Condition: excellent (used), Year of construction: 2015, operating hours: 12,068 h, functionality: fully functional, workpiece weight (max.): 20 kg, spindle speed (max.): 10,500 rpm, type of input current: three-phase, grinding wheel diameter: 200 mm, overall weight: 5,200 kg, grinding length: 350 mm, feed rate X-axis: 15 m/min, feed rate Y-axis: 15 m/min, feed rate Z-axis: 15 m/min, travel distance X-axis: 460 mm, travel distance Y-axis: 320 mm, travel distance Z-axis: 660 mm, grinding spindle motor power: 14,500 W, input voltage: 400 V, CNC Tool grinding machine WALTER Helitronic Power Diamond TECHNICAL CHARACTERISTICS: Year of manufacturing: 2015 CNC control: FANUC Series 31i-B5 Software installed: Tool Studio 2.1 R8 Colour touch screen: 15 ["] Number of axes: 5 Stroke X axis: 460 [mm] Resolution X axis: 0.0001 [mm] Stroke Y axis: 320 [mm] Resolution Y axis: 0.0001 [mm] Stroke Z axis: 660 [mm] Resolution Z axis: 0.0001 [mm] Traversing feeds X, Y and Z axes: 15000 [mm/min] Stroke A axis: 360 [°] Stroke C axis: +/- 200 [°] Resolution C axis: 0.0001 [°] Max. workpiece lenght : end face grinding: 280 [mm] Max. grinding lenght: 350 [mm] Max. grinding diameter: 320 [mm] Grinding spindle attachment: HSK-50 Max. grinding wheel speed: 10500 [rpm] Grinding spindle motor power: 14.5 [kW] Max. diameter grinding wheel: 200 [mm] Workpiece spindle nose: ISO 50 Max. part weight in part holder headstock: 20 [Kg] Working hours: 12068 [h] Coolant pump pressure: 7 [bar] Collant pump flow rate: 80 [l/min] Supply voltage: 400 [V] Total power required: 20 [kVA] Weight: 5200 [Kg] ADDITIONAL EQUIPMENT: Bdjdpfx Aks Ahpfbenoi CO2 fire extinguishing system (to be inspected by the buyer through a qualified body) A-axis for cylindrical grinding (Hollowshaft option) 8-position grinding wheel changer Electrostatic mist separator with noise silencer, DSL type AES-GAMMA 30 Hydraulic and electrical connections for automatic steady rest operation Automatic steady rest Manual tailstock Combined filtration system with paper band filter + cartridge filters, connected to a cutting fluid cooling unit 3-color signal tower light "Eco Loader" tool loader with its tool clamping system and 5 cassettes (Ø6, Ø8, Ø10, Ø12 and Ø16) E386ES tool clamping chuck with 5 collets (Ø8, Ø10, Ø12, Ø16, Ø20) Grinding wheel holders x2 electrode holders L = 25 mm x1 electrode holder L = 45 mm x5 grinding wheel holders L = 45 mm SOFTWARE: TOOLSTUDIO Standard & Advanced TOOLSTUDIO Step Tools License TOOL STUDIO PC License WALTER WINDOW MODE (P1, P2 & P3) for grinding (P51 & 52 for erosion) WALTER WINDOW MODE Package 63 for PCD drills More information upon request.

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, Tool grinding machine, Saacke, UWID: - Year of manufacture: 2007 - Software: NUM Axium - Grinding wheel changer: 8-position - Pick-up loader - Spindle power: 26 kW Bdjdpfxj Ahn Dts Aknji

Condition: excellent (used), Year of construction: 2018, operating hours: 13,617 h, functionality: fully functional, workpiece weight (max.): 20 kg, spindle speed (max.): 10,500 rpm, type of input current: three-phase, grinding wheel diameter: 150 mm, overall weight: 4,700 kg, feed rate X-axis: 15 m/min, feed rate Y-axis: 15 m/min, feed rate Z-axis: 15 m/min, travel distance X-axis: 470 mm, travel distance Y-axis: 330 mm, travel distance Z-axis: 640 mm, grinding spindle motor power: 7,000 W, input voltage: 400 V, CNC Tool grinding machine WALTER Helitronic Basic TECHNICAL CHARACTERISTICS: Bodpfx Ae Ahi Alsknedi Year of manufacturing : 2018 CNC control: FANUC Series 31i-B5 Software installed: Tool Studio 3 R2 Colour touch screen: 19 ["] Number of axes: 5 Stroke X axis: 470 [mm] Stroke Y axis: 330 [mm] Stroke Z axis: 640 [mm] Traversing feeds X, Y and Z axes: 15000 [mm/min] Stroke A axis: 360 [°] Stroke C axis: +/- 200 [°] Max. workpiece lenght: end face grinding: 280 [mm] Max. grinding diameter: 320 [mm] Max. grinding diameter with automated work table: 290 [mm] Grinding spindle attachment: NCT Grinding spindle diameter: 70 [mm] Grinding wheel speed: 10500 [rpm] Grinding spindle motor power: 7 [kW] Max. diameter grinding wheel: 150 [mm] Workpiece spindle nose: ISO 50 Max. part weight in part holder headstock: 20 [Kg] Working hours: 13617 [h] Coolant pump pressure: 7 [bar] Collant pump flow rate: 80 [l/min] Lubrication tank capacity: 350 [l] Supply voltage: 400 [V] Total power required: 20 [kVA] Weight: 4700 [Kg] More information upon request.

Condition: used, Year of construction: 1995, Suitable for regrinding and reworking of wood and metalworking tools of all kinds. Accessories: Software package 1 (cylindrical tools sharp-edged, corner and full radius), Software package 2 (conical-spiral tools sharp-edged, corner and full radius), Software package 3 (drill and step drill), Software package 16 (warming-up program), Heli-Flute & Cone (span layout calculation program for cylindrical and conical cutters), Bdjdo Ahhumjpfx Aknji Pneumatic workpiece clamping, Machine light, Measuring probe, Coolant tank 180 L. X-axis longitudinal movement: 400 mm Y-axis vertical movement: 250 mm Z-axis (transverse movement): 580 mm Z-axis (lateral movement): 580 mm C-axis swivel range: +/- 200° Workpiece holder: ISO 50 Workpiece diameter: 260 mm max. workpiece length: 270 mm Max. Workpiece length: 270 mm Grinding wheel RPM continuously adjustable: RPM. Grinding wheel drive power: 10 kW Grinding wheel speeds infinitely variable: 0-10,000 rpm. Grinding wheel diameter: Max. 200 mm Connected load: 15 kVA (400 V / 50 Hz) Dimensions W x D x H: 1960 x 2010 x 2500 mm Weight approx.: 3100 kg colour: gray RAL 7035

Condition: good (used), functionality: fully functional, Internal article number: 26102 Universal tool grinding machine Deckel S1 The machine is fully functional and can be inspected under power by arrangement in our heated warehouse, which covers an area of over 500 m². Bodpfxs Ahhtae Aknedi

Condition: good (used), functionality: fully functional, Net price: €6,800 Internal article number: 26096 Bjdpfx Ake Ahhl Nsnsdi Universal tool grinding machine Deckel S11 Includes dividing head (without Deckel brand dividing head) Includes documentation (electrical circuit diagram, operating manual, parts list) The machine is fully functional and can be inspected under power by appointment in our heated warehouse, which has over 500 m² of space.

Condition: good (used), functionality: fully functional, Internal article number: 26101 Universal tool grinding machine Deckel S11 Clamping surface of the tool slide: 500 x 180 mm Max. tool diameter between centers: 130 mm Max. tool diameter with free clamping in the universal dividing head: 620 mm Max. tool length between centers: 270 mm Grinding stroke: 190 mm Grinding stroke during helical grinding: 190 mm Transverse adjustment of the tool slide: 100 mm Vertical adjustment of the grinding head: 325 mm Longitudinal adjustment of the grinding spindle: 5 mm Coarse adjustment travel: Tool holder: 220 mm Grinding head holder: 800 mm Universal dividing head on tool slide: 330 mm Three-phase drive motor: 1.1 kW at 2800 rpm Spindle speeds, stepless: 2000 to 12000 rpm Max. cutoff wheel diameter: 200 mm The machine is fully functional and can be inspected under power by arrangement in our heated warehouse of over 500 m². Bjdpfxo Ahhius Aknodi

Condition: good (used), Year of construction: 2004, max. grinding diameter 230 mm grinding length 5x9 / 19.05x27,94 mm workpiece length 65 mm control GE Fanuc Series 160i-M Bedpfxs Ahdt No Aknsdi weight of the machine ca. 7,7 t dimensions of the machine ca. 3,8x2,6x2,3 m

Condition: good (used), Technical Specifications Type: WS11 Manufacturer: EWAG AG, Solothurn (Switzerland) Extraction System: Present (switch "Aspiration", extraction hose) Workpiece Head: With angular adjustment (angle scale) Optics: Optics or magnifying glass as shown in the photos Connection, Weight, and Dimensions Bdedpfx Ae Agpd Ioknji Power Connection: 380 V Equipment and Scope of Delivery Extraction system with extraction hose Optics or magnifying glass Accessories as shown in the photos Extraction system, optics or magnifying glass, and accessories as shown in the photos. Technical data is subject to change without notice. Errors and prior sale are reserved. The properties agreed upon in the purchase contract and the agreed scope of delivery shall be decisive.

Condition: used, Year of construction: 1991, functionality: fully functional, Equipment: rotational speed infinitely variable, Tool grinding machine Manufacturer: DECKEL, Type: S 11 Year of manufacture: 1991 Bedpo Afyq Iofx Aknedi Technical details Manufacturer: DECKEL Type: S11 Year of manufacture: 1991 Clamping area: 500 x 180 mm Max. tool diameter: between centers 130 mm, with overhanging clamping 620 mm Max. tool length: between centers 270 mm Grinding stroke: 190 mm longitudinal Transverse adjustment of the tool slide: 100 mm Vertical adjustment of the grinding head: 325 mm Longitudinal adjustment of the grinding spindle: 5 mm Spindle speed: 2,000 to 10,000 rpm, continuously adjustable Drive power of the grinding motor: 1.1 kW Total power consumption: approx. 2.2 kW Connection voltage: 400 V / 50 Hz Max. grinding wheel diameter: 125 mm Workpiece spindle mounting: SK 40 T-slots: 12 mm on the machine frame Machine weight: approx. 850 kg Dimensions: L 1.60 x W 1.10 x H 1.60 m Equipment • 5-axis adjustability • Motorized height adjustment of the grinding head • Opto-electronic measuring system with 2-axis digital display • Very large range of accessories as shown in the photos • Technical documentation All information without guarantee. A demonstration under power is possible at any time in our showroom.

Condition: good (used), Year of construction: 1988, functionality: fully functional, machine/vehicle number: 88-009-01, overall weight: 600 kg, Grinding machine by Jungner, model US-350, including cabinet with accessories – see images. Bdedpfx Ae Afnd Ajknoi

Condition: like new (used), Year of construction: 2012, operating hours: 10,422 h, functionality: fully functional, spindle speed (max.): 10,000 rpm, type of input current: three-phase, overall weight: 4,250 kg, grinding spindle speed: 1,000 rpm, grinding spindle motor power: 4 W, input current: 20 A, input frequency: 50 Hz, input voltage: 380 V, space requirement width: 1,800 mm, space requirement length: 5,000 mm, space requirement height: 2,200 mm, Equipment: rotational speed infinitely variable, ANCA FastGrind 5-axis tool grinding machine with integrated loader Year of manufacture 2012, 10 kW (spindle 3.7 kW), RN34.1 control system (replacement/update in 2019) including VOMAT coolant system with backflushing and air conditioning including various collets and grinding wheels including 5 loader pallets (3, 6, 8, 10, 12 mm) Bdedpfx Ae Adu Tboknsi This machine has performed flawlessly throughout its service life and has consistently worked reliably and precisely until the very end. The software is a pleasure to use! It is being sold only due to the closure of the business.

Condition: good (used), Year of construction: 2007, Rollomatic GrindSmart 620XS Bjdo Aba Tnspfx Aknedi Technical Data Model designation: CNC 620 XS Control system: FANUC, operator panel FANUC PANEL i Loading system: Gripper with workpiece pallets Oil mist separator: Elbaron, included in the scope of supply Accessories: Workpiece pallets and grinding wheel holders as shown in the photos Connection, weight and dimensions Electrical connection: 3 × 400 V / 50 Hz Equipment and scope of supply Elbaron oil mist separator (part of the machine) Loading system with gripper and workpiece pallets Additional workpiece pallets as shown in the photos Grinding wheel holders with grinding wheels as shown in the photos Related accessories as shown in the photos Technical specifications are subject to change without notice. Errors and prior sale are reserved. The characteristics and scope of supply agreed upon in the purchase contract shall apply.

Condition: used, Year of construction: 1995, machine/vehicle number: UWIIA/3472/95, grinding wheel diameter: 300 mm, grinding length: 400 mm, center height: 150 mm, No minimum price – guaranteed sale to the highest bidder! Loading: December 1st to December 10th. TECHNICAL DETAILS General Information Machine type: Universal CNC tool grinding machine Condition: very good Working Area Grinding diameter: max. 300 mm Grinding length: 400 mm Workpiece length: 520 mm Center height: 150 mm Distance between centers: 350 mm Grinding table stroke: 550 mm Grinding Table Table speed: 0.005–5.0 m/min Grinding Spindle Grinding spindle speed: 250 / 3,750 / 5,000 / 7,500 rpm Speed stages: 4 Grinding wheel diameter: max. 250 mm Swivel range of grinding spindle head: 11–60° Drive power of spindle motor: max. 3.0 kW Control and Axes Control: Siemens 810 G3 Axes: 4 Performance Data Total power requirement: 7.7 kW EQUIPMENT Electronic handwheel Spindle lead correction Hydraulic collet chuck FORKARDT OVERZ-BR Coolant system Automatic central lubrication Enclosure with movable viewing window at the operator station Separate control cabinet Bods Aa Aipspfx Aknodi Safety emergency stop on the control cabinet Machine light Siemens servo drives

Condition: good (used), Year of construction: 1996, functionality: fully functional, machine/vehicle number: 12-09, Used tool grinding machine Bdedpfx As Aay Dqeknoi Manufacturer: SCHÜTTE Type: WU 405 Year of manufacture: 1998 Machine No.: 12/09

Condition: used, Year of construction: 1996, total height: 2,150 mm, total length: 1,420 mm, total width: 2,010 mm, overall weight: 3,100 kg, grinding spindle speed: 6,000 rpm, travel distance X-axis: 400 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 580 mm, NC Universal 5-Axis Tool-and Cutter Grinder Walter Helitronic Power Technical details: CNC Control HMC 400 CNC X-axis movement 400 mm Y-axis movement 250 mm Z-axis movement 580 mm C-axis (table rotation) ± 200° Max diameter grinding wheel Ø 200 mm Spindle speed (grinding) 3000 / 6000 R/Min If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Bdedpfs Aawiqsx Aknji Feel free to view our other advertisements for a complete overview of our stock.

Condition: used, Year of construction: 2001, functionality: fully functional, X / Y / Z / B / C axes X / Y / Z axis travels 360 / 240 / 360 mm X / Y / Z axis rapid traverse rate 10,000 mm/min Grinding spindle speed 1000–9000 min-1 Maximum grinding wheel diameter 160 mm Grinding spindle drive motor 4 kW at 4000 min-1 Grinding spindle mount STRAUSAK taper 1:5 Maximum grinding spindle torque 7 Nm Bdsdpfx Aoz Tv Dheknei Workpiece spindle mount ISO 50 Center height 125 mm B axis: rotation range 470° B axis: maximum rapid traverse rate 4000°/min C axis: rotation range continuous C axis: maximum angular velocity 14,400°/min Smallest data input unit X / Y / Z 0.001 mm Smallest data input unit B / C 0.001° Connection, weight and dimensions Connected power 12 kW Electrical connection 3 × 400 V / 50 Hz Equipment and scope of delivery Loading device Additional accessories included as shown in the photos Loading device and additional accessories included as shown in the photos.

Condition: used, Year of construction: 2001, Strausak Fleximat 91L Technical Data Axes: X / Y / Z / B / C Travel distances X / Y / Z: 360 / 240 / 360 mm Rapid traverse rate X / Y / Z: 10,000 mm/min Grinding spindle speed: 1000–9000 min-1 Grinding wheel diameter max.: 160 mm Bsdpfsz Tc T Nox Aknodi Grinding spindle drive: 4 kW at 4000 min-1 Grinding spindle mount: STRAUSAK taper 1:5 Grinding spindle torque max.: 7 Nm Workpiece spindle mount: ISO 50 Center height: 125 mm B-axis: Swiveling range: 470° B-axis: Rapid traverse rate max.: 4000°/min C-axis: Rotation range: Continuous C-axis: Angular speed max.: 14,400°/min Smallest input unit X / Y / Z: 0.001 mm Smallest input unit B / C: 0.001° Connection, weight, and dimensions Connected power: 12 kW Electrical connection: 3 × 400 V / 50 Hz Equipment and scope of supply Loading device Related accessories as shown in the photos Loading device and related accessories as shown in the photos. Technical data is subject to change without notice. Errors and prior sale are reserved. The properties and scope of supply agreed upon in the purchase contract shall apply.

Condition: excellent (used), For sale: Professional tool grinder by HASBERG, model FSS. German-made, solid and precise construction. Bdsdpfx Aksz Smxbonoi 📊 Technical data: Manufacturer: HASBERG Model: FSS Year of manufacture: approx. 1976 Power supply: 3-phase 220/380 V Motor power: 250 W Speed: 2750 rpm 🛠 Condition: The item is used, shows normal signs of wear, and is in good technical condition. The machine is fully functional and ready for operation. 📦 Included: Set of collets (various diameters – as shown in the photos) Additional grinding wheels Accessories as visible in the photos ✅ Advantages: Very robust construction (German quality) Large set of collets (high value) Precise machining and tool sharpening Ideal for workshops, tool rooms, or production ℹ️ Additional information: The set for sale is exactly as shown in the pictures. Inspection on site possible. Shipment on a pallet or personal collection possible.

Condition: excellent (used), For sale: a professional milling cutter and drill sharpener, model PP U3. In very good condition, the device is complete and ready for use. The set includes: • a set of grinding wheels Bdedpfxjz Slf Tj Aknsi • an adjustable angle vise • a workshop lamp on a flexible arm • wrenches and fastening elements Parameters: • for sharpening cylindrical and spiral shank milling cutters • for sharpening stepped and cylindrical drills • linear speed of the wheel up to 35 meters per second • maximum noise level of 66 decibels • device weight: 41 kg A robust and stable design, ideal for precise tool machining. A reliable solution for toolrooms, CNC workshops, and machine shops.

Condition: refurbished (used), total height: 1,050 mm, total length: 850 mm, total width: 620 mm, spindle speed (max.): 2,500 rpm, type of input current: three-phase, grinding wheel diameter: 175 mm, overall weight: 350 kg, rotational speed (max.): 2,500 rpm, grinding spindle motor power: 750 W, input frequency: 50 Hz, input voltage: 400 V, year of last overhaul: 2026, warranty duration: 24 months, For sale: fully overhauled, high-precision Agathon 175-A tool sharpener Accessories included with the machine: - 2 new Diametal MD16 and D91 grinding wheels - Centralized automatic spindle lubrication - 1 articulated arm LED lamp, CCEA - 1 fixed table - 1 PET rear guard - 1 PET front guard - 1 new electrical unit, CE compliance certificate - 1 frequency converter for adjusting the spindle speed Bodpfoz R Darex Aknjdi Machine price: CHF 19,900,- (excluding VAT)

Condition: excellent (used), Amada Togu Surface Grinder Tool diameter (min.) Ø 2 Bdedpfxez R A T De Aknei Tool diameter (max.) Ø 160 Vertical traverse (mm) 200 Grinding speed: Stations A / B / C (mm/min) 0.06 Stations D / E (mm/min) 0.03 Dimensions: Length (mm) 750 Width (mm) 800 Height (mm) 1920 Weight (kg) 470

Condition: good (used), Year of construction: 2009, functionality: fully functional, Anca control system. Bdodpfx Akjz Ry Tusnei

Condition: used, Year of construction: 1978, functionality: limited functionality, year of last overhaul: 2017, We are offering this used Klingelnberg AGW 231, manufactured in 1978. It was overhauled in 2017. Manufacturer: W. Ferd. Klingelnberg Söhne Remscheid Type: AGW 231 Serial number: 3419 Year of manufacture: 1978 The machine was overhauled in 2017 and equipped with a PLC control system. However, this control system no longer functions because the memory is defective. The machine is mechanically complete and includes change gears and indexing plates. Bsdpfxoz Rx N Ij Aknsdi If you have any questions or would like more information, please do not hesitate to send us a message or call us.

Condition: used, Year of construction: 2006, Suitable for regrinding and making new wood and metalworking tools of all kinds. Accessories: Pallet loader, Quinto software, version 4.3b, Software for cylindrical cutters, Software for conical cutters, Software for hemispherical conical cutters, Software for two-flute cutters, Software for three-flute cutters, Software for hob cutters, Software for up-and-down cutters, Software for wood drills, Software for tools with an axial angle, Software for taps, Software for step drills, Software for drills, types H and S, ISO axial software, ISO spiral software, Elbaron electrostatic mist extractor, Hydraulic workpiece clamping, Renishaw measuring probe, Automatic fire-extinguishing system, Automatic centralized lubrication system, Glass scales on the linear axes, 1 loading pallet, 16 grinding wheel flanges, 4 collets, 1 collet chuck, 1 automatic 5-jaw chuck, PMH. X-axis longitudinal movement: 380mm Y-axis transverse movement: 280 mm Z-axis vertical movement: 280 mm Bdodpez Rpnhofx Aknoi C-axis swivel range: 340° A-axis rotation range: 360 ° Center height: 210 mm Workpiece holder: ISO 50 Grinding wheel diameter: Max. 200 mm Drive power grinding lockers: 7,5 kW Grinding spindle speed: stepless 0 - 9000 rpm Connected load: 29 kW (400 V / 50 Hz) Dimensions W x D x H: 1590 x 1930 x 2550 mm mass: approx. 4800 kg colour: turquoise / grey
