Used Knuth for sale (74)

Condition: like new (used), Year of construction: 2017, functionality: fully functional, machine/vehicle number: 163190, grinding length: 600 mm, grinding width: 300 mm, workpiece weight (max.): 270 kg, grinding wheel diameter: 350 mm, distance table to spindle center: 565 mm, Like-new horizontal surface grinding machine with few operating hours! TECHNICAL DETAILS Grinding area Grinding length: 600 mm Grinding width: 300 mm Work table and workpiece load Table dimensions: 300 mm × 630 mm Maximum workpiece weight: 270 kg Distance spindle axis – table surface: 565 mm Travel distances and feeds Crjdjzqcvgepfx Aiiji Travel distance X-axis: 765 mm Travel distance Y-axis: 340 mm Scale ring graduation Y-axis: 0.02 mm Scale ring graduation Z-axis: 0.005 mm Automatic transverse feed Z-axis: 0.1–8 mm Feeds and rapid traverses Hydraulic feed X-axis: 7–23 m/min Rapid traverse Y-axis: 990 mm/min Rapid traverse Z-axis: 460 mm/min Grinding wheel Grinding wheel dimensions: 350 mm × 40 mm × 127 mm MACHINE DETAILS Control type: Conventional 2-axis position indicator: KNUTH Xpos 3.1 Motor power grinding spindle: 5.5 kW Total power requirement: 7 kW Dimensions & Weight Machine dimensions: 2,800 mm × 2,200 mm × 1,890 mm Machine weight: approx. 2.7 t EQUIPMENT 2-axis position indicator KNUTH Xpos 3.1 Grinding wheel Grinding wheel flange Balancing arbour Balancing stand Halogen work light Magnetic chuck 600 mm × 300 mm Adjustment screws Operating tool Automatic transverse and longitudinal feed Hydraulic table longitudinal movement Double V-guides for the longitudinal movement Combined V- and flat guides for the transverse movement Hardened and ground table guide rails with PTFE counter coating Grinding spindle with maintenance-free, preloaded precision angular ball bearings External hydraulic unit Automatic central lubrication

Condition: used, Lathe KNUTH SH150H/610 R, year of manufacture 1988 Chuck: 200 mm, spindle bore: 36 mm. Power supply: 16A / 380V. Csdpfx Aez Hkn Tjiisri No sales to private individuals.

Year of construction: 2001, condition: used, Total power: 6kW, voltage: 400V, frequency: 50Hz/3-phase. Documentation available. Inspection by appointment possible. Cjdsz Dki Sjpfx Aiiori

Condition: used, Year of construction: 1995, x-travel 300 mm y-travel 200 mm z-travel 350 mm tool taper SK40 spindle turning speed range 110 - 1230 U/min table-size 270 x 700 mm total power requirement 3,7 kW weight of the machine ca. 900 kg dimensions of the machine ca. 1400 x 1400 x 1700 mm Features: Crodpfszx Hfbsx Aiisi - 3-axis digital display - Milling head swivels ± 45 degrees - Coolant system - User manual

Condition: good (used), Year of construction: 2001, Power: 4.5 kW Codpfxozvnlds Aiieri Drilling capacity: 30 mm End milling: 25 mm Motor power: 0.85/1.5; 2.2 kW

Condition: used, Year of construction: 2002, x-travel 400 mm y-travel 320 mm z-travel 440 mm table-size 80 x 325 mm spindle taper ISO Sk 40 spindle turning speed range 63 - 3150 U/min quill stroke 60 mm weight of the machine ca. 1,5 t dimensions 1,8 x 1,8 x 1,9 m Universal Milling Machine Cedpfew Tdxijx Aiiori - Digital Display - Hydraulic Tool Clamp - Central Lubrication - Coolant System - Machine Light - Machine Feet - Counter Bearing - Chip Tray

Condition: good (used), Year of construction: 2002, Drilling and Milling Machine Manufacturer: KNUTH Type: TBF 500 Year: 2002 with coordinate table Spindle taper: MK4 Spindle speeds: 125-2500 rpm Motor power: 1.1 kW Table travel: X 500 mm, Y 160 mm Max. installation height: 300 mm Spindle stroke: 130 mm Table size: 200 mm x 730 mm Cedpfx Aiey Spubeieri Machine dimensions: Width 1000 mm, Depth 800 mm, Height 1800 mm, Weight approx. 350 kg In good condition.

Year of construction: 2005, condition: ready for operation (used), Stroke: 135mm, max. sheet thickness: 20mm, max. bending length: 3050mm, pressing force: 80t, max. operating pressure: 2975psi, max. die opening: 250mm, bending angle range: 1°-42°, oil capacity: 150L, max. tool weight upper/lower: 40kg/115kg. Machine dimensions X/Y/Z: approx. 4000mm/2050mm/2450mm, weight: approx. 6000kg. Documentation available. An on-site inspection is possible. Cjdsxl Upnspfx Aiisri

Year of construction: 2017, condition: excellent (used), Control Siemens 828 D Travel X / Y / Z 850/550/550 mm Spindle speed 8000 rpm Crsdpjft U S Nofx Aiioi Tool magazine for 24 tools BT40 Table size 950x550 mm

Condition: ready for operation (used), Year of construction: 2014, functionality: fully functional, drilling depth: 315 mm, rotational speed (max.): 2,000 rpm, throat depth: 1,600 mm, drilling capacity: 62 mm, column diameter: 350 mm, TECHNICAL DETAILS Drilling capacity in steel (diameter): 62 mm Thread cutting in steel (St 60): M46 Thread cutting in grey cast iron (GG 20): M52 Credpfoxxrcxjx Aiiji Maximum drilling depth: 315 mm Machine table dimensions: 2,400 x 1,000 x 200 mm Throat: 1,600 mm Drill head travel (horizontal): 1,250 mm Arm stroke (vertical): 585 mm Column diameter: 350 mm Speed range: 38 – 2,000 rpm Spindle taper: MK 5 Feeds: 0.06 – 1 mm/rev MACHINE DETAILS Total power requirement: 5.5 kW Dimensions & Weight Space requirement: approx. 2,490 x 1,050 x 2,780 mm Machine weight: approx. 3,800 kg

Condition: good (used), Year of construction: 2002, machine/vehicle number: 025137, Offer 24190 Technical specifications: - Drilling capacity: 25 mm - Drill spindle taper: MK 3 - Drill spindle stroke: 140 mm - 8 spindle speeds: 100 - 2900 rpm - Min./max. distance spindle/table: 110 / 405 mm - Work light Codpfxewyl H Ne Aiieri - Quick-action drill chuck - Coolant device - Machine vice - Machine base - Drive: 400 V / 0.75 kW - Required space (W x H x D): 400 x 1250 x 600 mm - Weight approx.: 200 kg

Condition: used, machine/vehicle number: 127963, functionality: fully functional, input voltage: 400 V, type of input current: three-phase, spindle mount: MK 3, drilling depth: 130 mm, total width: 420 mm, total length: 800 mm, total height: 1,800 mm, throat depth: 230 mm, overall weight: 190 kg, column diameter: 102 mm, spindle speed (max.): 1,880 rpm, spindle speed (min.): 160 rpm, Dear Sir or Madam, Cedpfx Aisv T Ax Djieri We are happy to answer any questions. This sale is made without any warranty or guarantee. Errors and typos cannot be ruled out. Please check the information in the PDF. No returns accepted.

Condition: used, Year of construction: 2008, x-travel 400 mm y-travel 300 mm z-travel 400 mm spindle taper ISO 40 Csdpfx Aioxa Hf Rjijri spindle turning speed range 40 - 2.000 U/min table-size 750 x 320 mm feeds -stepless- 10 - 380 mm/min rapid traverse 1.200 mm/min power capacity 2,2 kW quill stroke 80 mm voltage 400 V total power requirement 4,7 kW weight of the machine ca. 1,1 t dimensions of the machine ca. 1,15 x 1,40 x 1,85 m - Serial-No.: 148373 - 3-axis digital display - Horizontal milling device - Milling head swivels ±45° - Coolant device

Condition: ready for operation (used), 1 used bed type milling machine Manufacturer: Knuth Model: KB 1400 Year: 2006 Technical Specifications: Working Area Distance spindle axis to table surface: 150 mm – 650 mm Number of T-slots: 3 Table clamping surface: 1400 mm x 400 mm T-slot width: 18 mm T-slot spacing: 100 mm Height adjustment speed (max.): 1670 mm/min Travel Cjdpoxnp Epjfx Aiieri X-axis travel: 950 mm Y-axis travel: 400 mm Z-axis travel: 500 mm Vertical Milling Head Spindle taper: SK 50 DIN 2080 Overhang: 510 mm Spindle speed (vertical): 30 rpm – 1800 rpm Quill stroke: 105 mm Head swivel range: ±30° Rapid Traverse Rapid traverse X-axis: 1670 mm/min Rapid traverse Y-axis: 1670 mm/min Rapid traverse Z-axis: 1670 mm/min Feed Feed speed X-axis: 18 mm/min – 627 mm/min Feed speed Y-axis: 18 mm/min – 627 mm/min Feed speed Z-axis: 18 mm/min – 627 mm/min Drive Capacity Main drive motor power: 7.5 kW Feed motor power: 0.75 kW Z-axis motor power: 0.75 kW Coolant pump motor power: 0.04 kW Dimensions and Weight Coolant pump flow rate: 12 l/min Dimensions (L x W x H): 2.29 m x 1.77 m x 2.12 m Weight: 3660 kg

Year of construction: 2010, condition: good (used), machine/vehicle number: 182245, table mounting size: 500 x 1050 mm movements x/y/z: ca. 800/500/500 mm spindle taper: BT 40 ISA min./max. distance table/spindle: 100/650 mm spindle turning speed range: 8000 rpm number of tool positions: 24 pieces carriages: 5 - 6000 mm/min rapid move: ca. 15 m/min spindle drive: 11/15 kW electrical connection: 400 V, ca. 20 kVA kW Crodedbh Udjpfx Aiioi space needed: 2450 x 2220 x 2780 mm weight: 5200 kg Delivery time: approx. middle April 2017

Condition: ready for operation (used), Turning diameter over bed/cross slide: 530mm/280mm, center height: 264mm, center width: 2000mm, bed width: 370mm, speed: 2000rpm, spindle bore: 80mm, tool shank dimensions X/Y: 25mm/25mm, cross slide travel: 300mm, quill diameter: 65mm, quill stroke: 180mm, repeat accuracy: mm. The machine has an electrical problem on the tool head. Documentation available. On-site inspection is possible. Cjdpfjv Amrtsx Aiiori

Condition: good (used), Year of construction: 1994, Universal machining center, CNC tool milling machine, milling machine, universal milling machine, tool milling machine, drilling and milling machine -Manufacturer: Knuth, CNC tool milling machine type WF 5 NC -Clamping table: 800 x 330 mm -Travel: X/Y/Z 400/330/440 mm -Spindle holder: SK40 -Quill stroke: 60 mm -Speeds from: 63 to 3150 rpm -Coolant system Crodpfx Aswyivneiioi -Accessories: including extensive accessories see photos -Dimensions: Machine: 1500/1345/H1900 mm / Control cabinet 750/450/H1730 mm -Total weight: 1960 kg

Year of construction: 1995, condition: used, bore capacity in steel (diameter) 50 mm throat 335 mm bore stroke 250 mm feed power max. 16 kN spindle taper MK4 spindle motor 3 kW table surface area 850 x 450 mm travel -x axis 600 mm Csdpfowu Hg Tox Aiijri travel -y axis 300 mm travel -z axis 205 mm weight of the machine ca. 1,8 t dimensions of the machine ca. 1,618 x 1,802 x 2,520 m

Condition: good (used), Year of construction: 1986, Table size: 600 x 350 mm Travel X-axis: 340 mm Y-axis: 260 mm Head adjustment travel: 200 mm Codory Tq Dopfx Aiiori Quill stroke (servo): 210 mm Max. workpiece weight: 500 kg Includes as-new dielectric fluid, additional filters, user manual Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: used, Year of construction: 1987, bore capacity in steel (diameter) 32 mm throat 280 mm Crodpfxjxqrd Hs Aiiji bore stroke 110 mm spindle taper MT 3 table-size 340 x 400 mm turning speeds 210- 2600 U/min total power requirement 1,8 kW weight of the machine ca. 325 kg dimensions of the machine ca. 950 x 450 x 1750 mm

Condition: used, Year of construction: 1996, sheet width 1350 mm plate thickness 3 mm cutting angle 1° 30' no. of strokes 35 Hub/min table height 850 mm rear stop 450 Cjdpfx Ajwngqfoiisri weight of the machine ca. 1200 kg dimensions ca. 1700 x 1650 x 2000 mm manually operated back gauge 450 mm working lifght included safety gate included

Year of construction: 2006, condition: good (used), functionality: fully functional, machine/vehicle number: 138883, TECHNICAL DETAILS Press force: 160 t Bending length: 4100 mm Distance between uprights: 3100 mm Control system: DELEM DA66W Table width: 120 mm Stroke: max. 800 mm Downstroke speed: 80 mm/sec Csdpfelp Iq Rjx Aiisri Upstroke speed: 80 mm/sec Speed under load: 8 mm/sec MACHINE DETAILS Oil capacity: 185 l Total power consumption: 24 kW Machine weight: approx. 13 t Space requirement: approx. 4.8 x 2.2 x 2.2 m

Condition: used, thickness of jaw:160 mm dimensions of the machine ca.:0,40 x 0,27 x 0,20 m Codpfecxxnzjx Aiisri

Condition: used, thickness of jaw:160 mm dimensions of the machine ca.:0,4 x 0,2 x 0,17 m Crjdpocxxq Aofx Aiiji
