Edge banders Homag OPTIMAT KAL310/5/A3/S2 2008

Homag OPTIMAT KAL310/5/A3/S2

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, input voltage: 400 V, total height: 2,200 mm, total length: 7,500 mm, total width: 1,500 mm, overall weight: 4,000 kg, TECHNICAL DETAILS Overall height: 2,200 mm Overall length: 7,500 mm Overall width: 1,500 mm MACHINE DETAILS Weight: 4,000 kg Year of manufacture: 2007 Voltage: 400 V Power consumption: 46 A Fuse: 63 A Transport dimensions: 7,500 mm x 1,500 mm x 2,200 mm (L x W x H) Transport weight: 4,000 kg EQUIPMENT Tools included: Yes (for 1st, 3rd, 4th, 5th, 7th, and 8th unit) Tools included: No (for 6th unit) Bljdpfx Asy Akytok Eog

Condition: used, machine/vehicle number: 007289, X axis working area: 3200 mm Y axis working area: 900 mm Main Electrospindle power: 4.5 KW Number of controlled axes: 3 axes Total number of drilling spindles: 16 Bjdpowukyqjfx Ak Ejlg

Condition: refurbished (used), Year of construction: 2024, Manufacturer: Elumatec Type SA/ SAS 142 Overhaul year: 2024 Saw blade max. carbide: 500 mm Drive power saw motor: 4 KW Saw motor speed: 2800 min-1 Cutting speed saw blade 500 mm: 4400 m/min Saw height control: infinitely variable, fully electronic Working range square 90° max.: 130 x 130 mm Working range flat: 90° max.: 190 x 130 mm Working range round: 90° max.:150 mm Pneumatic feed length: 5-560, 10-1120 mm Compressed air connection, on site 6 bar Weight(saw)approx.: 800 kg Dimensions LxWxH (saw)approx.:2900mm x 1400mm x 1500mm Installation area LxW: 2900mm x 1400mm Additional description Elumatec SA/ SAS 142 4KW Retrofit Elumatec SA 142 4KW Retrofit Fully automatic sawing machine for non-ferrous metal and plastic After completion of the retrofit, the machine is in mint condition, both technically and visually. The machine will be overhauled in our company at the customer's request. Among other things, the following points were renewed: - Conversion to Siemens S7 PLC control - Conversion to Siemens HMI control panel - New electrical components - New pneumatic lines - Maintenance or replacement of all pneumatic cylinders and valve terminals - Maintenance of minimum lubrication system - Replacement of general wear parts - Overhaul of the cab Warranty: Unless otherwise agreed, we provide a 6-month warranty on all parts overhauled or replaced by us. Working time and wearing parts are excluded from the warranty. Optional: - Extension of the sawing area to flat 90° max.: 300 x 120 mm - Splitting extension (for a high-quality cut surface without return marks) - Servo-controlled material feed Blodjuiy Nyepfx Ak Eog - Saw blade feed Servo-controlled - Mass clamping device Feed vice - Delivery and installation on your premises - Training of your employees

Condition: excellent (used), Year of construction: 2017, functionality: fully functional, cutting height (max.): 90 mm, cutting width (max.): 3,800 mm, saw blade diameter: 380 mm, overall weight: 4,400 kg, cutting length (max.): 3,800 mm, main saw diameter: 380 mm, Beamsaw SIGMA IMPACT 90 (SCM Group) suitable for furniture panels precize cutting by one or more panels overlapped. Manufacturer: SCM Group Model: Sigma Impact 90 Production year: 2017 Cutting width: 3.800 mm Cutting depth: 3.200 mm Max. cutting height: 90 mm Front tables (air cushion): 1x 2.500x600mm, 3x 2.500x600mm Machine basement with air-cushion. Max. main blade diameter: 380 mm Scorer diameter: max. 300 mm PUSHER: brushless motor, max. speed 120 m/min ! SAW CARRIAGE: brushless motor, max. speed 150 m/min ! THK linear guides for the saw carriage movement. THK linear guides for the PUSHER movement. Automatic centralized lubrication of THK linear guides. Hi-Tronic kit: - main motor 15 kW (mode S6) - vertical movement of main and scoring blade by price ball-screws - optimized stroke of the main blade - electronic scorer adjustment in 2 axis (vertical, horizontal) - grooving with the main blade (electronic depth adjustment) - postforming cuts - window cut outs (blind cuts) - AKE flange for main and scoring blade Quantity of clamps (grippers): 10 pcs (maximum) Automatic exclusion of the clamp acting on the panels edge (up to 800 mm width). Start/stop pedal. Bljdpfx Akex Nc Ayo Eog Label printer. Control SW: WINCUT Optimalisation program: OTTIMO PERFECT CUT TOP (1x HW key) Control PC Eye-S: Windows + LCD touch screen 21" Air conditioning device for the electric box. Panel´s dimension automatic measuring. Laser line for the visualisation of the cutting line. Automatic double side aligner - motorized (60-2.200 mm). Machine stat: fully working Possibility to see in actuall production. Availability: cca April 2026

Condition: used, machine/vehicle number: 008161, Type of edging: Thin edge, Thick edge Gluing System: EVA Hotmelt, PUR Premilling Unit: yes Corner Rounding Unit: yes Max feed speed: 14 m/min Bsdpfox A Tlcsx Ak Eslg Maximum panel thickness: 60 mm Operating Units: 6 nr

Condition: reconditioned (used), Double-side Sizing-Milling & Edge Banding - First (1st) machine in a line Edges (band in rolls) thickness (Min/Max) mm 0,3 / 3 Panels thickness (min/max) mm 8 / 45 Working width (min/max) mm 236 / 1300 Numerical Control /Software ICOS Open Adjustable feeding speed (m/min ) 10 / 50 Without Transmission bar (Master & Slave system) Safety and sound-proof enclosures/cabins SIZING PART (for each side): Spraying unit (Anti-sticking liquid) Milling Unit (vertical Joint Trimmers) 08. 0555 max. 3° (2 x 1 kW) Free space EDGE-BANDING PART (for each side): Glueing Unit (Hot Melt Glue + Quick Melt system) 04.1570 Band Pressure zone Edge coils supporting unit (reels N°) 6 Rough Trimming unit 08. 0555 (2 x 1 kW) max. 3° Fine Trimming unit 08. 055 (2 x 0,66 kW) 30° + 30 m/min Glue scraping unit 08.517 Blodjdh Tfgspfx Ak Eog Spraying Unit (for polishing liquid) Buffing unit 08.617-2 (2 x 0,18 kW) Free space

Condition: excellent (used), Year of construction: 2017, functionality: fully functional, power: 7 kW (9.52 HP), input voltage: 400 V, input frequency: 50 Hz, Equipment: documentation/manual, OPTIMAT BHX055 Bodpfx Akoyvh Dps Eslg

Condition: used, Year of construction: 2008, POWER CONTROL PC 20+ Panel height (mm) 60 PVC-ABS edge thickness (mm) 3 Solid wood edge thickness (mm) 12 Feed speed 20 m/min Manual infeed guide Pre-trimming unit EVA glue application and pre-melting unit Edge holder plate End trimming unit Two-motor overlapping trimming unit Two-motor staggered chamfering unit with NC adjustments Two-motor rounding unit Edge scraper unit Glue scraper unit Brush unit Bodpow Db Rfsfx Ak Eolg

Condition: used, Year of construction: 2016, Angular panel saw with automatic pre-loading and twin pusher system for optimised cutting Osi Plus Numerical Control Os Labelling labelling machine with on-board graphic labelling with part drawings Label printing management software Optiplanning Cutting Optimizer Cutting length mm 4500 Cutting width mm 2200 Blade projection 95 mm Motorized rollers for lateral loading on lifting table 4500 x 2200 mm. The translation speed is 10.8 m\min (50hz) - 13.1 m\min (60hz) Automatic recognition of the lost panel (martyr panel) based on the thickness specified in the machine data Low battery stop Automatic side loading buffer. Includes: perimeter nets, double photocell, push-button panel, predisposition electric for the two motorized pre-rollers and the amplification of 4 rollers in place of the fork passages in the pre- intermediate roller conveyor Pre-loading side roller conveyor dim 3800 x 2200 mm with motorized rollers (height from the ground 325 mm) Inertial conveyor for conveying longitudinal trimmings for angular systems 4500 mm (total length 7295 mm) 3000 mm extension to the inertial conveyor to also convey transverse trimmings Long chute for manual conveying of cross-cut trimmings to the centralized inertial conveyor 2050 x 850 mm air curtain discharge table with wheels at the front Air generator up to 6 floors with air curtain MULTIPUSHER 2.4 system with automatic lubrication Additional mobile lateral aligner on the transverse plane. The presence of this device allows to reduce from 1830 to 1220 mm is the minimum length of the panels that must be sent for cross-sectioning. Automatic blade shaft bending detection device for angular systems (longitudinal and transversal) consisting of a sensor that detects the deflection directly on the blade shaft and a device that detects the revolutions blade directly on the spindle. Bsdpfsuc Idxjx Ak Eslg Remote cycle start button panel Automatic panel loading via rear lifting table Automatic double aligner with pneumatic cylinders Additional movable lateral aligner on the transverse plane Main blade, max diameter mm, KW 15 Scoring blade, max diameter mm, KW 2.2 Blade carriage speed 1-140 m/min. – BRUSHLESS motors Longitudinal pusher carriage speed 90 m/min. Cross pusher carriage speed 135 m/min. Double pusher carriage with 6 grippers on the longitudinal carriage + 10 grippers on the transverse carriage (8 fixed grippers + 2 on the multi-push system) Cutting system for thin panels

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, Cutting dimensions 4300x4300 mm Cutting height 95 mm Beam feed with grippers 90 m/min Cutting speed up to 150 m/min, steplessly adjustable Main motor power 13.5 kW Blodpfoylbdtsx Ak Esg Scoring saw motor power 2.2 kW Saw blade diameter 350 mm 4 air tables Extraction requirement 3800 m³/h Overall dimensions 6500x7700 mm
