Digital print machine

SKODIX S75

Scodix S Series™
Digital Enhancement Presses Product Specifications
Printing technology
UV based inkjet
Resolution
Up to 2,540 x 360 DPI
Variable data
PDF, Optimized PDF, Optional Barcode system
Supported image standards
Standard PDF
Camera based Registration (OPA)
±200 micron image to image
Communication protocol
Hot Folder, LAN
Substrates *
Offset, Digital, Laminated substrates
Substrates loading sizes
Minimum L297 x W420 mm / 11.7 x 16.5 in S52 – Maximum – L353 x W520 mm / 13.9 x 20.4 in S75 – Maximum – L520 x W735 mm / 20.4 x 28.9 in
Printing Image size (with OPA marks)
S52 – Maximum – L341 x W516 mm / 13.4 x 20.3 in S75 – Maximum – L508 x W731 mm / 20 x 28.8 in
Polymer
Scodix PolySENSE™ Clear Polymer
Polymer layer thickness
Up to 250 microns
Redpfoyya A Sjx Ab Ijbw
Substrates input system
Automatic feeder
Substrates output systems
Automatic Production stacker, Basic stacker unit
Substrates weight
135 - 675 gsm / 6 - 30 points
Substrates thickness
Up to 0.7mm / 700 micron
Air requirements
Air Flow: 10 CFM. Between 6-8 bar - regulated
Additional software
Internal RIP, Software Editor
Presses dimensions (L x H x W)
Scodix S52 - 3793 x 1883 x 2576 mm / 150x 75 x 102 in Scodix S75 - 4753 x 1883 x 2576 mm / 187 x 75 x 102 in With Basic / Production stacker unit
Operating environment
Temperature: 15ºC to 30ºC (59ºF - 86ºF) Humidity: 40% to 80% relative humidity, non-condensing
Electrical requirements
Voltage: 400 VAC, + 10% 3 Phases Frequency: 50 to 60 Hz Current: Avg. 20 Amps in Print mode Power consumption: Avg. 8 kVA in print mode Circuit Breaker: 32 Amps
Presses weight
Scodix S52 – Net: 2,390 kg / 5,269 lbs Scodix S75 – Net: 2,905 kg / 6,404 lbs
* Based on the Scodix recommended list of materials. For expected Scodix SENSE™ quality, surface tension should be within the range of 36-44 dyne/cm.
Depends on print mode and substrate.
