Edge banding machine with joining

Holz-Her Contriga 1366

HOLZ-HER edge banding machine CONTRIGA 1366 Edge thickness: 0.4-30 mm (depending on equipment) Edge height: 51/66 mm (depending on equipment) Panel thickness: 6-45/60 mm (depending on equipment) Edge types: Rolls and strips Feed speeds: Continuous feed from 12-30 m/min (depending on equipment) With adjustable infeed level in the magazine area (max. adjustment range 30 mm) With height-adjustable magazine plate for changing the lower edge overhang With large magazine plate Ø 820 mm for edge rolls up to Ø 800 mm With transport chain including automatic central lubrication With motor-driven, position-controlled bridge height adjustment With pneumatic locking roller for the shortest workpiece sequence With extendable workpiece support (extension width 1600 mm) With space-saving, pneumatically controlled sliding hoods over the entire machine (Deviations for individual units are possible) with motorized infeed guide with injection oiler for lubricating all joints and bolts (including operating hours counter) with central connection for extraction (2x Ø 200 mm) with integrated chip collection box at the end of the machine (when radius scraper unit is installed) PPC 231 control system - Power PC for efficient setup and changeover - 15" SVGA screen with touchscreen - 128 MB CF memory card - USB connector on board - Ethernet network connection - Keyboard connector on board - Windows-like user interface - all information in plain text and/or graphics - Rotatable and pivoting control panel at eye level - Dust-proof membrane keyboard with softkeys (pushbuttons) - LED display for unit preselection - Program list with program names and numbers - Extensive program memory - Individual selection of the units with the functions as basic setting options for setpoints, route points and tool corrections as well as the fixed route points - Centralized and clear setup processes for units and their axis settings via fine adjustment (depending on the equipment) - Interval display for the shortest workpiece distance - Integrated path control - Path points are controlled generally or program-specifically - Clear and complete recording of all operating data - Service messages in plain text - Diagnostic system - including integrated synchronous bus system for high precision in unit control - Individual administration for up to ten users, including password protection - Online maintenance (optional), data exchange with HOLZ-HER Service - Barcode interface (optional) BASIC MACHINE CONTRIGA 1366 - Belt bridge Options and accessories for the basic machine Spraying device 1856 for the inlet and outlet area For the inlet area: Electronically controlled release agent sprayer with Riepe-LPZ/II release agent For the outlet area: Electronically controlled cleaning agent sprayer with Riepe-LP163/93 cleaning agent (only in conjunction with pre-milling unit 1961 and surface scraper 1964) Joint milling unit Joint milling station 1803 (2x 2.6 kW, 200 Hz, 12000 min-1) With two plunge-controlled milling units 1 unit in up-cutting direction 1 unit in down-cutting direction Plunge path 5 mm With static frequency converter 200 Hz Without milling tool With ProLock screw-in clamp for fast tool changes Tool for 1803 (workpiece height up to 60 mm) Diamond milling cutter PRO UT 2 pieces (front and rear) including protective covers Ø 100-63 - Ø 30 mm, Z = 3 + 3 + 3, 1x left-hand rotation, 1x right-hand rotation Noise-reduced milling cutter with integrated chip guide DFC technology (Leitz syst
Csdsvvkfdjpfx Af Iorh

The listing was translated automatically. Translation errors are possible.
