Condition: ready for operation (used), Year of construction: 2008, operating hours: 411 h, functionality: fully functional, chuck outer diameter: 1,200 mm, spindle speed (max.): 300 rpm, spindle speed (min.): 2 rpm, turning diameter: 1,600 mm, Massa Heavy Duty Precision CNC Vertical Borer Model: VL-1200 ATC + C Control: Fanuc 18i TB Year: 2008 Max Swing Dia:1600mm Max Turning Dia: 1350mm Max Turning Height: 1250mm 4 Jaw Scroll Chuck Dia: 1200mm Table Speeds: 2-300 RPM 16 Station Tool Changer Lrodpfszv T A Ijx Ahkor ‘C’ Axis 360 Degrees ‘C’ Axis Milling Spindle BT 50 Dimensions: 6300 x 4500 x 5800mm Weight: 33,000 KGS

Condition: used, Year of construction: 2000, vertical turret lathe Vertical turning machine Hardinge AG / EMAG VL3 Ledjzv Edkspfx Ahkerr Year of manufacture 2000

Condition: used, Year of construction: 2002, CNC vertical turret lathe CNC vertical turning machine EMAG HSC 450 DS Ledpfxozv Ecme Ahkjrr 2002

Condition: used, Year of construction: 2001, machining line Machining line consisting of 2x EMAG 2x VSC 400 Year of manufacture 2001 Lrsdozv Ea Espfx Ahker

Condition: good (used), Year of construction: 2008, Machining center consisting of: 2x EMAG VSC400 Year of manufacture 2008 Lsdozv Earopfx Ahkerr

Condition: used, Year of construction: 2006, vertical turret lathe machining center Gildemeister CTV 250 Year of manufacture: 2006 Lrodpfezv Eafox Ahkor

Condition: used, Year of construction: 2013, vertical turret lathe Lrsdpfszvzfqox Ahkor EMAG VSC 315 Duo DD Year of manufacture: 2013

Condition: good (used), Year of construction: 2013, vertical turret lathe EMAG VTC 315 DS Ljdozvzd Tjpfx Ahkorr 2013

Condition: used, Year of construction: 2014, vertical turret lathe Lrodpfozvzdyjx Ahker EMAG VSC 315 Duo DD Year of manufacture: 2014

Condition: used, Year of construction: 2016, CNC vertical turret lathe Weisser Vector C-1R Year of manufacture 2016 Ljdpfx Ahszvzdmjkorr

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, Control system: SIEMENS 840D Machining diameter: 2,800 mm Machining height: 1,000 mm Load capacity: 16,000 kg Max. swing diameter, approx.: 2,800 mm Turning diameter – external, max.: 2,800 mm Spindle speed: 63 min-1 Travel of the cross slide: 620 mm Ram stroke – max.: 690 mm INCLUDES Chip conveyor 4-position tool turret Hydraulic chuck: 2,800 mm EQUIPMENT Tool holder CAPTO 6 Electric handwheel Lrodpfx Ahezvxiaekor Retrofit in 2009 DESCRIPTION The machine is in very good condition and was used for hard turning of roller bearings. In 2009, the machine underwent a mechanical overhaul by Maschinenbau HELLWIG. As part of this general overhaul, the control system was also upgraded to a SIEMENS 840 Powerline.

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, Control system: SIEMENS 840D Turning diameter: 4,000 mm Turning height: 1,400 mm Lodpfezvxh Aex Ahkorr Travel range of the rotary table: 850 mm Max. swing diameter, approx.: 4,200 mm Turning diameter - external, max.: 4,000 mm Travel range of the cross slide: 850 mm Ram stroke - max.: 950 mm EQUIPMENT - Hydraulic chuck - Tool holder CAPTO 6 - Electric handwheel - Retrofit in 2007 INCLUDES Chip conveyor 4-position tool turret DESCRIPTION The machine is in very good condition and was used for hard turning of 4m cylindrical roller bearings. In 2007, the machine underwent mechanical refurbishment by Maschinenbau HELLWIG. As part of this general overhaul, the control system was also upgraded to a SIEMENS 840 Powerline.

Condition: good (used), Year of construction: 2008, For sale: 1 unit Scherer VDZ 80 DS with the following technical specifications: Swing diameter: 120 mm Z-axis (vertical): 265 mm Lrodpfx Aozvniiohker X-axis (horizontal): 280 mm Front bearing diameter: 85 mm Rear bearing diameter: 75 mm 2 x A4 spindle Spindle drive unit rated power: 16.8 kW Rated torque: 100 Nm Speed: 1,000 – 7,000 rpm Travel speed Z-axis: max. 30 m/min Travel speed X-axis: max. 30 m/min Dimensions: 2.44 x 2.3 x 1.42 m (L x H x W) Weight: 9,000 kg Complete documentation available. Note: The system will likely require some reprogramming, as it was previously integrated into a complete processing line. However, a stand-alone program is available. Transportation and loading can be organized Europe-wide at extra cost upon request. Prices are subject to VAT. Inspection possible by appointment. Please contact us; our team will be happy to assist you. Machinery Purchase / Sales PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINERY, MACHINE TOOLS, AND MORE. Are you looking for a high-quality yet affordable machine for your production? Or do you wish to sell your machine? For further information or contact options, please reach us via the contact form.

Condition: good (used), Year of construction: 2004, For sale are 2 units of Scherer VDZ 80 DS with the following technical specifications: Swing diameter: 120 mm Z axis (vertical): 265 mm X axis (horizontal): 280 mm Front bearing diameter: 85 mm Rear bearing diameter: 75 mm 2 x A4 spindle Spindle drive rated power: 16.8 kW Rated torque: 100 Nm Speed range: 1000 - 7000 rpm Traverse speed Z axis: max. 30 m/min Traverse speed X axis: max. 30 m/min Dimensions: 2.44 x 2.3 x 1.42 m (L x H x W) Weight: 9000 kg Complete documentation available. Attention! The system will likely need some reprogramming as it was part of a complete production line. However, an individual program is available. Lredozvnh Sopfx Ahksr On request, transport and loading can be organized throughout Europe for an additional charge. Prices are subject to VAT. Inspection possible by appointment. Please contact us; our team looks forward to assisting you. Machinery Purchase / Sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES, MACHINE TOOLS, AND MORE. Are you looking for a high-quality yet affordable machine for your production? Or do you want to sell yours? For more information or contact options, please reach us via the contact form.

Condition: good (used), Year of construction: 2013, functionality: fully functional, The FAMAR TANDEM 400 is a powerful CNC vertical lathe with two independent machining stations. The machine is equipped with driven tools, automatic workpiece loading and unloading, a measuring probe, high-pressure coolant, and coolant filtration. The tandem design enables efficient series production and the simultaneous use of two separate machining stations. Main technical parameters: Standard chuck diameter: 400 mm Maximum chuck diameter: 400 mm Nominal turning diameter: 300 mm Maximum turning diameter: 400 mm Maximum turning length: 480 mm Maximum turning length: 300 mm Number of main spindles: 2 Max. main spindle speed: 4,000 rpm Rated power of main electric spindle: 49.6 kW Rated torque: 458 Nm S6 40% power: 61.7 kW S6 40% torque: 724 Nm Machine dimensions: approx. 3,900 × 3,500 × 3,200 mm Machine weight: approx. 21,000 kg Electrical connection: 400 V / 50 Hz Installed power: 90 kW CE compliant Tooling equipment UTTUM50 – turret for driven tools, size 50 Max. driven tool speed: 8,000 rpm Torque: 100 Nm Ledezvd Unjpfx Ahkerr Power: 15.6 kW UTDUM50 – turret tool disk Size VDI 50 12 tool positions Direct tool drive PPP40 – preparation for 2 hydraulic circuits For special workpiece clamping Piping and valves Control via M-functions Automation TRPAPE20 – 1 automatic circulating pallet conveyor for loading and unloading workpieces A single conveyor system for both workpiece infeed and outfeed Circulating pallet magazine Belt design Pallet occupancy monitoring system Pallet sorting system Working height approx. 950 mm Automatic workpiece loading and unloading via the machine TRPNVBPTE4 – Shuttle system with rotary station Loading/unloading shuttle system Integrated rotary station Including 1 set of jaws for the workpiece AZGRRB500 – set of jaws for Shuttle rotary station MPDM2 – automatic measuring probe Automatic workpiece measurement Coolant, filtration, and chip removal LBCVTT50 – belt conveyor for chips Separate conveyor for chip removal Particularly suitable for short chips, such as cast iron, brass, and some aluminum alloys LBVA760 – coolant tank Volume 760 l LBAP10 – high-pressure pump Pressure 20 bar Internal tool cooling LBFTC – paper filter for coolant Suitable for cast iron and aluminum Filtration of particles approx. 0.08 mm Flow rate max. 60 l/min LBFTTDF – double switchable filter Filtration of particles approx. 0.1 mm Bypass system allowing filter cartridge replacement AZPL – air workpiece position control Additional equipment: CNC control Siemens 840D sl 2 main spindles Driven tools C-axis 12-position turret VDI 50 1 automatic workpiece pallet conveyor Shuttle system with rotary station Automatic measuring probe Separate belt conveyor for chips High-pressure cooling 20 bar Coolant filtration Hydraulic clamping circuits Central lubrication Complete safety guarding CE The machine is particularly suitable for automated series production of rotational parts, where the two independent machining stations, driven tools, and automatic workpiece handling can be utilized.

Condition: good (used), Year of construction: 2007, - Speed range: [rpm]: 6,000 - Torque: [Nm]: 480 - Max. turning diameter over bed: 290 mm - Chuck diameter: 200 mm - Turret: 12-position, VDI 40, Sauter - Driven tools: 7.8 kW - Travel: - X-axis: 550 mm - Z-axis: 200 mm - Rapid traverse (X/Z) [m/min]: 30 / 20 - Feed (X/Z): [m/min.] 11 kN - Features: - Left-hand chip conveyor; 300 mm wide; ejection height 800 mm - Probe; direct linear measuring system; glass scales on all axes - Heidenhain circulating pickup tape - Machine with feed belt for part loading - Specification: Lrsdezvbr Dopfx Ahkjr - Overhauled in 2007 for approx. €50,000, complete headstock replaced. - Feed unit exchanged.

Condition: used, Year of construction: 2020, workpiece weight (max.): 35,000 kg, total length: 15,600 mm, total height: 6,000 mm, total width: 6,000 mm, overall weight: 155,000 kg, The Pittler WMZ PV4000 / 1-2 is a heavy CNC vertical turning machine with a portal design, featuring one workpiece spindle and two independently movable tool carriers. The machine enables turning, drilling, milling, and grooving. The right tool carrier is designed as a swiveling multifunction head with a B-axis and driven tools. Two separate chain magazines provide a total of 94 tool positions. Technical Data Machine Number: ZV029 Machine Concept: Portal machine with one workpiece spindle and two tool carriers Machining Processes: Turning, drilling, milling, and grooving Maximum Swing Diameter: 3800 mm Maximum Workpiece Diameter: 3800 mm Maximum Workpiece Speed: 100 min-1 Rated Speed: 36.7 min-1 Workpiece Clamping: Manual Chuck: Röhm Tool Holder: Capto C8 Tool Magazines: 2 chain magazines Tool Positions: 2 x 47 Total Number of Tool Positions: 94 Maximum Tool Diameter: 120 mm according to the operating manual Maximum Tool Diameter: 150 mm according to the order confirmation with appropriate magazine loading Maximum Tool Length: 400 mm Maximum Tool Weight: 20 kg Travel Paths X1-Axis Right Tool Carrier: 3200 mm X2-Axis Left Tool Carrier: 2800 mm Z1-Axis Right Tool Carrier: 1000 mm Z2-Axis Left Tool Carrier: 1000 mm Rapid Traverse X-Axes: up to 32 m/min Rapid Traverse Z-Axes: up to 20 m/min Workpiece Spindle Gear Reduction: 1 to 30 Maximum Speed: 100 min-1 Rated Speed: 36.7 min-1 Rated Power: 67.4 kW Short-Term Total Power: 202.2 kW Rated Torque: 52.65 kNm Maximum Drive Torque: 71.55 kNm Torque according to Order Confirmation: 67000 Nm at 40% duty cycle Motor Spindle Power according to Order Confirmation: 200 kW at 100% duty cycle Maximum Spindle Load Capacity including Chuck, Clamping Jaws, and Workpiece: 35000 kg Spindle Flange Diameter: 1900 mm Thrust Bearing Diameter: 1400 mm The workpiece spindle is designed as a water-cooled motor spindle with precision axial deep groove ball bearings. Tool Carrier and Multifunction Head The right tool carrier features a swiveling multifunction head with two Capto C8 holders for turning tools as well as drilling and milling tools. B-Axis for Stepless Positioning Swivel Range: 180 degrees Speed of Driven Tools: up to 6000 min-1 Tool Spindle Torque: approx. 120 Nm at 100% duty cycle Hydraulic Clamping Direct Measurement System Direct Coolant Supply High-Pressure Coolant Supply: up to 70 bar Tool Magazines Two chain magazines with 47 tool positions each Tool Holder: Capto C8 Maximum Tool Diameter: 120 mm Up to 150 mm with appropriate magazine loading Maximum Tool Length: 400 mm Lrsdpfxezu S U Ho Ahker Maximum Tool Weight: 20 kg Tool Cleaning with Blowing Air Manual Magazine Loading Coolant and Chip Disposal Two Knoll Chip Conveyors Type 600 S-2/120 Knoll Band Filter Type KF400-2300 Additional Equipment Röhm Chuck Spindle Cooling Hydac FLKS-4S Hydraulic Unit Hydac TBM20 Electrical Data Operating Voltage: 3 x 400 VAC Protection Class: IP55 Maximum Power Consumption: 280 kVA Component weight max.: 35,000 kg Weight approx.: 155,000 kg Rotation height max.: 2,100 mm Table diameter: 3,800 mm Swing: 3,800 mm Control: Siemens SINUMERIK 840D sl Dimensions (LxWxH) approx.: 15600 x 6000 x 6000 mm Year of construction: 2,020 Condition: good Terms of payment: 100% prepayment before pick-up Terms of delivery: EXW EX Works under power: Yes

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, controller model: Siemens 840 D, table diameter: 1,220 mm, TECHNICAL DETAILS Table diameter: 1,220 mm Max. turning diameter: 1,500 mm Max. height under the cross beam: 900/1,200 mm Saddle travel, X-axis: 1,000 mm Table speed range: 4.5 to 100 RPM Feed rate range: 0.127 to 6.35 mm/rev Tool changer: 30 positions MACHINE DETAILS Control system: Siemens 840 D Main drive motor: 41 kW EQUIPMENT 8 clamping jaws 30 tool holders Full enclosure Ljdpfxezuy Eas Ahksrr Mist extraction system

Condition: ready for operation (used), Year of construction: 2005, operating hours: 31,899 h, spindle motor power: 22,000 W, spindle speed (max.): 4,000 rpm, workpiece diameter (max.): 280 mm, number of axes: 2, This Okuma LVT 300 was manufactured in 2005. A robust vertical turning machine featuring a max. turning diameter of 280 mm and a swing diameter of 320 mm. It offers a rapid traverse rate of 60 m/min on the X-axis and 30 m/min on the Z-axis, with a turning speed range up to 4000 U/min. Ideal for efficient, precise operations, the machine includes 12 tool positions. A great opportunity to buy this Okuma LVT 300 vertical turning machine. Contact us for more information. Machine Benefits Technical Machine Benefits • Max diameter of the parts for the table pallet: 160 mm • Max. Turning height: 200 mm Extra Information • Machine still under power / two machines with interlinking available • Single-shift operation for 7 years • Cutting TIME: • 1st machine: 33,594 hours • 2nd machine: 31,899 hours • 3rd machine: 33,863 hours • 4th machine: 34,408 hours • The machines operate in a linked configuration (2 machines per pair, processing on both sides) Lsdpfxozt Nvfo Ahkjrr Technical Specification Taper Size VDI 40

Condition: excellent (used), Webster & Bennett 72” CNC Elevating Rail Vertical Turning & Boring Machine Fanuc control Tool changer Table Size 72” Machine swing 84” Table speed Range 3.8 to 150 rpm. Feed range .156mm to 7.5mm per rev. Max Height under cross slide 48” Max Height under turret 48” Ram Travel 38” Ljdpfx Aszrpmujhkerr Main motor 50hp Fully interlocked guards with swarf conveyor

Condition: ready for operation (used), Year of construction: 2007, travel distance X-axis: 850 mm, travel distance Z-axis: 315 mm, spindle motor power: 58,000 W, spindle speed (max.): 4,000 rpm, total height: 3,000 mm, total width: 4,500 mm, overall weight: 9,000 kg, product length (max.): 9,500 mm, number of axes: 2, Vertical turning machine manufactured in 2007. This EMAG VSC 400 features a turning diameter of 400 mm and a swing diameter of 420 mm. It offers an X-travel of 850 mm and Z-travel of 315 mm, with a maximum spindle speed of 4000 rpm. If you are looking to get high-quality turning capabilities, consider the EMAG VSC 400 machine we have for sale. Contact us for further details regarding this machine. Lredpfx Aozrnwrjhkjr - Turning Diameter: 400 mm- Swing Diameter: 420 mm- Spindle Head: DIN 55026 - Size 11- Spindle Bearing Diameter: 140 mm- Rapid Traverse X + Z Axes: 45 / 30 m/min- Feed Force Z/X: 11 kN- Total Power Requirement: 58 kW- Installed Power (Nameplate): 54 kW- Frequency: 50 Hz- Voltage (Power): 400 V- Control Voltage: 230 V- Nominal Current: 104 A- Cos Phi: 0.83- Fuse Protection: 125 A- Features: Hard turning, Dry machining, Chip conveyor Technical Specification Driven Tools No

Condition: used, Year of construction: 2016, Technical details: Lsdpjzq Aw Rjfx Ahkerr turning diameter: 150 mm

Condition: used, Year of construction: 2016, Technical details: Ledpfxjzq Aw Ds Ahkjrr turning diameter: 150 mm

Condition: excellent (used), Year of construction: 2020, Maximum turning diameter 3800 mm Maximum swing diameter 3800 mm diameter of spindle flange 1900 mm control Siemens 840 D sl Table rpm 100 1/min Maximum speed of driven tools 6000 1/min x-travel 2800/3200 mm z-travel 1000 mm Feed - X 20 m/min feed capacity - x 22 kN tool taper CAPTO C8 total power requirement 280 kVA dimensions of the machine ca. 10,4 x 6.3 x 5,7 m weight of the machine ca. 155 t Equipment/Accessories: - 2 tool changers, each with 60 positions Lrsdezpzblspfx Ahksr - 2 x chip conveyors - Coolant system, 6 bar - High-pressure cooling, 70 bar - Knoll paper belt filter - 12-jaw balancing chuck, RÖHM - internal coolant supply - Hydraulic unit - Automatic door - Electric handwheel - Technical documentation

Condition: ready for operation (used), functionality: fully functional, travel distance X-axis: 800 mm, travel distance Z-axis: 300 mm, chuck outer diameter: 250 mm, spindle bore: 79 mm, number of slots in tool magazine: 12, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel in X-axis: 800 mm Travel in Z-axis: 300 mm Chuck diameter: 250 mm Spindle head: 170 h5 Spindle diameter at the front bearing: 120 mm Spindle bore: 79 mm Number of tool stations: 12 EQUIPMENT Ledpfjzpxf Uex Ahkorr C-axis
