Test stand for filter testing

Lorenz FMP 03 FH 143/149

Year of construction: 2024, condition: new, machine/vehicle number: H3000-H5000TM, Universal testing machine H3000TM-H5000TM according to DIN EN ISO 7500 The universal testing machine of the H3000TM-H5000TM series is a single-spindle machine, a robust construction made of aluminum and V2a with ball screws, ball bushing guides and toothed belt drive. The bellows cover protects the spindle and guides. The testing machine is microprocessor controlled and has a membrane keypad. The 2-line LCD display shows the force and travel. The testing machine can be used as standalone or with a PC via USB interface. The displacement is measured by means of an encoder 0.01 mm visible resolution on LCD (internal 0.0001mm). The machine is manufactured with a standard load cell: 0.03% linearity and the corresponding calibration. Optionally it is possible to add a second channel for a second load cell or a displacement transducer. The universal testing machine is manufactured with two different travels, 500mm or 1200mm (without load cell and testing tool). Further scope of delivery: One load cell up to nominal load, 220 Volt cable, USB cable, description, CE declaration of conformity. For more information, please refer to the attached description. Load cell 3000N-5000N Measuring range: 5-5000N tension and compression, with nom. 2mV/V output signal, overload protection: +/- 1000%, linearity: +/- 0.05%, hysteresis: +/- 0.03%, repeatability: +/- 0.02%, with, incl. 1.5m connection cable incl. calibration certificate Long travel extensometer HE 900mm measuring travel, measuring arms motorized, including electronics Accuracy class class 1 from 1mm travel according to DIN EN ISO 9513 Measuring principle optical incremental Measuring path 900 mm , minus measuring length Display error 6 µm or 2 Resolution 1 µm Actuating force 10 cN Iasdoiq Hxkopfx Ad Uen Standard initial device measuring length (Lo) 10-100 mm, in 5 mm steps Lo adjustment is manual Measuring arm opening and closing is motorized specimen diameter 0-30 mm specimen thickness 0-30 mm sample width 0-100 mm Weight approx. 32kg Scope of delivery strain gauge complete with electronics Cutting edges round: 1 set each carbide / rubber wear parts measuring blades optional rectangular cutting edges ATTENTION: When using optional cutting edges a readjustment of the lo a readjustment of the lo stop is necessary.

Year of construction: 2020, condition: like new (used), With autom. feed + discharge Workpieces are fed in as bulk material, inspected, bad parts are sorted out and good parts are transferred to containers as bulk material. Workpiece: Bolt, Ø 6 - 12 mm Workpiece length: 33 - 56 mm Cycle time: 1.8 s Camera inspection (dimensions and surface defects) - high-resolution matrix camera (21 Mp), dimensions - line scan camera (4K), surface inspection Iasdpslpcm Rsfx Ad Uen parts bunker SKAKO, 71 l volume up to 125 kg storage New price: € 230.000,-.

Condition: excellent (used), functionality: fully functional, Year of construction: 2019, (Please tell us your offer price) Sale only within Europe, incl. Turkey Price without packaging; delivery condition: FCA (machine location) ===== Isdpfx Aswydbxsd Uoan Technical data see handout. All warranty rights are excluded. For the correctness of the technical data and year of construction, for the completeness of accessories and tool equipment, and for compliance with all safety and environmental protection requirements specified in the accident prevention regulations. No sale to private individuals. Sales only within Europe, incl. Turkey Price without packaging; Delivery condition: FCA (machine location) ===== Technical data please see handout in attachment. German text leading language. Without any guaranty and warranty, including completeness of tools & accessories as well as environmental and safety regulations. No private sales.

Condition: excellent (used), Agilent 34970A Data Acquisition / Switch Unit from a test stand includes the following measurement cards 34903A: 20 Channel Actuator / General purpose switch 34908A: 40 Channel Multiplexer Single Ended 34907A: Multifunction Module DIA / Totalize / DAC See also my other measurement/test equipment. We also buy equipment Iedpfowpgqhjx Ad Ujan

Condition: used, Nirox Sensor Nirox multi-Thick-MS1-CH1 Iaedpfjw Elmyox Ad Uen Nirox multi-Thick-MS1-CH1 – Sensor for Multi-Layer Thickness Measurement For sale is a high-quality optical sensor of the type Nirox multi-Thick-MS1-CH1, designed for precise, non-contact measurement of multi-layer materials such as plastic films, composites, or coated substrates. This sensor system is ideally suited for quality control in the plastics or packaging industries. Technical highlights: Model: multi-Thick-MS1-CH1 Manufacturer: Nirox s.r.l. (Italy) Function: Optical precision sensor for micrometer-accurate layer thickness measurement Measuring method: A-Scan / optical interference analysis Channel: 1 (CH1) Fields of application: Inline measurement in production lines or for laboratory use Typical materials: Multi-layer films, coated glass, technical laminates Condition: used Scope of delivery: (see image) Sensor multi-Thick-MS1-CH1 Connection cable (Subject to changes and errors in technical data. All information is provided without guarantee!) If you have any further questions, we are happy to assist you by phone.
