Tischlerei Pircher KG

Year of construction: 2012, condition: used,

Condition: good (used), functionality: fully functional, spindle mount: MK 4, Drilling capacity: 40 mm, speeds: 60 - 1600 rpm, threading device, feeds. Dkjdjz N Ex Hopfx Al Aju

Condition: good (used), Year of construction: 1991, Used Darley press brake Type EHP 50 20 15 Capacity 2050 x 50 tons Delem control system Y1, Y2, and X-axis CNC Dkedpfxez N Exge Al Aeu Includes a set of tooling

Condition: used, Year of construction: 1997, CNC lathe, cycle-controlled Manufacturer: VDF Boehringer Type: DUS 560 Year of manufacture: 1997 Control: CNC Plus Swinging diameter over bed max.: 570 mm Turning length: 1,000 mm Spindle head size 8 according to DIN 55027 Tool cross-section H/W max.: 32 x 25 mm Thread pitch: 0.1 – 400 mm Spindle speed: Gear stage 1: Speed range from 3 to 500, infinitely variable Gear stage 2: Speed range from 15 to 2,500, infinitely variable Speed: Main drive: 8,000 min⁻¹ Feed drive X: 2,000 min⁻¹ Feed drive Z: 2,000 min⁻¹ Tailstock: Arbor taper: MK 5 Dedpoz N Ew Nefx Al Ajku Tailstock movement by hand Feed rate: longitudinal max.: 10 m/min radial max.: 5 m/min automatic feeds: longitudinal + radial 0.01 – 50 Feed force max.: longitudinal 12.5 kN Main drive: 50/21 kW Voltage: 400 V / 50 Hz Total connected load: 50 kVA Accessories: Coolant pump Brinkmann 47 l/min at 0.2 bar Manual chuck Forkardt F 250 Parat quick-change tool holder Weight approx.: 4,000 kg Space requirement L/W/H: 3,150 x 1,800 x 1,800 mm 91026

Condition: used, minimum range for wine: 15,000 litres/hour Dkedpfsz N Ewvex Al Aou

Condition: good (used), Code: 0496 Brand: POR - ITALY Model: CASTORO - CE Standard Shredder for wood waste, wood industry, carpentry shops, furniture manufacturers, paper industry, footwear industry, plastics industry, and other sectors - CE Standard Technical data: Dkodpez N Ewpofx Al Aeu Automatic hydraulic release pusher Motor Hp 10 + 2 Hourly output approx. 100–150 kg Inlet opening 870 x 425 mm Electrical control panel Overall dimensions mm 1550 x 950 x 1550 h Weight kg 1000

Condition: ready for operation (used), Year of construction: 2004, operating hours: 91,012 h, functionality: fully functional, machine/vehicle number: 31-46644, The HELLER MCi 16.2 is a high-precision, CNC-controlled horizontal machining center (HMC) from the German manufacturer HELLER. The machine is designed for productive and flexible series production (e.g., in mechanical engineering or the automotive sector). Equipment: -Horizontal spindle, pallet changer with rotary table, additional 4-position pallet changer (manufacturer: RILE RSP-MC+16.2, year of manufacture: 2004, serial number: 0421635093) -2nd operator terminal, chain-type tool changer with approximately 80 positions, chip conveyor (manufacturer: Knoll 600K, coolant/lubricant processing with band filter, switch cabinet, separate cooling unit (manufacturer: BKW) Dsdpfxjz N Ewij Al Asku Control: -Siemens 840D Accessories: -Telescopic drawer cabinet (8 drawers) with attached work surface, workbench (1 door) with partition, lighting fixture Contents: various machine accessories

Condition: used, machine/vehicle number: 296510, Machine: Bortolin Kemo FOC 23/30 Carton erector FOC 23/30 Dkedpfoz N Ewcox Al Aou

Condition: used, Year of construction: 2014, functionality: fully functional, power: 315 kW (428.28 HP), pressure (max.): 10.4 bar, type of cooling: air, Equipment: refrigerant dryer, type plate available, Screw compressor Atlas Copco ZT315VSDFF Dksdpfx Aloz N Evxj Aeu Inverter and dryer integrated Year of manufacture: 2014 Total operating hours/load hours: 32,354/32,056 h Maximum pressure: 10.4 bar Delivery rate: 22.3 – 44.6 m3/min

Condition: used, Cap Maschine Dodpfxjz N Evrj Al Aoku

Condition: used, machine/vehicle number: FDU1308/2161348 001, Main Gearbox Bertolaso Capper for Servo Motor Dkjdpfez N Evlsx Al Aeu

Condition: used, Bag filter housing – 4 size #2 bags – stainless steel 304 Number of bags 4 Bag size #2 Material Stainless steel 304 Housing dimension D (mm) 530 Height H (mm) approx. 1741 Max. working pressure (bar) 6 Dkodpfoz N Evfex Al Aeu Design pressure (bar) 8 Max. working temperature (°C) 80 Inlet/outlet Ø108 flange Seal Silicone Surface Mirror polished Data source Individual drawing Dimensions and operating limits follow the assigned technical drawing. The offered material is stainless steel 304; the drawing also applies geometrically where its title block specifies a different material.

Condition: used, Bag filter housing – 2 size #2 bags – stainless steel 304 Dsdoz N Eu Ispfx Al Asku Number of bags 2 Bag size #2 Material Stainless steel 304 Housing dimension D (mm) 426 Height H (mm) 1580 Max. working pressure (bar) 8 Design pressure (bar) 10 Max. working temperature (°C) 130 Inlet/outlet DN65 flange Seal Silicone Surface Sandblasted Data source Individual drawing Dimensions and operating limits follow the assigned technical drawing. The offered material is stainless steel 304; the drawing also applies geometrically where its title block specifies a different material.

Condition: used, Bag filter housing – 1 size #2 bag – stainless steel 304 Number of bags 1 Dodpfxez N Euuo Al Asku Bag size #2 Material Stainless steel 304 Housing dimension D (mm) 204 × 2 Height H (mm) approx. 1405 Max. working pressure (bar) 6 Design pressure (bar) 8 Max. working temperature (°C) 100 Inlet/outlet 1½″ Quick Chuck Seal Silicone Surface Polished Data source Individual drawing Dimensions and operating limits follow the assigned technical drawing. The offered material is stainless steel 304; the drawing also applies geometrically where its title block specifies a different material.

Condition: used, *Filter area: 3 m2 Installed power: 2,45 kW Horizontal disk filter with manual discharge system* This filter uses the horizontal disc system, the only type able to ensure the panel is undamaged even by accidental interruptions in filtration. There is no risk to the panel even in the event of incorrect operation or power cuts. The liquid in the vessel, batching unit and pipes is filtered perfectly at the end of work using a special disc for the purpose. The special filter unit used means that cleaning can be carried out simply using a jet of water and the sped al chute supplied. Manufactured in stainless steel throughout, including the feed pump, pipes, valves and caster-mounted frame. Dkodpfx Ajz N Euhjl Aju Complete kieselgur batching system with vanable delivery piston pump and stainless steel tank with built-in electric mixer. Electric panel complete with every control and safety device required for safe, dependable operation.

Condition: used, Year of construction: 2015, Pursuit of high-speed and optimal print quality Brighter and clearer touch screen Dkedoz N Eubjpfx Al Asu Improved ink circulation block AUTO power OFF function User friendly operation

Condition: good (used), Year of construction: 1998, functionality: fully functional, overall weight: 1,650 kg, Table surface: 800 x 400 mm Travel ranges: Longitudinal travel (X): 600 mm Lateral travel (Y): 400 mm Vertical travel (Z): 380 mm Weight, approx.: 1.65 tons Dedez N Et Rjpfx Al Ajku

Condition: excellent (used), Year of construction: 2024, ENGEL DUO 36060/2700 TECH INJECTION MOLDING MACHINE Year of manufacture: 2024 Clamping force: 27,000 kN (2700 tons) Robot: ENGEL VIPER 90 CLAMPING UNIT Clamping force: 27,000 kN Mold opening stroke: 3300 mm Maximum mold opening distance: 4100 mm Minimum mold height: 800 mm Maximum mold height: 2200 mm Column spacing (H × V): 2180 × 1750 mm Platen dimensions (H × V): 2970 × 2640 mm Opening force: 770 kN Opening force with hydraulic cushion: 1600 kN Dry cycle time (EUROMAP 6): 5.6 s INJECTION UNIT Screw diameter: 190 mm L/D ratio: 25:1 Screw stroke: 850 mm Injection volume: 24,100 cm³ Theoretical injection weight (PS): approx. 21.9 kg Injection rate: 2620 cm³/s Injection pressure (regenerative mode): 1300 bar Maximum injection pressure: 1600 bar Screw speed: 85 rpm Maximum screw speed: 100 rpm Screw torque: 24,000 Nm Torque at maximum speed: 20,400 Nm Plasticizing rate (3-zone screw): 238 g/s Plasticizing rate (barrier screw): 296 g/s INJECTION NOZZLE Nozzle stroke: 1300 mm Nozzle closing force: 210 kN Djdpfx Asz N Et Dsl Aoku EJECTION SYSTEM Ejector stroke: 400 mm Ejector forward force: 420 kN Ejector return force: 420 kN HEATING SYSTEM Number of heating zones (including nozzle): 12 Installed heating power: 160.9 kW DRIVE AND HYDRAULIC SYSTEM Installed motor power: 355 kW Motor power for charging pump: 3 kW Hydraulic oil tank capacity: 3500 l COOLING SYSTEM Required cooling capacity: 66.9 kW Water consumption (supply temperature 32°C): 5.88 m³/h ADDITIONAL EQUIPMENT Linear robot: ENGEL VIPER 90 Movable / pull-out guide column Hot runner control: 160 zones Hydraulic core control: 3 + 3 Cascade control: 72 channels

Condition: used, Ausziehlänge: 1,5 - 4,5 m Dodpfx Aoz N Etwol Asku

Condition: used, Candles: 08 cartridge type: code 41 with fin end, 3 locking tab ext 222 O-ring Dksdpfxjz N Etqo Al Aeu

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: 02260002571, The Gildemeister CTX 420 Linear is a powerful and highly precise CNC universal lathe (or turning-milling center) designed for demanding series and mass production. It is primarily characterized by its linear motor technology in the X-axis, which, compared to conventional ball screws, ensures extremely high dynamics, rapid positioning, and wear-free operation. Equipment: Dkjdpez N Etkefx Al Aou -Single spindle, three-jaw chuck, 11-position tool turret, automatic tailstock, chip conveyor Control system: -Heidenhain Accessories: -Workbench, under-mounted telescopic drawer unit (7 drawers) Contents: Hand tools, analog and digital measuring instruments, indexable cutting inserts.

Condition: used, Year of construction: 2006, machine/vehicle number: XDCY003807, Bertolaso Sorting Unit Dkjdpfxjz N Etdo Al Asu

Condition: used, Year of construction: 2012, BESEL SK PD3 (2012) Dodpfxez N Er Te Al Ajku

Condition: used, Carton Libra  with Powered Conveyor Belt Dkedpfx Aljz N Er He Aju Dimensons: 0.45x0.9x0.67m

Condition: used, z.B. for Borelli Alexa / Futura screw capper Dkedsz N Ertjpfx Al Asu
