Used Index Cutting Machine for sale (134)

Condition: good (used), Year of construction: 1990, Index MS 25 E (3 pieces per package) Number of spindles: 6 Spindle bore: 27 mm Turning length: 59 mm Hexagon material: 24 mm Square material: 18 mm Cross slide travel: 36 mm Longitudinal slide travel: 85 mm Spindle speeds: 366 - 5020 rpm Torque: 95 Nm Control system: INDEX Total power consumption: 20 kW Kdsdpfx Abjzvpt Nonsr - 6 cross slides - 6 longitudinal slides - Multi-tool turret - Thread cutting device - Hydraulic part removal device - Workpiece conveyor belt - Bar feeder magazine

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, We offer you: Manufacturer: INDEX Type: MS40-6 C Year of construction: 2019 Control: Index control C200-SL, MS40C Double-NCU Technical data: Kjdpfxszlutms Abnedr Working spindles: Number: 6 pcs. Spindle bore: max. 40 mm Max. speed: 7,000 rpm Power (100% / 25%): 13 / 24 kW Torque (100% / 25%): 31 / 57 Nm Synchronous spindle: Number: 1 pc. Spindle bore: 40 mm Max. speed: 8,000 rpm Power (100% / 25%): 10 / 14 kW Torque (100% / 25%): 16 / 22 Nm Slide travel z: 150 mm Number of tools for back-end machining: 3 pcs. Swiveling range b: 144 ° Tool holder: Number: 12 pcs. Slide travel x: 73 mm Slide travel z: 120 mm Tool holder, cut-off and back-boring slide: Number: 1 pc. Slide travel x: 82 mm Number of tools for back-end machining: 3 pcs. Electrical connection data: Rated power: 85 kW Connection power: 101 kVA Rated current: 145 A Max. pre-fuse: 160 A Note: Mains voltage: 400V Note: Electrical frequency 50 Hz Technical features & accessories: - Double-NCU - Signal light 'Smartlight' with LED - Machine designed for connection to a TN network. - Coolant: Cutting oil - NC option Synchronous spindle / Multi-sided turning incl. electronic shaft - INDEX loading magazine MBL40-6/3300/Strip loader/50Hz: - Strip loader 50Hz - for bar diameter D13 - D40 - Bar length 3300 mm - with pilot drilling unit - Material storage with 700 mm support area - Profibus-DP-Master interface. - 1 set (6 pieces) reducing sleeves manufactured for bar or corner dimensions, diameter D = * mm, Inner diameter range D14 - D41 - 1 set (6 pieces) material sliders for material diameter D24mm - D32mm, consisting of: - 6 material sliders D23 - 6 rotating sleeves D23 - 1 set (6 pieces) internal clamping sleeves D23mm - for material diameter D24mm - D32mm - pilot drilling diameter D15mm - 1 set (6 pieces) external stops D23mm - for material diameter D24mm - D32mm - pre-machined - 1 set (12 pieces) reducing sleeves for material sliders. The outer diameter of the reducing sleeves corresponds to the material diameter (D13 - D40) - 1 set (6 pieces) adapter sleeves, inner diameter range D13.5 - D40.5. The inner diameter of the adapter sleeves should be bar diameter + 0.5mm. - 1 set (6 pieces) two-part guide intermediate tubes, diameter 29 mm - Assembly aid for the sleeves of the guide intermediate tubes - UNIMAG - Interface for connecting a bar loader - Part discharge via slide into spindle position 6 - Workpiece conveyor belt in spindle position 6, machine-integrated - Hainbuch TOPlus Axfix D40 for synchronous spindle - Multi-sided and thread milling device - Reduction ratio i=5:1 - Inductive encoder for reference query - Internal oil lubrication - INDEX short taper connection - without converter - Back-end machining device on slide position 6.2 for max. three boring positions for fixed tools FURTHER INFORMATION IN THE PICTURES Accessories, tools and clamping devices shown are only included in the scope of delivery if this is stated in the additional information. Changes and errors in the technical data and information, as well as prior sale, are reserved!

Condition: ready for operation (used), Year of construction: 2012, operating hours: 75,685 h, spindle speed (max.): 6,000 rpm, travel distance X-axis: 85 mm, travel distance Z-axis: 280 mm, spindle motor power: 20,000 W, controller manufacturer: SIEMENS, number of axes: 7, This 7-axis Index ABC horizontal turning machine was manufactured in 2012. It features a main spindle with a maximum speed of 6000 rpm and a sub spindle with a speed of 4500 rpm. The machine includes two turrets, each equipped with X and Z axes, and a powerful tool drive. If you are looking to get high-quality turning capabilities, consider the Index ABC machine we have for sale. Contact us for further details. Kodpfx Abszvu Ryjnedr • Main spindle: D65, spindle interface AD140, ID83, max speed 6000 rpm; max power 20 kW at 100% duty cycle; C-axis; electronic synchronization between spindles • Sub spindle: 7.5" chuck interface, max speed 4500 rpm • Spindle hours: • S1 – 18914h • S2 – 661h • S3 – 3h • S4 – 29211h • S5 – 2413h • S7 – 1250h • The synchronous spindle was renewed in September 2024 • Chuck: 3-jaw KFN95/3, clamping force 480 daN, max 4000 rpm • Turrets: two turrets each with X and Z axis; tool drive on turret 6000 rpm, 3.3 kW • Rear working attachment: without quill, 5 quill positions • Coolant: 80 l/min at 8 bar and 20 l/min at 18 bar; system prepared for emulsion; coolant return at spindle end D60 (without bar feed) • Control: INDEX C200-4D based on Siemens 840D; color display 26 cm; thread cutting without compensating chuck; motor-current-based tool monitoring; internal tool management and setup dialog; extended machining cycles; parts counter and production monitoring • Power/connection data: 400 V, 50 Hz TN network; total connected load 45 kVA; rated power 38 kW; rated current 65 A; max fuse protection 100 A • Hydraulic hollow clamping cylinder D65 Additional equipment • Chip conveyor: hinged belt, discharge height 1250 mm • Bar feeder: MBL 65/3700 for spindle height 1010 mm; bar diameters up to 65 mm; bar feeder length 3700 mm; guide channel system with rolling bearings; loading rods (Ø12 mm and Ø20 mm, length 1400 mm); guide sets for 14–18 mm, 18–22 mm, 22–65 mm • Workpiece unloading device for main and sub spindle with part catcher • Teleservice preparation (ISDN) with software • Machine prepared for extraction system 230 V • Working area light • Two electrical cabinet cooling units • Transformer 3 kVA Technical Specification Counter Spindle Yes Driven Tools Yes

Year of construction: 2004, condition: used, An INDEX CNC lathe with counter spindle and IEMCA bar feeder is offered. Main spindle bore: 65mm, max. spindle speed: 7000rpm, axes: 4, live tooling: possible, tool system: VDI25, spindle operating hours: approx. 80000h, control: Siemens 840D. 2) Bar feeder: IEMCA Master 880/MP 33 L, Year of manufacture: 2004, max. bar length: 3300mm, round bars: 8mm-80mm, hexagonal bars: 7mm-65mm, square bars: 10mm-50mm, max. bar weight: 120kg, min. remnant length: 110mm, bar feeder weight: approx. 1350kg. Including chip conveyor. Machine was continuously maintained. The machine is available from October. Documentation available. Inspection possible by arrangement. Kdodpfx Abozu Sz Tsnor

Condition: used, Year of construction: 2007, machine/vehicle number: 511979, Turning length: approx. 400 mm, bar passage: 60 mm, Y-axis, counter spindle, 2x 14-station tool turret, cross slide X/Y/Z, B-axis slide control INDEX C 200-4 D, workpiece removal, conveyor belt, chip conveyor, manufacturer: KNOLL, bar loader MBL 65/3700, machine requires repair, gear pump defective, repair costs according to quotation: approx. €6,000.00 net, drilling emulsion/lubricants must be professionally extracted and disposed of by the customer. Kodpfx Abozqy Uyonsdr

Condition: used, Year of construction: 2007, machine/vehicle number: 511966, Turning length: approx. 400 mm, bar passage: 60 mm, counter spindle, 2 x 14-position tool turret, cross slide X/Y/Z, B-axis slide control INDEX C 200-4 D, workpiece removal, conveyor belt, chip conveyor, manufacturer: KNOLL, bar feeder MBL 65/3700, the machine requires repair; repair costs according to the cost estimate: approx. €1,880.00 net; drilling emulsion/lubricants must be professionally extracted and disposed of by the customer. Kedpjzqy U Hefx Abnsdr

Condition: used, Year of construction: 2007, machine/vehicle number: 402235, Spindle bore: 36 mm, maximum spindle speed: 7,000 rpm. C-axis, 1 turret, X/Z-axis, 7-station + synchronized spindle, driven tools, 1 tool turret, X/Z-axis, 6-station, driven tools, control system: INDEX C 200-4 D, back-side machining, workpiece removal, conveyor belt, chip conveyor, bar loader MBL 52/3200. Drilling emulsion/lubricants must be professionally extracted and disposed of by the customer. Kjdpfozqy U Tjx Abnsdr

Condition: good (used), Year of construction: 1998, functionality: fully functional, Siemens 840D control system, two turrets, all stations are powered, Kdedpfx Aezu Awxjbnsr counter spindle, spindle bore 60mm, chip conveyor, FMB magazine loader, fire extinguishing system (as the machine operates with cutting fluid), extensive accessories.

Condition: used, Year of construction: 2005, operating hours: 30,000 h, functionality: fully functional, turning length: 200 mm, turning diameter: 42 mm, spindle bore: 43 mm, spindle speed (max.): 6,000 rpm, Turning length 280 mm Controller Siemens 2x revolver 2x spindle live tools for working on back spndle Kdsdpfx Aozlcpvebner live tools on revolver 1 high pressure coolant system swarf coveyour Iemca bar feeder Machine has been running using cutting oil. Machine geometry and precision in like new condition. Machine is under power and ready for production. All books and manual available. Also big selection of collects for main spindle and sub spindle.

Condition: good (used), Year of construction: 2014, functionality: fully functional, using Stäubli robots Kdodpfxszuc T Tj Abnsr Specifications, information, price, images, etc. can be found in the PDF documents attached.

Condition: ready for operation (used), Year of construction: 2015, functionality: fully functional, Equipment: bar feeder, chip conveyor, A rebuild was carried out by Index for €380,000! EQUIPMENT Prepared as a double 3-spindle machine Part pick-off device Ksdpfoyx Tzrjx Abnedr Thread cutting gearbox Cucci Giovanni integral loader Brankamp tool breakage monitoring and tool monitoring Cucci Giovanni bar feeder (2015) Knoll chip conveyor (2015)

Condition: used, Year of construction: 2015, Technical details: turning diameter: 65 mm turning length: 120 mm control: Index C200-4D SL z-axis main spindle travel: 390 mm z-axis subspindle travel: 390 mm x-axis subspindle travel: 600 mm Travel Y1: ± 80 mm Kdsdpfx Abjyxpadoner Travel y2: ± 80 mm x-axis rapids: 45 m/min y-axis rapids: 15 m/min z-axis rapid travel: 45 m/min Spindle 1 RPM: 5000 1/min Spindle 1 Power: 35,5/27,5 kW Spindle 1 Torque: 170 /125 Nm Spindle 2 RPM: 5000 1/min Spindle 2 power: 35,5/27,5 kW Spindle 2 torque: 170/125 Nm c-axis: 0,00014 ° bar material dia.: 65 mm spindle nose: AD 140 spindle bore: 85 mm Milling spindle 1 RPM: 18000 1/min Milling spindle 1 power: 11 kW Milling Spindle1 torque: 19 Nm Milling spindle 2 RPM: 18000 1/min Milling Spindle 2 power: 11 kW Milling spindle 2 torque: 19 Nm B-axes swivel angle: 230 ° B-axes torque: 440 Nm B-axes angle resolution: 0,001 ° Milling spindle 1 & 2 tool magazine: 80 HSK A40 Milling spindle 2 tool magazine static tools : 6 x VDI 25 internal coolant system feed: Knoll 80 bar / Ecofluid weight of the machine ca.: 16,3 t dimensions of the machine ca.: 3,73x2,92x2,58 m Accerories Chip conveyor Spindle 1 Chuck SMW HFKN 165-46 mm Spindle 2 Chuck SMW HFKN 165-46 mm Collet chuck main spindle Hainbuch Spanntop Collet chuck subspindle Hainbuch Spanntop Barfeeder Interface Unimag Short bar loader IRCO ILS RBK 10016 Parts catcher for main- and sub-spindle Conveyor for partsdisposal Air Filter Büchel High performance heavy duty turning and milling center with 2 multi axis milling heads and two spindles. Both milling heads are full 5-axis. The z-axes are installed in the spindle heads The x2 axis is installed in the spindle head of the subspindle Milling1 head has x/y/b -axes Milling head 2 has y/b-axes Both milling heads have B-(Swivel-)axis 230° The machine is equipped with an IRCO short barfeeder and parts gripper for finished parts. Max. dim for finished parts: Ø 65 mm, length 120 mm, weight 5 kg. Rest piece length 200 mm All linear- axes are equipped with linear scales. Coolant through main and subspindle. Tool breakage control from drill Ø 1mm All existing tool from machine are part of delivery Machine is in excellenten Condition! *

Condition: ready for operation (used), Year of construction: 2004, travel distance X-axis: 300 mm, travel distance Z-axis: 1,400 mm, total height: 2,400 mm, total width: 2,560 mm, overall weight: 13,500 kg, controller manufacturer: SIEMENS, controller model: SINUMERIK, product length (max.): 5,460 mm, number of axes: 8, This 8-axis Index G250 turn-mill centre was manufactured in 2004. It includes a Knoll chip conveyor, EMAG cooling unit, and ISI mist extraction system. The machine features a hydraulic power chuck with a clamping range of 125–152 mm and an overhead gantry loader for automation. If you are looking to get high-quality turning and milling capabilities, consider the Index G250 machine we have for sale. Contact us for further details. - Control Unit: Siemens SINUMERIK / INDEX C 200-4D- Rated Voltage: 400 V AC (3 Phase, 50 Hz)- Rated Current: 74 A- Rated Power: 43 kW- Control Voltage: 24 V DC- Tool Turret: 12-station tool turret with driven/live tool capability (individual powered tools are not included in the scope of delivery)- Workholding: Main spindle with hydraulic power chuck / collet system, SMW-Autoblok SLU-3-ZS hydraulic power chuck (clamping range 125-152 mm)- Steady Rest: SMW-AUTOBLOK / Original SMW Steady Rest (Type: SLU-3-28, Clamping range: 12-152 mm, Max. operating pressure: 60 bar)- SMW Autoblok steady rest: • hydraulic/self-centering steady rest • mounted on its own lower slide • suitable for providing additional support for long or thin workpieces- Tailstock unit with a rotating center on the right side of the work area for supporting longer workpieces- Hydraulic System: Integrated hydraulic power unit operating at 95 bar pressure- Automation / Gantry Loader: Promet Automation gantry loading system overhead- Coolant / Chip System: Knoll chip conveyor / coolant unit (YOM: 2004)- Chiller Unit: EMAG Chiller / Cooling Unit (YOM: 2016, Cooling capacity: 9.5 kW, Refrigerant: 2.5 kg)- Mist Collector / Air Cleaner: ELBARON / ISI RON / A 2500 Electrostatic Air Cleaner / Mist Extractor (YOM: 2004)- Documentation Included: Complete documentations, operating manuals, etc.- Transport Dimensions (L x W x H): Approx. 5460 x 2560 x 2400 mm (width reducible to 2450 mm)- Machine Weight: Approx. 13,500 kg Kdedpfx Abeznc Nbsnsr Technical Specification Counter Spindle No Driven Tools No

Year of construction: 2008, condition: ready for operation (used), Two Index CNC turning and milling centers are available. 1) Index G250, year of manufacture: 2008, swing diameter: 560mm, turning length: 800mm, bar capacity: 90mm, spindle diameter: 140mm, spindle speed: 3500rpm, spindle power: 43kW/57kW, torque: 275Nm/363Nm, indexing: 2.5°, tool speed: 6000rpm, tool drive power: 11kW, X/Z travel: 300mm/800mm, rapid traverse X: 30m/min, rapid traverse Z: 22.5m/min, feed force X/Z: 7200N/9000N, quill diameter: 65mm, machine dimensions X/Y/Z: approx. 7300mm/4000mm/2600mm, weight: approx. 14000kg, control: Siemens 840D C200-4D. 2) Index G300, year of manufacture: 1998, retrofit: 2022, turning diameter: 270mm, turning length: 710mm, max. swing diameter: 590mm, main spindle bore: 65mm, spindle diameter: 110mm, spindle speed: 5000rpm, torque: 275Nm, power: 43kW, tailstock center distance: 740mm, max. thrust force: 10kN, short slide travel X/Y: 215mm/180mm, short slide travel Z: 710mm/1250mm, feed force X/Y/Z: 8kN/16kN/13kN, rapid traverse: 20m/min, tool stations: 12. Documentation available. An on-site inspection is possible. Kodpfxjznmxmj Abnedr

Condition: used, Year of construction: 1995, turning diameter 250 mm turning length 750 mm control Siemens type 840 c spindle passage 65 mm Tool changer 2 live tooling 2x Revoler Kdsdpszfqhyefx Abnor weight of the machine ca. 7 t Main and counter spindle 3-jaw chuck with numerous jaws Hainbuch collets Many tool holders Various driven tools Bar loader "Index MBL" Chip conveyor with coolant unit Complete set of spindle reducers etc. see photo The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, TECHNICAL DETAILS - Number of spindles : 6 - Number of counter-spindles : 1 SPINDLES - Max. bar diameter : 22 [mm] - Spindle speeds : 10000 [rpm] - Spindle power : 8.5/15 [kW] NUMERICAL AXES - Slide unit 1.1 : X and Z axes controlled by NC - Slide unit 1.2 : Z controlled by NC - Slide unit 2.1 : Z controlled by NC - Slide unit 2.2 : X and Z axes controlled by NC - Slide unit 3.1 : X and Z axes controlled by NC - Slide unit 3.2 : X and Z axes controlled by NC - Slide unit 4.1 : X and Z axes controlled by NC - Slide unit 4.2 : X and Z axes controlled by NC - Slide unit 5.1 : X and Z axes controlled by NC - Slide unit 5.2 : X and Z axes controlled by NC - Slide unit 6.1 : Z axis controlled by NC - Slide unit 6.2 : X and Z axes controlled by NC POWER SUPPLY - Supply voltage : 380 [V] - Total installed power : 77 [kW] WEIGHT & DIMENSIONS - Machine floor space : 3329 x 2032 [mm] - Machine height : 2654 [mm] - Machine weight : 7100 [kg] MACHINE HOURS - Number of hours under power : 36508 [h] - Number of working hours : 26721 [h] - Number of spindle hours : 20860 [h] Kodpfxsyzi Ums Abnsdr EQUIPMENT - CNC : Siemens 840D SL - Cutting force monitoring: ARTIS - Chips conveyor - Coolant tank * with high-pressure pump : 80 [bars] - Bar loader : IEMCA SIR mS22P/33 - Fire extinguisher * * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer. - Electric transformer

Year of construction: 1995, condition: ready for operation (used), A CNC counter-spindle lathe Index with Y-axis and bar feeder MBL 42 is available. Turning length: 400mm, turning diameter: 420mm, bar capacity: 60mm, speed: 6000rpm, machine dimensions X/Y: 4750mm/1950mm. Documentation available. An on-site inspection is possible. Kdedoym Dgmjpfx Abner

Condition: used, TECHNICAL DETAILS - Number of axes : 11 - Number of spindles : 2 MAIN SPINDLE - Spindle power : 47 [kW] - Spindle speeds : 3500 [rpm] - Max. bar diameter : 102 [mm] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Spindle power : 47 [kW] - Spindle speeds : 3500 [rpm] Kjdpfx Aozgx Ahsbnsdr - Max. bar diameter : 102 [mm] - C axis indexing precision : 0.001 [°] - Travel : 610 [mm] TURNING-MILLING SPINDLE - X stroke : 580 [mm] - Y stroke : ± 140 [mm] - B Axis stroke : 270 [°] - B axis indexing precision : 0.001 [°] - Tool type : HSK-T63 - Spindle speeds : 9000 [rpm] - Spindle power : 24.5 [kW] - Fixed tools on a milling electrospindle : 6 x VDI30 LOWER TURNING-MILLING SPINDLE - Y stroke : ± 140 [mm] - B Axis stroke : 270 [°] - B axis indexing precision : 0.001 [°] - Tool type : HSK-T63 - Spindle speeds : 9000 [rpm] - Spindle power : 24.5 [kW] - Fixed tools on a milling electrospindle : 6 x VDI30 TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 140 - Tool exchange time : 6 [sec] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 114 [kW] WEIGHT & DIMENSIONS - Machine floor space : 4800x2960 [mm] - Machine height : 3170 [mm] - Machine weight : 18500 [kg] MACHINE HOURS - Number of hours under power : 57184 [h] - Spindle hours : 1756 [h] - Number of turning-milling spindle hours : 1694 [h] EQUIPMENT - CNC : Siemens Sinumerik 840D SL - Coolant tank * with high-pressure pump * with paper filtering unit * Coolant through spindle - Chips conveyor - Spindle cooling unit - Workpiece probe : Renishaw

Condition: used, Year of construction: 2001, swing diameter max. 450 mm chucking diameter 400 mm control Siemens 840D (Index) Max. rpm 4.200 min/-1 power capacity - main spindel ( 35,5 / 56 ) kW max. Torque ( 340 / 550 ) Nm C-Axis 0,001 ° number of toolpositions 2x 12 pos driven statition 2x 12 pos worktool system VDI 30 max. spindle speed driven tools 6.000 U/min. power capacity - driven tools 9,5 kW max. Torque 40%: 19 Nm Y - Axis +/- 90 mm B-Axis +270° / -90 ° x-axis 730 mm z-axis 340 mm y-axis +/- 90 mm b-axis +270° / -90 ° rapid traverse X: 40 / Z: 30 m/min numbers of pallets 24 pos. size of pallet 410 x 300 mm max. workpiecediameter 300 mm max. workpiece weight incl. Pallet: 25 kg Kdjdpfjyq Sk Ijx Abner Chain width 75 mm band speed 7,5 m/min total power requirement 56 kW weight of the machine ca. 9,0 t dimensions of the machine ca. 8,5 x 6,0 x 2,7 m CNC - Vertical Lathe INDEX - V 300 Y/B - incl. 24 pos. palett changing system Schnaithmann - incl. ball screw as spare part - incl. 39x driven tools - incl. 39x tool holders

Condition: used, TECHNICAL DETAILS - Number of spindles : 2 - Number of axes : 8 - Number of turrets : 2 MAIN SPINDLE - Spindle power : 53 / 68 [kW] - Spindle speeds : 3000 [rpm] - Max. bar diameter : 102 [mm] - 1 - Saisie libre : 2000 [mm] - Max. chuck diameter : 420 [mm] - Rapid traverse rate : 30 [m/min] - C axis indexing precision : 0,001 [°] COUNTER-SPINDLE - Spindle power : 50 / 70.5 [kW] - Spindle speeds : 3000 [rpm] - Max. bar diameter : 102 [mm] - Rapid traverse rate : 30 [m/min] - C axis indexing precision : 0,001 [°] UPPER LEFT TURRET - Number of positions : 12 - Number of motorized positions : 12 - Tool holder type : VDI 40 - X/Z stroke : 320 x 2.000 [mm] - Y stroke : 210 [mm] - Live tools speed : 6000 [rpm] - Live tools power : 17 [kW] LOWER RIGHT TURRET - Number of positions : 10 - Number of motorized positions : 10 - Tool holder type : VDI 40 - X/Z stroke : 210 x 2.000 [mm] - Live tools speed : 6000 [rpm] Kodpfxsuhbpfo Abnedr - Live tools power : 11.3 [kW] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 137 [kW] WEIGHT & DIMENSIONS - Machine floor space : 9.000 x 3.500 [mm] - Machine height : 3.000 [mm] - Machine weight : 21.000 [kg] MACHINE HOURS - Number of working hours : 34274 [h] EQUIPMENT - CNC : INDEX C200-4D (Siemens 840D) - Coolant tank : KNOLL * with high-pressure pump : 80 [bars] * with paper filtering unit - Automatic doors - Chips conveyor : Droite

Condition: used, TECHNICAL DETAILS - Number of axes : 10 - Number of spindles : 2 MAIN SPINDLE - Spindle power : 24 [kW] - Spindle speeds : 5000 [rpm] - Max. bar diameter : 65 [mm] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Spindle power : 24 [kW] - Spindle speeds : 5000 [rpm] - Max. bar diameter : 65 [mm] - C axis indexing precision : 0.001 [°] - Travel : 390 / 600 [mm] TURNING-MILLING SPINDLE - X stroke : 350 [mm] - Y stroke : ± 80 [mm] - B Axis stroke : 270 [°] - B axis indexing precision : 0.001 [°] - Tool type : HSK-T40 - Spindle speeds : 18000 [rpm] - Spindle power : 11 [kW] - Fixed tools on milling electrospindle : 6 x VDI25 LOWER TURNING-MILLING SPINDLE - Y stroke : ± 80 [mm] - B Axis stroke : 270 [°] Kedjv Ig Avjpfx Abnsdr - B axis indexing precision : 0.001 [°] - Tool type : HSK-T40 - Spindle speeds : 18000 [rpm] - Spindle power : 11 [kW] - Fixed tools on milling electrospindle : 6 x VDI25 TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 80 - Tool exchange time : 4.5 [sec] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 68 [kW] WEIGHT & DIMENSIONS - Machine height : 2500 [mm] - Machine weight : 11000 [kg] MACHINE HOURS - Spindle hours : 19781 [h] - Number of turning-milling spindle hours : 9713 [h] EQUIPMENT - CNC : Siemens Sinumerik 840D SL - Coolant tank * with high-pressure pump * with paper filtering unit * Coolant through spindle - Chips conveyor - Spindle cooling unit - Parts catcher

Condition: used, Year of construction: 1998, turning diameter 200 mm turning length 400 mm control Siemens type C 200-4 840 C spindle passage 65 mm Tool changer 2 x14 Pos. Kdodjyqvygepfx Abnor live tooling 2x Revoler weight of the machine ca. 4 t Main and counter spindle 3-jaw chuck with numerous jaws Hainbuch collets Many tool holders Various driven tools Bar loader "Index MBL" Chip conveyor with coolant unit Complete set of spindle reducers etc. see photo The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, TECHNICAL DETAILS - number of spindles : 6 independent - bar clearance : 32 [mm] - maxi spindle speed : 6 300 [rpm] Kdjdeuhangepfx Abnjr - machine equipped with 32 numerical axes - slide unity 1.1 : X and Z axes controlled by CNC - slide unity 1.2 : fixed X axis, Z axis controlled by CNC - slide unity 2.1 : fixed X axis, Z axis controlled by CNC - slide unity 2.2 : X and Z axes controlled by CNC - slide unity 3.1 : X and Z axes controlled by CNC - slide unity 3.2 : fixed X axis, Z axis controlled by CNC - slide unity 4.1 : X and Z axes controlled by CNC - slide unity 4.2 : fixed X axis, Z axis controlled by CNC - slide unity 5.1 : fixed X axis,Z axis controlled by CNC - slide unity 5.2 : X and Z axes controlled by CNC - slide unity 6.1 : X and Z axes controlled by CNC - slide unity 6.2 : X and Z axes controlled by CNC - counter-spindle in position 6.1 EQUIPMENT - INDEX C200-4 (Siemens SINUMERIK 840D) - Simple NCU - IEMCA SIR 32/33/P bar loader - Coolant tank with HP pump - KNOLL chips conveyor - RIEDEL cooling unit - Parts catcher with conveyor in position 6.1 - Cross rilling device in position 3.1 et 4.1

Condition: used, TECHNICAL DETAILS - number of spindles : 6 independent - bar clearance : 32 [mm] - maxi spindle speed : 6 300 [rpm] - machine equipped with 32 numerical axes - slide unity 1.1 : X and Z axes controlled by CNC - slide unity 1.2 : fixed X axis, Z axis controlled by CNC - slide unity 2.1 : fixed X axis, Z axis controlled by CNC - slide unity 2.2 : X and Z axes controlled by CNC - slide unity 3.1 : X and Z axes controlled by CNC - slide unity 3.2 : fixed X axis, Z axis controlled by CNC - slide unity 4.1 : X and Z axes controlled by CNC - slide unity 4.2 : fixed X axis, Z axis controlled by CNC - slide unity 5.1 : fixed X axis, Z axis controlled by CNC - slide unity 5.2 : X and Z axes controlled by CNC Kodpfouhaxlox Abnodr - slide unity 6.1 : X and Z axes controlled by CNC - slide unity 6.2 : X and Z axes controlled by CNC - counter-spindle position 6.1 EQUIPMENT - INDEX C200-4 control (Siemens SINUMERIK 840D) - Simple NCU - IEMCA SIR MS32/33/P bar loader - Coolant tank with HP pump - KNOLL chips conveyor - Parts catcher with conveyor in position 6 - Cross drilling device in position 3.1 et 4.1

Condition: used, TECHNICAL DETAILS - Number of axes : 6 - Number of spindles : 1 MAIN SPINDLE - Spindle nose : A2-5 - Spindle power : 20/27 [kW] - Spindle speeds : 6300 [rpm] - Max. bar diameter : 42 [mm] - Max. diameter on bench : 200 [mm] - Max. chuck diameter : 160 [mm] - C axis indexing precision : 0.001 [°] UPPER TURRET * Number of positions : 12 * Number of motorized positions : 12 - Tool type : VDI 25 * Live tools speed : 6000 [rpm] * Live tools power : 8 [kW] LOWER TURRET - Number of positions : 12 - Number of motorized positions : 12 - X/Z stroke : 110/800 [mm] - Tool type : VDI 25 - Live tools speed : 6000 [rpm] - Live tools power : 5,5 [kW] TAILSTOCK - Tailstock type : Numérique POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 43 [kW] WEIGHT & DIMENSIONS - Machine floor space : 4435x1950 [mm] - Machine height : 1930 [mm] - Machine weight : 7500 [kg] Kjdpfxouhacdo Abnjdr EQUIPMENT - CNC : INDEX C200-4D - Linear scales - Coolant tank * with high-pressure pump : 80 [bars] * with paper filtering unit - Chips conveyor - Oil mist extractor - Chuck 3 jaws
