Hennig Systems GmbH

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, travel distance X-axis: 1,250 mm, travel distance Y-axis: 880 mm, travel distance Z-axis: 800 mm, controller model: TNC 426 Heidenhain, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel Range X-axis: 1,250 mm Travel Range Y-axis: 880 mm Travel Range Z-axis: 800 mm Main Spindle Max. Speed Range: 12,000 rpm Drive Power: 15 / 10 kW Max. Torque: 500 Nm Tool Holder: SK 40 Work Table Clamping Surface: 1,500 x 1,050 mm Max. Table Load: 2,500 kg Number of T-slots: 10 T-slot Width: 18 H7 mm T-slot Pitch: 100 mm Tool Changer Number of Tool Stations: 30 Max. Tool Diameter: 80 mm Nkodpeyxmmnjfx Ahvjw Max. Tool Diameter with Empty Adjacent Pocket: 160 mm Max. Tool Length: 315 mm Max. Tool Weight: 8 kg Max. Total Weight: 100 kg Feeds Rapid Traverse (X / Y / Z axis): 15 m/min Feed Rate: 10,000 mm/min MACHINE DETAILS Control Model: TNC 430 Heidenhain Total Power Requirement: 29 kW Dimensions & Weight Space Requirement: approx. 7.0 x 5.0 x 3.3 m Machine Weight: approx. 16.0 t EQUIPMENT Documentation Chip Conveyor Coolant System High-Pressure Coolant Measuring Probe (Manufacturer: Heidenhain) Internal Coolant Supply Note: The transport rigging must be arranged by the buyer!

Condition: ready for operation (used), Year of construction: 1990, functionality: fully functional, travel distance X-axis: 1,250 mm, travel distance Y-axis: 880 mm, travel distance Z-axis: 800 mm, controller model: TNC 430 Heidenhain, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel range X-axis: 1,250 mm Travel range Y-axis: 880 mm Travel range Z-axis: 800 mm Main spindle Max. speed range: 12,000 rpm Nodpfsyxmd Tjx Ahvskw Drive power: 15 / 10 kW Max. torque: 500 Nm Tool holder: SK 40 Work table Clamping area: 1,500 x 1,050 mm Max. table load: 2,500 kg Number of T-slots: 10 T-slot width: 18 H7 mm T-slot spacing: 100 mm Tool changer Number of tool stations: 60 Max. tool diameter: 80 mm Max. tool diameter with free adjacent station: 160 mm Max. tool length: 315 mm Max. tool weight: 8 kg Max. total weight: 100 kg Feeds Rapid traverse (X / Y / Z-axis): 15 m/min Feed rate: 10,000 mm/min MACHINE DETAILS Control model: TNC 430 Heidenhain Total power requirement: 29 kW Dimensions & Weight Space requirements: approx. 7.0 x 5.0 x 3.3 m Machine weight: approx. 16.0 t EQUIPMENT Documentation Chip conveyor Coolant system Tool changer Note: Transport tackle must be organized by the buyer!

Condition: good (used), Year of construction: 2018, functionality: fully functional, travel distance X-axis: 1,270 mm, travel distance Y-axis: 508 mm, travel distance Z-axis: 635 mm, spindle speed (max.): 10,000 rpm, TECHNICAL DATA - Number of axes: 3 MILLING SPINDLE SK 40 Spindle speed: max. 10,000 rpm LINEAR AXES - Travel distance X/Y/Z axes: 1270/508/635 [mm] Nsdpfx Ahoyxfklovskw - Rapid traverse speed (X/Y/Z): 35.6/35.6/35.6 [m/min] - Feed rate (X/Y/Z): 21 [m/min] - Distance from table to spindle nose: 742 [mm] TOOL CHANGER - Number of tools in magazine: 20 TABLE - Table size: 1321/495 [mm] - Max. table load: 794 [kg] ELECTRICAL SUPPLY - Supply voltage: 400 [V] - Total drive power: 30 [kW] WEIGHT AND DIMENSIONS - Footprint: 3870/2510 [mm] - Machine height: 2690 [mm] - Machine weight: 6260 [kg] MACHINE HOURS ACCESSORIES - Control: HAAS - Interface: Ethernet / RS232 / USB / PCMCIA - Teach-in programming - Electronic handwheel - Synchronized tapping - Chip conveyor

Condition: ready for operation (used), Year of construction: 2007, operating hours: 8,400 h, travel distance X-axis: 1,200 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 610 mm, controller manufacturer: HEIDENHAIN, controller model: iTNC 530, total height: 2,880 mm, total width: 3,680 mm, table load: 1,800 kg, overall weight: 9,100 kg, spindle speed (max.): 12,000 rpm, spindle motor power: 30,000 W, number of axes: 3, This 3-axis Quaser MV-204 CP vertical machining centre was manufactured in 2007. It features a working area with X-axis travel of 1200 mm, Y-axis travel of 700 mm, and Z-axis travel of 610 mm. The machine includes a robust table size of 1400 x 700 mm and a maximum table load capacity of 1800 kg. If you are looking to get high-quality milling capabilities, consider the Quaser MV-204 CP machine we have for sale. Contact us for further details. • Machine table: 1400 x 700 mm • T-slots: 6; width 18 mm; spacing 100 mm • Distance table to spindle nose: 150–760 mm • Spindle type: WEISS WB-40R • Spindle torque: 192 Nm • Tool changer: 30 positions • Utilities: compressed air 6 bar; voltage 400 V; mains fuse 63 A; connection cable cross-section 4 x 16 mm² • Usage/condition notes: • Spindle collision in 2018; spindle functions for plastics, but spindle condition should be assessed • Machine out of operation for approximately 6 months due to new purchase • Spindle hours: 8,400 Additional equipment • Coolant system with 600-liter tank • Chip conveyor • Heidenhain handwheel HR410 • Various milling chucks • Haimer shrink-fit chuck • Slimline base holder for DuoBlock • Various collet base holders (without collets) • Albrecht drill chuck • Haimer dial gauge • Complete machine documentation Njdpsyw S Diefx Ahvjkw Technical Specification Taper Size BT 40

Condition: ready for operation (used), Year of construction: 1999, Available immediately ex location: CNC Vertical Machining Center EMCO Type VMC 600 Year of manufacture: 1999 Heidenhain TNC 426 D Electronic handwheel Travel X/Y/Z: 1200/410/370 mm SK 40 Njdoyw Nbrepfx Ahvokw 24-position tool magazine Speeds up to 6,000 rpm 3 vices Weight: 4 t Price: EUR 6,500.-- plus VAT, ex location SK 40

Condition: ready for operation (used), Year of construction: 2012, travel distance X-axis: 1,500 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 800 mm, controller manufacturer: HEIDENHAIN, controller model: ITNC 530, spindle speed (max.): 18,000 rpm, number of slots in tool magazine: 40, This 5-axis LGB KX45 SQUARE FIVE 2 vertical machining centre was manufactured in 2012. It features a moving table of 1480 x 1440 mm, a Heidenhain ITNC 530 control, and a high-speed capability of 18,000 rpm with HSK 63A. Additional highlights include a chip conveyor, a Renishaw tool filler, 40 tool places, and an IKZ 40 bar with a cooling unit. For more information about this vertical machining centre, please reach out to us. Additional equipment • Electronic handwheel HR 420 • Renishaw tool filler • Cooling unit Njdpfx Ahjywvrwsvekw • MFE 28 filter unit • Laser tool measuring system Extra Information Machine still under power

Condition: new, Sale exclusively within Switzerland. X-axis travel: approx. 1500 mm Y-axis travel: 740 mm Z-axis travel: 610 mm Distance from spindle nose to table center: 125 ~ 735 mm Table size (X-direction): approx. 1600 mm Nsdpeywtpajfx Ahvjkw Table size (Y-direction): approx. 700 mm Table load capacity: approx. 1450 kg Spindle taper: BT 40 / BT 50 (optional) Spindle speed: Belt drive 10,000 rpm.

Condition: new, Sale exclusively within Switzerland. X-axis travel: 1400 mm Y-axis travel: 650 mm Z-axis travel: 610 mm Distance from spindle nose to table center: 125 ~ 735 mm Table size (X direction): approx. 1500 mm Nkodpfx Asywtncohvjw Table size (Y direction): 650 mm Table load capacity: 1000 kg Spindle taper: BT40 (BT50 optional) Spindle speed: Belt drive 10,000 rpm.

Condition: excellent (used), Year of construction: 2010, Control: Siemens 828D Travel X/Y/Z: 1300 x 710 x 610 mm Table size: 1450 x 610 mm Spindle speed: 12,000 rpm Tool magazine for 30 tools, SK 40 Nkedpsywpfwofx Ahvsw Through-spindle coolant 3D probing system

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, travel distance X-axis: 1,200 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 400 mm, controller model: Heidenhain TNC 426 PB, spindle speed (max.): 9,000 rpm, No reserve price – guaranteed sale to the highest bidder! Increased pressure to sell – exceptionally attractive offer! TECHNICAL DETAILS Travel X-axis: 1,200 mm Travel Y-axis: 800 mm Travel Z-axis: 400 mm Machine table: 1,280 x 830 mm Number of T-slots: 3x 18 H10 Spindle speed: 9,000 rpm Spindle taper: SK40 Nsdpfxoywgvto Ahvjkw Spindle power: 9 kW Spindle torque: 84 Nm Max. linear axis speed: up to 30 m/min Tool changer: 24 stations MACHINE DETAILS Control system: Heidenhain TNC 426 PB Connection data: 400 V / 50 Hz Connected load: 32 kVA Fuse protection: 3x 63 A Transport dimensions Dimensions (L x W x H): 2525 x 2440 x 2700 mm Weight: 8,500 kg + 3 additional EU pallet spaces, each 1200 x 800 x 2200 mm

Condition: used, Year of construction: 2019, x-travel 1270 mm y-travel 508 mm z-travel 635 mm control Haas table surface area 1.300 x 500 mm table load 794 kg rapid traverse 35,6 m/min turning speed range 12.000 U/min power capacity - milling spindle 22,4 kW tool taper SK 40 | no. of tools in the magazine 30 Stück weight of the machine ca. 6,0 t dimensions 3,1 x 2,1 x 2,5 m less used vertical Machining Center - chipconveyor - 4x hydr. clamping vieces 125 mm - Dual tool change arm - internal coolant - filter Nkodpeyv Ipxsfx Ahvew - cableless 3D touch probe - programmable coolant position - tool presetter

Condition: ready for operation (used), Year of construction: 1999, travel distance X-axis: 1,600 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 700 mm, total height: 2,800 mm, total width: 3,000 mm, table load: 1,500 kg, overall weight: 9,000 kg, spindle speed (max.): 10,000 rpm, spindle motor power: 11,000 W, product length (max.): 4,000 mm, number of axes: 3, This 3-axis FAGIMA FAST 160 was manufactured in 1999. It features an X-axis travel of 1600 mm, Y-axis travel of 700 mm, and Z-axis travel of 700 mm. The machine includes a table size of 1800 × 700 mm with a maximum table load of 1500 kg. If you are looking to get high-quality machining capabilities, consider the FAGIMA FAST 160 vertical machining centre we have for sale. Contact us for further details. • Table: • Size: 1800 × 700 mm • Spindle: • Torque: 75 Nm Nedpfxsyv Df Ns Ahvokw • Feed rates: • Rapid X/Y/Z: 20,000 mm/min • Cutting feed: 1 – 10,000 mm/min • Tooling: • Tool changer: 38 positions Additional information: • Machine overhauled in 2016

Condition: not inspected (used), Year of construction: 2001, functionality: unexamined, travel distance X-axis: 1,200 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 800 mm, controller model: Heidenhain TNC 426, rotational speed (max.): 8,000 rpm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS X-axis travel: 1,200 mm Y-axis travel: 600 mm Z-axis travel: 800 mm Nkodpfxsyv Ayfj Ahvsw Spindle speed: 30–8,000 rpm Spindle taper: ISO 40 Table size: 1,250 x 630 mm Workpiece weight: 1,000 kg Tool changer: 24 positions MACHINE DETAILS CNC control: Heidenhain TNC 426 Dimensions & Weight Space requirements: approx. 4.2 x 3.3 x 3.15 m Machine weight: approx. 7,500 kg

Condition: ready for operation (used), Year of construction: 2008, travel distance X-axis: 1,600 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 850 mm, overall weight: 27,000 kg, spindle speed (max.): 18,000 rpm, number of axes: 3, This 3-axis Rambaudi RF103 was manufactured in 2008. It features a maximum spindle speed of 18,000 rpm and a robust table size of 1,900 x 1,200 mm. The machine includes a tool changer with 24 positions, ensuring efficient operation. If you are looking to get high-quality machining capabilities, consider the Rambaudi RF103 vertical machining centre we have for sale. Contact us for further details. • Spindle: • Type: Electrospindle Nkedpeyvt Sfjfx Ahvsw • Tool interface: HSK-A63 • High-pressure coolant: 20 bar • Electrospindle delivered at 0 hours • Table: • Type: Fixed • Size: 1,900 x 1,200 mm • Tooling: • Tool changer: 24 positions

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, CNC Machining Center Hedelius C60S -1200 Control: Heidenhain iTNC 530 Year of manufacture: 2016 Internal machine no.: 9 Travel paths: X-axis: 1,200 mm Y-axis: 620 mm Z-axis: 520 mm Clamping area: 1,550 x 600 mm Table load: approx. 1,500 kg Spindle taper: SK 40 Nksdeyvp U Nopfx Ahvew Tool magazine: 30 positions Spindle speed: 30 - 6,000 rpm Equipment: - KM500 sieve filter system - High-pressure pump - Chip conveyor - Machine enclosure - LTA extraction system

Condition: used, Year of construction: 2004, travel distance X-axis: 1,600 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, controller manufacturer: Fanuc, overall weight: 9,000 kg, table length: 825 mm, table width: 625 mm, controller model: 21i MB, Travelling Bridge CNC Vertical Machining Centre Table size (2) 825 x 625 mm. Number of pallets: 2 Movement x-Axis 1600 mm. Movement y-Axis 600 mm. Movement z-Axis 500 mm. 4th Axis (Rotary table) NC Max table load 1200 kg Number of tools in magazine 51 pieces. Maximum spindle speed 12.000 R/pm. Tool taper DIN 69871A CNC control Fanuc 21i MB Nedpoyu Trhsfx Ahvjkw If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: excellent (used), Year of construction: 2008, Johnford SV-41 (2008) – Technical Specifications Type: Vertical CNC Machining Center Control Unit: Fanuc CNC Control Nkodpeyu R N Rofx Ahvjw Year: 2008 Travels (X / Y / Z): approx. 1,020 / 510 / 610 mm Table Size: approx. 1,100 x 500 mm Max Table Load: approx. 600–800 kg Spindle Taper: BT40 Spindle Speed: up to 8,000 rpm Spindle Motor: approx. 11–15 kW Tool Magazine: 24 ATC (Automatic Tool Changer) Rapid Traverse: approx. 24–30 m/min Coolant System: Yes Chip Conveyor Machine is equipped with Fanuc control and is in good working condition.

Condition: good (used), Year of construction: 2011, In good technical condition and fully functional. Year of manufacture: 06/2011. Fanuc control system. Axis travel – X-axis 2400 mm, Y-axis 960 mm, and Z-axis 800 mm. Nkjdpfx Ahjyu Nb Sjvsw

Condition: good (used), Year of construction: 2008, Used milling machine by Style Model: BT 1500 Nkjdpeyu Ifpofx Ahvow Max RPM: 6000 Year of manufacture: 2008 4th axis Spindle coolant

Condition: excellent (used), Year of construction: 2020, Data: XYZ: 2160 x 760 x 650 mm Control: Fanuc Magazine: 30 tools Spindle: 12,000 rpm -- SK 40 Table: 2160 x 760 mm Nkjdpfx Ahjyuiqtjvow Tool measurement Renishaw probe Through spindle coolant (IKZ) Chip conveyor Weight: 15,000 kg Machine powered and ready for demonstration

Condition: reconditioned (used), Year of construction: 2017, functionality: fully functional, travel distance X-axis: 1,150 mm, travel distance Y-axis: 640 mm, travel distance Z-axis: 660 mm, rapid traverse X-axis: 33 m/min, overall weight: 7,400 kg, spindle speed (max.): 11,000 rpm, number of slots in tool magazine: 28, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, The used and REFURBISHED AKIRA SEIKI 4.5 XP vertical machining center is a 3-axis continuous CNC machining center suitable for small/medium-sized parts. It features a 1300×600 mm table, travel: X 1,150 mm, Y 640 mm, Z 660 mm. Year of manufacture: 2017. CE compliant, equipped with FANUC 0i-MF CNC, rapid feedrates at 33 m/min and working feedrates at 12 m/min, weight 7,400 kg. Fitted with a 40-taper milling spindle, 11,000 rpm, 27 HP, refrigerated by dedicated chiller, belt-type chip conveyor, high-pressure through-spindle coolant system, random tool changer with 28 positions, USB port, memory card slot, RJ45 Ethernet network port. Nkedjyt Sanjpfx Ahvew The machine has been refurbished, including axes and a brand new complete spindle line, with 0 working hours. FULLY OPERATIONAL!

Condition: ready for operation (used), Year of construction: 2024, travel distance X-axis: 1,626 mm, travel distance Y-axis: 813 mm, travel distance Z-axis: 762 mm, controller manufacturer: HAAS, table width: 711 mm, table length: 1,626 mm, table load: 1,814 kg, overall weight: 10,887 kg, spindle speed (max.): 12,000 rpm, tool weight: 5,400 g, number of axes: 3, This 3-axis HAAS VM-6 was manufactured in 2024. It features a spindle speed of 12,000 rpm and a robust table size of 1,626 x 711 mm, with a maximum weight capacity of 1,814 kg. The machine includes a tool changer capacity of 30+1 and a rapid traverse rate of 15.2 m/min. If you are looking to get high-quality machining capabilities, consider the HAAS VM-6 vertical machining centre we have for sale. Contact us for further details. • Spindle nose to table: max 864 mm (34.0 in), min 102 mm (4.0 in) • Spindle • Max torque: 122.0 Nm @ 2000 rpm (90.0 ft-lbf) • Drive system: Inline direct-drive • Taper: CT40 | BT40 | HSK-A63 • Lubrication: Air/oil injection • Cooling: Liquid cooled • Table • Length: 1626 mm (64.0 in) • Width: 711 mm (28.0 in) • T-slot width: 15.90–16.00 mm (0.626–0.630 in) • T-slot center distance: 125 mm (4.92 in) • Max weight on table: 1814 kg (4000 lb) • Feedrates and thrust • Max cutting feedrate: 12.7 m/min (500 ipm) Nodpfjyt Riusx Ahvekw • Rapids (X/Y/Z): 15.2 m/min (600 ipm) • Max thrust X: 15,124 N (3400 lbf) • Max thrust Y: 18,238 N (4100 lbf) • Max thrust Z: 24,910 N (5600 lbf) • Tool changer • Type: SMTC (side-mount) • Capacity: 30+1 • Max tool diameter (full): 64 mm (2.5 in) • Max tool diameter (adjacent empty): 127 mm (5.0 in) • Max tool length: 406 mm (16 in) • Tool-to-tool time (avg): 2.80 s • Chip-to-chip time (avg): 3.60 s • Utilities • Coolant capacity: 360 L (95 gal) • Air required: 113 L/min @ 6.9 bar (4 scfm @ 100 psi) • Minimum air pressure: 5.5 bar (80 psi) • Electrical • Input AC voltage (3-phase) low: 220 VAC, full load amps: 70 A • Input AC voltage (3-phase) high: 440 VAC, full load amps: 35 A Technical Specification Taper Size ISO 40

Condition: good (used), Year of construction: 2018, Traverses X Y Z: 1270 x 508 x 635mm, Spindle nose to Table: 102 – 737mm, Table 1324 x 457mm, Spindle speed 7500 rpm, Spindle taper BT40, Spindle Motor 40Hp, HAAS Control, 20 Station ATC, Nodoyt Hf Sopfx Ahvskw Programmable Coolant nozzle, swarf auger, Low Volt light

Condition: used, 1 unit 5-axis universal machining center MIKRON HBM 1350 with chip conveyor BÜRENER KFE 63/40-900 Z60, spindle and guideways worn in, self-dismantling required. Color: as shown, according to pictures and inspection. Condition: used. Storage location: production hall. Payment method: advance payment by bank transfer. Shipping: collection only from location in Regensburg. Nedpfoytqaaex Ahvjkw

Condition: used, Year of construction: 2008, functionality: fully functional, HAAS VF-4SS Machining Center, 4th Axis – !!!! SPINDLE NEW !!!!! Year of manufacture: 11/2008, Commissioned 03/2009 Description: X-axis travel: 1270 mm Y-axis travel: 508 mm Z-axis travel: 635 mm Distance spindle nose to table max.: 742 mm Spindle power: 22.4 kW Max. spindle speed: 12,000 rpm Max. spindle torque: 122.0 Nm at 2,000 rpm Drive system: Direct drive, inline Spindle taper: SK40 Table size (L x W): 1321 x 457 mm T-slot width: 16 mm Number of standard T-slots: 5 Feed rates: - Max. cutting feed: 21.2 m/min - Rapid traverse: 35.6 m/min Nkodpfx Ahjytpqkjvow Tool changer capacity: 40 stations Max. tool weight: 5.4 kg Tool-to-tool change (avg.): 1.80 s Chip-to-chip change (avg.): 2.40 s Coolant capacity: 208 L Machine weight: 6,033 kg Accessories/Options: - 4th axis rotary table, HAAS HRT210 - Spiral chip conveyor - Coolant tank 200L - Through-spindle coolant (TSC 20 BAR) - 2-stage 25µ filter system - 40+1 position tool magazine - Programmable spindle orientation - 16MB program memory - 8M functions - 4th axis interface - Manual tailstock HTS6 Machine is powered and currently in production.
