capacity: 3000 kg - load Centre of gravity: 600 - lifting height: 0 mm - range: 0 mm - year: 2009 - operating hours: 0 - internal No.: A409 _
Mast data - mast type:-lifting height: 0 mm - height: 0 mm - free lift: 0 mm - carriage: 0 mm - forks: 0 x 0 x 0 mm _
Dimensions - length: 0 mm - width: 0 mm - height: 0 mm - weight: 1060 kg _
Battery & charger - battery voltage: 0 V - battery AH: ... more
bore capacity in steel (diameter):28 / 35 mm
arm length:1012 mm
workpiece height max.:758 mm
spindle taper MT:3
spindle turning speed range:5 - 2240 U/min
feed per revolution:0,075 - 0,45 mm
table surface area:500 x 1200 mm
spindle stroke - max.:150 mm
Dgjxpch
total power requirement:3 kW
weight of the machine ca.:1,6 t
dimensions of the machine ca.:1,8 x 2,2 x 2 m
with threading St 60 M30 biggest drilling radius 1087 mm smallest drilling radius 487 mm vice more
max. wheel diameter 1200 mm
gear width 260 mm
max. module 16
table diameter 900 mm
table bore diameter 320 mm
max. workpiece diameter 1500 mm
table load 95 kN
stroke length max. 270 mm
work-spindle diameter 125 mm
number of strokes (double strokes) 10 - 270 DH/min
coolant pump 120 l
taper of shaper cutter SK 45
voltage 400 V
frequency 50 Hz
9mmypf3gq
control LH 90 GS Liebherr CNC
table turning speeds 12 U/min
dividing plate diameter 722 mm
Distance of shafts 0 - 820 mm
radial speed max. 4 m/m... more
planing lenght 650 mm
planing width 690 mm
workpiece height 420 mm
vertical movement of steel head holder slide 190 mm
table surface - upper 625 x 340 mm
no. of strokes 15 - 160 Stück
feeds of table 0,2 - 2,0 mm/min
motor cap. in case of hydrl. drive 1 PS
flange-mounted motor 6,5 PS
cutting speed Stufe I 8-28 m/min
cutting speed Sufe II 28-42 m/min
table height 375 mm
weight of the machine ca. 2,1 t
8u3relsco
dimensions of the machine ca. 2,54x 1,5x 1,5 m
with misc. tools!
more
max. wheel diameter 800 mm
gear width 170 mm
max. module 12
min. module 1
max. number of teeth 400
Zbddj8kre
min. number of teeth 10
max. angle of teeth 23 mm
max. ram stroke 200 mm
dia. of shaper cutter 200 mm
dividing plate diameter 672 mm
taper Morse Nr. 5
faceplate diameter 800 mm
Length movement of the table 700 mm
double strokes/min. 33 - 188 Stück
electrics - voltage/frequency 380 / 50 V/Hz
workpiece height max. 300 mm
table bore diameter 120 mm
total power requirement 15 kW
weight ... more
spindle diameter:160 mm
x-travel:7000 mm
y-travel:3500 mm
z-travel:1000 mm
w-axis:900 mm
rotary table::2500 x 2000 mm
table load:ca. 20 t
table adjustment - longitudinal:1000 mm
b-axis:360 °
spindle taper ISO:50
Caetgfh2m
spindle turning speed - stepless:2 - 2000 U/min
feed speeds infinitely variable:1 - 5000 mm/min
rapid traverse:z-16, x-y-w- 20 m/min
total power requirement:125 kW
weight of the machine ca.: t
dimensions of the machine ca.:13,2 x 12,8 x üF 6,0 m
new in 1993 retrofitted in 20... more
spindle diameter 140 mm
x-travel 3500 mm
y-travel 2500 mm
z-travel 1600 mm
w-travel 800 mm
9orweucbz
tool taper ISO 50
turning speed range 2 - 1600 U/min
feed range W+X+Y+Z: 1-5000 mm/min
rapid traverse W+X+Y+Z: 10 m/min
feed range B 1-540 "/min
rapid travel - B 1,5 Upm
table - swivable 360 Grad
surface area 2500 x 2000 mm
table load 25 t
T-slots 9
T-slot - width 28 mm
T-slot - distance 220 mm
electrics - voltage/frequency 380/50 V/Hz
drive of main spindle 56 kW
weight of the machine ca. 36,6... more
max. wheel diameter 1100 mm
gear width 1000 mm
max. module 25
min. module 1
grinding wheel diam. min/max. 400
root circle dia. min. 50 mm
[...] angle +/- 45 °
height of profile 41 / 60 mm
spindle speeds (infinitely variable) 0 - 4000 U/min
table diameter 900 mm
table load capacity 6000 kP
stroke length max. 1000 mm
grinding spindle drive 14 kW
cutting speed 30 (50) m/s
workpiece height max. 2600 mm
table bore diameter 150 mm
depth of hole 300 mm
total power requirement 50 kW
weight of the mac... more
min. 10 x 14 cm, max. 35 x 50 cm,
manual feeding station mit automatic feeding control,
16 stations with belt-conveyor equipment,
Bnvtd20y
high pile up to 70 cm, paper weight 14 - 1000 g/m²,
electronic machine control, color display,
self-calibrating missing sheet and double sheet control each station,
tandem-function for two-up 2:1,
ejecting station including blank station at delivery for incorrect products,
delivery-jogger-system (normal and criss/cross),
jogging bridge for transfer to SFC-un... more
lifting capacity in kg: 1000 kg
Tpsvwcjaz
fork length: 1150 mm
Lifting height: 800 mm
weight of the machine approx.: 125 kg
2 pcs avaiable
delivery without battery
more
Höchstlast 10 kg
measurement range - mm
table surface area - mm
total power requirement kW
weight of the machine ca. t
dimensions of the machine ca. m
Qmvgsp0p
more
max. wheel diameter 630 mm
gear width 200 mm
max. module 10
min. module 1
work accuracy DIN 6
Mffvh
clamping table diameter 710 mm
table bore diameter 150 mm
number of strokes - stepless 35,5 - 560
max. ram stroke 230 mm
feeds 3,55 - 40 mm/min
radial feed 0,8 - 9 mm/min
work-spindle diameter 110 mm
total power requirement 28,2 kW
weight of the machine ca. 9 t
dimensions of the machine ca. 3,8 x 2,3 x 2,5 m
build under licence of LORENZ and identically constructed as LS 630
2012 partl. r... more
spindle diameter 140 mm
x-travel 7500 mm
y-travel 2500 mm
z-axis 800 mm
Qxaauzufi
w-axis 600 mm
V-axis 1500 mm
spindle taper ISO 50
spindle turning speed range 4 - 1600 U/min
rapid traverse feeds 10000 mm/min
spindle drive motor 57 kW
control HEIDENHAIN TNC426
total power requirement 75 kW
weight of the machine ca. 39 t
dimensions of the machine ca. 11,5 x 3,5 x 6,05 m
coolant
- retrofit in 2000 with new HEIDNEHAIN TNC 426 control for 6 axis.
- changer for 2 angular milling heads
- tool ... more
bore capacity in steel (diameter) 40/50 mm
arm length 635 - 1230 mm
workpiece height max. 707 mm
spindle taper MK 4
threading M 28 / M 32
388ieroka
spindle stroke 200 mm
table-size 1300 x 710 mm
feeds 9, von 0,08-1,25 mm/U
spindle turning speed range 12, von 56-1120 U/min
distance table-spindle nose min./max. 157 / 707 mm
Drive 4 / 3,4 kW
Machine height max. 2765 mm
weight of the machine ca. 2,5 t
dimensions of the machine ca. 2,1 x 1,5 x 2,76/3,3 m
Condition: ready for operation
Condition... more
planing lenght: ca. 600 mm
planing width: - mm
workpiece height: ca. 400 mm
adjustment of stroke: 300 mm
ram strokes: 16 - 182 Hub/min
Table dimensions: LxB: 500 x 360 mm
total power requirement: 3,0 kW
weight of the machine ca.: 1,7 t
dimension machine [...]: 1,15 x 1,3 x 1,8 m
further technical details:
- number of double strokes 8x, stroke 16-182 strokes per minute
7nyso7rjs
- transverse movement approx. 500mm
- vertical movement approx. 400mm
- table feed 0,2 - 4 mm/stroke
- table fixed
ac... more
max. external diameter in case of internal gears 4000 mm
max. wheel diameter 3500 mm innen
3bdfr3yzj
max. ram stroke 450 mm
min. ram stroke 80 mm
min. module
max. module 20
min. root circle dia. (external) at module 5 200 mm
min. root circle diameter (external) at module 20 160 mm
tip root circle min. (internal) at module 20 640 mm
min. tip root [...] (internal) at module 5 600 mm
max. pitch (steel) 15 Modul
max. pitch (cast iron) 20 Modul
gear height -max. 1100 mm
workpiece weight 20 t
ram ... more
bore capacity in steel (diameter) 40,in Guss 50 mm
arm length 1050 mm
workpiece height max. 95 - 1605 mm
Bbydl8fi
table-size 600 x 1800 mm
thread dia. max M36 in Stahl mm
feed stepless 5-2000 mm/min
spindle taper: Sk 40
bore radius max./min max.1590 mm
column diameter 195 mm
crossrail adjustment horizontal 1050 mm
quill stroke 200 mm
410
distance spindle nose and table 95/705 mm
995/1605
total power requirement 13 kW
weight of the machine ca. 3,0 t
dimensions of the machine ca. m
Mechani... more
max. wheel diameter 150 mm
gear width 42 mm
max. module 5
min. module 0,5
table diameter 250 mm
swing diameter 280 mm
table bore diameter 100 mm
stroke length max. 50 mm
stroke position adjustment 0 - 70 mm
taper of shaper cutter SK 40
total power requirement 25 kW
weight of the machine ca. 8,5 t
dimensions of the machine ca. 3,3 x 2,1 x 2,7 m
Shbzyxmn
Control SIEMENS 840 C
workpiece ring magazine
steady rest
chip conveyor
machine full coverage
working area locking
noise protection cabin
... more
DIDN'T FIND ANYTHING SUITABLE?
Save this search now and we will inform you about new machines free of charge!
The Machineseeker trust seal gives buyers the ability to detect whether they have to do it with a trusted seller at a glance.
What do we check?
Check of the trade licence or commercial register extract.
Check the address of the dealer.
Validation of Bank connection .
Verification of the telephone accessibility the main phone number.
Credit report must not contains negative criteria.
Buyer complaints can lead to the withdrawal of the seal.
What does this mean for buyers?
Buyers can restrict the circle of potential business partners without extensive checks and favor companies that make honest and righteous shops with high probability.
Of course occur anyway during the purchase process differences of opinion. Machineseeker and Thorsten Muschler GmbH is not liable for violations of the active Maschinensucher or Machineseeker buyer or seller.
Try our Machineseeker app now! Machineseeker app for iPhone and Android.
+44 (0) 20 806 810 84
+49 (0) 201 857 86 10
+48 (0) 223 076 958
