Condition: used, - Angular head with 4 different quick-change inserts - one SK 50 collet - Mounting wrench for mounting the tools - SK50 collet according to DIN 69871 Gkedpfx Aswxw R Dsk Ueb Includes test report.

Condition: used, Wohlhaupter Alu-Line ø 425 - 505 mm boring tool including SK 50 holder Godpfx Ajwxw Icsk Uokb

Condition: reconditioned (used), Tool milling machine: Deckel Type: FP 2 Condition: Geometrically overhauled, used Gkjdpfx Akezcdarj Ueb Year of manufacture: 1980s, geometrical overhaul in 2026 Technical data: Travel distances X/Y/Z, approx.: 400 / 200 / 400 mm Tool holder: S20 Spindle speeds: (18) 40 - 2000 min-1 Feed rates: (18) 8 - 400 mm/min Head swiveling: 180° Equipment: - Geometry report - 3-axis digital display, new - Spindle protection device with limit switch, new - Machine light, new - Horizontal and vertical spindle - Fixed angle table - Coolant system - Chip tray

Condition: used, 2 x radial tool holders VDI 40, each: 400 Euro net. 2 x axial tool holder VDI 40, each: 250 Euro net. Gsdpfxotz U Iio Ak Uskb

Condition: new, Universal tool milling machine according to DIN 8615. The torsion-resistant machine stand made of MEEHANITE® quality casting and the high-precision, hardened and ground guides in all axes guarantee high precision and durability. With the 3-axis digital display, all values can be called up directly and with the user-friendly control panel on the jib arm (OPTION), it can be positioned individually. Clamping area of the fixed angle table: 900 x 500 mm Max. Workpiece weight: 360 kg Horizontal and vertical tool holder: ISO 40 Main spindle motor power / 100% ED: 3.75 kW Power feed motors X/Y/Z-axis: 1.0 / 1.0 / 1.5 kW Total connected load: 7.4 kVA Speed range: 40 - 3800 1/min Speed steps: 18 Manual drill sleeve stroke: 120 mm Swivel range: +/- 90 Travel X (automatic/manual): 600 mm Travel Y (automatic/manual): 460 mm Z travel (automatic/manual): 380 mm Feed range, infinitely variable X/Y/Z: 10 - 650 mm/min Rapid traverse: 1000 mm/min Dimensions LxWxH, approx.: 1850 x 1650 x 1900 mm Weight, approx.: 1780 kg Equipment: - 3-axis digital display (e.g. FAGOR® Innova), with various comfort functions, on user-friendly swivel arm (OPTION) - DC servo motors for all X/Y/Z axes, e.g. from DELTA® - Spindle concentricity max. 0.005 mm, incl. test report to DIN 8615 (SKF®/NSK® roller bearings) - Spring-loaded safety handwheels in all axes, e.g. from GANTHER® - Torsion-free machine bed made of MEEHANITE® quality casting Gksdpouxt N Isfx Ak Usb - High-precision, hardened and ground guideways in all axes with TURCITE®-B coating - Backlash-free HIWIN® precision ball screws in all axes - Electrical overload protection in all axes - Multi-adjustable spindle protection device secured via micro limit switch - Automatic interval central lubrication - Drilling quill - Swivel-mounted control panel on extension arm (approx. 1,600 mm) (OPTION) - Hydraulic tool clamping - SIEMENS®, BALLUFF® electrical equipment - Coolant device - Horizontal device - LED machine light - Spacious chip collection tray - Test report according to DIN 8615 - Operating tool - Operating instructions, spare parts list, incl. electrical circuit diagrams etc. in German - CE

Condition: used, Year of construction: 1998, STIMIN Oradea FUS-22-2M Universal Tool Milling Machine Universal Tool Milling Machine STIMIN Oradea Type/Model: FUS-22-2M Condition: Used Year of manufacture: 1998 Technical data: Travel, X-axis: 300 - 320 mm Travel, Y-axis: 240 - 270 mm Gkedpfxezxhnde Ak Ueb Travel, Z-axis: 300 - 310 mm Tool holder: SK 40 / ISO 40 Spindle speed: 45 - 2,240 rpm (in 18 steps) Quill stroke: 60 mm (manually adjustable) Clamping surface: 670 x 320 mm Max. table load: approx. 75 - 150 kg (depending on table design) Feeds (X/Y/Z): 12.5 - 630 mm/min Rapid traverse: approx. 1,200 mm/min Spindle motor power: 1.5 kW - 2.0 kW Total connected load: approx. 2.5 – 3.0 kW (400 V / 50 Hz) Space requirement (L x W x H): approx. 1,200 x 1,100 x 1,620 mm Inquiry item: Transportation costs will be provided in an individual offer.

Condition: used, Year of construction: 1997, Hermle UWF 1202 S CNC machining center CNC machining center Hermle Type/Model UWF 1202 S CNC control Heidenhain TNC 426 Condition Used Year of manufacture 1997 Technical data Travel X / Y / Z axis: 850 mm / 630 mm / 500 mm Spindle speed: 20 - 4,200 rpm (stepless) Table dimensions: 1,200 x 550 mm Rapid traverse (X/Y/Z): 10 m/min Machine weight approx.: 5,500 - 6,000 kg Installation dimensions (L x W x H) approx.: 3.3 x 2.24 x 2.24 m Accessories: Gjdpfx Akszx Umto Uekb - approx. 85 collets SK 40 - extensive milling cutter assortment - swivel head - measuring probe - zero-setting device - set of parallel blocks - Almatic machine vise - dividing head - collet chuck Röhm ZG250 Inquiry item: Transportation costs in a separate quotation.

Condition: new, Technical Data: Fixed angle table: Clamping surface of the fixed angle table: 800 x 400 mm Max. table load: 200 kg Working spindle: Tool holder, horizontal and vertical: ISO 40 Power of the main drive motor / 100% duty cycle: 2.2 kW Vertical milling head: Speed range, stepped: (12) 50 - 2000 rpm Drill quill, stroke: 100 mm Swivel range: +/- 90° Travel distances: X-axis, automatic/manual: 385/400 mm Y-axis, automatic/manual: 185/200 mm Z-axis, automatic/manual: 365/380 mm Feeds: Feed range: 0-650 mm/min Number of feeds: continuously adjustable Rapid traverse: 1000 mm/min Features: - Machine accuracy according to DIN 8615 - 3-axis digital displays FAGOR® Innova (option) - Spindle runout max. 0.005 mm, incl. test report according to DIN 8615 (roller bearings SKF®/NSK®) - Vertical milling head can be swiveled for horizontal milling (without disassembly) Gkodpfx Aked R S Ndo Ueb - All critical parts of the machine, e.g. machine frame, table, milling head, housing, etc., are made of stress-relieved MEEHANITE® quality cast iron (FC 30) and are extensively ribbed to provide the machine with maximum stability and working accuracy. All guide rails are coated with TURCITE®-B - All machined surfaces in the working area, such as guide rails, table surfaces, T-slots, etc., are hardened and precision-ground. - The powerful drive transmits the power of the main motor to the gearbox via belts. - All axes have their own DC servo motors. These enable sensitive, stepless adjustment of the feed speed. Standard equipment: - DC servo motors for all axes X/Y/Z, incl. electromagnetic brake - Fixed box table - Original Ganter Norm® safety handwheels - Chip collection tray - Backlash-free HIWIN® precision ball screws in all axes X/Y/Z - Gearbox for main spindle - Safety device according to CE or better: - Spindle guard with several micro-switches, adjustable in several steps (enclosure available as an option) - Two emergency stop pushbuttons (1 x machine frame, 1 x control panel) - Mechanical Ganter Norm® safety handwheels in all axes - Electromagnetic spindle brake (for immediate spindle stop) - Electrical overload protection for all axes - Electrical equipment SIEMENS®, BALLUFF® - Braking system prevents the table from dropping - Three reducing sleeves SK 40 to MK 1, 2, 3 - Collet chuck with holder according to DIN 2080 incl. collet set (Ø 6, 8, 10, 12, 16, 20, 25 mm) - Draw-in thread spindle - Horizontal milling arbor (Ø27 mm) - Automatic central lubrication - Lamellar stainless steel cover for the Z-axis guide rail in the working area - Machine light - Coolant system integrated in the machine base - Test report according to DIN 8615 - Operating tool - Machine according to CE - Operating manual, parts list, incl. electrical wiring diagrams, etc.

Condition: used, x-travel 400 mm y-travel 315 mm z-travel 400 mm control Dialog 4 spindle tunring speed 3.150 U/min In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice and errors. Godpfezz S Rnsx Ak Uekb Prior sale is reserved.

Condition: used, Year of construction: 1984, x-travel 300 mm y-travel 160 mm z-travel 340 mm spindle taper ISO 40 digital readout 3 Achsen HEIDENHAIN spindle turning speed range 40 - 2000 U/min quill stroke 60 mm feeds -stepless- 5 - 500 mm/min table-size 600 x 210 mm rapid traverse 1200 mm/min power capacity 1,6 - 2,0 kW table load 200 kg voltage 400 V weight of the machine ca. 800 kg dimensions of the machine ca. 1,15 x 1,15 x 1,65 m electric cabinet 0,60 x 0,35 x 0,90 m !!! ATTENTION !!! EXCELLENT CONDITION !!! This machine comes from a vocational school! Gjdpjzz S Duefx Ak Uekb - Serialä-No.: 2102-2445 - 3-axis active digital display HEIDENHAIN TNC 116 - Rapid traverse - Machine light

Condition: ready for operation (used), functionality: fully functional, total height: 1,840 mm, total length: 1,700 mm, total width: 1,750 mm, type of input current: three-phase, overall weight: 1,850 kg, travel distance X-axis: 490 mm, travel distance Y-axis: 130 mm, travel distance Z-axis: 115 mm, grinding spindle motor power: 2,200 W, input voltage: 400 V, spindle nose: HSK 63, Tool grinding machine EWAG RS15 TECHNICAL CHARACTERISTICS: Gjdpfx Akezz Rtus Uokb Stroke X axis: 490 [mm] Stroke Y axis: 130 [mm] Stroke Z axis: 115 [mm] Grinding spindle motor power: 2.2 [kW] B axis swivelling stroke: 260 [°] Workpiece spindle nose: HSK 63 Variable power feeding: Yes Digital read out: RSF-Elektronik Number of axes Digital Read Out: 3 Lubrication tank capacity: 100 [l] Centralized lubrication: Oui Supply voltage: 400 [V] Dimensions: 1700 x 1750 x 1840 [mm] Weight: 1850 [Kg] Machine visible under power in our premises by appointment. Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed. Machine for sharpening tools, milling cutters, taps and drills. Machine similar to brands Blohm, Elb, Ewag, Favretto, Fenix, Ger, Jones & Shipman, Jung, Karstens, NUMAFFUT, Okamoto, Okuma, Saacke, SMP, Studer, Vollmer, Walter; also consider cylindrical or surface grinding machines, lathes, machining centres and milling machines.

Condition: used, #200112 Trumpf OW200/S (16-piece) 86.00° R4.00 / H=218.30 / 800 kN/m Segment lengths: 2x 25 mm 1x 30 mm 1x 40 mm 2x 100 mm (reduced body 70 mm, 1x left / 1x right) 5x 200 mm 5x 300 mm Total length: 2820 mm ----- #200113 Trumpf OW201/S (18-piece) 86.00° R1.00 / H=220.00 / 800 kN/m Gjdoy Anydepfx Ak Uskb Segment lengths: 2x 25 mm 1x 30 mm 1x 35 mm 1x 40 mm 1x 45 mm 1x 50 mm 3x 100 mm (2x reduced body 70 mm, 1x left / 1x right) 1x 200 mm 7x 300 mm Total length: 2850 mm ----- #200117 Trumpf OW200/S (18-piece) 86.00° R1.00 / H=220.00 / 800 kN/m Segment lengths: 18x 100 mm Total length: 1800 mm ----- #200118 Trumpf OW/S (28-piece) 86.00° R1.00 / H=220.00 / 400 kN/m Segment lengths: 4x 25 mm 2x 30 mm 1x 35 mm 2x 40 mm 1x 45 mm 1x 50 mm 4x 100 mm 5x 200 mm 8x 300 mm Total length: 4170 mm ----- #200119 Trumpf OW200/S (25-piece) 86.00° R4.00 / H=218.30 / 800 kN/m Segment lengths: 2x 25 mm 1x 30 mm 1x 35 mm 1x 40 mm 3x 100 mm (2x reduced body 70 mm, 1x left / 1x right) 10x 200 mm 7x 300 mm Total length: 4555 mm

Condition: used, Year of construction: 2015, Voltage: 24 V DC Current: 2 A Gkedpozz Hkcefx Ak Ueb Weight: 135 kg Max. measuring diameter: 400 mm Max. measuring radius: 200 mm Max. measuring height: 600 mm Axis resolution X: 1 µm Axis resolution Z: 1 µm Spindle runout: < 4 µm Tool holders: ISO / BT / HSK / CAPTO / VDI Camera sensor: CMOS Sensor area: 6.4 × 6.4 mm Magnification: approx. 30× Footprint: approx. 1200 x 600 x 2000 mm

Condition: excellent (used), functionality: fully functional, total height: 1,760 mm, total length: 1,100 mm, total width: 800 mm, type of input current: three-phase, grinding wheel diameter: 125 mm, overall weight: 520 kg, input voltage: 400 V, spindle nose: ISO 40, Tool grinding machine DECKEL S11 TECHNICAL CHARACTERISTICS: Grinding wheel diameter: 125 [mm] Workpiece spindle nose: ISO 40 Paper filtration unit: No Supply voltage: 400 [V] Total power required: 2 [kVA] Dimensions: 1100 x 800 x 1760 Weight: 520 [Kg] EQUIPMENT INCLUDED: x1 universal index head - Part N°: 255X0X x10 dividing inserts for universal index head x1 tailstock with transverse adjustment - Part N°: 2621000 x1 tailstock with vertical adjustment - Part N°: 2624000 x1 swivel bracket assembly - Part N°: 2626000 x1 universal wheel dresser - Part N°: 2628000 x1 universal setting gauge - Part N°: 2570000 x1 spiral and relief grinding attachment - Part N°: 2580000 x1 relief grinding slide - Part N°: 2673000 x1 machine vice - Part N°: 2635000 x1 opto-electronic measuring unit with miscroscope - Part N°: 2650012 Gksdpfx Akezz Hk Nj Ueb x2 digital readouts RSF-Elektronik x1 radius grinding attachment - Part N°: 2601X00 x1 LED lamp x3 feet pads Machine visible under power in our premises by appointment. Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed. Machine for sharpening tools, milling cutters, taps, and drills. Similar to brands such as Blohm, Elb, Ewag, Favretto, Fenix, Ger, Jones & Shipman, Jung, Karstens, NUMAFFUT, Okamoto, Okuma, Saacke, SMP, Studer, Vollmer, Walter. Also see cylindrical or surface grinders, lathes, machining centers, and milling machines.

Condition: ready for operation (used), Montronix TS100 Tool Monitor, serial number: T1000022A0964, used, shows normal signs of wear, 100% functional, scope of delivery as shown in the photos. Gksdji Eb R Ajpfx Ak Ueb

Condition: ready for operation (used), Montronix TS100 Tool Monitor, Serial No.: T1000025A0991, used, shows normal signs of wear, 100% functional, scope of delivery as shown in the photos. Gksdpsi Eb R Hjfx Ak Uob

Condition: good (used), Year of construction: 1984, Grinding wheelhead: Gkjdpfovmpabex Ak Usb - motor power : 2,2 kW - spindle speeds : 1 000 - 8 000 rpm - spindle inclination (A-axis): -10° up to +27° - setting accuracy 1 min - height adjustment (Y axis) : 130 mm - stroke range (X axis) : 220 mm - oscillation stroke, steplessly adjustable during oscillation : 0-30 mm - oscillation frequency : 30/60 1/min Workhead: - radius setting (Z axis) : 0.01-50 mm - setting accuracy: 0,01 mm - retraction of slide from the grinding to the measuring position : max. 49 mm - cross table, clamping surface : 155 x 205 mm - travel X - Y : each 60 mm - maximum swivelling angle (B axis): 260° - supply voltage : 380 V - weight : 1200 kg Accessories/options: - grinding pressure variable - projector fixed in measuring position - 1 cabinet with accessories - different grinding wheels, flanges - coolant tank - documentation Under power in our warehouse.

Condition: excellent (used), SIZING-TENONING LINE, composed of the following machines: A) Loader (portal/bridge) double pick-up station "SAG" CAR MS 2000 with central motorized rollers conveyor and 2 external on-ground roller ways to in-feed the piles (stacks) of panels to the Loader. B) 1st Double-End Tenoning-sizing Machine "ULMADAN" Mod. 1136 Gedpfx Aozzzupjk Uokb C) Turning Station "SAG" Mod. Girapannelli (from lengthwise to crosswise) with double cone system. D) 2nd Double-End Tenoning-sizing Machine "ULMADAN" Mod. 1136 E) Turning Station "SAG" Mod. Girapannelli, (from lengthwise to crosswise) with double cone system. F) 3rd Double-End Tenoning-sizing Machine "ULMADAN" Mod. 1136 H) Stacker (portal/bridge) double stacking station "SAG" CAR/S MS 2000 with central motorized rollers conveyor and 2 external on-ground roller ways to out-feed the piles (stacks) of panels from the Stacker

Condition: ready for operation (used), functionality: fully functional, total height: 1,840 mm, total length: 1,700 mm, total width: 1,750 mm, type of input current: three-phase, overall weight: 1,850 kg, travel distance X-axis: 490 mm, travel distance Y-axis: 130 mm, travel distance Z-axis: 115 mm, grinding spindle motor power: 2,200 W, input voltage: 400 V, Tool grinding machine EWAG RS 15 TECHNICAL CHARACTERISTICS: Stroke X axis: 490 [mm] Stroke Y axis: 130 [mm] Stroke Z axis: 115 [mm] Grinding spindle motor power: 2.2 [kW] B axis swivelling stroke: 260 [°] Workpiece spindle nose: HSK 63 Variable power feeding: Yes Digital read out: RSF-Elektronik Number of axes Digital Read Out: 3 Gsdpszzyrtofx Ak Ujkb Lubrication tank capacity: 100 [l] Centralized lubrication: Yes Supply voltage: 400 [V] Dimensions: 1700 x 1750 x 1840 [mm] Weight: 1850 [Kg] Machine visible under power in our premises by appointment. Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed. Machine for sharpening tools, milling cutters, taps and drills. Machine similar to brands Blohm, Elb, Ewag, Favretto, Fenix, Ger, Jones & Shipman, Jung, Karstens, NUMAFFUT, Okamoto, Okuma, Saacke, SMP, Studer, Vollmer, Walter; also consider cylindrical or surface grinding machines, lathes, machining centres and milling machines.

Condition: good (used), Year of construction: 2004, functionality: fully functional, Technical details x-travel 620 mm y-travel 420 mm z-travel 400 mm Control Heidenhain TNC 410M table surface area 800 x 400 mm tool taper ISO 40 Gkedpfx Aozzw A Ajk Ujb spindle turning speed - stepless 50 - 4000 U/min main drive motor 5,5 kW weight of the machine ca. 2,1 t Additional information * CNC control HEIDENHAIN TNC 410M * Coolant equipment * Machine lamp

Condition: used, gebraucht 9313A prompt, Zwischenverkauf v 2900 € 1 4080 mm MINT CONDITION Gksdpsyukacjfx Ak Uob manual clamping

Condition: like new (used), Year of construction: 2023, functionality: fully functional, For sale: 4 x Tacchella PROFLEX C3 / PROFLEX 3 C1 LR/R-B CNC external/internal cylindrical grinding machines. All four machines are from the year 2023 and are equipped with Siemens SINUMERIK ONE CNC controls. Gkedpfx Akezdv S Is Usb They feature hydrostatic guides, a CNC B-axis, an LR/R-B grinding head configuration, Marposs measuring/process monitoring, AE gap crash monitoring, grinding wheel balancing system, workpiece spindle, tailstock, external and internal cylindrical grinding capabilities, and automatic workpiece handling. The machines are designed for medium to large-sized workpieces. According to the PROFLEX C3 parameters, the maximum grinding diameter is up to 600 mm, the maximum workpiece weight between centers is up to 400 kg, the distance between centers is 800 – 2,100 mm, and the maximum grinding length is 400 – 1,600 mm. Clean note in the offer:

Condition: used, Year of construction: 2012, Technical details: Number of drawer: 48 Shelf width: 160 shelf length: 600 shelf height: 60 mm electrical connection: 230V / 50Hz / 16A V / Hz. dimensions L x W x H: 0,8 x 0,72 x 1,7 m Tool dispensing system - Warehouse management system Selection through automatic processes Electronic access to definable drawers via warehouse management software -Optimized storage and management of tools Storage above the drawers, rubberized, WxD: 720 x 190mm Gkedju Nkz Aopfx Ak Ueb Equipment: Computer HP pro monitor and input device Hand scanner *

Condition: used, functionality: fully functional, Ferwood code: RU0009932 - Manufacturer code: 4-014-12-0207 - Condition: Used - Functionality: Fully operational - Compatible machine: - If interested, we offer an overhaul service. Please contact us. 1KG - 20X20X20 Gsdpsyk Edusfx Ak Uokb

Condition: used, functionality: unexamined, Ferwood Code: RU0010261 - Manufacturer Code: 2-055-05-1680 - Condition: Used - Functionality: Untested - If interested we offer a revision service, contact us. Gedpfx Aev Izy Nsk Ujkb
