Used Mazak Super Quick Turn 200 X 500 for sale (321)

Condition: ready for operation (used), Year of construction: 2004, spindle speed (max.): 5,000 rpm, travel distance X-axis: 580 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 1,045 mm, total width: 2,100 mm, overall weight: 9,200 kg, product length (max.): 3,850 mm, number of slots in tool magazine: 40, number of axes: 5, This 5-axis Mazak INTEGREX 200-3 was manufactured in 2004. It features a maximum turning diameter of 660 mm and a maximum turning length of 1045 mm. The machine is equipped with a main spindle speed of 5000 rpm and a milling spindle speed of up to 12000 rpm. If you are looking to get high-quality mill-turn capabilities, consider the Mazak INTEGREX 200-3 machine we have for sale. Contact us for further details. Itedpfezwx Acjx Ah Ejl - Maximum Turning Diameter: 540-660 mm- Maximum Swing Diameter Over Bed: 660 mm- Maximum Turning Length: 1016-1045 mm- Main Spindle Speed: 35-5000 rpm- Milling Spindle Speed: up to 12000 rpm- Tool Holder: Capto C6- Machine Height: 2597 mm- Main Circuit Voltage: 3AC 400V 50/60Hz- Control Circuit Voltage: AC 100V / DC 24V- Main Motor Current: Max 84 A (400 V)- Rated Capacity: 50.0 kVA- Oil Cooling Unit Model: Daikin (Weight 190 kg)- Cooling Unit Capacity: Comp. 1.1 kW, Circulating Pump P1 0.4 kW, Circulating Pump P2 0.4 kW- Refrigerant: R407C (0.83 kg)

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, turning length: 1,045 mm, spindle motor power: 18,500 W, spindle speed (max.): 6,000 rpm, spindle bore: 82 mm, travel distance X-axis: 580 mm, travel distance Y-axis: 580 mm, travel distance Z-axis: 1,045 mm, total height: 2,900 mm, total length: 4,500 mm, total width: 2,400 mm, overall weight: 9,200 kg, Multi-tasking lathe MAZAK - INTEGREX 200-4 S MACH-ID 9810 Make: MAZAK Type: INTEGREX 200-4 S Control: MAZATROL MATRIX Year: 2010 The Mazak INTEGREX 200-IV S is a multi-tasking CNC turning and milling center with a second/sub-spindle. The “S” indicates the sub-spindle, allowing complete machining of both sides of a workpiece in a single setup. Typical specifications include a maximum machining diameter of approximately 660 mm, a machining length of around 995 mm, and X/Y/Z travels of approximately 580 / 160 / 1,045 mm. The machine features a B-axis milling head, a main spindle and sub-spindle up to approximately 5,000 rpm, and a milling spindle typically capable of 12,000 rpm. It normally uses Capto C6 tooling and is often equipped with a 40-position automatic tool changer. Machines manufactured around 2006–2010 are commonly equipped with the Mazatrol Matrix CNC control. The INTEGREX 200-IV S is designed for complete machining of complex components, combining turning, milling, drilling, tapping and 5-axis positioning in one machine. This significantly reduces the number of setups and eliminates the need to move components between separate turning and milling machines. Max. turning Ø: 660mm X-Axis: 580mm Y-Axis: 160mm Itjdoz Ar Ucopfx Ah Esl Z-Axis: 1045mm B Axis: 225° Spindle bore: 82mm Speedrange: 5000Rpm Spindle power: 18.5kW Subspindle speeds:6000Rpm Subspindle bore: 82mm Subspindle power:18.5kW ATC / revolver: 80 Speed live tools:12.000Rpm Length: 4500mm Width: 2400mm Height: 2900mm Weight: 9200kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: excellent (used), Year of construction: 2007, operating hours: 5,500 h, functionality: fully functional, turning length: 1,545 mm, spindle motor power: 22,000 W, spindle speed (max.): 5,000 rpm, spindle bore: 65 mm, travel distance X-axis: 580 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 1,545 mm, total height: 2,600 mm, total length: 5,200 mm, total width: 2,550 mm, overall weight: 14,000 kg, Equipment: documentation/manual, Multi-Tasking Machining in a Single Machine Setup Sub spindle for overtaking with full C-Axis 0,001 Degrees 5500 Cutting hours ! The INTEGREX IV series can finish all machining processes. High speed, advanced milling spindle that can tilt up to 240 degrees swiveling. Lower turret with rotary tool spindle so livew tooling Chip conveyor with coolant and 15 Bar iKZ Double chuck KNCS-N 210-53 SMW Autoblock MAZAK Flex -GL150F Gantry Loader Gripping range 200 x 120 length x 15 Kg Max. turning Ø: 660mm X-Axis: 580mm Y-Axis: 160mm Z-Axis: 1545mm B Axis: 270° Spindle bore: 65mm Speedrange: 5000Rpm Spindle power: 22kW Subspindle speeds:5000Rpm Subspindle bore: 65mm Subspindle power: 18.5kW ATC / revolver: 40 B-Axis Toolsystem:Capto C6 B-Axis Speedranges:12000Rpm Length: 5200mm Width: 2550mm Height: 2600mm Iedpfxjz Ar R Dj Ah Estl Weight: 14000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: excellent (used), Year of construction: 1989, I am selling a CNC lathe Mazak QuickTurn 20N. Lathe in bdb condition. Equipment: MAZATROL T-2, control MAZATROL CAM-T-2. Isdou U R E Aepfx Ah Estl

Condition: used, Year of construction: 2013, functionality: fully functional, Equipment: documentation/manual, Mazak Machining Center 5-Axis (4 + 1 Positional) Variaxis J-500 Model Year 2013 Mazatrol Matrix Nexus 2 CNC Ijdpfezxpv Njx Ah Eetl

Condition: ready for operation (used), Year of construction: 1992, spindle speed (max.): 3,600 rpm, bar diameter (max.): 60 mm, total width: 2,000 mm, total height: 1,900 mm, travel distance X-axis: 180 mm, overall weight: 4,300 kg, controller manufacturer: MAZATROL, controller model: T32-2, product length (max.): 2,700 mm, number of axes: 2, Multi-spindle turning machine manufactured in 1992. This Mazak Quick Turn 18 NSP features a maximum turning diameter of 260 mm and a turning length of 500 mm. It includes a tool turret with 8-fold / 16 positions and a spindle speed range of 36 - 3,600 rpm. If you are looking to get high-quality turning capabilities, consider the Mazak Quick Turn 18 NSP machine we have for sale. Contact us for further details regarding this machine. - Control: MAZATROL T32-2- Max. Turning Diameter: 260 mm- Max. Turning Length: 500 mm- Speed Range Main Spindle: 36 - 3,600 rpm- Speed Range Sub-Spindle: 36 - 3,600 rpm- Travel Z-Axis: 510 mm- Travel X-Axis: 180 mm- Spindle Bore: Ø 70 mm- Bar Loader Length: 3,000 mm- Collet Chuck Holder: For 185 E collets- Collet Chuck Range (Main Spindle): Ø 4 - 60 mm- Sub-Spindle: 3-jaw chuck, Ø 125 mm to Ø 70 mm- Tool Turret: 8-fold / 16 positions- Tool Eye: Measuring probe for tool measurement in working area- Main Spindle Chuck: KITAGAWA 3-jaw chuck Ø 254 mm- Coolant System: Complete coolant equipment- Foot Switch: 2 double foot switches for opening/closing both chucks- Machine Weight: 4,300 kg- Machine Dimensions (L x W x H): 2.7 x 2.0 x 1.9 m Itjdpszarf Refx Ah Eel Optional - Drip pan (2500 x 2700 mm), IRCO 3000 mm bar loader Technical Specification Counter Spindle Yes

Condition: used, Year of construction: 2000, operating hours: 42,362 h, functionality: fully functional, machine/vehicle number: 148417, overall weight: 8,000 kg, total length: 6,000 mm, total width: 2,900 mm, total height: 2,000 mm, travel distance X-axis: 2,650 mm, travel distance Y-axis: 1,670 mm, travel distance Z-axis: 100 mm, controller manufacturer: Mazatrol, controller model: L-32B, working width: 1,250 mm, workpiece weight (max.): 300 kg, laser hours: 42,362 h, laser power: 1,500 W, sheet thickness (max.): 12 mm, sheet thickness aluminum (max.): 3 mm, sheet thickness steel (max.): 12 mm, working length: 2,500 mm, control type: CNC control, degree of automation: automatic, sheet thickness stainless steel (max.): 6 mm, laser type: CO₂ laser, actuation type: electric, Equipment: emergency stop, nozzle changer, Used Turbo X48 champion from 2001 located in Serbia. This laser cutting is equipped with a control unit Mazatrol L-32B and has a working area of 2500 x 1250 mm, laser power 1.5 kW. 42362 total hours on. Cutting capacity: -12mm mild -6mm stainless -3mm aluminium For additional pictures and videos of laser cutting in action feel free to contact me. Itodpfx Ajxl Sfyjh Eol

Condition: used, Year of construction: 2007, MAZAK TURNING CENTRE TYPE INTEGREX 200 IV S - 1000 mm The machine is supplied in standard configuration and equipped with the following options: - Through‑spindle coolant 15 bar - Synchronized tapping with milling spindle - Cylindrical interpolation and polar coordinates - 40‑tool magazine Capto C6 - Preparation for visual tool (visual tool probe) - Form/geometry compensation for rotary axes - 3D coordinate conversion - Management of rapid traverses - Preparation for flash tool (tool‑change flash tooling) - Simultaneous 5‑axis functions - Tool pivot point management - 5‑axis tool radius compensation - Part catcher (automatic part collector) - Double clamp pressure on the secondary spindle - Overload detector Maximum swing 660mm Itodpfx Ajzuy Tdjh Eol Swing over cross slide 660mm Swing during Y-axis process 660 to 500mm Maximum machining diameter 660mm Through-hole diameter 76mm

Condition: used, Year of construction: 2004, turning diameter: 660 mm, spindle speed (max.): 5,000 rpm, spindle speed (min.): 35 rpm, travel distance X-axis: 580 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 1,045 mm, total height: 2,600 mm, total length: 3,820 mm, total width: 2,060 mm, overall weight: 10,400 kg, Equipment: documentation/manual, CNC Turning Milling centre with Second Spindle CNC Control Mazatrol PC Fusion CNC 640 MT PRO Turning diameter 550/660 mm Iodpfx Ahezv Sfbj Eotl Turning length 1016 mm Spindle bore diameter 65 mm Spindle speed 35-5000 R/min X-axis movement 580 mm Y-axis movement 160 mm Z-axis movement 1045 mm B-axis travel 225 ° mm C-axis indexing 360° Spindle nose A2-6 Tool Taper Capto C6 Number of tools in magazine 40 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail.

Condition: like new (used), Year of construction: 2003, functionality: fully functional, travel distance X-axis: 510 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 460 mm, controller manufacturer: MAZATROL 640M 5X, controller model: MAZATROL 640M 5X, workpiece height (max.): 405 mm, workpiece diameter (max.): 500 mm, workpiece weight (max.): 300 kg, table width: 400 mm, table length: 500 mm, spindle speed (max.): 12,000 rpm, spindle motor power: 22,000 W, spindle nose: CAT40, number of slots in tool magazine: 40, input voltage: 400 V, type of input current: AC, Equipment: documentation/manual, rotational speed infinitely variable, *MAZAK VARIAXIS 500-5X 5 AXIS TWIN PALLET VMC* Category: Vertical Machining Centers (VMC) Reference No.: 3877 Capacity: 510 X 510 X 460 MM Year of Construction: 2003 Technical Specification: SPINDLE Spindle Taper : CAT40 Spindle Speeds : 12000 RPM Spindle Motor Power : 30 HP WORKING CAPACITY Pallet Size : 500 x 400 mm Travels (XYZ) : 510 x 510 x 460 mm A Axis : -120 / +30 Deg C Axis : 0.001 Deg Max Workpiece Size : Ø500 x 405 High Itsdpfx Aox Adn Ush Ejl Max Workpiece Weight : 300 Kgs ATC Tool Change Capacity : 40 Tools (CAT40) CNC Control : MAZATROL 640M 5X PC-FUSION-CNC Additional Details: Twin Pallet

Condition: like new (used), Year of construction: 2022, operating hours: 10,000 h, functionality: fully functional, number of slots in tool magazine: 80, MAZAK HCN-5000 Horizontal Machining Center Year 2024 Control Unit: Smooth G X-axis travel: 730 Itjdpfx Ajz Aaukjh Ejl Y-axis travel: 730 Z-axis travel: 800 Table length: 500 Table width: 500 Maximum workpiece dimensions (length x width x height): D.800x1000 Table surface: Tapped holes Maximum workpiece weight: 700 kg Spindle speed: 18000 rpm (high torque) Spindle taper: ISO 40 Rapid traverse rate (X-axis): 60,000 Rapid traverse rate (Y-axis): 60,000 Rapid traverse rate (Z-axis): 60,000 Number of tools (ATC): 40-60-80 Maximum tool diameter (ATC): D. 95 D.170 Maximum tool length (from reference line) (ATC): 170 Tool selection method (ATC): FIXED Maximum tool weight (ATC): 12 Tool change time (ATC): 2.8 Coolant pressure: 15 Bar Coolant tank capacity: 500L Height (machine dimensions): 2813 Width (machine dimensions): 2623 Depth (machine dimensions): 5769 Weight (machine dimensions): 11430 Pallet size: 500x500

Condition: used, TECHNICAL DETAILS - Number of axes : 5 MILLING SPINDLE - Tool holder type : SK 40 - Spindle power : 12 [kW] - Spindle speeds : 12.000 [rpm] LINEAR AXES - Travels on X/Y/Z axes : 510 x 510 x 460 [mm] A ROTARY AXIS - Travel : [°] - Indexing precision : 0,001 [°] B ROTARY AXIS - Travel : 360 [°] Itodpfouhbr Hox Ah Ejl - Indexing precision : 0,001 [°] TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 40 TABLE - Table dimensions : 400 x 400 [mm] - Maximum weight upon table : 300 [kg] - Max. turning diameter : 500 [mm] - Max. machining height : 405 [mm] PALLET CHANGER - Pallet size : 400 X 400 [mm] - Pallets number : 2 POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 50 [kVA] WEIGHT & DIMENSIONS - Machine weight : 11500 [kg] MACHINE HOURS - Number of working hours : 32763 [h] EQUIPMENT - CNC : Mazatrol PC-Fusion 640 - Interactive programming - Supports : RS232/RJ45/PCMCIA - Rigid tapping - Coolant tank * with high-pressure pump : 15 [bars] - Coolant through spindle - Spindle cooling unit - Chips conveyor : MAYFRAN - Tool probe

Condition: used, MAZAK QT 20 Model: OT-20-N-K Turret: 8 positions Motor: 18.5 kW Year: 1988 Weight: 11,700 lbs Chuck: diameter 250 renewed operational panel Itedpswulzvefx Ah Eol

Condition: excellent (used), functionality: fully functional, Year of construction: 2022, operating hours: 966 h, MAZAK OPTIPLEX NEXUS 3015 FIBER - 4 kW CNC Fiber Laser Cutting Machine Price: EUR 190,000 net Condition: Used – VERY LOW OPERATING HOURS Resonator: IPG YLS-4000 U VERY LOW WORKING HOURS The machine has exceptionally low operating hours. The IPG resonator and critical components are in near-factory condition: - Practically full remaining lifespan of the IPG resonator (rated for up to 100,000 h) - Minimal wear on the optical system, Multi-Control Torch 2.1 head, and linear guideways - Cutting quality and precision comparable to a new machine - Operating hours confirmed by CNC readout – documentation available upon request or during inspection TECHNICAL SPECIFICATIONS Model: Optiplex Nexus 3015 Fiber Laser Type: Ytterbium fiber laser Resonator: IPG YLS-4000 U Laser Power: 4.0 kW Max. Sheet Size: 1,525 x 3,050 mm Max. Pallet Load: 930 kg Travel (X/Y/Z): 3,100 / 1,580 / 150 mm Rapid Traverse (X/Y): 60 m/min (85 m/min combined) Drive X1/X2/Y: Rack & pinion, direct-drive Drive Z: Servo, ball screw Accuracy X/Y: ±0.05 mm / 500 mm Repeatability: ±0.03 mm Head: Multi-Control Torch 2.1, F125-F200 mm Assist Gases: O2, air, third gas; 0.02–2.5 MPa CNC: Mazatrol Preview G, 19" touchscreen Pallet Changer: Automated, 2-pallet Weight: Approx. 12,850 kg Power: 380–480 V, max. 18 kW CUTTING CAPACITY (4 kW) Mild steel O2: 20 mm Mild steel N2: 4 mm Stainless steel N2: 15 mm Aluminum N2: 15 mm Copper O2: 8 mm Brass N2: 8 mm Iedpfx Aoy Dgxush Eotl INTELLIGENT FUNCTIONS (INCLUDED) Automatic nozzle changer (8 nozzles), auto focus positioning, focus detection, auto profiler calibration, auto nozzle cleaning, beam diameter control, pierce/plasma/burn detection, fine power ramping, flash cut. SCOPE OF DELIVERY (INCLUDED IN PRICE) Cast-iron frame (foundation-free installation), Mazatrol Preview G CNC 19", Multi-Control Torch 2.1 head with 8-position nozzle changer, OPTIPOD module, automatic 2-pallet changer, chiller with 6 m hoses, cutting nozzles 1.2/2.0/3.0 mm plus 5 adapters, laser edge detection, numerical gas pressure control, multi-tap transformer, slatted table (100 mm spacing), tools, documentation (PL/EN). OPTIONAL EQUIPMENT – NOT INCLUDED The laser system can be purchased separately for EUR 190,000. Options below are available at additional cost. OPTION A – PRESSURE-BOOSTING UNIT – EUR 15,000 net Allows cutting with compressed atmospheric air instead of expensive nitrogen, greatly reducing operating costs. Components: 1. Compressor SK 25 / max. 15 bar / SK.2-13318 2. Condensate Drain Ultramat UFM-D03 3. Economizer Ultra-Filter DF 0035 - DF 1100 4. Ultra-Filter DF 0035 - DF 1100 5. Pressure vessel, 500 l Air cutting capacity: mild steel up to 6 mm, stainless up to 4 mm. OPTION B – SHEET LOADING CRANE – EUR 5,500 net Sheet loading crane, lifting capacity up to 700 kg. Enables safe and quick loading of sheets onto the laser pallet. PRICE SUMMARY (NET, EUR) Machine only: EUR 190,000 Option A (pressure unit): EUR 15,000 Option B (loading crane): EUR 5,500 Total with both options: EUR 210,500 COMMERCIAL TERMS - All prices are net, in EUR (VAT not included) - Offer valid for 30 days - Payment and delivery terms to be agreed - Inspection and test cutting available by appointment

Year of construction: 2006, condition: ready for operation (used), A Mazak CNC 5-axis turning and milling center with counter spindle is available. Swing diameter: 820mm, machining diameter: 820mm, machining length: 1500mm, max. workpiece weight in chuck/between centers: 650kg/150kg, main spindle speed: 1600rpm, spindle bore: 185mm, power: 30kW/40kW, tailstock force: 15kN, quill stroke: 1466mm, tool holder: BT50, spindle speed: 10000rpm, travel X/Y/Z: 870mm/500mm/1600mm, rapid traverse: 40m/min. Machine dimensions X/Y/Z: approx. 6500mm/3700mm/3200mm, weight: approx. 26000kg, control: Mazatrol Matrix. Documentation available. An on-site inspection is possible. The machine is located in China. Itodpfjxf Iklox Ah Ejl

Condition: used, Year of construction: 2005, Mazak QTN 200 lathe, year of manufacture 2005 Mazatrol 640T 210 mm Kitagawa BB 208 chuck Spindle bore 65 mm Turning length 500 mm Turning diameter 380 mm Tailstock Iodpfxsxgpqpe Ah Eotl Tool probe

Condition: good (used), Year of construction: 2003, functionality: fully functional, Horizontal machining center MAZAK Model: VARIAXIS 630-5X, complete with PALLETECH system with 12 pallets + 2 loading/unloading stations Iodpfx Ajz Apg Ash Eotl Year: 2003 Table size: 500 x 500 X-axis travel: 630 mm Y-axis travel: 765 mm Z-axis travel: 560 mm Spindle connection: ISO 40 Spindle speed (main spindle): 12,000 rpm Number of tools (ATC magazine): 120 Spindle power: 26 Kw High-pressure system through the spindle: 18 BAR Chip conveyor with belt Control unit: Mazatrol 640M Maximum load on the table: 500 Kg Weight (machine dimensions): 25,000 Kg Renishaw radio probing system

Condition: used, Year of construction: 1998, overall weight: 8,500 kg, Technical Data | Specification Machine Type | CNC turning/milling center Control System | Mazatrol Fusion 640T Year of Manufacture | 1998 Itedpfx Ahezx Sirj Esl Spindles | 2 Turret | 2 Y-axis | ± 50 mm X-axis | 240 mm Z1-axis | 440 mm Z2-axis | 495 mm C-axis | 0.001° Max. Turning Diameter | approx. 260–320 mm* Bar Capacity | 51 mm Spindle Bore | 61 mm Spindle Speed | 35–5,000 rpm Spindle Motor | 22 / 15 kW Max. Torque | 349 Nm Spindle Nose | A2-6 Chuck | approx. Ø 210 mm Tool Positions | 2 × 12 Driven Tools | 2 × 12 Drive for Driven Tools | 3.7 kW Speed of Driven Tools | 25–4,500 rpm Tool Holder | VDI 40 Rapid Traverse X | 30 m/min Rapid Traverse Y | 10 m/min Rapid Traverse Z | 33 m/min Machine Weight | approx. 8.0–8.5 t Connected Load | approx. 76–77 kVA

Year of construction: 2000, condition: ready for operation (used), General Data Measurements width 2105 mm Measurements depth 3485 mm Machine weight 7500 kg Control Unit Brand MAZATROL Main Drive Spindle speed range 3500–5000 Spindle bore 61 mm Number of axis 4 Movement X-Axis Movement 530 mm X-Axis Feed Force 0–6000 mm/min X-Axis Rapid Traverse 30 m/min Y-Axis Movement ±70 mm Y-Axis Feed Force 0–6000 mm/min Y-Axis Rapid Traverse 15 m/min Z-Axis Movement 1065 mm Z-Axis Feed Force 0–6000 mm/min Z-Axis Rapid Traverse 33 m/min Tail Stock Pinol diameter 80 mm Pinol way 870 mm Pinol tool taper MK4 Tools Number of station 20 Max weight 7 kg Max tool diameter 90 mm Max tool length 250 mm This 4-axis Mazak INTEGREX 200 Y was manufactured in 2000. It features a maximum turning diameter of 540 mm, a swing diameter of 540 mm, and a bar diameter capacity of 51 mm. The machine supports a workpiece weight up to 150 kg and offers a spindle speed range up to 5,000 rpm. It includes a Mazak KM 63 quick change tool system with 20 slots. If you are looking to get high-quality turning capabilities, consider the Mazak INTEGREX 200 Y machine we have for sale. Contact us for more information. Application Types Turning Ijdpfx Asx D N Ipoh Eotl

Condition: ready for operation (used), Year of construction: 2003, MAZAK INTEGREX 200 III-ST milling turning center CN: Mazatrol 640 MT PRO Year 2003 Hours: 87,613h Max diameter: 660 Races: X 580mm X2 150mm Z 1.045mm Z2 1.010mm Y +/- 80mm W 1050mm main spindle: power: 22kw max rotation: 5000 rpm Chuck: Kitagawa BB208 (210mm) bar passage: 65 mm secondary spindle: power: 18.5kW Ijdek D Ez Iepfx Ah Ejtl maximum rotation: 5000 rpm Chuck: Kitagawa BB-208 (210mm) bar passage: 65 mm Milling spindle: Power: 18.5kW Maximum rotation: 12000 rpm Tool magazine capacities: 40 x km63 (120 tools km63 with the machine) Lower tower: 9 tools Chip conveyor Mayfran consep B-axis tilt for turning tools flash tools HOB 5 simultaneous axes C axis on main spindle and secondary spindle Bar feeder interface New spindle, replaced by MAZAK on 06/2022 Machine visible in operation in France (loan to the Belgian border)

Condition: good (used), Year of construction: 2005, turning length: 200 mm, turning diameter: 350 mm, Used Mazak Multiplex 6300 Max turning diameter approx. Ø 350 mm Max turning length approx. 200 mm Itjdpsy I Sfujfx Ah Eel Many fine tools included "Auto operation" hours: 76,300 Gantry loader max. 2 x 40 kg 2 spindles, 2 axes per spindle (X/Z), C-axis, M-spindle Portal load and unload table

Condition: used, Year of construction: 2010, turning length: 1,495 mm, spindle speed (min.): 35 rpm, spindle speed (max.): 5,000 rpm, spindle bore: 65 mm, travel distance X-axis: 580 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 1,545 mm, workpiece weight (max.): 300 kg, total height: 2,577 mm, total length: 5,088 mm, total width: 2,450 mm, spindle nose: A2-6, spindle diameter: 660 mm, Equipment: documentation/manual, CNC Control Mazatrol Matrix Turning diameter 660 / 260 mm Turning length 1495 mm Isdpfx Ajzqt Umsh Ejtl Spindle bore diameter 65 mm Spindle nose A2-6 Spindle nose sub spindle A2-6 Turning speed spindle 35 - 5.000 R/min Turning speed sub spindle 35 - 5.500 R/min Milling head speed 15 - 21.500 R/min Movement X-axis 580 mm Movement Y-axis 160 mm Movement Z-axis 1.545 mm B-axis travel 225° C-axis indexing 0,0001 (360) ° Tool taper Capto C6 Tools in tool magazine 120 Barfeeder Irco-Breuning ILS-MUK If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: good (used), Year of construction: 2005, operating hours: 4,630 h, turning length: 1,585 mm, spindle motor power: 30,000 W, spindle speed (max.): 3,300 rpm, spindle bore: 102 mm, travel distance X-axis: 630 mm, travel distance Y-axis: 115 mm, travel distance Z-axis: 1,585 mm, total height: 2,800 mm, total length: 7,000 mm, total width: 2,700 mm, overall weight: 14,500 kg, Multi-tasking lathe MAZAK - INTEGREX 400 III-S MACH-ID 9809 Make: MAZAK Type: INTEGREX 400 III-S Control: MAZATROL 640 MT PRO Year: 2005 Only 4630 Cutting hours Automatic door 40 CAPTCO C6-Tool magazin Robot interface 5 Axis simulteneous package Sub spindel with C-Axis and 0,0001 Degree Internal Grundfos 15 Bar coolant Chip conveyor Optional tooling package with 40 holders Max. turning Ø: 850mm X-Axis: 630mm Y-Axis: -115 to + 115mm Z-Axis: 1585mm B Axis: -30 to +195° Spindle bore: 102mm Speedrange: 3300Rpm Spindle power: 30kW Subspindle speeds:3300Rpm Subspindle bore: 102mm Subspindle power: 26kW ATC / revolver: 40 B-Axis Toolsystem:Capto C6 B-Axis Speedranges:12000Rpm B-Axis power: 19kW Chip conveyor: Yes Tool eye: Yes Hours: 4630H Length: 7000mm Width: 2700mm Iedpfx Ajz Ata Hjh Estl Height: 2800mm Weight: 14500kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: good (used), Year of construction: 2001, functionality: fully functional, turning length: 1,500 mm, turning diameter: 720 mm, travel distance X-axis: 800 mm, travel distance Z-axis: 1,500 mm, spindle motor power: 30,000 W, total height: 2,500 mm, total length: 5,000 mm, total width: 3,000 mm, workpiece weight (max.): 1,500 kg, type of input current: three-phase, overall weight: 16,000 kg, Equipment: documentation/manual, rotational speed infinitely variable, Mazak Integrex 50 YB × 1500 – CNC Multi-Tasking Machine Heavy-duty, versatile CNC turn-mill center with live tooling, B-axis, Y-axis, and a large chain tool magazine. Well-suited for demanding high-precision machining with heavy workpiece loads. Key highlights: Large capacity: 1,500 mm between centers, 710 mm swing over bed Heavy workpiece capacity: up to 1,500 kg shaft work / 400 kg chuck work Full multi-tasking axes: C-axis (0.001°), B-axis swivel (210°, 0.001° indexing), Y-axis (±105 mm) High tool capacity: chain magazine for 90 milling / 30 turning tools (ISO 50 CAT taper) Capacity & dimensions: Ijdpfx Ajzugfysh Ejtl Max swing over bed: 710 mm Max swing over cross slide: 520 mm Swing range depending on Y-axis position: 310–710 mm Distance between centers: 1,500 mm Max workpiece weight (incl. chuck): 400 kg chuck work / 1,500 kg shaft work Machine weight: 14,500 kg Main spindle & C-axis: Spindle speed: 5–3,000 rpm (stepless, 4 speed ranges) Main motor (AC): 30 kW (30 min) / 22 kW (continuous) Max torque: 314 kpm (approx. 3,080 Nm) C-axis indexing: 0.001° Turret, axis travels & rapid traverse: Turret swivel (B-axis): 210°, indexing 0.001° Travels: X 680 mm · Z 1,612 mm · Y ±105 mm Rapid traverse: X 12 m/min · Z 15 m/min · Y 10 m/min Z-axis feed force: 2,840 kp max (approx. 27.9 kN) / 1,150 kp continuous (approx. 11.3 kN) Tool shank: OD turning 25 × 25 × 150 mm / boring bar Ø50 mm Milling spindle & live tooling: Speed range: 18–6,000 rpm Milling motor (AC): 15 kW (30 min) Tool taper: ISO 50 CAT Automatic tool changer (ATC): Type: chain magazine Capacity: 90 milling tools / 30 turning tools Max tool diameter: 120 mm Max tool length: 460 mm Turning tool length (using B-axis): 165 mm Max tool weight: 20 kg Tailstock: Type: programmable quill and body Quill travel: 130 mm Quill diameter: 130 mm Quill taper: MT 5 (MK 5) Max clamping force: 1,500 kp (approx. 14.7 kN)

Condition: ready for operation (used), Year of construction: 2006, travel distance X-axis: 510 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 460 mm, controller manufacturer: MAZATROL, controller model: Matrix, table load: 300 kg, overall weight: 11,000 kg, spindle speed (max.): 3,000 rpm, spindle motor power: 22,000 W, number of slots in tool magazine: 60, number of axes: 5, This 5-axis Mazak VARIAXIS I 500 was manufactured in 2006. It features an X-axis travel of 510 mm, Y-axis travel of 510 mm, and Z-axis travel of 460 mm. The machine includes a tool magazine capacity of 60 tools and a maximum spindle speed of 12,000 rpm. If you are looking to get high-quality milling capabilities, consider the Mazak VARIAXIS I 500 vertical machining centre we have for sale. Contact us for further details. • A: -120° / +30° • C: 360°Table • Dimensions: 500 × 400 mm • Number of tables/pallets: 2 • Spindle nose to horizontal table: 190–650 mm • Spindle nose to vertical table: 140–600 mmSpindle • Max torque: 252 NmTool magazine / ATC • Automatic tool changer: YesControl and software functions • Automatic pecking cycle with load detection • Synchronized tapping • EIA Dynamic Compensation 2 • Two additional M-code functions • G00 slope constant • High-speed function • MAZACC-3D high-speed software package Ijdpjzpygasfx Ah Eetl • Shape compensation for rotary axes Additional equipment • Pallet changer (two pallets/tables) • Belt-type chip conveyor • Chip conveyor preparation with chip pan • High-pressure coolant through spindle system (stated as 15 kg)
