Machining Center - Universal

HERMLE C 40 U DYNAMIC

Condition: ready for operation (used), Year of construction: 2011, operating hours: 35,044 h, spindle speed (max.): 10,000 rpm, total height: 3,000 mm, total width: 2,500 mm, overall weight: 11,000 kg, travel distance X-axis: 850 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 500 mm, controller manufacturer: SIEMENS, controller model: 840D, spindle motor power: 16,800 W, product length (max.): 2,500 mm, table load: 500 kg, tool weight: 8,000 g, number of slots in tool magazine: 82, number of axes: 5, This 5-axis HERMLE C40U Dynamic universal machining centre was manufactured in 2011. It features a travel of 850 mm in the X-axis, 700 mm in the Y-axis, and 500 mm in the Z-axis. The machine has a maximum spindle speed of 10,000 rpm and a magazine capacity of 38 positions plus 43 additional. If you are looking to get high-quality machining capabilities, consider the HERMLE C40U Dynamic machine we have for sale. Contact us for further details. • Utilization: 70% • Shifts: 2 • Operating hours: 35,044.4 h Dedpfjy Al Ufsx Ac Hoci • Rotary table diameter: 420 mm • Clamping surface diameter: 420 mm • Spindle: • Power at 40%: 1500 rpm = 25 / 16.8 kW; 10,000 rpm = 7 kW • Torque at 40%: 1500 rpm = 159 / 107 Nm; 10,000 rpm = 6.7 Nm • Tooling/magazine: • Number of revolvers/magazines: 2 • Magazine capacity: 38 positions • Additional magazine + 43 positions • Maximum tool length: 300 mm • Maximum tool diameter: 140 mm • Knoll Cooling • Renishaw OMP 40 probe • IKZ (inner cooling through spindle) • Laser beam monitoring • Chip conveyor • SK 40 • Operating voltage 400 V/3~ • Mains frequency 50 Hz • Control voltage 24 V- • Total nominal current 60 A • Total performance 41 kVA Additional equipment • OPTIONAL for an additional charge: Tooling package available: approx. 530 tools • OPTIONAL for an additional charge: Zero-Point Clamping SystemMachine was maintained in 2025 by HERMLE officialIn August 2025, the spindle head was replaced and the geometry was checked and adjusted again by HERMLE official Technical Specification Taper Size SK 40

Condition: used, Year of construction: 2004, x-travel 650 mm y-travel 600 mm z-travel 500 mm control Sinumerik 840 D pl Siemens turning speed range - main spindle 20 - 28.000 min/-1 power capacity - main spindel 23 / 18 kW max. Torque 79 Nm tool taper HSK-A63 table surface area Ø 630 mm Swivel range A: +30° / -115 ° rotatable C: 360 ° max. table load 500 kg max. workpiece sizes Ø 630 x 313 mm table speed A:25 / C:65 min/-1 number of toolpositions 117 pos. max. tool diameter 90 (125) mm max. tool length 300 mm rapid traverse ( X / Y / Z ) 60 m/min Accelaration 10 m/s² Djdpfxszd E Tbe Ac Hjci feed power 8,5 kN total power requirement 43 kVA weight of the machine ca. 10,5 t dimensions of the machine ca. 6,5 x 4,5 x 3,0 m 5 Axis CNC - Machining Center Universal HERMLE - C 30 U Dynamic - Tool-Magazine 117 pos. - ca. 9.000h Spindle-hrs. after change - OPTIONALLY available with a pallet changer (extra cost)

Condition: used, Year of construction: 2011, Technical details: x-travel: 800 mm y-travel: 950 mm z-travel: 1020 mm control: Sinumerik 840D sl MDynamics Operate turning speeds: 10.000 1/min Spindle power: 26/20 kW max. torque on the spindle: 340/262 Nm tool taper: HSK-A 100 tool change unit: 120 (2x60) Pos. Pallet changer 2x: 630 x 630 mm table load capacity: 800 kg weight of the machine ca.: 20 t dimensions of the machine ca.: 3,3 x 6,15 x 3,2 m 6-axis simultaneous horizontal machining center with controlled swivel-rotary table (A/B-axis), Swivel table can swing overhead (180°), that means the part is hanging down overhead and chips don’t accumulate on pallet, they can fall free into the chip conveyor CNC controlled U-axis enables radial movement of tool for variable spindling diamenter. twin pallet changer 630 x 630 mm 6 hydraulic couplings for pallet fixture clamping with rotary joint in A and B-axis Dsdpfxsyzza Ie Ac Heci special hydraulic pump for fixture coolant through spindle (10-80bar), one channel with proportional valve for pressures 10-200 bar, electromech. tool-length measuring device GROB, BLUM laser for tool measuring, tool coding, chip conveyor, 3D touch probe M&H, el. handwheel Siemens HT8 coolant gun, coolant shower, air gun, oilskimmer, automatic door Remote diagnosis A 6th axis MAPAL Tooltronic U-axis system comes with the machine with two heads: 1. LAT125-HSK100 2. LAT160-HSK100 *

Condition: good (used), Year of construction: 2004, functionality: fully functional, The used FANUC ALFA 1-iC wire EDM is a medium-sized, 5-axis CNC-controlled electrical discharge machine with submerged machining; X/Y/Z travel: 550/370/410 mm; year of manufacture: 2004, CE-compliant, complete with automatic wire threading, chiller, and openable roof. Technical specifications of the FANUC ROBOCUT ALPHA 1iC wire EDM: - Maximum workpiece dimensions (L x W x H): 820 x 730 x 300 mm - Maximum workpiece weight: 1000 kg - CNC control: Fanuc Series 180is-WB - 5 axes (X, Y, Z, U, V) - Stroke on axes X/Y/Z/U/V: 550/370/410/120/120 mm - Rapid traverse on X, Y, Z axes: 900 mm/min Dcjdpfx Acsxd R Hme Hoi - Rapid traverse on U, V axes: 450 mm/min - Worktable size (L x W): 780 x 600 mm - Maximum cutting angle: 30 degrees - Automatic wire threading - Wire diameter: 0.1–0.3 mm - Electrical supply: 400 V; 50/60 Hz - Total power requirement: 13 kW - Total machine weight: 3100 kg

Condition: used, Year of construction: 2018, Delivery time approx. 5 months. Machine from educational use – TOP condition, low hours (edging unit unused). No tools included. Dismantling, delivery, assembly, commissioning, and training not included in the price. Includes Maestro 3D and Pro View. MORBIDELLI P200 Working area X-Y: 3,110 x 1,620 mm, workpiece height Z180 mm Edge banding made for you: The CNC machining center is equipped with a comprehensive selection of edge banding tools to meet any woodworking requirement. MAIN ADVANTAGES · High performance with the advanced H80C edge banding unit, 8,000 rpm drilling spindles. The most robust spindle technology on the market, offering over 1,000 maintenance-free operating hours. · Better equipped: Suction cups can be disabled and configured via the FLEX worktable to optimally adapt the machine to requirements. · Easier, more intuitive programming thanks to the integrated CAD-CAM module for edge banding technologies “MAESTRO EDGE”. · Easier operation: The lowered frame ensures the worktable is always accessible. The control cabinet and vacuum pump are integrated, and in the PRO SPACE configuration, no safety barriers are needed. Base structure: The base frame is a monolithic construction made from thick-walled steel, reinforced across the entire machine bed with welded square plates for exceptional rigidity. The bed’s shape, with a wide base, is the secret to lasting precision and stability. The load-bearing structure consists of a particularly robust, monolithic steel base, heavily ribbed and highly stiffened; the extra-wide support was specially designed to give the machine maximum stability, ensuring lasting precision regardless of operating conditions—with no need for floor anchoring. The base provides a large, solid support for the moving gantry: the working unit is thus equipped with a balanced, stable, and resilient support capable of handling the highest loads, ensuring top-quality performance and greater accuracy. The moving gantry is made from a robust single piece anchored to the base, sliding along top-quality prismatic guides with recirculating ball carriages. The working unit is attached and moves along the Y and Z axes on prismatic guides with recirculating ball carriages. Movement of the lower carriage (X-axis) and the working unit along the moving carriage (Y-axis) is enabled by rack-and-pinion transmission with helical teeth. This design results in greater tooth-on-tooth engagement, delivering higher acceleration and greater speed along the X and Y axes. The specially designed helical gearing ensures reduced wear on mechanical components and quieter operation. The vertical Z-axis is driven by a ball screw, ensuring perfect balance with dynamic loads and smooth acceleration and deceleration. The main milling unit is directly coupled to the Z-axis carriage for maximum finishing quality. Dcsdpoyuw Srsfx Ac Hsi

Condition: used, Year of construction: 2004, x-travel 650 mm y-travel 600 mm z-travel 500 mm control Sinumerik 840 D pl Siemens turning speed range - main spindle 20 - 28.000 min/-1 power capacity - main spindel 23 / 18 kW max. Torque 79 Nm tool taper HSK-A63 table surface area Ø 630 mm Swivel range A: +30° / -115 ° rotatable C: 360 ° Dcedpoxmagzefx Ac Hei max. table load 500 kg max. workpiece sizes Ø 630 x 313 mm table speed A:25 / C:65 min/-1 number of toolpositions 117 pos. max. tool diameter 90 (125) mm max. tool length 300 mm rapid traverse ( X / Y / Z ) 60 m/min Accelaration 10 m/s² feed power 8,5 kN total power requirement 43 kVA weight of the machine ca. 10,5 t dimensions of the machine ca. 6,5 x 4,5 x 3,0 m 5 Axis CNC - Machining Center Universal HERMLE - C 30 UP Dynamic - palletchanger - Tool-Magazine 117 pos. - ca. 9.000h Spindle-hrs. after change - OPTIONALLY available without pallet changer

Condition: excellent (used), Year of construction: 2008, travel distance X-axis: 3,000 mm, travel distance Y-axis: 825 mm, travel distance Z-axis: 1,100 mm, rapid traverse X-axis: 48,000 m/min, rapid traverse Y-axis: 80,000 m/min, rapid traverse Z-axis: 48,000 m/min, table width: 835 mm, table length: 3,500 mm, table load: 3,500 kg, 1 Axis CNC Swivel head, infinitely variable Axis drive with ball screw drive Roller linear guides in all axes Direct path measuring systems Full work area encosure with roof Chip conveyor Coolant unit Dsdpfjwyv Nzex Ac Hsci X - Travel: 3000mm Y - Travel: 825mm Z - Travel: 1100mm B - Axis: - 3 to + 105° Table Length: 3500mm Table Width: 835mm Table load: 3500 Feed rate X-Axis: 48000mm/min. Feed rate Y-Axis: 80000mm/min. Feed rate Z-Axis: 48000mm/min. Spindle Taper: HSK 100ISO/Bt/Mk Power on spindle: 37kW Speeds / ranges: 8000Rpm ATC / revolver: 40 Coolant through spindle / Bar:25 Number of controlled axis: 4 Chip conveyor: Yes Coolantsystem: Yes Length: 8000mm Width: 3800mm Height: 3800mm

Condition: ready for operation (used), Year of construction: 2000, operating hours: 38,515 h, spindle speed (max.): 10,000 rpm, overall weight: 6,500 kg, travel distance X-axis: 450 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 400 mm, controller manufacturer: HEIDENHAIN, controller model: iTNC 426, number of axes: 5, This 5-axis HERMLE C 600 U was manufactured in 2000. It features an X-axis travel of 450 mm, Y-axis travel of 300 mm, and Z-axis travel of 400 mm, providing versatile machining capabilities. The machine is equipped with a HSK 63 tool holder and a Heidenhain iTNC 426 CNC control for precision operations. If you are looking to get high-quality machining capabilities, consider the HERMLE C 600 U universal machining centre we have for sale. Contact us for further details. • Interference circle (Störkreis): 400 mm • Operation voltage: 400 V (3 phase, 50 Hz) • Control voltage: 24 V (DC) • Total nominal current: 63 A • Total power rating: 42 kVA • Spindle on: 38,515 hours • Axes in motion: 36,413 hours • CTS • Chip conveyor Technical Specification Taper Size HSK 63 Through-spindle Coolant Yes Djdpsyz Tygjfx Ac Hoci

Condition: good (used), Year of construction: 2014, functionality: fully functional, turning length: 760 mm, turning diameter: 376 mm, spindle speed (max.): 3,500 rpm, quill diameter: 78 mm, overall weight: 6,000 kg, Equipment: documentation/manual, rotational speed infinitely variable, Main parameters: Controller: FANUC 0iD/31iA Chuck.: SAMCHULLY 10" Spindle bore: 86mm With jacket tube.:78mm Dcedpfxoykikxs Ac Hoi Turret head: 12 main positions 12 secondary positions, BMT65 connection, Programmable hydraulic tailstock: MT5 Main spindle power: 22kW S1max=3500 1/min Living tool power: 5.5kw S2max=5000 1/min X movement range: 260mm Z axis movement range: 830mm Y axis movement range: + - 52mm (104mm) C axis Maximum turning length: L=760 Largest turning diameter: D=376mm Fast travel speed: 30m/min Automatic tool measurement with probe arm Weight: 6000 kg

Condition: new, Year of construction: 2025, Ref. -No.: 10463 Manufacturer: IGREK Type: FR 3500 XL Year of construction: 2025 Type of control: CNC-Steuerung Control: Siemens 840 D / Heidenhain iTNC 640 Storage location: Istanbul Country of origin: Türkiye X-Travel: 6500 mm Y-Travel: 3500 mm Z-Travel: 1400 mm A-Axis: +/- 115 ° C-Axis: 360 ° Turning Speeds: 12500 RPM Max. Torque: 235 Nm Rapid Traverse X/Y/Z: 30 m / min Table-Size (Lxw): 2290 - 6490 x 3580 mm Drive power spindle: 54 kW Table load max.: 4000 kg Tool Taper: HSK-A100 Machine length: 11500 mm Machine width: 7400 mm Machine Height: 6600 mm Weight: 120 t Further information: IGREK FR 3500 XL – Precision and performance at the highest level The IGREK FR 3500 XL is a CNC-controlled 5-axis portal milling machine of the latest generation (year of manufacture 2024). It was specially developed for the demanding machining of large workpieces and impresses with its versatility and precision. With a modern control system from Siemens 840D or Heidenhain iTNC 640 and a robust construction, the machine offers optimal conditions for manufacturing in a wide range of industries. Key features: Dcedpfxoxmd Szo Ac Hji Large machining areas: With travel distances of 6,500 mm (X), 3,500 mm (Y) and 1,400 mm (Z), the machine is ideal for machining large components. 5-axis simultaneous machining: The A-axis with a swivel range of +/- 115° and the C-axis with a rotation of 360° enable highly precise machining of complex geometries. Powerful spindle: The spindle reaches speeds of up to 12,500 rpm and a maximum torque of 235 Nm – perfect for demanding milling work. High stability: The machine weight of 120 tons and the table load of up to 4,000 kg ensure low-vibration machining even with heavy workpieces. Flexible tool holding fixture: The HSK-A100 tool holding fixture enables quick tool changes and optimal process times. Rapid feed rate: High productivity is achieved with 30 m/min in the X, Y and Z directions. Technical data at a glance: Table size: 2,290 – 6,490 x 3,580 mm Spindle power: 54 kW Max. torque: 235 Nm Tool holder: HSK-A100 Machine dimensions (LxWxH): 11,500 x 7,400 x 6,600 mm Max. table load: 4,000 kg The IGREK FR 3500 XL sets new standards in the machining of large parts. It is available immediately and offers comprehensive warranties and services directly from the manufacturer, internationally and across the board. Use the latest technology for your production – contact us for further details!
