Used Spotting for sale (1,748)

Year of construction: 2015, condition: like new (used), Servo-motorised 3G-X-forceps / modular welding gun for robots was mounted on KUKA robots - the adaptation to such is included Electrode force max. 6kN at 500mm radius X-tongs for Cu-arms with diameter 54mm MF transformer 560V / 1kHz, 56kVA Ratio 1:70 - U20, 7.2V with measuring coil 150 mV / kA and thermal switch Servomotor 8-pole 300V - 20kN maximum power Working stroke 95mm + 10mm reserve PDIV display Resolver 8-pin Spindle pitch 5mm Electrode arm for 3G pliers, projection approx. 400mm with brake (24VDC 1A) as required for KUKA robot Long 90 ° L console Dkedpfxsd Eaz To Ab Tsp complete tube package including control and cooling tubes enclosed

Condition: good (used), Year of construction: 1986, Power: 400kN Size of bolster: 900 x 1.280 mm Size of ram: 900 x 1.2200 mm Weight of mold: max. 7.000kg Power main motor: 7,5 kW Stroke: 1.000 mm - With movable bolster Dkedpfxjthdbns Ab Tjp - Bolster can be swiveled Weight: app. 7.000kg

Condition: like new (used), Year of construction: 1989, Sheet stamping press ERFURT PE2-H-315 ES Manufacturer: ERFURT Made in: Germany Specification: Max slide-block force over distance to bottom dead center 12.5 mm: 3150 kN Slide-block force over distance to bottom dead center 160 mm: 1100 kN Idle stroke amount: 25 mm Slide-block stroke: 500 mm Min closed die height: 680 mm Max closed die height: 1000 mm Moving table dimensions: 2800x1500 mm Die cushion: -Max stroke: 160 mm -Adjustable stroke: 160 mm Dkjdpsyir Uksfx Ab Tsp -Max double-acting force: 630 kN -Max ejector force: 630 kN Main motor power: 45 kW Height above floor level: 7100 mm Press weight: 71.3 tons

Condition: new, Year of construction: 2025, MDP-01 SPOT WELDER 10 kW High-performance transformer 5 levels of power regulation Possibility to work with 2 x 230V (380V) power supply Bottom sliding handle Dedpfx Ajfwxr Tjb Tokp The range of welded sheets: 0.4 + 0.4 to 2 + 2 mm Width: 490mm Length: 1010mm Height: 1100mm Weight: 130kg Power supply: 380V / 3phase / 10kw

Condition: new, Year of construction: 2025, MDPE-1 SPOT WELDER portable 1 kVA High-performance transformer 2 levels of power regulation Electronic current and time control Possibility to work with 230V power supply The range of welded sheets: to 1 + 1 mm Width: 110mm Dkodpjf Eyvvefx Ab Tjp Length: 460mm Height: 300mm Weight: 12,5kg Power supply: 230V

Condition: new, Year of construction: 2025, MDPE-02 SPOT WELDER 20 kVA High-performance transformer 5 levels of power regulation Electronic current and time control Dkodpef Eyu Asfx Ab Top Possibility to work with 2 x 230V (380V) power supply Bottom sliding handle The range of welded sheets: to 3 + 3 mm Width: 620mm Length: 1100mm Height: 1200mm Weight: 230kg Power supply: 380V / 3phase

Condition: good (used), Good working condition. Please check out our other listings as well. Djdpjn Uv Ulefx Ab Tskp

Year of construction: 2011, condition: ready for operation (used), System includes (1) Industrial Robot KUKA KR 150-2 2000 (2) Spot Welding System SPATZ (3) Camera Inspection OMRON (4) Light Barrier SICK, operational hours counter: 2602h. Dkjdpfjgqkpmox Ab Top

Year of construction: 2000, condition: ready for operation (used), Arm length: 550mm, max. welding power: 136kVA, length: 640mm, width: 930mm, height: 1550mm, weight: 290kg. Dedpsk N Dmvjfx Ab Tekp

Condition: excellent (used), throat depth: 1,100 mm, nominal power at 50% duty cycle: 96 kVA, short-circuit current: 31,500 A, input voltage: 400 V, type of cooling: water, overall weight: 830 kg, Equipment: type plate available, Spot welding machine, type PMS 11-4 G3, 3-phase DC version - specifically designed for welding aluminum sheets - rarely used, completely inspected and cleaned - fully functional, ready for demonstration - rated voltage 400V/50Hz - rated power 96 kVA - welding current 23 kA - connection cable cross-section 10 sq mm/phase - fuse rating 63A - arm reach 1050 mm (!!) - electrode arm diameter 60 mm - electrode holder diameter 30 mm - electrode force 600 daN - stroke 65+25 mm - electrode cone MK2 - control unit MPS 8043/1 from Harms & Wende with current ramp-up and pulse function - with operating manual - 2-stage foot switch according to UVV standards - main machine switch - pneumatic maintenance unit - weight approx. 830 kg Dksdpfx Aboh N Sc Eo Tsp - complete documentation with wiring diagram, compressed air circuit diagram, and cooling water circuit - VAT can be shown separately - delivery from warehouse in Dresden approx. 4 days within Germany - export may take longer! On-site commissioning is subject to a charge and will be billed according to the actual effort involved. The machine is located in Dresden, near the A17 highway, and can be inspected and demonstrated by appointment.

Year of construction: 1991, condition: ready for operation (used), Dalex DR-F 2 0.35 m³/h Dedpfx Absftbtmj Tekp 220 Volt No. 109115732 Year of manufacture 1991 Refrigerant R12 – needs to be refilled.

Condition: refurbished (used), Power at 50%: 25kVA Short circuit-current: 12kA Electrode force: 120daN / single stroke Throat depth: 150mm --- Weld control: AR.01 (5-times, 2-program) --- Extra Equipment: - doppel foot pedal "currentless contact" - forearm support --- Warranty: 12 months Dksdew Natbspfx Ab Tep --- Spotwelding electrodes + spare parts at stock

Condition: excellent (used), manually operated, water-cooled spot welding pliers Dksdpfog Ew H Njx Ab Tep DALEX, type A 3119 with double-stroke mechanism and short-stroke latch Short stroke: 25 mm - Long stroke: 57 mm with electrode force switch and secondary transformer for current control Rated power at 50% duty cycle: 8 kVA Secondary short-circuit current: 9.5 kA Electrode force: 180 daN Arm spacing: 120 mm Arm extension: 250 mm with synchronous welding control RS 11-2 Main switch, connection cable, and 16 A CEE plug Extensive range of water-cooled electrode arms in stock.

Condition: good (used), Peco welding machine spot welding machine Peco welding machine welding flat strip and electric cable Dsdeivappjpfx Ab Tjkp Peco LA 40 air control Bosch E35...DYF welding controller More welding machines in other sizes - new and used - you will find in our store! International shipping costs on request!

Condition: like new (used), Year of construction: 2023, functionality: fully functional, machine/vehicle number: 21220, type of input current: AC, total height: 3,100 mm, total width: 4,000 mm, total length: 9,400 mm, overall weight: 8,600 kg, input voltage: 400 V, type of cooling: water, Resistance spot welding system LASO Tech Systems "WP Welding System" Year of manufacture: 2023 Serial number: 21220 Order number: 11B01 265845 Manufacturer: LASO Tech Systems GmbH, 98527 Suhl Type: WP welding system Total weight: approx. 8,600 kg Dimensions (L x W x H): approx. 9.4 x 4.0 x 3.1 m Rated voltage: 400 V / 3 Ph / 50 Hz Rated power: 138 kVA at 100% duty cycle Main Components: YASKAWA Positioner V2-500D3 L = 1650 Serial number: 466843-1-1 | Year of manufacture: 2022 | Weight: 1,409 kg | Item number: 411503 | Part No.: 148548-100 (Yaskawa Nordic AB, Sweden) Equipment: Servo rotary axis, swivel unit, Penlink rotary union (P/N 365003 – S/N 3197). Total unit weight: approx. 1,500 kg. Project assignment: LASO Tech, Project No. 30101293. Welding cell LASO WP-SLK Steel frame construction with safety enclosure, electrically interlocked access points. Integrated positioning systems (S1 / S2). Controller: LASO industrial PC / Siemens S7 / Robot controller compatible with YASKAWA Motoman. Power supply 400 V / 50 Hz / 138 kVA. Process control for resistance spot welding with cooling water, compressed air, and network interfaces. Full I/O wiring provided. YASKAWA Industrial Robot GP180 with Controller YRC1000 Djdpfx Abexlixwo Tskp Type: YR-1-06VX180-A00 | Year of manufacture: 11/2022 | Payload: 180 kg | Own weight: 1,020 kg Serial number: 6V22Y2842450001 | Manufacturer: YASKAWA Europe Robotics d.o.o., Kocevje (Slovenia) Controller: YRC1000, type ERAS-1000-06VX280-E10, SN 6V22X2807840001, year: 10/2022 Power: 6.5 kVA, supply: AC 380–440 V, 50/60 Hz | Teach Pendant +RM1 | Integrated safety shutdown. Control Cabinet NIMAK multiCONTROL with Bosch Rexroth PRC7300 Type: PRC7300-L1-01VRS-0105-01-00002-EC-01 | Serial number: 7261404217680 Supply: 3~ 400–480 V / 110 A | Manufacturer: Bosch Rexroth AG, Lohr am Main Year: 2023 | Fully wired with safety modules and EMZ interface. RSP Tool Changer System Manufacturer: Robot System Products (RSP), Sweden | Type: P8366-150 with tool changer P7501-036 (Sn 0001 / 0002) and docking units P8303A. Pneumatic, coolant, and signal transfer integrated. Connection via RobiFix. Welding Guns Gun 1 – NIMAK LRN 300-650-R54-175-150-P2U-WR Project: 95.011.360 | Machine No.: 2212–2129 N | Weight: 120.5 kg | Year: 2023 Transformer: Expert MF100-530 V-A.01 (SN: T-297432). Coupling: RSP P7501-036 + P8303A. Gun 2 – NIMAK CRN 300-650-R54-200-P2U-WL Project: 95.029.224 | Machine No.: 2212–2128 N | Weight: 109.5 kg | Year: 2023 Transformer: Expert MF100-530 V-A.01 (SN: T-297431). Coupling: RSP P7501-036 + P8303A. Welding Gun Cleaning Station (LASO Special Construction) Free-standing unit on steel base with SEW geared motor (400 V). Two round brushes Ø 180 mm x 150 mm. Condition and Scope of Delivery Entire system built 2022/2023, as new condition. All components including cabling, control cabinets, safety enclosure, and documentation are supplied. Dismantled and transport-secured as agreed.

Condition: good (used), nominal power at 50% duty cycle: 50 kVA, - Power 50 kVA Dedpsyda Dvsfx Ab Tokp - Pneumatic - Throat depth 425 mm - PX 1500 Plus control - 400V

Condition: good (used), Hommel Dura measuring plate / control plate made of natural hard stone Hommel Dura measuring plate made of hard stone (granite plate) length: 3000 mm width: 1000 mm thickness: 300 mm 1 x T-slot More measuring plates in other sizes - new and used - you will find in our store! Dksdpek Shcujfx Ab Tsp International shipping costs on request!

Condition: new, Year of construction: 2025, Power rating at 50%: 2,5kVA Short-circuit current: 8,2kA Dkedpoxl Uqxefx Ab Top Electrode force: 120daN (at 125mm Throat depth) weight: 11kg --- with Electrode arm 125mm --- welding control --- warranty: 12 months

Condition: new, Year of construction: 2025, Power at 50%: 40kVA Dkjdpoxl Urcjfx Ab Tjp Short circuit-current: 26,2kA Electrode force: 100-600daN / single stroke Throat depth: 250-550mm --- Weld control: MPS 10 (5-times, 8-program) --- Extra Equipment: - doppel foot pedal "currentless contact" - forearm support --- Warranty: 12 months --- Spotwelding electrodes + spare parts at stock

Condition: new, Year of construction: 2025, Power at 50%: 80kVA Short circuit-current: 35kA Electrode force: 100-600daN / single stroke Throat depth: 350-650mm --- Weld control: MPS 10beta (5-times, 8-program) Dsdpfx Aboxl Uudj Tjkp --- Warranty: 12 months --- Spotwelding electrodes + spare parts at stock

Condition: excellent (used), Water-cooled, pneumatically operated rocker arm spot welding machine Dodpfxoxvh Hbs Ab Tokp Manufacturer: DALEX Model: SL 25-1 Rated power at 50% duty cycle: 25 kVA Secondary short-circuit current: 22.4 kA Secondary open-circuit voltage: 1.8 - 5.2 V Electrode force: 278 daN Arm gap: 140 or 300 mm Arm reach: 180-500 mm With attached control cabinet according to VDE 0100 With main switch Synchronous welding control MPS 15036

Condition: excellent (used), Year of construction: 2019, We are selling a PCB spot welding system from AMADA, mounted on a workbench. The welding head is type FD 120-A/So, year of manufacture 2019. Dsdpfx Ajyhwdueb Tjkp

Condition: good (used), Medium frequency 1000 Hz spot welding machine, 400 V 50 Hz Make: DALEX Model: PMS 11-4 MF Arm reach: 950 mm with double-acting cylinder Rated power at 20% duty cycle: 180 kVA Secondary short-circuit current: 37 kA Secondary open-circuit voltage: 9 V Electrode force: 60-600 daN Weight: 550 kg Dsdsvyk Sfepfx Ab Tjkp

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, total height: 5,750 mm, clearance between the columns: 3,200 mm, installation height: 6,800 mm, total width: 2,890 mm, total length: 8,500 mm, table width: 2,000 mm, table length: 3,000 mm, table load: 70,000 kg, reverse speed: 50 mm/s, clamping force: 3,000 kN, Millutensil Spotting Press MIL 303 Short Description Year of manufacture: 2012 • Hydraulic press type 303.011 • 300 t pressing force • Usable table length: 3000 mm • Usable table width: 2000 mm • Max. distance between columns (lengthwise): 2130 mm • Max. distance between columns (widthwise): 3200 mm Dkedjygkwxepfx Ab Tjp • T-slots in the tables: 28 mm (DIN 650) • Max. opening force: 800 kN – Max. closing force: 3000 kN • Upper table rotation: 100–180 degrees • Hydraulic pressure, adjustable from 0–240 bar • Approach speed (fast): 65–80 mm/sec • Working speed: 8 mm/sec • Return speed: 35–50 mm/sec • Main upper motor power: 30 kW • Upper auxiliary motor power: 1.1 kW • Total press power: 31.1 kW • Max. load on upper table: 30,000 kg • Max. load on lower table: 70,000 kg

Condition: like new (used), water-cooled, pneumatically actuated spot welding gun with 5/2 solenoid valve Make: DALEX Type: 3228-4 Rated power at 50% duty cycle: 16 kVA Secondary short-circuit current: 13.5 kA Electrode force: 270 daN Arm spacing: 130 mm Arm reach: 350 mm With double stroke cylinder Long stroke: 75 mm Pre-stroke: 50 mm Working stroke with adjustable height: 0-25 mm Cardan suspension and suspension bracket 10 m connection cable and control cable Includes: External welding controller MPS 15033 Dodpfxexwlzle Ab Tokp The spot welding gun shows hardly any signs of use and is in like-new condition.
